Daikin VRV III User manual

COOLING ONLY
Cooling Only
50 Hz
ED 34 - 862
   
http://splitoff.ru/tehn-doc.html
, ,  , .

ED34-862
Table of Contents i
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1515
16
17
18
Introduction ........................................................................ ........................................ ii
Part 1 General Information ............................................... ................................ 1
Part 2 Indoor Units............................................................ ...................................... 45
Ceiling Mounted Cassette Type (Round Flow) ...................... ................47
Ceiling Mounted Cassette Type (Double Flow) ...................... ..............121
Ceiling Mounted Cassette Corner Type ................................. ..............143
Slim Ceiling Mounted Duct Type ............................................ ..............163
Ceiling Mounted Built-In Type ................................................ ..............201
Ceiling Mounted Duct Type (Middle and High Static Pressure) ... ..............243
Ceiling Mounted Duct Type ................................................... ..............295
Ceiling Suspended Type ........................................................ ..............315
Wall Mounted Type................................................................. ............. 331
Floor Standing Type / Concealed Floor Standing Type ......... ..............359
Ceiling Suspended Cassette Type (Connection Unit Series) ..... ..............381
Part 3 Outdoor Air Processing Unit ................................. .................................... 415
Outdoor Air Processing Unit ................................................... ..............417
Part 4 Outdoor Units; Normal Series (Space Saving Series) ................................ 451
Cooling Only (50Hz) ............................................................... ..............453
Part 5 Outdoor Units; High COP Series (Energy Saving Series) ........................... 533
Cooling Only (50Hz) ............................................................... ..............535
Part 6 Installation of Outdoor Units ................................. ............................ 581
Part 7 Control .................................................................... ............................ 643
Part 8 Guide Specification................................................ ............................ 841
1
FXFQ-P
2
FXCQ-M
3
FXKQ-MA
4
FXDQ-PB, NB
5
FXSQ-M
6
FXMQ-P
7
FXMQ-MA
8
FXHQ-MA
9
FXAQ-MA
10
FXLQ/FXNQ-MA
11
FXUQ-MA
12
FXMQ-MF
13
RXQ-PA
14
RXQ-PAH
15
16
17
18
    : http://splitoff.ru/tehn-doc.html

Introduction ED34-862
ii Introduction
1. Introduction
Preface
Along higher quality building environment and more sophisticated building function, there is now a greater demand
for system expansion for a flexible air-conditioning system capable of finer air-conditioning, thus increasing
importance of individual air-conditioning systems. On the other hand, due to social significance of environmental and
energy problems, elements such as energy-efficiency and low maintenance are still strongly desired.
Daikin is the sole air conditioning company in the world that manufactures every component from refrigerant to
complete air conditioning systems itself. Our commitment to offering the best for people as well as the environment
inspires us to develop new systems that make the most effective use of energy resources.
Daikin, the first in the industry to develop the VRV system, has now enhanced the R-410A, R-22 with the
Inverter that features an upgraded capacity of up to 54 horsepower to further refine all the features of the
current VRV system.
This publication contains a variety of information related to the design and installation of this new VRV System. We
hope this information will serve to deepen your understanding of the system, and will help you to efficiently develop
its highly evolved characteristics.
Global Operations Division
DAIKIN INDUSTRIES, LTD
    : http://splitoff.ru/tehn-doc.html

