Daikin VRV FXZQ07MVJU9 User manual

SYSTEM Inverter Air Conditioners
INSTALLATION MANUAL
MODELS
(Ceiling mounted Multi ow Cassette type)
FXZQ07MVJU9
FXZQ09MVJU9
FXZQ12MVJU9
FXZQ15MVJU9
FXZQ18MVJU9
English
Français
Español
3P184443-12N
Read these instructions carefully before installation.
Keep this manual in a handy place for future reference.
This manual should be left with the equipment owner.
Lire soigneusement ces instructions avant l’installation.
Conserver ce manuel à portée de main pour référence ultérieure.
Ce manuel doit être donné au propriétaire de l’équipement.
Lea cuidadosamente estas instrucciones antes de instalar.
Guarde este manual en un lugar a mano para leer en caso de tener alguna duda.
Este manual debe permanecer con el propietario del equipo.

13P184443-12N English
FXZQ07MVJU9
VRV SYSTEM Inverter Air Conditioners Installation manual
FXZQ09MVJU9
FXZQ12MVJU9
FXZQ15MVJU9
FXZQ18MVJU9
CONTENTS
1. SAFETY CONSIDERATIONS......................................................................................1
2. BEFORE INSTALLATION ............................................................................................4
3. SELECTING INSTALLATION SITE..............................................................................6
4. PREPARATIONS BEFORE INSTALLATION ................................................................8
5. INDOOR UNIT INSTALLATION ...................................................................................9
6. REFRIGERANT PIPING WORK................................................................................11
7. DRAIN PIPING WORK...............................................................................................13
8. ELECTRIC WIRING WORK.......................................................................................17
9. WIRING EXAMPLE AND HOW TO SET THE REMOTE CONTROLLER..................18
10. INSTALLATION OF THE DECORATION PANEL .......................................................23
11. FIELD SETTINGS......................................................................................................24
12. TEST RUN .................................................................................................................25
1. SAFETY CONSIDERATIONS
Read these SAFETY CONSIDERATIONS carefully before installing air conditioning equipment. After
completing the installation, make sure that the unit operates properly during the startup operation.
Instruct the customer on how to operate and maintain the unit. Inform customers that they should store
this Installation Manual with the Operation Manual for future reference.
Always use a licensed installer or contractor to install this product. Improper installation can result in
water or refrigerant leakage, electrical shock, re, or explosion.
Meanings of DANGER, WARNING, CAUTION, and NOTE Symbols:
DANGER ....... Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING ...... Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION ....... Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury. It may also be used to alert against unsafe practices.
NOTE .......... Indicates situations that may result in equipment or property-damage accidents
only.
DANGER
• Refrigerant gas is heavier than air and replaces oxygen. A massive leak can lead to oxygen
depletion, especially in basements, and an asphyxiation hazard could occur leading to serious
injury or death.
• Do not ground units to water pipes, gas pipes, telephone wires, or lightning rods as incomplete
grounding can cause a severe shock hazard resulting in severe injury or death. Additionally,
grounding to gas pipes could cause a gas leak and potential explosion causing severe injury or
death.

2
3P184443-12N English
• If refrigerant gas leaks during installation, ventilate the area immediately. Refrigerant gas may
producetoxicgasifitcomesincontactwithre.Exposuretothisgascouldcausesevere
injury or death.
• After completing the installation work, check that the refrigerant gas does not leak throughout
the system.
• Donotinstallunitinanareawhereammablematerialsarepresentduetoriskofexplosions
that can cause serious injury or death.
• Safely dispose all packing and transportation materials in accordance with federal/state/local
laws or ordinances. Packing materials such as nails and other metal or wood parts, including
plastic packing materials used for transportation may cause injuries or death by suffocation.
WARNING
• Onlyqualiedpersonnelmustcarryouttheinstallationwork.Installationmustbedonein
accordance with this installation manual. Improper installation may result in water leakage,
electricshock,orre.
• When installing the unit in a small room, take measures to keep the refrigerant concentration
from exceeding allowable safety limits. Excessive refrigerant leaks, in the event of an accident
inaclosedambientspace,canleadtooxygendeciency.
• Useonlyspeciedaccessoriesandpartsforinstallationwork.Failuretousespeciedparts
mayresultinwaterleakage,electricshocks,re,ortheunitfalling.
• Install the air conditioner on a foundation strong enough that it can withstand the weight of the
unit.Afoundationofinsufcientstrengthmayresultintheunitfallingandcausinginjuries.
• Take into account strong winds, typhoons, or earthquakes when installing. Improper
installation may result in the unit falling and causing accidents.
• Make sure that a separate power supply circuit is provided for this unit and that all electrical
workiscarriedoutbyqualiedpersonnelaccordingtolocal,stateandnationalregulations.
Aninsufcientpowersupplycapacityorimproperelectricalconstructionmayleadtoelectric
shocksorre.
• Makesurethatallwiringissecured,thatspeciedwiresareused,andthatnoexternalforces
act on the terminal connections or wires. Improper connections or installation may result in
re.
• When wiring, position the wires so that the control box cover can be securely fastened.
Improperpositioningofthecontrolboxcovermayresultinelectricshocks,re,orthe
terminals overheating.
• Before touching electrical parts, turn off the unit.
• Be sure to install a ground fault circuit interrupter if one is not already available.This helps
preventelectricalshocksorre.
• Securely fasten the outside unit terminal cover (panel). If the terminal cover/panel is not
installedproperly,dustorwatermayentertheoutsideunitcausingreorelectricshock.
• When installing or relocating the system, keep the refrigerant circuit free from substances
otherthanthespeciedrefrigerant(R410A)suchasair.Anypresenceofairorotherforeign
substance in the refrigerant circuit can cause an abnormal pressure rise or rupture, resulting in
injury.
• Do not change the setting of the protection devices. If the pressure switch, thermal switch, or
otherprotectiondeviceisshortedandoperatedforcibly,orpartsotherthanthosespeciedby
Daikinareused,reorexplosionmayoccur.

