Daikin BRC1E61 User manual

Thank you for purchasing the wired remote controller.●
This manual describes safety precautions required for the use of the●
product.
Read this manual carefully and be sure you understand the
information provided before attempting to use the product.
Keep this manual where it is readily accessible after reading it through.
If another user operates the product in the future, be sure to hand over
this manual the new user.
Proper Use for Effective Energy Saving
MODEL BRC1E61
WIRED REMOTE
CONTROLLER
OPERATION MANUAL
00_CV_3P243520-1B.indd 100_CV_3P243520-1B.indd 1 5/15/2009 10:15:43 AM5/15/2009 10:15:43 AM

English 1
Notices Safety Precautions Items to be Strictly Observed .........
2
Names and Functions ............................................... 8
Simple Settings in Direct Buttons for
Basic Operation Items
Basic Operation Method
(Use of Direct Buttons)
Cool/Heat/Auto/Fan Operation .............................. 14
Program Dry Operation .......................................... 17
Home Leave ........................................................... 19
Ventilation Operation .............................................. 20
Setting Method of the Cooling/Heating Selection
Eligibility ................................................................. 21
Key Lock ............................................................... 23
Ease of Cellular-like Function Settings
Quick Reference of
Main Menu Items Main Menu Items ...................................................
24
Menu Manipulation Manipulating the Main Menu Screen .....................
26
Set temp mode changeover ................................... 27
Airflow Direction Setting ......................................... 28
Quick Cooling/Heating On/Off ................................ 31
Ventilation .............................................................. 32
Timer Settings ........................................................ 34
Service Contact/Model Information ........................ 44
Convenient Functions ............................................ 45
Setting Status List .................................................. 48
Clock Setting .......................................................... 48
Language changeover ........................................... 50
Maintenance Filter Sign Resetting ...............................................
51
Maintenance of Unit and LCD ................................ 52
Useful Information Error code Display .................................................
53
After-sale Service ................................................... 54
Contents
01_EN_3P243520-1B.indd 101_EN_3P243520-1B.indd 1 5/15/2009 10:20:58 AM5/15/2009 10:20:58 AM

2 English
Safety Precautions
Read the safety precautions attentively for the correct use of the product.
The precautions described herein are classified as WARNING and CAUTION.●
They both contain important information regarding safety. Be sure to observe all precautions
without fail.
WARNING Failure to follow these instructions properly may result in personal
injury or loss of life.
CAUTION
Failure to observe these instructions properly may result in property
damage or personal injury, which may be serious depending on the
circumstances.
The following pictograms are used in this manual.●
Never do. Always follow the instructions given.
Be sure to ground the unit. Absolutely keep wet hands away.
Absolutely keep water and moisture
away.
About Remote Controller
WARNING
Do not install the remote controller by yourself.●
Improper installation may result in electric shocks or fire.
Consult your Daikin dealer.
Do not modify or repair the remote controller.●
This may result in electric shocks or fire.
Consult your Daikin dealer.
Do not relocate or reinstall the remote controller by yourself.●
Improper installation may result in electric shocks or fire.
Consult your Daikin dealer.
Do not use flammable materials (e.g., hairspray or insecticide) near the●
product.
Do not clean the product with organic solvents such as paint thinner.
The use of organic solvents may cause crack damage to the product, electric shocks, or
fire.
01_EN_3P243520-1B.indd 201_EN_3P243520-1B.indd 2 5/15/2009 10:20:58 AM5/15/2009 10:20:58 AM

