Daikin VRVIII RXYQ Series User manual

English
Français
Español
OPERATION MANUAL
MODEL
RXYQ72PBYD
RXYQ96PBYD
RXYQ120PBYD
RXYQ144PBYD
RXYQ168PBYD
RXYQ192PBYD
RXYQ216PBYD
RXYQ240PBYD
RXYQ264PBYD
RXYQ288PBYD
RXYQ312PBYD
RXYQ336PBYD
RXYQ360PBYD
RXYQ72PBTJ
RXYQ96PBTJ
RXYQ120PBTJ
RXYQ144PBTJ
RXYQ168PBTJ
RXYQ192PBTJ
RXYQ216PBTJ
RXYQ240PBTJ
RXYQ264PBTJ
RXYQ288PBTJ
RXYQ312PBTJ
RXYQ336PBTJ
RXYQ360PBTJ
REYQ72PBYD
REYQ96PBYD
REYQ120PBYD
REYQ144PBYD
REYQ168PBYD
REYQ192PBYD
REYQ216PBYD
REYQ240PBYD
REYQ264PBYD
REYQ288PBYD
REYQ312PBYD
REYQ336PBYD
REYQ72PBTJ
REYQ96PBTJ
REYQ120PBTJ
REYQ144PBTJ
REYQ168PBTJ
REYQ192PBTJ
REYQ216PBTJ
REYQ240PBTJ
REYQ264PBTJ
REYQ288PBTJ
REYQ312PBTJ
REYQ336PBTJ
System air conditioner
Read these instructions carefully before installation.
Keep this manual in a handy place for future reference.
This manual should be left with the equipment owner.
On/Off
Mode
Fan
Speed
Cancel
Menu
OK
00_CV_3P215731-9N.indd 100_CV_3P215731-9N.indd 1 11/4/2010 4:12:30 PM11/4/2010 4:12:30 PM

English 1
RX(E)YQ72PBYD
RX(E)YQ96PBYD
RX(E)YQ120PBYD
RX(E)YQ144PBYD
RX(E)YQ168PBYD
RX(E)YQ192PBYD
RX(E)YQ216PBYD
RX(E)YQ240PBYD
RX(E)YQ264PBYD
RX(E)YQ288PBYD
RX(E)YQ312PBYD
RX(E)YQ336PBYD
RXYQ360PBYD
RX(E)YQ72PBTJ
RX(E)YQ96PBTJ
RX(E)YQ120PBTJ
RX(E)YQ144PBTJ
RX(E)YQ168PBTJ
RX(E)YQ192PBTJ
RX(E)YQ216PBTJ
RX(E)YQ240PBTJ
RX(E)YQ264PBTJ
RX(E)YQ288PBTJ
RX(E)YQ312PBTJ
RX(E)YQ336PBTJ
RXYQ360PBTJ
VRVIII System
air conditioner
Operation
manual
Contents
Safety Considerations .............................................................1
Specifications ..........................................................................4
What to do before Operation ...................................................5
Remote Controller and Cool/Heat Selector :
Name and Function of Each Switch and Display.....................6
Names and Functions..............................................................8
Operation Range ...................................................................10
Operation Procedure .............................................................10
Basic Operation.....................................................................11
Quick Reference....................................................................17
Menu Options ........................................................................18
Maintenance..........................................................................31
Reference Information...........................................................32
Optimum Operation ...............................................................33
Seasonal Maintenance..........................................................33
Following Symptoms are not Air Conditioner Troubles..........34
Trouble Shooting ...................................................................36
After-Sales Service And Warranty .........................................37
Safety Considerations
Read these Safety Considerations for Operations carefully
before installing air conditioning equipment. After completing
the installation, make sure that the unit operates properly
during the startup operation. Instruct the customer on how to
operate and maintain the unit.
Inform customers that they should store this Operation Manual
with the Installation Manual for future reference.
Meanings of DANGER, WARNING, CAUTION, and NOTE
Symbols:
DANGER............Indicates an imminently hazardous
situation which, if not avoided, will result
in death or serious injury.
WARNING..........Indicates a potentially hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTION...........Indicates a potentially hazardous
situation which, if not avoided, may result
in minor or moderate injury. It may also
be used to alert against unsafe practices.
NOTE .................Indicates situations that may result in
equipment or property-damage accidents
only.
DANGER
Do not install the unit in an area where flammable●
materials are present due to risk of explosion resulting
in serious injury or death.
Any abnormalities in the operation of the air●
conditioner such as smoke or fire could result in severe
injury or death. Turn off the power and contact your
dealer immediately.
Refrigerant gas may produce toxic gas if it comes in●
contact with fire, such as from a fan, heater, stove, or
cooking device. Exposure to this gas could cause
severe injury or death.
For refrigerant leakage, consult your dealer.●
Refrigerant gas is heavier than air and replaces oxygen.
A massive leak could lead to oxygen depletion,
especially in basements, and an asphyxiation hazard
could occur leading to serious injury or death.
If equipment utilizing a burner is used in the same room●
as the air conditioner, there is the danger of oxygen
deficiency which could lead to an asphyxiation hazard
resulting in serious injury or death. Be sure to ventilate
the room sufficiently to avoid this hazard.
Safely dispose of the packing materials. Packing●
materials, such as nails and other metal or wooden
parts, may cause stabs or other injuries.
Tear apart and throw away plastic packaging bags so●
that children will not play with them.
Children playing with plastic bags face the danger of
death by suffocation.
WARNING
Contact your dealer for repair and maintenance.●
Improper repair and maintenance may result in water
leakage, electric shock, and fire. Only use accessories
made by Daikin that are specifically designed for use
with the equipment and have them installed by a
professional.
Contact your dealer to move and reinstall the air●
conditioner. Incomplete installation may result in water
leakage, electric shock, and fire.
Never let the indoor unit or the remote controller get●
wet. Water can cause an electric shock or a fire.
Never use flammable spray such as hair spray, lacquer,●
or paint near the unit. Flammable spray may cause a
fire.
When a fuse blows out, never replace it with one of●
incorrect ampere ratings or different wires. Always
replace any blown fuse with a fuse of the same
specification.
Never remove the fan guard of the unit. A fan rotating at●
high speed without the fan guard is very dangerous.
Never inspect or service the unit by yourself. Contact a●
qualified service person to perform this work.
Turn off all electrical power before doing any●
maintenance to avoid the risk of serious electric shock;
never sprinkle or spill water or liquids on the unit.
01_EN_3P215731-9N.indd 101_EN_3P215731-9N.indd 1 11/8/2010 8:38:40 PM11/8/2010 8:38:40 PM