33P184443-12N English
CAUTION
• Donottouchtheswitchwithwetngers.Touchingaswitchwithwetngerscancauseelectric
shock.
• Do not allow children to play on or around the unit to prevent injury.
• Do not touch the refrigerant pipes during and immediately after operation as the refrigerant
pipesmaybehotorcold,dependingontheconditionoftherefrigerantowingthroughthe
refrigerant piping, compressor, and other refrigerant cycle parts.Your hands may suffer burns
or frostbite if you touch the refrigerant pipes. To avoid injury, give the pipes time to return to
normal temperature or, if you must touch them, be sure to wear proper gloves.
• Heatexchangernsaresharpenoughtocut.
Toavoidinjuryweargloveorcoverthenswhenworkingaroundthem.
• Install drain piping to proper drainage. Improper drain piping may result in water leakage and
property damage.
• Insulate piping to prevent condensation.
• Be careful when transporting the product.
• Do not turn off the power supply immediately after stopping operation. Always wait for at least
5 minutes before turning off the power supply. Otherwise, water leakage may occur.
• Do not use a charging cylinder. Using a charging cylinder may cause the refrigerant to
deteriorate.
• RefrigerantR410Ainthesystemmustbekeptclean,dry,andtight.
(a) Clean and Dry -- Foreign materials (including mineral oils such as SUNISO oil or moisture)
should be prevented from getting into the system.
(b) Tight--R410Adoesnotcontainanychlorine,doesnotdestroytheozonelayer,anddoes
notreducetheearth’sprotectionagainharmfulultravioletradiation.R410Acancontribute
to the greenhouse effect if it is released.Therefore take proper measures to check for the
tightness of the refrigerant piping installation. Read the chapter Refrigerant Piping and
follow the procedures.
• SinceR410Aisablend,therequiredadditionalrefrigerantmustbechargedinitsliquidstate.If
the refrigerant is charged in a state of gas, its composition can change and the system will not
work properly.
• TheindoorunitisforR410A.Seethecatalogforindoormodelsthatcanbeconnected.Normal
operation is not possible when connected to other units.
• Remote controller (wireless kit) transmitting distance can be shorter than expected in rooms
withelectronicuorescentlamps(inverterorrapidstarttypes).Installtheindoorunitfaraway
fromuorescentlampsasmuchaspossible.
• Indoor and outside units are for indoor installation only.
• Do not install the air conditioner in the following locations:
(a) Where a mineral oil mist or oil spray or vapor is produced, for example, in a kitchen.
Plastic parts may deteriorate and fall off or result in water leakage.
(b) Where corrosive gas, such as sulfurous acid gas, is produced.
Corroding copper pipes or soldered parts may result in refrigerant leakage.
(c) Near machinery emitting electromagnetic waves.
Electromagnetic waves may disturb the operation of the control system and cause the unit
to malfunction.
(d) Whereammablegasmayleak,wherethereiscarbonber,orignitabledustsuspensionin
theair,orwherevolatileammablessuchasthinnerorgasolinearehandled.Operatingthe
unitinsuchconditionscancauseare.
• Take adequate measures to prevent the outside unit from being used as a shelter by small
animals. Small animals making contact with electrical parts can cause malfunctions, smoke, or
re.Instructthecustomertokeeptheareaaroundtheunitclean.