English 3
―― Items to be Strictly Observed――
CAUTION
Do not play with the unit or its remote controller.●
Accidental operation by a child may result in impairment of bodily functions and harm
health.
Never disassemble the remote controller.●
Touching the interior parts may result in electric shocks or fire.
Consult your Daikin dealer or authorized contractor for internal inspections and
adjustments.
To avoid electric shocks, do not operate with wet hands.●
Do not wash the remote controller.●
Doing so may cause electric leakage and result in electric shocks or fire.
Do not leave the remote controller wherever there is a risk of wetting.●
If water gets into the remote controller there is a risk of electrical leakage and damage to
electronic components.
Indoor Unit and Outdoor Unit
WARNING
Be aware that prolonged, direct exposure to cool or warm air from the air●
conditioner, or to air that is too cool or too warm can be harmful to your
physical condition and health.
Do not place objects, including rods, your fingers, etc., in the air inlet or●
outlet.
Injury may result due to contact with the air conditioner’s highspeed fan blades.
Contact professional personnel about attachment of accessories and be●
sure to use only accessories specified by the manufacturer.
If a defect results from your own workmanship, it may result in water leaks, electric
shock or fire.
Do not use the product in the atmosphere contaminated with oil vapor,●
such as cooking oil or machine oil vapor.
Oil vapor may cause crack damage, electric shocks, or fire.
Do not use the product in places with excessive oily smoke, such as●
cooking rooms, or in places with flammable gas, corrosive gas, or metal
dust.
Using the product in such places may cause fire or product failures.
01_EN_3P243520-1B.indd 301_EN_3P243520-1B.indd 3 5/15/2009 10:20:58 AM5/15/2009 10:20:58 AM

4 English
WARNING
Beware of fire in case of refrigerant leakage.●
If the air conditioner is not operating correctly, i.e. not generating cool or warm air,
refrigerant leakage could be the cause. Consult your dealer for assistance. The
refrigerant within the air conditioner is safe and normally does not leak.
However, in the
event of a leakage, contact with a naked burner, heater or cooker may result in generation
of noxious gas. Do not longer use the air conditioner until a qualified service person
confirms that the leakage has been repaired.
In the case of using a load breaker provided with a fuse, make sure that●
the capacity of the fuse is correct.
Use of an ordinary conductive wire may cause malfunctions or fire.
Do not start or stop operating the air conditioner with the power supply●
breaker turned ON or OFF.
Otherwise, fire or water leakage may result.
Furthermore, the fan will rotate abruptly if power failure compensation is enabled, which
may result in injury.
Be sure to earth the unit.●
Do not earth the unit to a utility pipe, lightning conductor or telephone earth lead. Imperfect
earthing may result in electric shocks or fire. A high surge current from lightning or other
sources may cause damage to the air conditioner.
When the air conditioner is malfunctioning (giving off a burning odour, etc.) ●
turn off power to the unit and contact your local dealer.
Continued operation under such circumstances may result in a failure, electric shocks or
fire hazards.
Consult your local dealer regarding what to do in case of refrigerant●
leakage.
When the air conditioner is to be installed in a small room, it is necessary to take proper
measures so that the amount of any leaked refrigerant does not exceed the
concentration limit in the event of a leakage.
Otherwise, this may lead to an accident due to oxygen depletion.
Be sure to install an earth leakage breaker.●
Failure to install an earth leakage breaker may result in electric shocks or fire.
Consult the dealer if the air conditioner submerges owing to a natural●
disaster, such as a flood or typhoon.
Do not operate the air conditioner in that case, or otherwise a malfunction, electric
shock, or fire may result.
Be sure to use a dedicated power supply for the air conditioner.●
The use of any other power supply may cause heat generation, fire, or product failures.
Safety Precautions
01_EN_3P243520-1B.indd 401_EN_3P243520-1B.indd 4 5/15/2009 10:20:59 AM5/15/2009 10:20:59 AM