ED34-862 Publication History of VRV Engineering Data
Introduction iii
2. Publication History of VRV Engineering Data
Refrigerant Type Pub. : No. Outdoor Units Notes Published In
R-410A
Air
Cooled
INVERTER
M
ED39-436 50/60Hz H/P RXYMQ4, 5, 6M VRV II-S Heat Pump  New line up of 4, 5, 6HP outdoor units
New line up of FXDQ Indoor units Jul. 2004
ED39-526 50Hz H/R REYQ8M~48M
VRV II Heat Recovery
Separation of Heat Recovery Series
from ED39-226B Feb. 2006
ED35-511B 50/60Hz H/P RXYQ8~30MY1K(E)
RXYQ8~30MYLK(E)
VRV II Heat Pump for High outdoor
temperature.
Minor change of Indoor Units from
M to MA
Model change of Remote
Controller as follows
BRC1A61, 62 →BRC1C62
BRC8A61
Jul. 2006
INVERTER
MA ED39-428B 50/60Hz H/P
50Hz C/O RXYQ5MA~48MA RXQ5MA~48MA
VRV II Heat Pump, Cooling Only
New line up of 60Hz Heat Pump
outdoor units to ED39-428A Oct. 2005
INVERTER
P
ED34-762A 50Hz C/O
Normal Series
RXQ5P~54P
High COP Series
RXQ16PH~50PH
VRV III Cooling Only
Correction of errors Sep. 2007
ED34-845A 50/60Hz H/P
Normal Series
RXYQ5P(A)~54P(A)
High COP Series
RXYQ16P(A)H~50P(A)H
VRV III Heat Pump
Change of refrigerant amount
Refrigerant amount reduced to
less than 12 kg.
Oct. 2008
ED34-862 50Hz C/O
Normal Series
RXQ5PA~54PA
High COP Series
RXQ16PAH~50PAH
VRV III Cooling Only
Change of refrigerant amount
Refrigerant amount reduced to
less than 12 kg.
Nov. 2008
Water
Cooled
INVERTER
M
ED30-442B 50Hz H/P
50Hz H/R RWEYQ10, 20, 30M Y1
VRV-W II Heat Pump, Heat Recovery
Following change has been newly
added to ED30-442A
Minor change of Indoor Units from
M to MA
Model change of Remote
Controller as follows
BRC1A61, 62 →BRC1C62
BRC8A61
May. 2006
ED30-653A 60Hz H/P
60Hz H/R RWEYQ10, 20, 30M YL, TL
VRV-W II Heat Pump, Heat Recovery 60Hz
Correction of errors Jan. 2008
INVERTER
PED30-842 50/60Hz
H/P, H/R RWEYQ-P Y1, YL, TL
VRV-W III Heat Pump,
Heat Recovery Preliminary Oct. 2008
R-22 Air
Cooled
INVERTER
K-K ED35-211A 50/60Hz
50/60Hz RXY 16K-K~30K-K RX 16K-K~30K-K
Following change has been newly
added to ED35-211
FXD32~63M (Additional)
FXYB32~63K (Additional)
FXYA40~63K→FXA32~63L
(Model Change)
DCS302B61→DCS302C61
(Model Change)
Sep. 2004
INVERTER
M
ED38-225C 50/60Hz H/P
50Hz C/O RXY5M~48M RX5M~48M
VRV II Heat Pump, Cooling Only
Following change has been newly
added to ED38-225B
FXD20~32P (Additional)
Model change of Remote
Controller as follows
BRC1A61, 62 →BRC1C62
BRC8A61
 VAM150~2000FA → VAM150~2000GJ
(Model change)
Jun. 2006
ED38-329 50/60Hz H/P
50Hz C/O RXYM4, 5, 6M RXM4, 5, 6M
VRV II-S Heat Pump, Cooling Only
 New line up of 4, 5, 6HP outdoor units
New line up of FXD Indoor units Jan. 2004
INVERTER
MA ED38-825 50/60Hz H/P
50Hz C/O RXY5MA~48MA
RX5MA~48MA
VRV II Heat Pump, Cooling Only
Minor change of outdoor units from
M to MA.
Addition of DCS303A61
Oct. 2008
For All Types OH 08-1 For Indoor and Outdoor Units. Option Handbook Apr. 2008
HRV(VAM) GJ ED71-613 50/60Hz VAM150~2000GJ HRV
New line-up from FA to GJ Series Feb. 2006
HRV(VKM) GA(M) ED71-440A 50Hz VKM50~100GA(M)
(R-410A)
HRV
• With DX Coil (VKM-GA)
•
With DX Coil and Humidities (VKM-GAM)
Feb. 2007
This time we publish ED34-862 as shown by .
H/P : Heat Pump
H/R : Heat Recovery
C/O : Cooling Only
Note: The reference number “(V{{{{)” are noted on each figures in this book however they are only used for printing convenience.
    : http://splitoff.ru/tehn-doc.html

Step by Step VRV System Selection Process (Reference) ED34-862
iv Introduction
3. Step by Step VRV System Selection Process (Reference)
Caution
1. Air conditioners should not be installed in areas where corrosive gases, such as acid gas or alkaline gas, are
produced.
2. If the outdoor units is to be installed close to the sea shore, direct exposure to the sea breeze should be avoided.
3. Refer to the latest drawing numbers.
(1)
Obtain the maximum heat load for the area(s) to be conditioned.
(2)
Indoor unit specifications
Outdoor unit specifications
Capacity correction factor
Air velocity and temperature distributions
P.49, 124, 145, 165, 205, 245,
297, 317, 333, 361, 363, 383, 420
P.454~, 536~
P.516~, 568~
P.393
(3)
Selection of refrigerant pipes joints & headers P.592~
(4)
Selection of the control system
Control wiring method
Description of devices
P.646~
P.645, 652~
(5)
Electrical wiring
Electric characteristics
Field wiring
P.56, 133, 150, 176, 218, 255,
301, 323, 340, 373, 391, 432,
487~, 549~
P.484
    : http://splitoff.ru/tehn-doc.html