4
3P184443-12N English
NOTE
• Install the power supply and transmission wires for the indoor and outside units at least 3.5
feet away from televisions or radios to prevent image interference or noise. Depending on the
radiowaves,adistanceof3.5feetmaynotbesufcienttoeliminatethenoise.
• Dismantling the unit, treatment of the refrigerant, oil and additional parts must be done in
accordance with the relevant local, state and national regulations.
• Do not use the following tools that are used with conventional refrigerants: gauge manifold,
chargehose,gasleakdetector,reverseowcheckvalve,refrigerantchargebase,vacuum
gauge, or refrigerant recovery equipment.
• IftheconventionalrefrigerantandrefrigeratoroilaremixedinR410A,therefrigerantmay
deteriorate.
• This air conditioner is an appliance that should not be accessible to the general public.
• Thewallthicknessofeld-installedpipesshouldbeselectedinaccordancewiththerelevant
local, state and national regulations.
2. BEFORE INSTALLATION
Do not exert pressure on the resin parts when opening the unit or when moving it after opening.
BesuretocheckthetypeofR410Arefrigeranttobeusedbeforedoinganywork.(Usingan
incorrect refrigerant will prevent normal operation of the unit.)
• When opening the unit or moving it after opening, be sure to lift it by holding on to the hanger brackets
without exerting any pressure on other parts, especially drain piping and other resin parts.
• Decide upon a line of transport.
• Leave the unit inside its packaging while moving, until reaching the installation site. Use a sling of soft
material where unpacking is unavoidable, or protective plates together with a sling when lifting in order
to avoid damage or scratches to the unit.
• Important: Do not unfasten packing case (top) guarding the control box until suspending the
unit.
• Refer to the installation manual of the outdoor unit for items not described in this manual.
• Do not dispose of any parts necessary for installation until the installation is complete.
2-1 PRECAUTIONS
• Be sure to read this manual before installing the indoor unit.
• When selecting installation site, refer to the paper pattern.
• This unit is suitable for installation in a household, commercial and light industrial environment.
• Do not install or operate the unit in rooms mentioned below.
• Laden with mineral oil, or lled with oil vapor or spray like in kitchens. (Plastic parts may
deteriorate.)
• Where corrosive gas like sulfurous gas exists. (Copper tubing and brazed spots may corrode.)
• Where volatile ammable gas like thinner or gasoline is used.
• Where machines can generate electromagnetic waves. (Control system may malfunction.)
• Where the air contains high levels of salt such as that near the ocean and where voltage
uctuates greatly such as that in factories. Also in vehicles or vessels.

53P184443-12N English
2-2 ACCESSORIES
Check the following accessories are included with your unit
Name (1)Drain
hose
(2) Metal
clamp
(3) Washer for
hanger bracket (4) Clamp
(5) Paper
pattern for
installation
(6) Screws
(M5)
Quantity 1 pc. 1 pc. 8 pcs. (Large)
6 pcs.
(Small)
1 pc. 1 pc. 4 pcs.
Shape
Also used
as packing
material
For paper
pattern for
installation
Name (7) Washer
xing plate
Insulation
for tting Sealing pad (12) Sealing material
(13) Conduit
mounting
plate
(14) Screws
(M4)
(Other)
• Operation
manual
• Installation
manual
Quantity 4 pcs. 1 each 1 each 2 pcs. 1pc. 2pcs.
Shape
(8) For gas pipe
(9)For liquid pipe
(10)Large
(11)Small
2-3 OPTIONAL ACCESSORIES
• The optional decoration panel and remote controller are required for this indoor unit. (Refer to Table 1
and 2)
Table 1
Model Optional decoration panel
FXZQ07·09·12·15·18MVJU9 BYFQ60B8W1U
Color : White
• These are two types of remote controllers: wired and wireless. Select a remote controller from Table 2
according to customer request and install in an appropriate place.
Table 2
Remote controller type Heat Pump type
Wired type BRC1E71·72
Wireless type BRC7E830
NOTE
• If you wish to use a remote controller that is not listed in Table 2, select a suitable remote controller
after consulting catalogs and technical materials.

6
3P184443-12N English
FOR THE FOLLOWING ITEMS, TAKE SPECIAL CARE DURING CONSTRUCTION AND
CHECK AFTER INSTALLATION IS FINISHED.
a. Items to be checked after completion of work
Items to be checked If not properly executed, the following is likely to
occur: Check
Are the indoor and outdoor units xed rmly? The units may drop, vibrate or make noise.
Is the outdoor unit fully installed? The unit may malfunction or the components
may burn out.
Is the gas leak test nished? It may result in insufcient cooling and heating.
Is the unit fully insulated? Condensate water may drip.
Does drainage ow smoothly? Condensate water may drip.
Does the power supply voltage correspond to
that shown on the name plate?
The unit may malfunction or the components
may burn out.
Are wiring and piping correct? The unit may malfunction or the components
may burn out.
Is the unit safely grounded? Danger of electrical leakage.
Is wiring size according to specications? The unit may malfunction or the components
may burn out.
Is something blocking the air outlet or inlet of
either the indoor or outdoor units? It may result in insufcient cooling and heating.
Are refrigerant piping length and additional
refrigerant charge noted? The refrigerant charge in the system is not clear.
b. Items to be checked at time of delivery
Also review the SAFETY CONSIDERATIONS.
Items to be checked Check
Are the control box cover, air lter, and suction grille attached?
Did you explain about operations while showing the operation manual to your customer?
Did you hand the operation manual over to your customer?
c. Points for explanation about operations
The items with WARNING or CAUTION mark in the operation manual are the items pertaining
to possibilities for bodily injury and material damage in addition to the general usage of the product.
Accordingly, it is necessary that you make a full explanation about the described contents and also ask
your customers to read the operation manual.
2-4 NOTE TO THE INSTALLER
Be sure to instruct customers how to properly operate the unit (especially cleaning the lter, operating
different functions, and adjusting the temperature) by having them carry out operations while looking at
the manual.
3. SELECTING INSTALLATION SITE
<Hold the unit by the 4 hanger brackets when opening the box and moving it, and do not exert pressure
on-to any plastic or piping parts such as refrigerant or drain piping.
If the temperature or humidity inside the ceiling might rise above 86°F or RH 80%, respectively, add extra
insulation to the main unit body.
Use glass wool or polyethylene foam as insulation and make sure it is at least 3/8 in. thick and ts inside
the ceiling opening.>