English 5
CAUTION
After prolonged use, check the unit stand and its mounts for damage.●
If left in a damaged condition, the unit may fall and cause injury.
Do not allow a child to mount on the outdoor unit or avoid placing any●
object on it.
Falling or tumbling may result in injury.
Do not block air inlets nor outlets.●
Impaired air flow may result in insufficient performance or trouble.
To avoid injury, do not touch the air inlet or aluminium fins of the unit.●
Do not remove the outdoor unit’s fan guard.●
The guard protects against the unit’s high speed fan, which may cause injury.
Do not place objects that are susceptible to moisture directly beneath●
the indoor or outdoor units.
Under certain conditions, condensation on the main unit or refrigerant pipes, air filter dirt
or drain blockage may cause dripping, resulting in fouling or failure of the object
concerned.
Do not place water containers (flower vases, etc.) on the unit, as this●
may result in electric shocks or fire.
Do not use the air conditioner for purposes other than those for which it●
is intended.
Do not use the air conditioner for cooling precision instruments, food, plants, animals or
works of art as this may adversely affect the performance, quality and/or longevity of the
object concerned.
Do not place appliances that produce naked flames in places exposed to●
the air flow from the unit as this may impair combustion of the burner.
Do not place heaters directly below the unit, as resulting heat can cause●
deformation.
Be sure that children, plants or animals are not exposed directly to●
airflow from the unit, as adverse effects may ensue.
Do not put flammable containers, such as spray cans, within 1m from the●
blow-off mouth.
The containers may explode because the warm air output of the indoor or outdoor unit
will affect them.
Do not install the air conditioner at any place where there is a danger of●
flammable gas leakage.
In the event of a gas leakage, build-up of gas near the air conditioner may result in fire
hazards.
―― Items to be Strictly Observed――
01_EN_3P243520-1B.indd 501_EN_3P243520-1B.indd 5 5/15/2009 10:21:00 AM5/15/2009 10:21:00 AM

6 English
CAUTION
Do not sit or stand on any unstable base at the time of operating or●
maintaining the air conditioner.
The base may topple down and injury may result.
Do not touch the motor at the time of filter replacement.●
The motor in operation is at high temperatures and a burn may result.
Do not wash the air conditioner with water, as this may result in electric●
shocks or fire.
Perform ventilation from time to time.●
Be careful when using the air conditioner with other heating equipment.
Insufficient ventilation may result in oxygen deficiency.
Always stop the operation of the air conditioner and turn OFF the●
breaker at the time of cleaning.
Failure to do so may result in an electric shock or injury.
Do not wash the interior of the indoor and outdoor units by yourself.●
Always consult your Daikin dealer.
The use of an incorrect washing method or incorrect detergent may damage the resin
parts of the indoor unit or cause water leakage.
Moreover, malfunctions, smoke generation, or ignition may result if the electric parts or
motor in the indoor unit is wet with detergent.
Do not place objects in direct proximity of the outdoor unit and do not let●
leaves and other debris accumulate around the unit.
Leaves are a hotbed for small animals which can enter the unit. Once in the unit, such
animals can cause malfunctions, smoke or fire when making contact with electrical
parts.
Fix the units securely.●
If the units are not mounted securely, the units may fall or topple and injury may result.
Arrange the drain to ensure complete drainage.●
If proper drainage from the outdoor drain pipe does not occur during air conditioner
operation, there could be a blockage due to dirt and debris build-up in the pipe.
This may result in a water leakage from the indoor unit. Under these circumstances,
stop air conditioner operation and consult your dealer for assistance.
Safety Precautions
01_EN_3P243520-1B.indd 601_EN_3P243520-1B.indd 6 5/15/2009 10:21:00 AM5/15/2009 10:21:00 AM

English 7
01_EN_3P243520-1B.indd 701_EN_3P243520-1B.indd 7 5/15/2009 10:21:01 AM5/15/2009 10:21:01 AM

8 English
Names and Functions
Functions other than basic operation items (i.e., On/Off, Operation
mode selector, Fan speed control, and temperature settings) are set
from the menu screen.
NOTE
Do not install the remote controller in places exposed to direct sunlight.●
Otherwise, the LCD may become discolored and nothing may be displayed.
Do not pull or twist the remote controller cord.●
Otherwise, the remote controller may error.
Do not press the buttons on the remote controller with objects with sharp ends.●
Otherwise, the remote controller may receive damage or error.
2. Fan speed control
button
3. Menu/Enter button
8. On/Off button
10. Cancel button
9. Operation lamp
11. LCD (with backlight)
4. Up button
5. Down button
6. Right button
7. Left button
1. Operation mode
selector button
01_EN_3P243520-1B.indd 801_EN_3P243520-1B.indd 8 5/15/2009 10:21:01 AM5/15/2009 10:21:01 AM