ED34-862
General Information 1
1
Part 1
General Information
1. Model Names of Indoor/Outdoor Units....................................................2
2. External Appearance...............................................................................4
2.1 Indoor Units ..............................................................................................4
2.2 Outdoor Units ...........................................................................................5
3. Combination of Outdoor Units.................................................................7
4. Nomenclature..........................................................................................9
5. Capacity Range.....................................................................................11
6. Features ................................................................................................13
6.1 Technologies ..........................................................................................13
6.2 Flexible Design.......................................................................................15
6.3 A sense of responsibility.........................................................................18
6.4 Enhanced Comfort .................................................................................19
6.5 Control Systems .....................................................................................20
6.6 Advanced Control Systems ....................................................................22
6.7 HRV (Heat Reclaim Ventilation) .............................................................26
6.8 HRV-With DX Coil-(Heat Reclaim Ventilation) VKM-GA(M) Series .......34
    : http://splitoff.ru/tehn-doc.html

Model Names of Indoor/Outdoor Units ED34-862
2 General Information
1. Model Names of Indoor/Outdoor Units
Indoor Units
Note: FXDQ has following 2 series, as shown below.
FXDQ-PBVET, NBVET: without Drain Pump (For General, Asia: except for EU, China and Australia)
FXDQ-PBVE, NBVE: with Drain Pump
BEV unit is required for FXUQ only.
MA:
RoHS Directive models; Specifications, dimensions and other functions are not changed compared with M type.
Outdoor Units
Normal Series (Space Saving Series)
High COP Series (Energy Saving Series)
Type Model Name Power Supply
Ceiling Mounted
Cassette Type
(Round Flow) FXFQ — 25P 32P 40P 50P 63P — 80P
100P 125P ——
VE
Ceiling Mounted
Cassette Type
(Double Flow) FXCQ 20M 25M 32M 40M 50M 63M — 80M —
125M ——
Ceiling Mounted
Cassette Corner
Type FXKQ —
25MA 32MA 40MA — 63MA ——————
Slim Ceiling Mounted
Duct Type
FXDQ-
PBVE
20PB 25PB 32PB —————————
FXDQ-
PBVET
20PB 25PB 32PB —————————
FXDQ-
NBVE ———
40NB 50NB 63NB ——————
FXDQ-
NBVET ———
40NB 50NB 63NB ——————
Ceiling Mounted
Built-In Type FXSQ 20M 25M 32M 40M 50M 63M — 80M
100M 125M ——
Ceiling Mounted Duct
Type (Middle and
high static pressure) FXMQ 20P 25P 32P 40P 50P 63P — 80P
100P 125P ——
Ceiling Mounted
Duct Type FXMQ ——————————
200MA 250MA
Ceiling Suspended
Type FXHQ — —
32MA —— 63MA —— 100MA ———
Wall Mounted Type FXAQ
20MA 25MA 32MA 40MA 50MA 63MA ——————
Floor Standing Type FXLQ
20MA 25MA 32MA 40MA 50MA 63MA ——————
Concealed Floor
Standing Type FXNQ
20MA 25MA 32MA 40MA 50MA 63MA ——————
Ceiling Suspended
Cassette Type FXUQ ——————
71MA — 100MA 125MA —— V1
Connection Unit for
FXUQ BEVQ ——————
71MA — 100MA 125MA —— VE
Series Model Name Power Supply
Cooling Only RXQ
5PA 8PA 10PA 12PA 14PA 16PA 18PA 20PA 22PA
Y124PA 26PA 28PA 30PA 32PA 34PA 36PA 38PA 40PA
42PA 44PA 46PA 48PA 50PA 52PA 54PA
Series Model Name Power Supply
Cooling Only RXQ
16PAH 18PAH 24PAH 26PAH 28PAH 30PAH 32PAH 34PAH 36PAH
Y1
38PAH 40PAH 42PAH 44PAH 46PAH 48PAH 50PAH
VE: 1φ, 220~240V, 50Hz
1φ, 220V, 60Hz V1: 1φ, 220~240V, 50Hz Y1: 3φ, 380~415V, 50Hz
    : http://splitoff.ru/tehn-doc.html