73P184443-12N English
The direction this product directs air can be selected. However, a separately sold sealing material
kit is needed in order to make the unit direct air in two, three, or four (corner shut-off) directions.
(1) Select an installation location with the customer’s approval which matches the following
conditions:
• Cool (or warm) air reaches.
• No objects block the air passage.
• Drainage can be done with no problem.
• Sturdy enough to support the weight of the indoor unit.
• The wall is not signicantly tilted.
• Enough room for installation and service work.
• No risk of ammable gas leaking.
• The length of the indoor-outdoor piping is no longer than the tolerated length (see the installation
manual that came with the outdoor unit for details).
[Space required for installation] (in.)
60
100
>
60
>
*60
>
*
>
Air
outlet
Air
outlet Air
inlet
For installation in high places
H
60
>
*60
>
*
60
>
*
60
>
*
Fig. 1 Fig. 2
NOTE
• Leave 8 in. or more space where marked with the *, on sides where the air outlet is closed.
Model H
FXZQ07·09·12·15·18MVJU9 11-1/4(Conrm the space of 11-5/8 or more)
CAUTION
• The indoor and outdoor units and the power supply wiring and remote controller wiring must be
installed at least 40 in. away from any televisions or radios. This is to prevent interference with picture
and sound reception. (Interference may occur even at 40 in. away depending on the reception quality.)
• If installing the wireless kit, the distance of the signal sent from the remote controller might be shorter if
there are uorescent lights which are electrically started (such as with inverters, rapid starters, etc.) in
the room. The indoor unit should be installed as far away from uorescent lights as possible.
(2) Ceiling height
• Install this unit where the height of bottom panel is more than 100 in. so that the user cannot easily
touch it.
(3) Air direction
The air direction shown is an example.
Select the appropriate number of directions according to the shape of the room and the location of
the unit. Field settings have to be made using the remote controller and the outlet vents have to be
shut off if two, three, or four (corner shut-off) directions are selected. See the sealing materials (sold
separately) installation manual for details.

8
3P184443-12N English
[Air ow direction] (Example)
Piping Piping Piping
Air outlet in 4 directions Air outlet in 3 directions Air outlet in 2 directions
(4) Use suspension bolts for installation. Check whether the ceiling is strong enough to support
the weight of the unit or not. If there is a risk, reinforce the ceiling before installing the unit.
(Installation pitch is marked on the paper pattern for installation. Refer to it to check for points
requiring reinforcing.)
4. PREPARATIONS BEFORE INSTALLATION
(1) Relation of ceiling opening to unit and suspension bolt position.
A
Refrigerant
piping
Suspension
bolt (×4)
27-9/16 (Decoration panel)
23-26 (Ceiling opening)
22-5/8 (indoor unit)
21 (Suspension bolt pitch)
27-9/16 (Decoration panel)
23-26 (Ceiling opening)
22-5/8 (indoor unit)
21 (Suspension bolt pitch)
23
–
*26
(7-1/16)
13/16≤13/16 ≤
(Ceiling opening dimension)
(Ceiling-panel overlapping dimension)
View as seen from A
Hanger
bracket
False
ceiling
(in.)
Fig. 3 Fig.4
NOTE
• Installation is possible with a ceiling
dimension of 26in. (marked with *).
However, to achieve a ceiling-panel
overlapping dimension of 13/16in., the
spacing between the ceiling and the unit
should be 1-3/4in. or less. If the spacing
between ceiling and the unit is over
1-3/4in., attach ceiling material to
part or recover the ceiling.
<
1-3/4
<
1-3/4
False ceiling
False ceiling
Ceiling material
(in.)
Fig. 5
(2) Make the ceiling opening needed for installation where applicable. (For existing ceilings)
• Refer to the paper pattern for installation (5) for ceiling opening dimensions.
• Create the ceiling opening required for installation. From the side of the opening to the casing
outlet, implement the refrigerant and drain piping and wiring for remote controller (unnecessary for
wireless type) and wiring between units. Refer to each PIPING or WIRING section.
• After making an opening in the ceiling, it may be necessary to reinforce ceiling beams to keep the
ceiling level and to prevent it from vibrating. Consult the builder or engineer for details.