2 English
Do not touch the switch with wet fingers.●
Touching a switch with wet fingers can cause electric
shock.
Do not allow children to play on or around the unit to●
prevent injury.
The heat exchanger fins are sharp enough to cut. To●
avoid injury wear gloves or cover the fins while working
around them.
Do not put a finger or other objects into the air inlet or●
air outlet. The fan is rotating at high speed and will
cause injury.
Check the unit foundation for damage on a continuous●
basis, especially if it has been in use for a long time. If
left in a damaged condition the unit may fall and cause
injury.
Placing a flower vase or other containers with water or●
other liquids on the unit could cause a shock or fire if a
spill occurs.
Do not touch the air outlet or horizontal blades while●
the swing flap is in operation because fingers could get
caught and injured.
Never touch the internal parts of the controller. Do not●
remove the front panel because some parts inside are
dangerous to touch. To check and adjust internal parts,
contact your dealer.
Be sure to establish an earth.●
Do not earth the unit to a utility pipe, arrester, or
telephone earth. Incomplete earth may cause electrical
shock, or fire. A high surge current from lightning or
other sources may cause damage to the air conditioner.
Be sure to install a ground fault circuit interrupter.●
Failure to install a ground fault circuit interrupter may
result in electric shocks, or fire.
CAUTION
Do not use the air conditioner for any other purposes●
other than comfort cooling or heating. Do not use the
unit for cooling precision instruments, food, plants,
animals or works of art.
Do not place items under the indoor unit as they may●
be damaged by condensates that may form if the
humidity is above 80% or if the drain outlet gets
blocked.
Before cleaning, stop the operation of the unit by●
turning the power off or by pulling the supply cord out
from its receptacle. Otherwise, an electric shock and
injury may result.
Do not wash the air conditioner with excessive water.●
An electric shock or fire may result.
Avoid placing the controller in a spot splashed with●
water. Water entering the controller may cause an
electric shock or damage the internal electronic parts.
Do not operate the air conditioner when using a●
roomfumigation type of insecticide. Failure to observe
this could cause the chemicals to be deposited in the
unit and can endanger the health of those who are
hypersensitive to chemicals.
Do not turn off the power immediately after stopping●
operation. Always wait for at least five minutes before
turning off the power. Otherwise, water leakage may
occur.
The appliance is not intended for use by young children●
or infirm persons without supervision.
The remote controller should be kept away from●
children so they cannot play with it.
Consult with the installation contractor for cleaning.●
Incorrect cleaning of the inside of the air conditioner●
could make the plastics parts break and cause water
leakage or electric shock.
Do not touch the air inlet or aluminum fin of the air●
conditioner as they can cut and cause injury.
Do not place objects in direct proximity of the outside●
unit. Do not let leaves and other debris accumulate
around the unit. Leaves are a hotbed for small animals
which can enter the unit. Once inside the unit, animals
can cause the unit to malfunction, and cause smoke or
fire when they make contact with electrical parts.
NOTE
Never press the button of the remote controller with a●
hard, pointed object. The remote controller may be
damaged.
Never pull or twist the electric wire of the remote●
controller. It may cause the unit to malfunction.
Do not place appliances that produce open flames in●
places that are exposed to the air flow of the unit or
under the indoor unit. It may cause incomplete
combustion or deformation of the unit due to the heat.
Do not expose the controller to direct sunlight. The LCD●
display can become discolored and may fail to display
the data.
Do not wipe the controller operation panel with●
benzene, thinner, chemical dust cloth, etc. The panel
may get discolored or the coating can peel off. If it is
heavily dirty, soak a cloth in water-diluted neutral
detergent, squeeze it well and wipe the panel clean.
Then wipe it with another dry cloth.
Dismantling of the unit, disposal of the refrigerant, oil,●
and additional parts, should be done in accordance
with the relevant local, state, and national regulations.
Operate the air conditioner in a sufficiently ventilated●
area and not surrounded by obstacles. Do not use the
air conditioner in the following places.
Places with a mist of mineral oil, such as cutting oil.a.
Locations such as coastal areas where there is a lotb.
of salt in the air.
Locations such as hot springs where there is a lot ofc.
sulfur in the air.
Locations such as factories where the power voltaged.
varies a lot.
In cars, boats, and other vehicles.e.
Locations such as kitchens where oil may splatter orf.
where there is steam in the air.
Locations where equipment producesg.
electromagnetic waves.
Places with an acid or alkaline mist.h.
Places where fallen leaves can accumulate or wherei.
weeds can grow.
Take snow protection measures. Contact your dealer●
for the details of snow protection measures, such as
the use of a snow protection hood.
Do not attempt to do electrical work or grounding work●
unless you are licensed to do so. Consult with your
dealer for electrical work and grounding work.
01_EN_3P215731-9N.indd 201_EN_3P215731-9N.indd 2 11/8/2010 8:38:41 PM11/8/2010 8:38:41 PM