ED34-862 Model Names of Indoor/Outdoor Units
General Information 3
1
Combination of Outdoor Units (Normal Series (Space Saving Series))
Combination of Outdoor Units (High COP Series (Energy Saving Series))
HP 5HP 8HP 10HP 12HP 14HP 16HP 18HP
Model name RXQ5PA RXQ8PA RXQ10PA RXQ12PA RXQ14PA RXQ16PA RXQ18PA
HP 20HP 22HP 24HP 26HP 28HP 30HP 32HP
Model name RXQ20PA RXQ22PA RXQ24PA RXQ26PA RXQ28PA RXQ30PA RXQ32PA
Outdoor unit 1 RXQ8PA RXQ10PA RXQ8PA RXQ8PA RXQ10PA RXQ12PA RXQ16PA
Outdoor unit 2 RXQ12PA RXQ12PA RXQ16PA RXQ18PA RXQ18PA RXQ18PA RXQ16PA
Outdoor unit 3 – – – – – – –
HP 34HP 36HP 38HP 40HP 42HP 44HP 46HP
Model name RXQ34PA RXQ36PA RXQ38PA RXQ40PA RXQ42PA RXQ44PA RXQ46PA
Outdoor unit 1 RXQ16PA RXQ18PA RXQ8PA RXQ8PA RXQ8PA RXQ8PA RXQ10PA
Outdoor unit 2 RXQ18PA RXQ18PA RXQ12PA RXQ16PA RXQ16PA RXQ18PA RXQ18PA
Outdoor unit 3 – – RXQ18PA RXQ16PA RXQ18PA RXQ18PA RXQ18PA
HP 48HP 50HP 52HP 54HP
Model name RXQ48PA RXQ50PA RXQ52PA RXQ54PA
Outdoor unit 1 RXQ12PA RXQ14PA RXQ16PA RXQ18PA
Outdoor unit 2 RXQ18PA RXQ18PA RXQ18PA RXQ18PA
Outdoor unit 3 RXQ18PA RXQ18PA RXQ18PA RXQ18PA
HP 16HP 18HP 24HP 26HP 28HP 30HP 32HP
Model name RXQ16PAH RXQ18PAH RXQ24PAH RXQ26PAH RXQ28PAH RXQ30PAH RXQ32PAH
Outdoor unit 1 RXQ8PA RXQ8PA RXQ8PA RXQ8PA RXQ8PA RXQ8PA RXQ8PA
Outdoor unit 2 RXQ8PA RXQ10PA RXQ8PA RXQ8PA RXQ8PA RXQ10PA RXQ12PA
Outdoor unit 3 – – RXQ8PA RXQ10PA RXQ12PA RXQ12PA RXQ12PA
HP 34HP 36HP 38HP 40HP 42HP 44HP 46HP
Model name RXQ34PAH RXQ36PAH RXQ38PAH RXQ40PAH RXQ42PAH RXQ44PAH RXQ46PAH
Outdoor unit 1 RXQ10PA RXQ12PA RXQ12PA RXQ12PA RXQ12PA RXQ12PA RXQ12PA
Outdoor unit 2 RXQ12PA RXQ12PA RXQ12PA RXQ12PA RXQ12PA RXQ16PA RXQ16PA
Outdoor unit 3 RXQ12PA RXQ12PA RXQ14PA RXQ16PA RXQ18PA RXQ16PA RXQ18PA
HP 48HP 50HP
Model name RXQ48PAH RXQ50PAH
Outdoor unit 1 RXQ16PA RXQ16PA
Outdoor unit 2 RXQ16PA RXQ16PA
Outdoor unit 3 RXQ16PA RXQ18PA
    : http://splitoff.ru/tehn-doc.html

External Appearance ED34-862
4 General Information
2. External Appearance
2.1 Indoor Units
Ceiling Mounted Cassette Type (Round Flow)
FXFQ25P
FXFQ32P
FXFQ40P
FXFQ50P
FXFQ63P
FXFQ80P
FXFQ100P
FXFQ125P
Ceiling Mounted Duct Type
FXMQ200MA
FXMQ250MA
Ceiling Mounted Cassette Type (Double Flow)
FXCQ20M
FXCQ25M
FXCQ32M
FXCQ40M
FXCQ50M
FXCQ63M
FXCQ80M
FXCQ125M
Ceiling Suspended Type
FXHQ32MA
FXHQ63MA
FXHQ100MA
Ceiling Mounted Cassette Corner Type
FXKQ25MA
FXKQ32MA
FXKQ40MA
FXKQ63MA
Wall Mounted Type
FXAQ20MA
FXAQ25MA
FXAQ32MA
FXAQ40MA
FXAQ50MA
FXAQ63MA
Slim Ceiling Mounted Duct Type
FXDQ20PB FXDQ40NB
FXDQ25PB FXDQ50NB
FXDQ32PB FXDQ63NB
with Drain Pump (VE)
without Drain Pump (VET)
Floor Standing Type
FXLQ20MA
FXLQ25MA
FXLQ32MA
FXLQ40MA
FXLQ50MA
FXLQ63MA
Ceiling Mounted Built-In Type
FXSQ20M
FXSQ25M
FXSQ32M
FXSQ40M
FXSQ50M
FXSQ63M
FXSQ80M
FXSQ100M
FXSQ125M
Concealed Floor Standing Type
FXNQ20MA
FXNQ25MA
FXNQ32MA
FXNQ40MA
FXNQ50MA
FXNQ63MA
Ceiling Mounted Duct Type (Middle and high static
pressure)
FXMQ20P
FXMQ25P
FXMQ32P
FXMQ40P
FXMQ50P
FXMQ63P
FXMQ80P
FXMQ100P
FXMQ125P
Ceiling Suspended Cassette Type
FXUQ71MA +
FXUQ100MA +
FXUQ125MA +
Connection Unit
BEVQ71MA
BEVQ100MA
BEVQ125MA
    : http://splitoff.ru/tehn-doc.html