93P184443-12N English
(3) Install the suspension bolts.
(Use either an M8 – M10 size bolt or the
equivalent)
Use a hole-in anchor for existing ceilings,
and a sunken insert, sunken anchor or
other eld supplied parts for new ceilings to
reinforce the ceiling to bear the weight of the
unit.
Adjust clearance (2 – 4 in.) from the ceiling
before proceeding further.
NOTE
• All the above parts are eld supplied.
2-4
<Installation Example>
Ceiling slab
(Unit:in.)
Anchor
Long nut or turn-buckle
Suspension bolt
False ceiling
Fig. 6
5. INDOOR UNIT INSTALLATION
Installing optional accessories (except for the decoration panel) before installing the indoor unit
is easier. For existing ceilings, install Fresh air intake kit and branch duct before installing the
unit.
As for the parts to be used for installation work, be sure to use the provided accessories and specied
parts designated by Daikin.
(1) For new ceilings
(1-1) Install the indoor unit temporarily.
• Attach the hanger bracket to the suspension bolt. Be sure to x it securely by using a nut and
washer (3) from the upper and lower sides of the hanger bracket.
The washer xing plate (7) will prevent the washer from falling.
Washer (3) (accessory)
Hanger bracket
[Securing the hanger bracket]
Tighten
(double nuts)
Nut
(Field supplied)
Insert
Washer xing plate (7)
(accessory)
[Securing the washer]
Fig. 7 Fig. 8
(1-2) Refer to the paper pattern for installation (5) for ceiling opening dimension.
Consult the builder or carpenter for details.
• The center of the ceiling opening is indicated on the paper pattern for installation.
The center of the unit is indicated on the paper pattern for installation.
• Fix the paper pattern to the unit with screws (6) (×4).

10
3P184443-12N English
Paper pattern for installation (5)
[Installation of paper pattern for installation]
Screws (6)
Screws (6)
(accessory)
(accessory)
(accessory)
Fig. 9
<Ceiling work>
(1-3) Adjust the unit to the right position for
installation.
(Refer to 4.PREPARATIONSBEFORE
INSTALLATION-(1).)
(1-4) Check the unit is horizontally level.
• The indoor unit is equipped with a built-in
drain pump and oat switch. Verify that it
is level by using a water level or a water-
lled vinyl tube.
Vinyl tube
[Maintaining horizontality]
Water level
Fig.10
CAUTION
If the unit is tilted against condensate ow, the oat switch may malfunction and cause water to drip.
(1-5) Remove the washer xing plate (7) used for preventing the washer from falling and tighten the
upper nut.
(1-6) Remove the paper pattern for installation (5).
(2) For existing ceilings
(2-1) Install the indoor unit temporarily.
• Attach the hanger bracket to the suspension bolt. Be sure to x it securely by using a nut and
washer (3) from the upper and lower sides of hanger bracket. The washer xing plate (7) will
prevent the washer from falling.
Washer (3) (accessory)
Hanger bracket
[Securing the hanger bracket]
Tighten
(double nuts)
Nut
(Field supplied)
Insert
Washer xing plate (7)
(accessory)
[Securing the washer]
Fig. 11 Fig. 12
(2-2) Adjust the height and position of the unit.
(Refer to 4.PREPARATIONSBEFOREINSTALLATION-(1).)
(2-3) Perform steps (1-4), (1-5) in (1) for new ceilings.

11 3P184443-12N English
6. REFRIGERANT PIPING WORK
<For refrigerant piping of outdoor units, see the installation manual attached to the outdoor unit.>
<Execute thermal insulation work completely on both sides of the gas piping and the liquid
piping. Otherwise, a water leakage can result sometimes.>
Be sure to use insulation designed for use with HVAC systems.
<Also, in cases where the temperature and humidity of the refrigerant piping sections might
exceed86°ForRH80%,reinforcetherefrigerantinsulation(13/16in.orthicker).Condensation
may form on the surface of the insulating material.>
<Before refrigerant piping work, check which type of refrigerant is used. Proper operation is not
possible if the types of refrigerant are not the same.>
CAUTION
• Useapipecutterandaresuitableforthetypeofrefrigerant.
• Applyesteroiloretheroilonlyinsideoftheareportionsbeforeconnecting.
• Topreventdust,moistureorotherforeignmatterfrominltratingthetube,eitherpinchtheend
or cover it with tape.
• Do not allow anything other than the designated refrigerant to get mixed into the refrigerant
circuit, such as air. If any refrigerant gas leaks while working on the unit, thoroughly ventilate
the room immediately.
• Donotmixairorothergaswiththespeciedrefrigerantinthe
refrigeration circuit.
• Ventilate the room if refrigerant gas leaks during the work.
• The outdoor unit is charged with refrigerant.
• Be sure to use both a spanner and torque wrench together, as
shown in the drawing, when connecting or disconnecting pipes to/
from the unit. (Refer to Fig. 13)
• Refer to Table 3 for the dimensions of are nut spaces.
• When connecting the are nut, coat the are section (only inside)
with ester oil or ether oil, rotate three or four times rst, then screw
in. (RefertoFig.14)
• Keep all the screw mounting resin parts (e.g., piping presser
plates) away from oil.
If oil adheres, the strength of the screw mounting resin parts may
drop.
CAUTION
Over-tightening may damage the are and cause a refrigerant
leakage.
Torque wrench
Spanner
Piping union
Flare nut
Fig. 13
Apply ester oil or
ether oil only inside
Fig.14
NOTE
• Use the are nut included with the unit main body.
Table 3
Pipe size Tightening torque Flare dimensions A (in.) Flare
ø1/4” 10.4 - 12.7 ft-lbf 0.342 - 0.358
R0.016 - 0.031
ø1/2” 36.5 - 44.5 ft-lbf 0.638 - 0.654
• Refer to Table 3 to determine the proper tightening torque.