English 3
Pay Attention to Operating Sound. Be sure to use the●
following places:
Places that can sufficiently withstand the weight ofa.
the air conditioner yet can suppress the operating
sound and vibration of the air conditioner.
Places where warm air from the air outlet of theb.
outside unit or the operating sound of the outside
unit does not annoy neighbors.
Make sure that there are no obstacles close to the●
outside unit. Obstacles close to the outside unit may
drop the performance of the outside unit or increase
the operating sound of the outside unit.
Consult your dealer if the air conditioner in operation●
generates unusual noise.
Make sure that the drainpipe is installed properly to●
drain water. If no water is discharged from the drainpipe
while the air conditioner is in the cooling mode, the
drainpipe may be clogged with dust or dirt and water
leakage from the indoor unit may occur. Stop operating
the air conditioner and contact your dealer.
[Place of Installation]
Make sure that the air conditioner is located in a●
sufficiently ventilated place not surrounded by
obstacles.
Do not use the air conditioner in the following places.●
Places with a mist of mineral oil, such as cutting oil.a.
Locations such as coastal areas where there is a lot ofb.
salt in the air.
Locations such as hot springs resorts where there is a lotc.
of sulfur in the air.
Locations such as factories where the power voltaged.
varies a lot.
In cars, boats, and other vehicles.e.
Locations such as kitchens where oil may splatter orf.
there is steam in the air.
Locations where equipment that producesg.
electromagnetic waves is found.
Places with an acid or alkaline mist.h.
Places where fallen leaves are accumulated or weedsi.
grow close together.
Take snow protection measures.●
Contact your dealer for the details of snow protection
measures, such as the use of a snow protection hood.
[Electrical Work]
Do not attempt to conduct electrical work or grounding●
work unless you are licensed to do so.
Consult with your dealer for electrical work and grounding
work.
Use a dedicated circuit for the air conditioner.●
[Pay Attention to Operating Sound]
Be sure to use the following places.●
Places that can sufficiently withstand the weight of the aira.
conditioner and suppress the operating sound and
vibration of the air conditioner.
Places where warm air from the air outlet of the outsideb.
unit or the operating sound of the outside unit does not
annoy neighbors.
Make sure that there are no obstacles close to the●
outside unit.
Obstacles close to the outside unit may drop the
performance of the outside unit or an increase in the
operating sound of the outside unit.
Consult your dealer if the air conditioner in operation●
generates unusual noise.
[Drainage through Drainpipe]
Make sure that the drainpipe is installed properly to●
drain water.
If no water is discharged from the drainpipe while the air
conditioner is cooling operation, the drainpipe may be
clogged with dust or dirt and water leakage from the indoor
units may result.
Stop operating the air conditioner and consult your dealer.
01_EN_3P215731-9N.indd 301_EN_3P215731-9N.indd 3 11/8/2010 8:38:41 PM11/8/2010 8:38:41 PM