English 9
Operation mode selector button1.
Press this button to select the operation●
mode of your preference. (See page 14.)
Available modes vary with the connecting*
model.
Fan speed control button2.
Press this button to select the fan speed of●
your preference. (See page 15.)
Available fan speed vary with the*
connecting model.
Menu/Enter button3.
Used to indicate the main menu.●
(See page 24 for the menu items.)
Used to enter the setting item selected.●
Up button4. (Be sure to press the
part with the symbol )
Used to raise the set temperature.●
The next items on the upper side will be●
highlighted.
(The highlighted items will be scrolled
continuously when the button is kept
pressed.)
Used to change the item selected.●
Down button5. (Be sure to press
the part with the symbol )
Used to lower the set temperature.●
The next items on the lower side will be●
highlighted.
(The highlighted items will be scrolled
continuously when the button is kept
pressed.)
Used to change the item selected.●
Right button6. (Be sure to press
the part with the symbol )
Used to highlight the next items on the●
right-hand side.
Each screen is scrolled in the right-hand●
direction.
Home leave settings are enabled with this●
button kept pressed for at least four
seconds. (See page 19.)
Left button7. (Be sure to press
the part with the symbol )
Used to highlight the next items on the●
left-hand side.
Each screen is scrolled in the left-hand●
direction.
Home leave settings are enabled with this●
button kept pressed for at least four
seconds. (See page 19.)
On/Off button8.
Press this button and system will start.●
Press this button again and system will●
stop.
Operation lamp (Green)9.
This lamp lights up during operation.●
This lamp blinks if a error occurs.●
Cancel button10.
Used to return to the previous screen.●
LCD (with backlight)11.
The backlight will be light for approximately●
30 seconds by pressing any operation
button. Operate buttons excluding the On/
Off button while the backlight is lit.
If two remote controllers are used to control●
a single indoor unit, the backlight of the
remote controller operated earlier than the
other one will be lit.
01_EN_3P243520-1B.indd 901_EN_3P243520-1B.indd 9 5/15/2009 10:21:01 AM5/15/2009 10:21:01 AM

10 English
Liquid Crystal Display
Two types of liquid crystal display (LCD) are available. The standard display is by●
default set.
To go to the detailed display, select the detailed display in the main menu. ● (See page 46.)
The displayed contents of the screen vary with the operation mode of the equipment●
interlocked. (The following display will appear when the air conditioner is in automatic
heating operation.)
Standard display
Set temperature
20°C
Auto
Heat
This function not available
<Standard display example>
7.Ventilation
3.Fan speed
1.Operation mode
12.Home Leave
8.( ) display
4.Set temperature
display
5.Defrost/Hot start
6.Message
11.Changeover under control
10.Under centralized
control
9.( ) display
2.Automatic
operation mode
Detailed display
The airflow direction, clock, and detailed selection items appear
on the detailed display screen in addition to the items appearing
on the standard display.
Set temp
A12:05
Room
20°C
20°C
Auto
Return Setting
Heat
15.Detailed selection
(with room
temperature settings)
13.Airflow direction
(Displayed only when
the air conditioner is in
operation.)
14.Clock (24 hours
real time clock)
<Detailed display example 1>
Set temp
A
--
:
--
20°C
Auto
Return Setting
Heat
<Detailed display example 2>
Airflow direction
display
(with no airflow direction
settings)
3.Fan speed display
(with no fan speed
control function)
Detailed selection
(with no detailed items
selected)
Clock display
(with no clock settings)
16. ( ) display
Names and Functions
01_EN_3P243520-1B.indd 1001_EN_3P243520-1B.indd 10 5/15/2009 10:21:01 AM5/15/2009 10:21:01 AM