12
3P184443-12N English
Not recommended but in case of emergency:
You must use a torque wrench but if one is not available, you may follow the installation method
described below.
When you keep tightening the are nut with a spanner, there is a point where the tightening torque
suddenly increases. From that position, further tighten the are nut at the angle shown below:
Pipe size Further tightening angle Recommended arm length of tool
ø1/4” 60 – 90 degrees Approx. 6 in.
ø1/2” 30 – 60 degrees Approx. 10 in.
Aftertheworkisnished,makesuretocheckthatthereisnogasleak.
CAUTION
CAUTION TO BE TAKEN WHEN BRAZING REFRIGERANT PIPING
Do not use ux when brazing refrigerant piping. Therefore, use the phosphor copper brazing ller metal
(B-Cu93P-710/795:ISO 3677) which does not require ux.
Flux has extremely harmful inuence on refrigerant piping systems. For instance, if the chlorine based
ux is used, it will cause pipe corrosion or, in particular, if the ux contains uorine, it will damage the
refrigerant oil.
• Before brazing eld refrigerant piping, nitrogen gas shall be blown through the piping to expel air from
the piping.
If brazing is done without nitrogen gas blowing, a large amount of oxide lm develops inside the piping,
and could cause system malfunction.
• When brazing the refrigerant piping, only begin brazing after having carried out nitrogen substitution
or while inserting nitrogen into the refrigerant piping. Once this is done, connect the indoor unit with a
ared connection.
• Nitrogen should be set to 2.9 psig with a pressure-reducing valve if brazing while inserting nitrogen into
the piping. (Refer to Fig.15)
Refrigerant piping
Part to be
brazed
Taping
Nitrogen
Pressure-reducing valve
Nitrogen
Hand valve
Fig. 15
• Make absolutely sure to execute thermal insulation works on the pipe-connecting section after
checking gas leakage by thoroughly studying the following gure and using the attached insulation for
tting (8) and (9). Fasten both ends with the clamps (4). (Refer to Fig. 16)
• Wrap the sealing pad (11) only around the insulation for the joints on the gas piping side.
(Refer to Fig. 16)

13 3P184443-12N English
Small sealing pad
(accessory) (11)
Clamp (4)
(Large ×4) Insulation for tting
(accessory) (9)
Insulation for tting (accessory) (8)
Wrap the piping union
with the sealing pad.
(accessory)
Liquid piping
(for liquid pipe)
(for gas pipe)
Gas piping
Fig. 16
CAUTION
Be sure to insulate any eld piping all the way to the piping connection inside the unit. Any exposed
piping may cause condensation or burns if touched.
7. DRAIN PIPING WORK
(1) Carry out the drain piping
• Lay pipes properly to ensure that drainage can occur without problems.
• Employ a pipe with either the same diameter or with the diameter larger (excluding the raising section)
than that of the connecting pipe (PVC pipe, nominal diameter 1 in., outside diameter 1-1/4 in.).
• Keep the drain pipe short and sloping downwards at a gradient of at least 1/100 to prevent air pockets
from forming.
• If the drain hose cannot be sufciently set on a slope, refer to PRECAUTIONS FOR DRAIN RAISING
PIPING on page 14.
• To keep the drain hose from sagging, space hanger bracket every 40 to 60 in.
1/100
gradient or more
Hanger bracket
GOOD
40 – 60 in.
WRONG WRONG
Fig. 17 Fig. 18
CAUTION
Water pooling in the drainage piping can cause the drain to clog.
• Use the attached drain hose (1) and metal clamp (2).
• Insert the drain hose into the drain socket up to the base, and tighten the clamp securely within the
portion of a gray tape of the hose-inserted tip. Tighten the clamp until the screw head is less than 5/32
in. from the hose.
• Wrap the attached large sealing pad (10) over the metal clamp (2) and drain hose to insulate.
• Make sure that thermal insulation work is executed on the following 2 spots to prevent any possible
water leakage due to dew condensation.
• Indoor drain pipe
• Drain socket