4 English
Specifications
Model name RXYQ72PBYD RXYQ96PBYD RXYQ120PBYD RXYQ144PBYD RXYQ168PBYD RXYQ192PBYD RXYQ216PBYD RXYQ240PBYD RXYQ264PBYD RXYQ288PBYD RXYQ312PBYD RXYQ336PBYD RXYQ360PBYD
Power supply
Phase — 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~
Frequency (Hz) 60 60 60 60 60 60 60 60 60 60 60 60 60
Voltage (V) 460 460 460 460 460 460 460 460 460 460 460 460 460
Nominal cooling
Maximum capacity
(Btu/h) 72,000 96,000 120,000 144,000 168,000 192,000 216,000 240,000 264,000 288,000 312,000 336,000 360,000
Nominal heating
Maximum capacity
(Btu/h) 81,000 108,000 135,000 162,000 188,000 216,000 243,000 270,000 297,000 324,000 351,000 378,000 405,000
Dimensions H×W×D (inch)
66-1/8
×36-5/8
×30-1/8
66-1/8×48-7/8
×30-1/8
66-1/8×36-5/8
×30-1/8+66-1/8
×48-7/8×30-1/8
66-1/8×48-7/8
×30-1/8+66-1/8
×48-7/8×30-1/8
66-1/8×36-5/8×30-1/8
+66-1/8×48-7/8×30-1/8
+66-1/8×48-7/8×30-1/8
66-1/8×48-7/8
×30-1/8+66-1/8
×48-7/8×30-1/8
+66-1/8×48-7/8
×30-1/8
Mass (Ib) 433 633 433+433 433+633 633+633 433+633+633 633+633+633
Refrigerant
type — R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A
charge (*1) (Ib) 16.5 21.4 22.1 16.5+16.5 16.5+21.4 16.5+22.1 21.4+22.1 22.1+22.1 16.5+21.4
+21.4
16.5+21.4
+22.1
16.5+22.1
+22.1
21.4+22.1
+22.1
22.1+22.1
+22.1
Design pressure
High side (psig) 478 478 478 478 478 478 478 478 478 478 478 478 478
Low side (psig) 320 320 320 320 320 320 320 320 320 320 320 320 320
Model name RXYQ72PBTJ RXYQ96PBTJ RXYQ120PBTJ RXYQ144PBTJ RXYQ168PBTJ RXYQ192PBTJ RXYQ216PBTJ RXYQ240PBTJ RXYQ264PBTJ RXYQ288PBTJ RXYQ312PBTJ RXYQ336PBTJ RXYQ360PBTJ
Power supply
Phase — 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~
Frequency (Hz) 60 60 60 60 60 60 60 60 60 60 60 60 60
Voltage (V) 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230
Nominal cooling
Maximum capacity
(Btu/h) 72,000 96,000 120,000 144,000 168,000 192,000 216,000 240,000 264,000 288,000 312,000 336,000 360,000
Nominal heating
Maximum capacity
(Btu/h) 81,000 108,000 135,000 162,000 188,000 216,000 243,000 270,000 297,000 324,000 351,000 378,000 405,000
Dimensions H×W×D (inch)
66-1/8
×36-5/8
×30-1/8
66-1/8×48-7/8
×30-1/8
66-1/8
×51-3/16
×30-1/8
66-1/8×36-5/8
×30-1/8+66-1/8
×48-7/8×30-1/8
66-1/8×48-7/8
×30-1/8+66-1/8
×48-7/8×30-1/8
66-1/8×36-5/8×30-1/8
+66-1/8×48-7/8×30-1/8
+66-1/8×48-7/8×30-1/8
66-1/8×48-7/8
×30-1/8+66-1/8
×48-7/8×30-1/8
+66-1/8×48-7/8
×30-1/8
Mass (Ib) 420 620 747 420+620 620+620 420+620+620 620+620+620
Refrigerant
type — R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A
charge (*1) (Ib) 16.5 21.4 22.1 24.5 16.5+21.4 16.5+22.1 21.4+22.1 22.1+22.1 16.5+21.4
+21.4
16.5+21.4
+22.1
16.5+22.1
+22.1
21.4+22.1
+22.1
22.1+22.1
+22.1
Design pressure
High side (psig) 478 478 478 478 478 478 478 478 478 478 478 478 478
Low side (psig) 320 320 320 320 320 320 320 320 320 320 320 320 320
Model name REYQ72PBYD REYQ96PBYD REYQ120PBYD REYQ144PBYD REYQ168PBYD REYQ192PBYD REYQ216PBYD REYQ240PBYD REYQ264PBYD REYQ288PBYD REYQ312PBYD REYQ336PBYD
Power supply
Phase — 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~
Frequency (Hz) 60 60 60 60 60 60 60 60 60 60 60 60
Voltage (V) 460 460 460 460 460 460 460 460 460 460 460 460
Nominal cooling
Maximum capacity
(Btu/h) 72,000 96,000 120,000 144,000 168,000 192,000 216,000 240,000 264,000 288,000 312,000 336,000
Nominal heating
Maximum capacity
(Btu/h) 81,000 108,000 135,000 162,000 188,000 216,000 243,000 270,000 297,000 324,000 351,000 378,000
Dimensions H×W×D (inch) 66-1/8×51-3/16×30-1/8 66-1/8×36-5/8×30-1/8+66-1/8×36-5/8×30-1/8 66-1/8×36-5/8×30-1/8+66-1/8×36-5/8
×30-1/8+66-1/8×36-5/8×30-1/8
Mass (Ib) 732 463+ 463 463+573 573+573 463+573+573 573+573+573
Refrigerant
type — R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A
charge (*1) (Ib) 22.7 23.4 23.8 18.1+18.1 18.1+19.8 19.8+19.8 19.8+20.1 20.1+20.1 18.1+19.8
+19.8
18.1+19.8
+20.1
19.8+19.8
+20.1
19.8+20.1
+20.1
Design pressure
High side (psig) 478 478 478 478 478 478 478 478 478 478 478 478
Low side (psig) 320 320 320 320 320 320 320 320 320 320 320 320
Model name REYQ72PBTJ REYQ96PBTJ REYQ120PBTJ REYQ144PBTJ REYQ168PBTJ REYQ192PBTJ REYQ216PBTJ REYQ240PBTJ REYQ264PBTJ REYQ288PBTJ REYQ312PBTJ REYQ336PBTJ
Power supply
Phase — 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~ 3~
Frequency (Hz) 60 60 60 60 60 60 60 60 60 60 60 60
Voltage (V) 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230
Nominal cooling
Maximum capacity
(Btu/h) 72,000 96,000 120,000 144,000 168,000 192,000 216,000 240,000 264,000 288,000 312,000 336,000
Nominal heating
Maximum capacity
(Btu/h) 81,000 108,000 135,000 162,000 188,000 216,000 243,000 270,000 297,000 324,000 351,000 378,000
Dimensions H×W×D (inch) 66-1/8×51-3/16×30-1/8
66-1/8
×51-3/16
×30-1/8
66-1/8×36-5/8×30-1/8+66-1/8×36-5/8×30-1/8 66-1/8×36-5/8×30-1/8+66-1/8×36-5/8
×30-1/8+66-1/8×36-5/8×30-1/8
Mass (Ib) 730 747 450+560 550+550 450+560+560 560+560+560
Refrigerant
type — R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A R410A
charge (*1) (Ib) 22.7 23.4 23.8 24.5 18.1+19.8 19.8+19.8 19.8+20.1 20.1+20.1 18.1+19.8
+19.8
18.1+19.8
+20.1
19.8+19.8
+20.1
19.8+20.1
+20.1
Design pressure
High side (psig) 478 478 478 478 478 478 478 478 478 478 478 478
Low side (psig) 320 320 320 320 320 320 320 320 320 320 320 320
01_EN_3P215731-9N.indd 401_EN_3P215731-9N.indd 4 11/8/2010 8:38:42 PM11/8/2010 8:38:42 PM

English 5
What to do before Operation
This operation manual is for the following system with standard control. Before initiating operation, contact your Daikin dealer for
the operation that corresponds to your system type and mark.
If your installation has a customized control system, ask your Daikin dealer for the operation that corresponds to your system.
RXYQ series REYQ series Outdoor unit1.
Indoor unit2.
Remote controller3.
Inlet air4.
Outlet air5.
BS unit6.
Cool/Heat selector7.
Refrigerant piping8.
COOL/HEAT selector Operation modes
Inverter series
heat pumps RXYQ series ❏yes ❏no Cool, Heat, Fan
Heat recovery series
heat pumps REYQ series ❏yes ❏no Cool, Heat, Auto, Fan
01_EN_3P215731-9N.indd 501_EN_3P215731-9N.indd 5 11/8/2010 8:38:42 PM11/8/2010 8:38:42 PM

6 English
On/Off
Mode
Fan
Speed
Cancel
Menu
OK
Remote Controller and Cool/Heat Selector :
Name and Function of Each Switch and Display
2. Fan speed control button
3. Menu/OK button
8. On/Off button
10. Cancel button
9. Operation lamp
11. LCD (with backlight)
4. Up button.....
5. Down button
6. Right button
7. Left button...
1. Operation mode selector button
Functions other than basic operation items (i.e., On/Off, Operation mode selector, Fan speed control,
and temperature setpoint) are set from the menu screen.
NOTE
Do not install the remote controller in places exposed to direct sunlight, otherwise the LCD will be damaged.●
Do not pull or twist the remote controller cord, otherwise the remote controller may be damaged.●
Do not use objects with sharp ends to press the buttons on the remote controller otherwise damage may result.●
Button Locations and Descriptions
<Remote Controller>
01_EN_3P215731-9N.indd 601_EN_3P215731-9N.indd 6 11/8/2010 8:38:50 PM11/8/2010 8:38:50 PM