ED34-862 External Appearance
General Information 5
1
2.2 Outdoor Units
Normal Series (Space Saving Series)
RXQ5PA RXQ8PA, 10PA
RXQ20PA, 22PA, 24PA, 26PA, 28PA RXQ30PA, 32PA, 34PA, 36PA
RXQ38PA, 40PA, 42PA, 44PA, 46PA RXQ48PA, 50PA, 52PA, 54PA
RXQ12PA, 14PA, 16PA, 18PA
5HP 8, 10HP 12, 14, 16, 18HP
20, 22, 24, 26, 28HP
38, 40, 42, 44, 46HP
30, 32, 34, 36HP
48, 50, 52, 54HP
    : http://splitoff.ru/tehn-doc.html

External Appearance ED34-862
6 General Information
High COP Series (Energy Saving Series)
RXQ16PAH, 18PAH RXQ24PAH, 26PAH
RXQ28PAH, 30PAH
16, 18HP 24, 26HP
28, 30HP
RXQ32PAH, 34PAH
RXQ36PAH, 38PAH, 40PAH, 42PAH, 44PAH, 46PAH, 48PAH, 50PAH
32, 34HP
36, 38, 40, 42, 44, 46, 48, 50HP
    : http://splitoff.ru/tehn-doc.html

ED34-862 Combination of Outdoor Units
General Information 7
1
3. Combination of Outdoor Units
Normal Series (Space Saving Series)
★Note: For multiple connection of 20HP system or more, an optional Daikin Outdoor Unit Multi Connection Piping Kit is
required.
System
Capacity
Number
of units
Module Outdoor Unit Multi Connection
Piping Kit (Option)
5 8 10 12 14 16 18
5HP 1 ●
—
8HP 1 ●
10HP 1 ●
12HP 1 ●
14HP 1 ●
16HP 1 ●
18HP 1 ●
20HP 2 ●●
BHFP22P100
22HP 2 ●●
24HP 2 ●●
26HP 2 ●●
28HP 2 ●●
30HP 2 ●●
32HP 2 ●●
34HP 2 ●●
36HP 2 ●●
38HP 3 ●● ●
BHFP22P151
40HP 3 ●●●
42HP 3 ●●●
44HP 3 ●●●
46HP 3 ●●●
48HP 3 ●●●
50HP 3 ●●●
52HP 3 ●●●
54HP 3 ●●●
    : http://splitoff.ru/tehn-doc.html

Combination of Outdoor Units ED34-862
8 General Information
High COP Series (Energy Saving Series)
★Note: For multiple connection of 16HP system or more, an optional Daikin Outdoor Unit Multi Connection Piping Kit is
required.
System
Capacity
Number
of units
Module Outdoor Unit Multi Connection
Piping Kit (Option)
8 10 12 14 16 18
16HP 2 ●● BHFP22P100
18HP 2 ●●
24HP 3 ●●●
BHFP22P151
26HP 3 ●● ●
28HP 3 ●● ●
30HP 3 ●●●
32HP 3 ●●●
34HP 3 ●●●
36HP 3 ●●●
38HP 3 ●● ●
40HP 3 ●● ●
42HP 3 ●● ●
44HP 3 ●●●
46HP 3 ●●●
48HP 3 ●●●
50HP 3 ●● ●
    : http://splitoff.ru/tehn-doc.html

ED34-862 Nomenclature
General Information 9
1
4. Nomenclature
Indoor Unit
Power Supply Symbol
VE : Single Phase 220 to 240V, 50Hz : 220V, 60Hz
V1 : Single Phase 220 to 240V, 50Hz
Indicates Major Design Category
M : Standard
MA : Standard (RoHS Applied Models)
NB, PB : Standard
Capacity Indication
Conversion to Horsepower:
20 : 0.8 HP 50 : 2.0 HP 100 : 4 HP
25 : 1 HP 63 : 2.5 HP 125 : 5 HP
32 : 1.25 HP 71 : 3 HP 200 : 8 HP
40 : 1.6 HP 80 : 3.2 HP 250 : 10 HP
Refrigerant : R-410A
Type of Unit
F : Ceiling Mounted Cassette Type (Round Flow)
C : Ceiling Mounted Cassette Type (Double Flow)
K : Ceiling Mounted Cassette Corner Type
D : Slim Ceiling Mounted Duct Type
S : Ceiling Mounted Built-In Type
M : Ceiling Mounted Duct Type
H : Ceiling Suspended Type
A : Wall Mounted Type
L : Floor Standing Type
N : Concealed Floor Standing Type
U : Ceiling Suspended Cassette Type
Indicates that this is VRV system indoor unit.
C 40 VE MQ
FX
    : http://splitoff.ru/tehn-doc.html