English 11
Operation mode1.
Used to display the present operation●
mode Cool, Heat, Vent, Fan, Dry or Auto
mode.
Automatic operation mode2.
Used to display the present automatic●
operation mode (Cool or Heat).
Fan speed3.
Used to display the fan speed that is set for●
the air conditioner.
The fan speed will not be displayed if the●
air conditioner does not have fan speed
control function.
Set temperature display4.
Used to display the temperature set for the●
air conditioner.
Defrost/Hot start “5. ”
(See page 16.)
If Ventilating operation “ ” is displayed:
Displayed when a total heat exchanger●
unit, such as the Ventiair, is connected.
For details, refer to the Operation Manual
of the Ventiair.
Message6.
The following messages are displayed.
“This function not available.”
Displayed for a few seconds when an●
operation button is pressed if the indoor
unit is not provided with the corresponding
function.
If a number of indoor units are in operation,●
the message will appear only if none of the
indoor units is provided with the
corresponding function, i.e., the message
will not appear if at least one of the indoor
units is provided with the corresponding
function.
“Error: Press Menu Button.”
“Warning: Press Menu Button.”
Displayed if the error or warning is detected●
(see page 53).
“Quick Cool/Heat” (SkyAir only)
Displayed if the quick cooling/heating●
function is turned ON (see page 31).
“Clean the filter.”
“Clean the element.”
“Clean the filter and element.”
Displayed when the time to clean the filter●
or element has come (see page 51).
Ventilation / Purifying7.
Displayed when a total heat exchanger●
unit, such as the Ventiair, is connected.
Ventilation mode icon.“●”
These icons indicate the current ventilation
mode (HRV only) (AUTOMATIC, HEAT
EXCHANGE, BYPASS).
AIR Purifying ICON “●”
This icon indicates that the air cleaning unit
(option) is operational.
8. display (See page 23.)
Displayed when the key lock is set.●
9. display (See page 34.)
Displayed if the schedule timer or OFF●
reminder timer is enabled.
Under Centralized control “10. ”
Displayed if the system is under the●
management of central control equipment
(optional accessories) and the operation of
the system through the remote controller is
prohibited.
Changeover under control “11. ”
(VRV only)
Displayed on the remote controller if the●
remote controller has no cooling/heating
selection eligibility mode (see page 21).
01_EN_3P243520-1B.indd 1101_EN_3P243520-1B.indd 11 5/15/2009 10:21:02 AM5/15/2009 10:21:02 AM

12 English
Names and Functions
Home leave “12. ” (See page 19.)
The home leave icon shows the status of●
the home leave function.
ON Home leave is enabled
FLASHING Home Leave is active
OFF Home Leave is disabled
Airflow direction “13. ”
Displayed when the airflow direction and●
swing are set (see page 28).
This item is not displayed if the system is●
not provided with a function to set airflow
directions.
Clock (24 hours real time clock)14.
Displayed if the clock is set●(see page 48).
If the clock is not set, “ -- : -- ” will be●
displayed.
Detailed selection15.
Displayed if the detailed display items are●
selected (see page 47).
No detailed items are by default selected.●
16. display
Displayed to inform that the clock needs●
setting again.
The schedule timer function will not work●
unless the clock is set again.
01_EN_3P243520-1B.indd 1201_EN_3P243520-1B.indd 12 5/15/2009 10:21:03 AM5/15/2009 10:21:03 AM

English 13
01_EN_3P243520-1B.indd 1301_EN_3P243520-1B.indd 13 5/15/2009 10:21:03 AM5/15/2009 10:21:03 AM