14
3P184443-12N English
Metal clamp (2)
Drain hose (1)
Tape (Gray)
(accessory)
(accessory)
Large sealing pad (10)
Metal clamp (2)
(accessory)
(accessory)
≤ 5/32 in.
Fig. 19 Fig.20
<PRECAUTIONS FOR DRAIN RAISING PIPING>
• Install the drain raising pipes at a height of less than 21-7/16 in.
The drain pump of this unit has a high delivery ow rate. Therefore, the higher the drain raising height
is, the lower the sound of draining will be. For this reason, a minimum drain raising height of 11-3/4 in.
is recommended.
• Install the drain raising pipes at a right angle to the indoor unit and no more than 11-3/4 in. from the
unit.
( 21-7/16)
29-1/2
8-1/16
To prevent air bubbles in the
drain hose, keep it level or
slightly tilted up. Any bubbles in
the hose might cause the unit
to make noise due to backow
when the drain pump stops.
Drain hose (1)
Hanger bracket
Drain hose (accessory)(1)
Adjustable
Metal clamp (2) Drain raising pipe
Raising section
(accessory)
(unit: in.)
Ceiling slab
Level or
tilted slightly
up
(accessory)
Fig. 21
≤ 11-3/4 in. 40-60 in.
NOTE
• To ensure no excessive pressure is applied to the included drain hose (1), do not bend or twist the
hose when installing as it could cause leakage.
• If converging multiple drain pipes, install according to the procedure shown below.
21-7/16 in.
The drain pipe should have a
downward slope of at least 1/100 to
prevent air pockets from forming.
Water accumulating in the drain
piping can cause the drain to clog.
Central drain pipe
Fig. 22
Select converging drain pipes with gauges is suitable for the operating capacity of the unit.
(2) After piping work is nished, check if drainage ows smoothly.
• Add approximately 1/4 gallon of water slowly from the air outlet and check drainage ow.
CAUTION
• Drain piping connections
• Do not connect the drain piping directly to sewage pipes that smell of ammonia. The ammonia in the
sewage might enter the indoor unit through the drain pipes and corrode the heat exchanger.
• Keep in mind that it will become the cause of getting drain pipe blocked if water collects on drain pipe.

15 3P184443-12N English
WHEN ELECTRIC WIRING WORK IS FINISHED
• Add approximately 1/4 gallon of water slowly from the air outlet and check drainage ow.
• Check drainage ow during cooling operation, explained on 12. TEST RUN.
WHEN ELECTRIC WIRING WORK IS NOT FINISHED
CAUTION
• Electrical wiring work should be done by a certied electrician.
• If someone without the proper qualications performs the work, perform the following after the test run
is complete.
• Remove the control box cover, connect a power supply (SINGLE PHASE 60Hz 208/230V) to
connections L1, L2 and ground wire on the power supply terminal block and remote controller to
terminal block for remote controller. When carrying out wiring work around the control box, make sure
none of the connectors come undone. Be sure to attach the control box cover before turning on the
power.
Next, press the inspection/test run button “ ” on the remote controller. The unit will engage the test
run mode. Press the operation mode selector button “ ” until selecting FAN OPERATION “ ”.
Then, press the ON/OFF button “ ”. The indoor unit fan and drain pump will start up. After conrming
drainage (Fig.23,Fig.24), turn off the power supply and remove the power supply wiring. Press “ ”
to go back to the rst mode.
• Note that the fan also starts rotating.
• Attach the control box cover as before.
4
Drain pump
location
(in.)
Drain sockets
Service drain outlet (with rubber plug)
<Adding water through air outlet>
[Method of adding water]
(Use this outlet to drain water from
the drain pan)
Plastic container
for pouring
(Tube should be
about 4 in. long.)
(Check the drainage now.)
Fig. 23

16
3P184443-12N English
REMOTE
CONTROL
TRANSMISSION
WIRING
FORCED
OFF
LN
L1 L2
LN
( )
Control
box cover
Terminal block for
remote controller
Remove the control box cover
(take off 2 screws)
Remote controller
wiring
Power supply
terminal block
Ground
Single phase power
supply
60 Hz 208/230V
REMOTE
CONTROL
TRANSMISSION
WIRING
FORCED
OFF
Fig.24
CAUTION
• Drain piping connections
• Do not connect the drain piping directly to sewage pipes that smell of ammonia.The ammonia
in the sewage might enter the indoor unit through the drain pipes and corrode the heat
exchanger.
• Keep in mind that the drain pipe becomes blocked if water collects on it.

17 3P184443-12N English
8. ELECTRIC WIRING WORK
8-1 GENERAL INSTRUCTIONS
• All eld supplied parts and materials and electric works must conform to local codes.
• Use copper wire only.
• For electric wiring work, refer to also “Wiring diagram label” attached to the control box cover.
• For remote controller wiring details, refer to the installation manual attached to the remote controller.
• All wiring must be performed by an authorized electrician.
• This system consists of multiple indoor units. Mark each indoor unit as unit A, unit B..., and be sure
the terminal board wiring to the outdoor unit and BS unit are properly matched. If wiring and piping
between the outdoor unit and an indoor unit are mismatched, the system may cause a malfunction.
• A circuit breaker capable of shutting down power supply to the entire system must be installed.
• Refer to the installation manual attached to the outdoor unit for the size of power supply wiring
connected to the outdoor unit, the capacity of the circuit breaker and switch, and wiring instructions.
• Be sure to ground the air conditioner.
• Do not connect the ground wire to gas and water pipes, lightning rods, or telephone ground wires.
• Gas pipes : might cause explosions or re if gas leaks.
• Water pipes : no grounding effect if hard vinyl piping is used.
• Telephone ground wires or lightning rods : might cause abnormally high electric potential in the
ground during lightning storms.
8-2 ELECTRICAL CHARACTERISTICS
Units Power supply Fan motor
Model Hz Volts Voltage range MCA MFA kW FLA
FXZQ07MVJU9
60 208/230 Max. 253
Min. 187
0.8 15 0.055 0.6
FXZQ09MVJU9 0.8 15 0.055 0.6
FXZQ12MVJU9 0.8 15 0.055 0.6
FXZQ15MVJU9 0.8 15 0.055 0.6
FXZQ18MVJU9 0.9 15 0.055 0.7
MCA: Min. Circuit Amps (A) MFA: Max. Fuse Amps (A)
kW: Fan Motor Rated Output (kW) FLA: Full Load Amps (A)
8-3 SPECIFICATIONS FOR FIELD SUPPLIED FUSES AND WIRE
Model Power supply wiring Remote controller wiring
Transmission wiring
Field fuses Size, Length Wire Size
FXZQ07·09·12·15·18MVJU9 15A
Wire size and
length must
comply with
local codes.
Sheathed wire
(2 wire) AWG 18-16
Allowable length of transmission wirings and remote controller wiring are as follows.
(1) Outdoor unit-Indoor unit: Max. 3280 ft. (Total wiring length: 6580 ft.)
(2) Indoor unit-Remote controller: Max. 1640 ft.
NOTE
• Vinyl wiring with sheath or cable (Insulated thickness : 1/16 in. or more)