Nomenclature ED34-862
10 General Information
Connection Unit
Outdoor Unit
Power Supply Symbol
VE : Single Phase 220 to 240V, 50Hz : 220V, 60Hz
Indicates Major Design Category
MA : Standard (RoHS Applied Models)
Capacity Indication
Conversion to Horsepower:
71 : 3HP
100 : 4HP
125 : 5HP
Refrigerant : R-410A
Indicates that this is a Connection Unit
BEV MA VEQ 71
Y1
54Q
RX PA
Power Supply Symbol
Y1 : 3 phase 380 to 415V, 50Hz
Indicates Major Design Category
PA
: Normal Series (Space Saving Series)
PAH : High COP Series (Energy Saving Series)
5 : 5HP 14 : 14 HP 22 : 22 HP 30 : 30 HP 40 : 40 HP 48 : 48 HP
8 : 8 HP 16 : 16 HP 24 : 24 HP 32 : 32 HP 42 : 42 HP 50 : 50 HP
10 : 10 HP 18 : 18 HP 26 : 26 HP 34 : 34 HP 44 : 44 HP 52 : 52 HP
12 : 12 HP 20 : 20 HP 28 : 28 HP 36 : 36 HP 46 : 46 HP 54 : 54 HP
38 : 38 HP
Refrigerant: R-410A
Indicates that this is a function of Air Conditioner
RX : Cooling Only
    : http://splitoff.ru/tehn-doc.html

ED34-862 Capacity Range
General Information 11
1
5. Capacity Range
Outdoor Units
Maximum number of
connectable indoor units*
Total capacity index of
connectable indoor units*
HP Combination
62.5 to 162.5 (250)
100 to 260 (400)
125 to 325 (500)
150 to 390 (600)
175 to 455 (700)
200 to 520 (800)
225 to 585 (900)
250 to 650 (800)
275 to 715 (880)
300 to 780 (960)
325 to 845 (1,040)
350 to 910 (1,120)
375 to 975 (1,200)
400 to 1,040 (1,280)
425 to 1,105 (1,360)
450 to 1,170 (1,440)
475 to 1,235 (1,235)
500 to 1,300 (1,300)
525 to 1,365 (1,365)
550 to 1,430 (1,430)
575 to 1,495 (1,495)
600 to 1,560 (1,560)
Model name
5 HP
8 HP
10 HP
12 HP
14 HP
16 HP
18 HP
20 HP
22 HP
24 HP
26 HP
28 HP
30 HP
32 HP
34 HP
36 HP
38 HP
40 HP
42 HP
44 HP
46 HP
48 HP
8 (12)
13 (20)
16 (25)
19 (30)
22 (35)
26 (40)
29 (45)
32 (40)
35 (44)
39 (48)
42 (52)
45 (56)
48 (60)
52 (64)
55 (64)
58 (64)
61 (61)
64 (64)
Normal Type (Space Saving Type)
Outdoor unit multi
connection piping kit
–
–
–
–
–
–
–
BHFP22P100
BHFP22P151
625 to 1,625 (1,625)
650 to 1,690 (1,690)
675 to 1,755 (1,755)
50 HP
52 HP
54 HP
Maximum number of
connectable indoor units*
Total capacity index of
connectable indoor units*
HP Combination
200 to 520 (640)
Model name
16 HP 26 (32)
High-COP Type (Energy Saving Type)
Outdoor unit multi
connection piping kit
BHFP22P100 225 to 585 (720)18 HP 29 (36)
300 to 780 (780)24 HP 39 (39)
325 to 845 (845)26 HP 42 (42)
350 to 910 (910)28 HP 45 (45)
375 to 975 (975)30 HP 48 (48)
52 (52)
55 (55)
58 (58)
400 to 1,040 (1,040)32 HP
425 to 1,105 (1,105)34 HP
BHFP22P151 450 to 1,170 (1,170)36 HP
475 to 1,235 (1,235)38 HP 61 (61)
500 to 1,300 (1,300)40 HP
64 (64)
525 to 1,365 (1,365)42 HP
550 to 1,430 (1,430)44 HP
575 to 1,495 (1,495)46 HP
600 to 1,560 (1,560)48 HP
625 to 1,625 (1,625)50 HP
Note: • For multiple connection of 20 HP systems and above, the above Daikin optional kit (separately sold) is required.
*Values inside brackets are based on connection of indoor units rated at maximum capacity, 200% for single outdoor units, 160% for double
outdoor units, and 130% for triple outdoor units. Refer to page 15 for notes on connection capacity of indoor units.
Note:
• For multiple connection of 16 HP systems and above, the above Daikin optional kit (separately sold) is required.
*Values inside brackets are based on connection of indoor units rated at maximum capacity, 200% for single outdoor units, 160% for double
outdoor units, and 130% for triple outdoor units. Refer to page 15 for notes on connection capacity of indoor units.
RXQ16PAH
RXQ18PAH
RXQ24PAH
RXQ26PAH
RXQ28PAH
RXQ30PAH
RXQ32PAH
RXQ34PAH
RXQ36PAH
RXQ38PAH
RXQ40PAH
RXQ42PAH
RXQ44PAH
RXQ46PAH
RXQ48PAH
RXQ50PAH
RXQ5PA
RXQ8PA
RXQ10PA
RXQ12PA
RXQ14PA
RXQ16PA
RXQ18PA
RXQ8PA + RXQ12PA
RXQ10PA + RXQ12PA
RXQ8PA + RXQ16PA
RXQ8PA + RXQ18PA
RXQ10PA + RXQ18PA
RXQ12PA + RXQ18PA
RXQ16PA x 2
RXQ16PA + RXQ18PA
RXQ18PA x 2
RXQ8PA + RXQ12PA + RXQ18PA
RXQ8PA + RXQ16PA x 2
RXQ8PA + RXQ16PA + RXQ18PA
RXQ8PA + RXQ18PA x 2
RXQ10PA + RXQ18PA x 2
RXQ12PA + RXQ18PA x 2
RXQ5PA
RXQ8PA
RXQ10PA
RXQ12PA
RXQ14PA
RXQ16PA
RXQ18PA
RXQ20PA
RXQ22PA
RXQ24PA
RXQ26PA
RXQ28PA
RXQ30PA
RXQ32PA
RXQ34PA
RXQ36PA
RXQ38PA
RXQ40PA
RXQ42PA
RXQ44PA
RXQ46PA
RXQ48PA
RXQ14PA + RXQ18PA x 2
RXQ16PA + RXQ18PA x 2
RXQ18PA x 3
RXQ50PA
RXQ52PA
RXQ54PA
RXQ8PA x 2
RXQ8PA + RXQ10PA
RXQ8PA x 3
RXQ8PA x 2 + RXQ10PA
RXQ8PA x 2 + RXQ12PA
RXQ8PA + RXQ10PA + RXQ12PA
RXQ8PA + RXQ12PA x 2
RXQ10PA + RXQ12PA x 2
RXQ12PA x 3
RXQ12PA x 2 + RXQ14PA
RXQ12PA x 2 + RXQ16PA
RXQ12PA x 2 + RXQ18PA
RXQ12PA + RXQ16PA x 2
RXQ12PA + RXQ16PA + RXQ18PA
RXQ16PA x 3
RXQ16PA x 2 + RXQ18PA
    : http://splitoff.ru/tehn-doc.html