14 English
Cool/Heat/Auto/Fan Operation (SkyAir and VRV)
Operation Method
1 ●Displays the main menu screen.
(See page 26.)
●Press buttons to select
Timer setting on the main menu
screen.
Press Menu/Enter button to display
the timer settings screen.
* Items presently enabled or disabled are
displayed.
Return Setting
MainMenu
Set temp mode changeover
Airflow Direction
Quick Cool/Heat On/Off
Ventilation
Timer setting
Service Contact/Model info
1/2
Return Setting
Timer setting
Schedule timer
Off reminder timer
Disable
Disable
2/2
Operation screen
display
Describes screens that
will be displayed on the
remote controller in
operation.
Operation procedure
Explains a button operation
procedure for the remote controller.
Operate the buttons according to
the procedure.
Operation button
display
Displays the positions of
buttons to be operated.
Remote Controller Functions
Preparation
For mechanical protection purposes, turn ON the system at least six hours before starting the●
operation of the system.
Do not turn OFF the system in season in order to ensure the smooth starting of the system.●
Operation Method
1
Set temperature
28°C
Cool
Return Setting
Press Operation Mode Selector button●
several times until the desired mode
Cooling, Heating, Fan, or Auto mode is
selected.
Unavailable operation modes are not displayed.*
Only the Cooling or Fan mode can be selected if the air*
conditioner is a cooling-only model.
The Auto mode can be set in the case of the VRV cooling/*
heating simultaneous operation system.
Changeover under control will appear on each remote controller,*
but only the Cooling or Fan mode can be set in the case of the
VRV cooling-only system.
Note
Before making a mode change, make sure that Changeover●
under control is not displayed on the remote controller.
The cooling or heating mode cannot be selected if the above is
displayed on the remote controller. See page 21 if Changeover
under control display blinks.
Basic Operation Method (Use of Direct Buttons)
01_EN_3P243520-1B.indd 1401_EN_3P243520-1B.indd 14 5/15/2009 10:21:03 AM5/15/2009 10:21:03 AM

English 15
2 Press On/Off button.●
The Operation lamp (green) will be lit
and the system will start operating.
3
Set temperature
28°C
Cool
Return Setting
The set temperature will increase by●
1°C when button is pressed and
decrease by 1°C when button is
pressed.
No temperature settings are possible while in fan mode.*
4
Set temperature
28°C
Cool
Return Setting
Low Middle
High
To make fan speed control, press Fan●
speed control button and select the
desired fan speed from Low, Middle or
High.
Two fan speed adjustment levels Low, High may be available*
depending on the type of indoor unit.
The system may be in automatic fan speed control for*
mechanical protection purposes.
The system may be in automatic fan speed control according to*
the room temperature.
The fan may stop operating, which, however, is not a failure.
The completion of fan speed selection may take time, which,*
however, is not a failure.
5 Make airflow direction settings from the main menu●
(see page 28).
The airflow direction of the system cannot be changed unless*
the system is provided with a function to allow airflow direction
changes.
01_EN_3P243520-1B.indd 1501_EN_3P243520-1B.indd 15 5/15/2009 10:21:03 AM5/15/2009 10:21:03 AM

16 English
6 The Operation lamp will be turned OFF●
and the system will stop operating when
On/Off button is pressed again.
While the system is in heating operation, the*
system will be in fan operation for approximately
one minute in order to eliminate the heat in the
indoor unit after the heating operation comes to a
stop.
Note
Do not turn power OFF soon after the system stops operating.●
Be sure to wait for at least five minutes so that the drain
discharging device will finish discharging the residual drain.
Otherwise, water leakage or failures may result.
Characteristics of Heating Operation
Starting operation The system in heating operation generally requires a long time to●
attain the set temperature compared with the system in cooling
operation.
It is recommended to start operating the system in advance by utilizing
the timer.
Perform the following operation of the system in order to prevent the
degradation of the heating capability or cold winds from blowing out.
Defrosting
operation
The heating capability of the system will drop if the outdoor unit frosts●
up. Therefore, the system will go into defrosting operation
automatically.
The system will stop blowing out hot air, and “●” (Defrost/Hot
start) will be displayed on the remote controller.
The system will return to normal operation with an elapse of●
approximately six to eight minutes (but not more than 10 minutes).
Hot start
(VRV only)
When the system goes into heating operation, the wind will stop in●
order to prevent cold air from blowing out of the system in defrosting
operation.
(In that case, “ ” (Defrost/Hot start) will be displayed on the
remote controller.)
Basic Operation Method (Use of Direct Buttons)
01_EN_3P243520-1B.indd 1601_EN_3P243520-1B.indd 16 5/15/2009 10:21:04 AM5/15/2009 10:21:04 AM