18
3P184443-12N English
CAUTION
• Arrange the wires and x a cover rmly so that the cover does not oat during wiring work.
• Do not clamp remote controller wiring and transmission wiring together with power supply wiring. Doing
so may cause malfunction.
• Remote controller wiring and transmission wiring should be located at least 2in. from power supply
wiring. Not following this guideline may result in malfunction due to electrical noise.
9. WIRING EXAMPLE AND HOW TO SET THE REMOTE CONTROLLER
9-1 HOW TO CONNECT WIRINGS
Methods of wiring power supply, connecting transmission and remote controller wiring
• Power supply wiring and ground wire
Remove the control box cover. Connect wires to the power supply terminal block (3P) inside and the
ground wire to the terminal block. Then, fasten a conduit to the conduit mounting plate (13) with a
locknut securely. In doing this, pull the wires inside through the hole and x the wires securely with the
included clamp (4).
Give enough slack to the wires between the clamp (4) and power supply terminal block. (Use Fig. 26 as
a guide and allow at least 3-1/4 in. for removing the sheath.)
• After connection, attach the sealing material. (Refer to Fig. 25). Be sure to attach it to prevent
inltration of water from the outside. Make sure that the slit in the sealing material is positioned
vertically.
After attaching the sealing, screw the conduit mounting plate (13) using the 2 delivered screws (M4)
(14) to the side of the unit where the power supply cables enter the unit. (Refer to Fig. 25).
21
34 6
5
1. Hole in the side plate of the unit
2. Sealing material
3. Conduit mounting plate
4. Screw (M4)
5. Conduit (Field supply)
6. Locknut (Field supply)
Fig. 25
• Transmission wiring and remote controller wiring
Remove the control box cover and pull the wires inside through the hole and connect to the terminal
block (6P). Securely x the remote controller wiring and the transmission wiring with the included
clamp (4).
Give enough slack to the wires between the clamp (4) and the terminal block for the remote controller.
• After connection, attach sealing material (12).
• Be sure to attach it to prevent the inltration of water as well as any insects and other small creatures
from the outside. Otherwise a short circuit may occur inside the control box.

19 3P184443-12N English
[PRECAUTIONS]
Observe the notes mentioned below when wiring to the power supply terminal block and terminal block
for remote controller.
Precautions to be taken for power supply wiring
Use a round crimp-style terminal for connection to the power supply terminal block. If it cannot be used
due to unavoidable reasons, be sure to observe the following instructions:
Be sure to peel off the sheath of power supply wiring more than 3-1/4 in. (Refer to Fig. 26)
Attach insulation sleeve
Power supply wiring and ground wire
Round crimp-style terminal
3-1/4 in. or more
Fig. 26
When none is available, follow the instructions below.
Do not connect wires of different gauge to the same grounding terminal.
Connect wires of the same
gauge to each side.
Do not connect wires of
the same gauge to one
side.
Do not connect wires of
different gauges.
Looseness in the connection may deteriorate protection.
Tightening torque for the terminal blocks
• Use the correct screwdriver for tightening the terminal screws. If the blade of screwdriver is too small,
the head of the screw might be damaged, and the screw will not be properly tightened.
• If the terminal screws are tightened too hard, screws might be damaged.
• Refer to the table below for the tightening torque of the terminal screws.
Size Tightening torque (ft-lbf)
Terminal block for remote controller (6P) M3.5 0.58 – 0.72
Power supply terminal block (3P) M4 0.87 – 1.06
• For remote controller wiring, refer to the “INSTALLATION MANUAL OF REMOTE CONTROLLER.”
attached to the remote controller.
• Never connect power supply wiring to the terminal block for remote controller. This could
damage the entire system.
• Use only specied wire and tightly connect wires to terminals. Be careful wires do not place external
stress on terminals. Keep wiring in neat order and arrange so as not to obstruct other equipment
causing the control box cover to pop open. Make sure the cover closes tight. Incomplete connections
could result in overheating and, in the worst case, electric shock or re.