Capacity Range ED34-862
12 General Information
Indoor Units
Note: FXDQ has following 2 series, as shown below.
FXDQ-PBVET, NBVET: without Drain Pump (For General, Asia: except for EU, China and Australia)
FXDQ-PBVE, NBVE: with Drain Pump
BEV unit is required for FXUQ only.
MA:
RoHS Directive models; Specifications, dimensions and other functions are not changed compared with M type.
Type Model Name Power Supply
Ceiling Mounted
Cassette Type
(Round Flow) FXFQ — 25P 32P 40P 50P 63P — 80P
100P 125P ——
VE
Ceiling Mounted
Cassette Type
(Double Flow) FXCQ 20M 25M 32M 40M 50M 63M — 80M —
125M ——
Ceiling Mounted
Cassette Corner
Type FXKQ —
25MA 32MA 40MA — 63MA ——————
Slim Ceiling Mounted
Duct Type
FXDQ-
PBVE
20PB 25PB 32PB —————————
FXDQ-
PBVET
20PB 25PB 32PB —————————
FXDQ-
NBVE ———
40NB 50NB 63NB ——————
FXDQ-
NBVET ———
40NB 50NB 63NB ——————
Ceiling Mounted
Built-In Type FXSQ 20M 25M 32M 40M 50M 63M — 80M
100M 125M ——
Ceiling Mounted Duct
Type (Middle and
high static pressure) FXMQ 20P 25P 32P 40P 50P 63P — 80P
100P 125P ——
Ceiling Mounted
Duct Type FXMQ ——————————
200MA 250MA
Ceiling Suspended
Type FXHQ — —
32MA —— 63MA —— 100MA ———
Wall Mounted Type FXAQ
20MA 25MA 32MA 40MA 50MA 63MA ——————
Floor Standing Type FXLQ
20MA 25MA 32MA 40MA 50MA 63MA ——————
Concealed Floor
Standing Type FXNQ
20MA 25MA 32MA 40MA 50MA 63MA ——————
Ceiling Suspended
Cassette Type FXUQ ——————
71MA — 100MA 125MA —— V1
Connection Unit for
FXUQ BEVQ ——————
71MA — 100MA 125MA —— VE
    : http://splitoff.ru/tehn-doc.html