English 17
Outdoor
temperature and
heating capability
The heating capability of the system will drop with a decrease in●
outdoor temperature.
If that happens, use the system along with another heating appliance.
(In the above case, be sure to ventilate the room as frequently as
possible.)
Do not use the heating appliance in places where the heating
appliance is exposed to the wind from the system.
The system is of hot air circulation type. Therefore, it takes some time●
for the room to become warm after the system starts operating.
The indoor fan will automatically go into breezing operation until the
inner temperature of the system rises to a certain level.
If the hot air stays around the ceiling and your feet feel cold, the use of●
a circulator is recommended.
For details, consult your Daikin dealer.
Program Dry Operation
Preparation
For mechanical protection purposes, turn ON the system at least six hours before starting the●
operation of the system.
Do not turn OFF the system in season in order to ensure the smooth starting of the system.●
The dry mode may not be selected if the remote controller has no right to select cooling/●
heating mode (see page 22 for details).
Operation Method
1
Set temperature
28°C
Dry
Return Setting
Press Operation Mode Selector button●
several times until the Dry operation is
selected.
The dry operation may not be available depending on the type of*
indoor unit.
01_EN_3P243520-1B.indd 1701_EN_3P243520-1B.indd 17 5/15/2009 10:21:04 AM5/15/2009 10:21:04 AM

18 English
2 Press On/Off button.●
The Operation lamp (green) will be lit
and the system will start operating.
The microcomputer is in automatic temperature and fan speed*
control. Therefore, temperature or fan speed settings cannot be
made or changed while the air conditioner is in operation.
3 Make airflow direction settings from the main menu●
(see page 28).
The airflow direction of the system cannot be changed unless the*
system is provided with a function to allow airflow direction
changes.
4 The Operation lamp will be turned OFF●
and the system will stop operating when
On/Off button is pressed again.
Note
Do not turn power OFF soon after the system stops operating.●
Be sure to wait for at least five minutes so that the drain
discharging device will finish discharging the residual drain.
Otherwise, water leakage or failures may result.
Basic Operation Method (Use of Direct Buttons)
01_EN_3P243520-1B.indd 1801_EN_3P243520-1B.indd 18 5/15/2009 10:21:05 AM5/15/2009 10:21:05 AM

English 19
Operation Contents
Program Dry
The Program dry function of the system repeats the weak cooling
operation of the system intermittently to dehumidify the room without
dropping the room temperature as much as possible for the
prevention of excessive cooling.
Program Dry Operation
The microcomputer is in automatic temperature and fan speed control. Therefore, temperature or●
fan speed settings cannot be made or changed while the air conditioner is in operation.
Home Leave
Home Leave is a feature that enables to keep the room temperature above 10°C when the
occupants are out.
Note
This function will switch on heating if the installation is switched off.●
Operation Method
The home leave can not be enabled when a centralized control is connected.
1
Set temperature
28°C
Cool
Return Setting
Set temperature
28°C
Cool
Return Setting
Press and hold the “●” or “ ” button
for at least four seconds. (During
backlight lit)
The Home Leave icon displays and●
function is enabled.
The Home Leave icon shows the status
of the home leave function.
ON Home leave is enabled
FLASHING Home leave is active
OFF Home leave is disabled
To cancel the home leave mode, continue ●
pressing “ ” or “ ” button for at least
four seconds. (During backlight lit)
01_EN_3P243520-1B.indd 1901_EN_3P243520-1B.indd 19 5/15/2009 10:21:05 AM5/15/2009 10:21:05 AM