English 7
Operation mode selector button1.
Press this button to select the operation mode of your preference.●
(See page 11.)
Available modes vary with the indoor unit model.*
Fan speed control button2.
Press this button to select the fan speed of your preference.●
(See page 12.)
Available fan speeds vary with the indoor unit model.*
Menu/OK button3.
Used to indicate the main menu.●
(See page 17 for the menu items.)
Used to enter the selected item.●
Up button4.
Used to raise the setpoint.●
The item above the current selection will be highlighted.●
(The highlighted items will be scrolled continuously when the
button is continuously pressed.)
Used to change the selected item.●
Down button5.
Used to lower the setpoint.●
The item below the current selection will be highlighted.●
(The highlighted items will be scrolled continuously when the
button is continuously pressed.)
Used to change the selected item.●
Right button6.
Used to highlight the next items on the right-hand side.●
Each screen is scrolled in the right-hand direction.●
Left button7.
Used to highlight the next items on the left-hand side.●
Each screen is scrolled in the left-hand direction.●
On/Off button8.
Press this button and system will start.●
Press this button again to stop the system.●
Operation lamp (Green)9.
This lamp illuminates solid during normal operation.●
This lamp blinks if a error occurs.●
Cancel button10.
Used to return to the previous screen.●
LCD (with backlight)11.
The backlight will be illuminated for approximately 30 seconds by●
pressing any button.
If two remote controllers are used to control a single indoor unit,●
only the controller to be accessed first will have backlight
functionality.
<Cool/Heat selector>
Fan only/air conditioning selector switch12.
Set the switch to “●” for fan only operation or to “ ” for
heating or cooling operation.
Cool/heat changeover switch13.
Set the switch to “●” for cooling operation or to “ ” for
heating operation.
01_EN_3P215731-9N.indd 701_EN_3P215731-9N.indd 7 11/8/2010 8:38:51 PM11/8/2010 8:38:51 PM

8 English
Liquid Crystal Display
Two types of liquid crystal display (LCD) are available. The standard display is set by default. ●
Detailed display can be selected in the main menu. ● (See page 27.)
The displayed contents of the screen vary with the operation mode of the indoor unit model. (The following display will appear when the indoor ●
unit is in automatic operation.)
Standard display
Set to
Cool
Heat
74F
70F
Auto
This function is not available
<Standard display example>
6.Ventilation
2.Fan Speed
1.Operation mode
11.Setback
7.( ) display
3.Setpoint display
4.
Stand by for Defrost/
Hot start
5.Message
10.Changeover controlled by
the master indoor unit
9.Under centralized
control
8.( ) display
AUTO
ERV AIR PURIFY
CENTRAL
CONTROL MASTER CONTROLLED
SETBACK
STANDBY
Detailed Display
The air flow direction, clock, and detailed selection items appear on the detailed display screen in
addition to the items appearing on the standard display.
Cool
Heat 74
F
70 F
Room
Fri
11:03A
Set to
74
F
Auto
Return Setting
14.Detailed selection
12.
Air Flow Direction
(Displayed only when
the air conditioner is in
operation.)
13.Current Day/time
(12/24 hour time
display)
<Detailed display example 1>
AUTO
ERV AIR PURIFY
CENTRAL
CONTROL MASTER CONTROLLED
SETBACK
STANDBY
Auto
Return Setting
<Detailed display example 2>
No Air Flow
Direction display
(with no air flow direction
settings)
No Fan speed display
(with no fan speed
control function)
No Detailed item display
(with no detailed items
selected)
No Clock display
(when the clock has
not been set)
15. ( ) display
--
:
--
CENTRAL
CONTROL MASTER CONTROLLED
SETBACK
AUTO
ERV AIR PURIFY
STANDBY
Names and Functions
01_EN_3P215731-9N.indd 801_EN_3P215731-9N.indd 8 11/8/2010 8:38:51 PM11/8/2010 8:38:51 PM

English 9
Operation mode1.
Used to display the current operation●
mode: Cool, Heat, Vent, Fan, Dry or Auto.
Fan Speed2.
Used to display the fan speed that is set for the indoor unit.●
The fan speed will not be displayed if the connected model does●
not have fan speed control functionality.
Setpoint display3.
Used to display the setpoint for the indoor unit.●
Use the Celsius/Fahrenheit item in the main menu to select the●
temperature unit (Celsius or Fahrenheit).
Stand by for Defrost/Hot start4.
“
STANDBY
” (See page 12.)
If ventilation icon is displayed in this field:
Indicates that an energy recovery ventilator is connected.●
For details, refer to the Operation Manual of the ERV.
Message5.
The following messages may be displayed.
“This function is not available”
Displayed for a few seconds when an operation button is pressed●
and the indoor unit does not provide the corresponding function.
In a remote control group, the message will not appear if at least●
one of the indoor units provides the corresponding function.
“Error: Push Menu button”
“Warning: Push Menu button”
Displayed if an error or warning is detected●(see page 32).
“Time to clean filter”
“Time to clean element”
“Time to clean filter & element”
Displayed as a reminder when it is time to clean the filter or●
element (see page 31).
Ventilation6.
Displayed when a energy recovery ventilator is connected.●
Ventilation Mode icon.“●AUTO
ERV
ERV BYPASS
”
These icons indicate the current ventilation mode (ERV only)
(AUTO, ERV, BYPASS).
Air Purify ICON “●
A
IR
PURIFY
”
This icon indicates that the air purifying unit (option) in operation.
7. display (See page 16.)
Displayed when the key lock is set.●
8. display (See page 21.)
Displayed if the Schedule or Off timer is enabled.●
Under Centralized control “9.
CENTRAL
CONTROL
”
Displayed if the system is under the management of a multi zone●
controller (option) and the operation of the system through the
remote controller is limited.
Changeover controlled by the master indoor unit10.
“
MASTER
CONTROLLED
”
Displayed when another indoor unit on the system has the●
authority to change the operation mode between cool and heat.
Setback “11.
SETBACK
” (See page 13.)
The setback icon flashes when the unit is turned on under the●
setback control.
Air Flow Direction “12. ”
Displayed when the air flow direction and swing are set●(see page
19).
If the connected indoor unit model does not include oscillating●
louvers this item will not be displayed.
Current Day/Time (12/24 hour time display)13.
Displayed if the clock is set●(see page 29).
If the clock is not set, “ -- : -- ” will be displayed.●
12 hour time format is displayed by default.●
Select 12/24 hour time display option in the main menu under●
“Clock & Calendar”.
Detailed selection14.
Displayed if the detailed display item is selected●(see page 28).
Detailed items are not selected by default.●
15. display
Displayed when the clock needs to be set.●
The schedule function will not work unless the clock is set.●
01_EN_3P215731-9N.indd 901_EN_3P215731-9N.indd 9 11/8/2010 8:38:52 PM11/8/2010 8:38:52 PM