ED34-862 Features
General Information 13
1
6. Features
6.1 Technologies
Daikin’s constant efforts have been devoted towards using the latest and most revolutionary technologies in the
development of the VRVIII system for large-sized buildings. The system offers larger outdoor capacities, greater energy
savings, easier installation, longer actual and total piping, and more.
VRVIII —Created to respond to the needs
of large-sized buildings
The new heat exchanger contributes to a high COP
because of an increase from 7% to 10% of the effective
length as well as an optimised e-Pass heat exchanger.
1
26
5
3
4
7
2
A higher external static pressure has been achieved—from 58. 8 Pa to 78.4 Pa—thanks to
reduced internal pressure loss, use of the new fans and the new grilles.
The area of these new fan blades has been increased and optimised for each casing. This greatly reduces pressure loss, resulting in a
higher external static pressure.
The three-bladed fan on the 10 HP unit, with a diameter of
700 mm, has been redesigned to include four blades and now
has a diameter of 680 mm. Blade area has been increased by
25%.
1
Newly improved fans and grilles
Heat exchanger
New aero spiral fan and aero asymmetrical fan
Aero smooth grille
New aero asymmetrical fan
In the 14 and 16 HP unit, a single fan with a diameter of 700 mm
has been split into two fans with diameters of 540 mm each.
Blade area has been increased by 20% to increase airflow.
New aero spiral fan (Powerful Dual DC fan)
VRVII
The three-dimensional, integrated, soft woven steel grilles are
covered with a plastic coating that protects them from rotating
elements and the possibility of fire
damage.
Blade area
increased by
25%!
VRVII
Blade area
increased by
20%!
Diameter of 700 mmDiameter of 680 mmDiameter of 700 mm Diameter of 540 mm x 2
Perspective view
    : http://splitoff.ru/tehn-doc.html

Features ED34-862
14 General Information
3
7
DC fan motor
4
Heat transfer circuit
By performing super cooling before the expansion
process, the volume of refrigerant that needs to be
circulated to the indoor units can be reduced without
lowering the evaporation temperature. This permits the
use of narrower piping.
5
Compact aero box
Realises a compact casing by stacking the Inverter and
control PCBs plus optimising the internal design to suit
airflow speed. This achieves lower noise and reduces the
power required by the large-diameter fanned outdoor unit.
• Across entire range of models (from 5 to 54 HP).
• Efficiency improvement by approximately 40% especially
at low speed.
6
Smooth sine wave DC Inverter
By adoption of the Sine
Wave, which smoothes the
rotation of the motor,
operation efficiency is
improved sharply.
DC fan motor
structure
200 300 400 500 600 700 800 900 1000
0
20
40
80
60
100
Efficiency (%)
Motor speed ( rpm )
AC motor
AC motor
AC motor
AC motor
AC motor
DC motor efficiency
( comparison with a conventional AC motor )
Ferrite magnet
Secret to raising energy-efficiency!
Powerful magnets
Secret to raising energy-efficiency!
Powerful magnets
Neodymium magnets are much more
powerful than the widely used ferrite magnets.
Neodymium magnet
Reluctance
DC motor
Improving the high efficiency compressor to achieve
a high COP and larger capacity
Reluctance DC scroll compressor
High torque and efficiency is attained with the adoption of
neodymium magnets. Achieves 70% reduction in volume.
Daikin’s unique scroll compressor minimises heat loss, and is driven by a high
efficiency motor to achieve significant energy savings.
By introducing high pressure oil, the reactive
force from the fixed scroll is added to the internal
force, thereby reducing thrust losses. This
results in improved efficiency and suppressed
sound levels.
High-performance, low-noise new scroll
compressor operates at a faster rate.
The speed increase has been achieved
through advanced stress analysis for
increased strength and utilisation of the
advantages (oil film control) of the high
thrust mechanism*.
*High thrust mechanism
Note: Data are based on studies conducted under controlled conditions
at a Daikin laboratory.
Approx.
Approx.
40%
increase
increase
Approx.
40%
increase
DC motor
DC motor
DC motor
DC motor
DC motor
    : http://splitoff.ru/tehn-doc.html

ED34-862 Features
General Information 15
1
6.2 Flexible Design
Large capacities for large-sized buildings
Conditions of indoor unit connection capacity
The number of connectable indoor units has been drastically increased from 40 to 64!
An increased number of connectable indoor units
Connection capacity at maximum is 200%.
Combination ratio
40 64
Increased indoor unit connections
indoor
units
VRVII
MA series
indoor
units
Refer to page 11 for the maximum number of connectable indoor units.
Maximum number of connectable indoor units
Up to
Up to
Note:
* For the FXFQ25 models, maximum connection ratio is 130% for the entire range of outdoor units.
• If the operational capacity of indoor units is more than 130%, low airflow operation is
enforced in all the indoor units.
50%–200%
Connection capacity
Single outdoor units
Double outdoor units
Triple outdoor units
FXDQ, FXSQ, FXAQ models
Applicable indoor units Other indoor
unit models*
200%
200%
160%
130%
    : http://splitoff.ru/tehn-doc.html