10 English
Operation Range
COOLING HEATING
outdoor temperature 23°~110°FDB 0°~60°FWB
indoor temperature 57°~77°FWB 59°~80°FDB
indoor humidity 80% —
Note
Cooling operation:●
If the air conditioner is operated continuously while the indoor temperature is 70°F or below and the humidity is 80% or over, the interiors of
the indoor units may cause icing and water leakage may result.
Heating operation:●
The air conditioner may stop operating for the protection of the machine if the outdoor temperature is 70°F or over.
Operation Procedure
Operation procedure varies according to the combination of outside unit and remote controller. Read the chapter “What to do●
before operation”.
Do not turn it off during the air conditioning season for starting operation smoothly.●
If the main power supply is turned off during operation, operation will restart automatically after the power turns back on again.●
Note
Automatic operation (REYQ only)●
In this operation mode, cool/heat changeover is automatically conducted.
For Systems with Cool/Heat Selector
Select operation mode with the Cool/Heat selector as follows:●
Cooling operation
Heating operation
Fan only operation
Press On/Off button.●
The operation lamp lights up and the system starts
operation.
01_EN_3P215731-9N.indd 1001_EN_3P215731-9N.indd 10 11/8/2010 8:38:53 PM11/8/2010 8:38:53 PM

English 11
Basic Operation
Cool/Heat/Auto/Fan Operation
Operation
1
2
●Display the main menu screen.
(See page 18.)
●Before setting the schedule , the
clock must be set.
●The date & time screen will appear.
●Set the current year, month, day, and
time. (See clock settings on page 29.)
●
If the clock has not been set, a screen
like the one on the left will appear.
Press buttons to select Ye s and
press Menu/OK button.
●Press buttons to select
Schedule the main menu screen.
Press Menu/OK button to display
the timer screen.
Setting
Clock has not been set.
Would you like to set it now?
Schedule
Yes No
Setting
Date & Time
Year 2008
Month 01
Day 01
Tuesday
12:00A
Operation screen
display
Describes screens that
will be displayed on the
remote controller in
operation.
Operation procedure
Explains the sequence of
operation for the remote controller.
Operate the buttons according to
the procedure.
Operation button
display
Displays the location of
buttons to be operated.
How to follow the operation manual
Setting
Main Menu
Air Flow Direction
Ventilation
Schedule
Off Timer
Celsius / Fahrenheit
Maintenance Information
1/2
Preparation
For mechanical protection purposes, apply power to the outdoor units at least six hours before starting the operation of the system.●
Operation
1
Cool
Return Setting
Set to
Cool
74F
Press the Operation mode selector button several times until the desired●
mode Cool, Heat, Fan, or Auto mode is selected.
Unavailable operation modes are not displayed.*
Note
Before changing the mode, confirm that the display does not indicate master controlled status. Both●
heat and cool mode may not be selected if the unit is master controlled. See page 15 if MASTER
CONTROLLED icon blinks.
2
On/Off
n
u
K
Press On/Off button.●
The Operation lamp (green) will illuminate and the system will start operating.
3 Cool
Return Setting
Set to
Cool
74F
The setpoint will increase by●
1°F (or 1°C) when button is pressed and decrease by 1°F (or 1°C) when
button is pressed.
Setpoint is not available in fan or dry mode.*
01_EN_3P215731-9N.indd 1101_EN_3P215731-9N.indd 11 11/8/2010 8:38:53 PM11/8/2010 8:38:53 PM

12 English
Basic Operation
4 Cool
Return Setting
Set to
Cool
74F
Low Medium
High
To change the fan speed, press the Fan speed control button and select the●
desired fan speed from Low, Medium or High.
Only two fan speed adjustment levels, low and high may be available depending on the type of indoor unit.*
The system may be in automatic fan speed control for equipment protection purposes.*
The system may be in automatic fan speed control according to the room temperature. It is normal for the fan to*
intermittently stop operating.
It is normal for a delay to occur when changing the fan speed.*
5 Adjust Air Flow Direction from the main menu●(see page 19).
If the connected indoor unit model does not include oscillating louvers this function will not be available.*
6
On/Off
n
u
K
When the On/Off button is pressed again, the system will stop operating and●
the operation lamp will turn off.
When the system is stopped while in the heating mode, the fan will continue to operate for*
approximately one minute to remove residual heat from the indoor unit.
Note
To prevent water damage or system failure, do not immediately remove power from the indoor unit●
following system operation. Wait at least five minutes for the condensate pump to finishing draining
residual water from the unit.
Characteristics of Heat Mode
The system automatically controls the following operating modes to prevent the reduction of heating
capacity and space comfort.
Defrost operation The system will automatically go into defrost operation to prevent frost accumulation at the outdoor unit●
and loss of heating capacity.
The indoor unit fan will stop, and “●
STANDBY
” (Defrost/Hot start) will be displayed on the remote controller.
The system will return to normal operation usually within six to eight minutes (but not more than●
10 minutes).
Hot start When the system goes into heat mode, the indoor unit fan will stop in order to prevent a cold draft.●
(In that case, “
STANDBY
” (Defrost/Hot start) will be displayed on the remote controller.)
Dry Mode
Preparation
For equipment protection purposes, apply power to the outdoor units at least six hours before starting the operation of the system.●
The dry mode may not be selected if the remote controller is master controlled and the system is not already in the cooling mode of●
operation. (see page 15 for details)
In case of changing the operation mode by the Cool/Heat Selector, set it to cooling operation mode.●
01_EN_3P215731-9N.indd 1201_EN_3P215731-9N.indd 12 11/8/2010 8:38:54 PM11/8/2010 8:38:54 PM

English 13
Operation
1 Dry
Return Setting
Press Mode button several times until the Dry mode is selected.●
The dry mode may not be available depending on the type of indoor unit.*
2
On/Off
n
u
K
Press On/Off button.●
The Operation lamp (green) will illuminate and the system will start operating.
In Dry mode, the system maintains automatic temperature and fan speed control. Therefore, temperature*
setpoint or fan speed settings are not available while the indoor unit is in the Dry mode.
3 Adjust Air Flow Direction from the main menu●(see page 19).
If the connected indoor unit model does not include oscillating louvers this function will not be available.*
4
On/Off
nu
K
When the On/Off button is pressed again, the system will stop operating and●
the operation lamp will turn off.
Note
To prevent water damage or system failure, do not immediately remove power from the indoor unit●
following system operation. Wait at least five minutes for the condensate pump to finishing draining
residual water from the unit.
Characteristic of Dry mode
The Dry mode dehumidifys the space at reduced cooling capacity to prevent the room temperature
from dropping to uncomfortable levels.
Setback
The Setback feature will maintain the space temperature in a specific range during unoccupied periods.
Note
This function will temporarily start an indoor unit that was previously turned off by the user or turned off from a schedule event /●
off timer.
This function must be enabled by the system installer.●
01_EN_3P215731-9N.indd 1301_EN_3P215731-9N.indd 13 11/8/2010 8:38:55 PM11/8/2010 8:38:55 PM

14 English
Basic Operation
Operation
1 Cool
Return Setting
Setback
Cool
84F
Setback
Cool
84F
Cool
Return Setting
SETBACK
The setback icon flashes when the unit is turned on under the setback●
control.
Ventilation Mode When the Indoor Unit is Interlocked with Energy Recovery Ventilator
Preparation
For equipment protection purposes, apply power to the outdoor units at least six hours before starting the operation of the system.●
Operation
1
Vent
Return Setting
AUTO
ERV
When operating the energy recovery ventilator (ERV) between seasons●
without the air conditioner, set the control to ventilation mode.
2 Changes to the ventilation mode are made from the main menu.●
Ventilation Mode: Auto, ERV, and Bypass*
3 Changes to the ventilation rate are made from the main menu.●
Ventilation Rate: Low or High*
4
On/Off
n
u
K
Press On/Off button.●
The Operation lamp (green) will illuminate and the system will start operating.
5
On/Off
nu
K
When the On/Off button is pressed again, the system will stop operating and●
the operation lamp will turn off.
01_EN_3P215731-9N.indd 1401_EN_3P215731-9N.indd 14 11/8/2010 8:38:56 PM11/8/2010 8:38:56 PM

English 15
Setting the Cool / Heat Changeover Master
Setting Changes
See page 16 for an explanation of the cool/heat changeover master indoor unit.
1 Cool
Return Setting
Set to
Cool
74F
Cool
Return Setting
Set to
Cool
74F
MASTER
CONTROLLED
Press the Operation Mode Selector button on the remote controller of the ●
changeover master indoor unit for at least four seconds. (While the backlight is
illuminated)
The “ ●
MASTER
CONTROLLED
” icon on each remote controller for the indoor units connected to the same
outdoor unit or BS unit will start flashing.
Vent mode setting changes are possible regardless of the cool/heat changeover master indoor unit.*
If cool/heat mode is configured for control from the outdoor unit, all remote controllers serving the associated*
indoor units will display its “
MASTER
CONTROLLED
” icon.
Set the cool/heat changeover master indoor unit as outlined below. ●
The icon “ ” will flash on all remote controllers when the power is turned ON for the first time.
Selection Settings
MASTER
CONTROLLED
2
Cool
Return Setting
Set to
Cool
74F
MASTER
CONTROLLED
Cool
Return Setting
Set to
Cool
74F
Press the Mode Selector button on the remote controller of the indoor unit which ●
is to serve as the cool/heat changeover master.
The remote controller for the changeover master indoor unit is established and
the
MASTER
CONTROLLED
icon disappears.
Other remote controllers in the system (indoor units served by the same outdoor
unit or indoor units served by the same branch selector (BS) unit) will now
display the
MASTER
CONTROLLED
icon.
3 Cool
Return Setting
Set to
Cool
74F
Press the Mode button on the remote controller of the indoor unit designated●
as the cool/heat changeover master (the remote controller not displaying the
MASTER
CONTROLLED
icon) repeatedly until the desired mode is selected. The display will
change to “Fan”, “Dry”, “Auto”, “Cool”, “Heat” each time the button is pressed.
Simultaneously, the other indoor units on the system will follow suit and change ●
modes to reflect the new mode selected at the changeover master remote
controller.
Cool / Heat Mode Selection Availability
“Cool”, “Heat” and “Auto” are all only available for selection on the cool/heat changeover master indoor unit. The following table●
indicates the available operating modes of the other indoor units on the system based upon the selected mode of the master
indoor unit.
01_EN_3P215731-9N.indd 1501_EN_3P215731-9N.indd 15 11/8/2010 8:38:58 PM11/8/2010 8:38:58 PM

16 English
Basic Operation
When the master indoor
unit is set to
The other indoor units in the system can be set to
Cool Dry Heat Fan
Cool mode
Dry mode
Heat mode
Fan mode
Auto mode (Cooling operation)
Auto mode (Heating operation)
Precautions for Selecting the Cool / Heat Changeover Master Indoor Unit
The cool/heat changeover master must be set for a single indoor unit in the following applications●
(2-Pipe Heat Pump System) (3-Pipe Heat Recovery System)
Indoor unit Indoor unit
A number of indoor units are
connected to a single outdoor unit.
Set any one of the indoor units as
the cool/heat changeover master.
A number of indoor units are
connected to a single BS unit.
Set any one of the indoor units as
the cool/heat changeover master.
BS unit:
The BS unit is used for cooling or
heat mode selection.
Key Lock
Operation Confirm and cancel Key Lock settings in the basic display screen.
1 Cool
Return Setting
Set to
Cool
74F
Basic screen
Press the Menu/OK button for at least four seconds. (While the backlight is ●
illuminated)
2 Cool
Return Setting
Set to
Cool
74F
“●” will appear.
All buttons are disabled when the keys are locked.
To cancel the key lock mode, continue pressing Menu/OK button for at least●
four seconds. (While the backlight is illuminated)
01_EN_3P215731-9N.indd 1601_EN_3P215731-9N.indd 16 11/8/2010 8:38:59 PM11/8/2010 8:38:59 PM

English 17
Quick Reference
The main menu has the following items.
Menu item Description Reference page
Air Flow Direction Used to configure air flow direction settings.
The air flow direction louver is automatically operated up and down (left and right).●
The fixed air flow directions are configurable for five positions.●
This function is not available on all models.*
19
Ventilation
Ventilation
operation settings
for energy
reovery ventilator
Ventilation Rate Used to set “Low” or “High” 20
Ventilation Mode Used to set Auto, ERV, or Bypass. 21
Schedule Daily Patterns Day settings are selected from three patterns, i.e., “7Days”, “Weekday/Weekend”, and●
“Weekday/Sat/Sun”. 22
Settings Set the startup time and operation stop time.●
ON: Startup time, cooling and heating temperature setpoints can be configured.
OFF: Operation stop time, cooling and heating setback temperature setpoints can
be configured.
( -- : Indicates that the setback function is disabled for this time period. )
_ : Indicates that the temperature setpoint and setback temperature setpoint for
this time period is not specified. The last active setpoint will be utilized.
Up to five actions can be set for each day.●
23
Off Timer
Used to set each operation period of the system.
Possible to set in 10 minute increments from 30 to 180 minutes.●25
Celsius / Fahrenheit Used to select whether temperature values will be displayed in Celsius or●
Fahrenheit.
–
Maintenance Information Used to display the maintenance information. 26
Configuration
Contrast
Adjustment
Used to make LCD contrast adjustment. 27
Display
Standard or Detailed
Display
Used to set standard or detailed display mode.
Display mode●
Standard or detailed display
Detailed display provides the choice to display between Room Temp, Outside Air ●
Temp, System or None.
27
Current Settings Used to display a list of current settings for available items.●28
Clock &
Calendar
Date & time
Used to configure date and time settings and corrections.
The default time display is 12H.●
The clock will maintain accuracy to within ±30 seconds per month.●
If there is a power failure for a period not exceeding 48 hours, the clock will continue●
working with the built-in backup power supply.
29
12H/24H Clock The time can be displayed in either a 12 hour or 24 hour time format. 30
Daylight Saving Time Used to adjust the clock in observance of daylight saving time.
–
Language The display language can be selected between English, Francais or Espanol. 31
Note: Available setting items vary with the indoor unit model.
Sub Remote Controller Menu Items
Two remote
controllers in control
Outdoor unit
Indoor unit
If two remote controllers are in control of a single indoor unit, the following menu items are not set in the
sub remote controller. In this case, the following items should be configured in the main remote controller.
Schedule●
Off timer●
Setback●
01_EN_3P215731-9N.indd 1701_EN_3P215731-9N.indd 17 11/8/2010 8:39:06 PM11/8/2010 8:39:06 PM

18 English
Menu Options
Moving Within the Main Menu Screen
Display Method for Main Menu
Operation
1 Cool
Return Setting
Set to
Cool
74F
Basic screen
Press Menu/OK button.●
2
Setting
Main Menu
Air Flow Direction
Ventilation
Schedule
Off Timer
Celsius / Fahrenheit
Maintenance Information
1/2
Main menu screen
The main menu screen will appear.●
Instructions for moving within the main menu will appear.
3 Selecting items from the main menu.●
1. Press buttons to select the desired item to be set.
2. Press Menu/OK button to display the details for the selected item.
4 To go back to the basic screen from the main menu, press the Cancel button.●
Note
If a button is not pressed for 5 minutes during configuration, the controller will automatically revert to the basic screen.●
01_EN_3P215731-9N.indd 1801_EN_3P215731-9N.indd 18 11/8/2010 8:39:07 PM11/8/2010 8:39:07 PM

English 19
Air Flow Direction
Configuring Air Flow Direction
Operation
1
Setting
Main Menu
Air Flow Direction
Ventilation
Schedule
Off Timer
Celsius / Fahrenleit
Maintenance Information
1/2 Display the main menu screen.●(See page 18.)
Press●buttons to select Air Flow Direction on the main menu screen
and press the Menu/OK button.
(For models with no airflow direction adjustment, Air Flow Direction will not be displayed on
the main menu screen.)
2
Setting
Air Flow Direction
Swing
Air Flow Direction
(up/down)
Setting
Swing
Air Flow Direction
Air Flow Direction
(left/right)
The air flow direction screen will appear.●
Note
Air flow direction appears on the screen as below.●
1
2 3
4
0
Up/down direction
0
1
2
3
4
Left/right direction
0 : Position 0
1 : Position 1
2 : Position 2
3 : Position 3
4 : Position 4
3
Setting
Swing
Air Flow Direction
Left/right direction
Setting
Air Flow Direction
Swing
Up/down direction
Pressing●buttons changes the setting to (in order) Swing ,
Position 0 ,
Position 1 ,
Position 2 ,
Position 3 , and
Position 4 .
Selecting●Swing will cause the air flow direction louver to oscillate back
and forth.
For the swing setting only, all positions will be displayed.
4
Setting
Air Flow Direction
Position 2
Left/right direction
Cool
Heat20°C
15°C
Setting
Position 2
Air Flow Direction
Up/down direction
When you select positions 0 to 4, the louver will stay in a fixed position.●
The illustration is an example of the display when position 2 is selected.*
Press●buttons to select the desired air flow direction.
Press Menu/OK button to return to the basic screen.
01_EN_3P215731-9N.indd 1901_EN_3P215731-9N.indd 19 11/8/2010 8:39:07 PM11/8/2010 8:39:07 PM
