Dakota Alert RE-4k Plus User manual

www.bealert.co.nz www.bealert.com.au
NEW ZEALAND AUSTRALIA
Wireless Receiver
RE-4k PLUS ANZ
USER GUIDE

OVERVIEW
Terminals
Speaker
Volume button
Power adapter jack
LEDs
Mode button
DIP switches
Mounting holes
Bottom
Front
Back

PACKAGE CONTENTS
• RE-4k Plus receiver
• Power adapter
• User Guide
POWERING YOUR RECEIVER
1. Connect the power adapter to the jack in the bottom of the receiver.
2. Plug the power adapter into a power outlet.
Bottom
Power adapter
OVERVIEW

SETTING UP YOUR RECEIVER
‘Basic Setup’ lets you choose the tune and LED settings you want for Dakota Alert 4000 Series transmitters.
In addition to tune and LED settings, ‘Advanced Setup’ lets you set up exterior sensors using the Relay 1,
Relay 2, and the 12 VDC terminals.
BASIC SETUP
Note: You can connect up to 16 Dakota Alert 4000 Series transmitters to your receiver.
1. Place your receiver and transmitter(s) next to each other.
Note: Be careful not to activate your transmitter until you select the tune you want. If you do accidentally
activate the transmitter on the wrong tune, reselect a tune and reactivate the transmitter.
2. Press and hold the MODE button for three seconds until all LEDs flash and start blinking slowly.
3. Press the (volume) button repeatedly until you find the tune you want to sound when a transmitter
is activated.
4. After you choose a tune, activate the transmitter (for example, press its button or wave your hand over
its motion sensor). The receiver emits a short beep to confirm the transmitter has been coded.
Note: If you accidentally activate the transmitter on the wrong tune, press the (volume) button to
reselect a tune and reactivate the transmitter.
5. If you are coding more than one transmitter, repeat steps 3–4.
6. After your transmitter(s) are coded, press and hold the MODE button until the LEDs stop flashing.
7. To test the transmitter tune, activate the transmitter. You’ll hear the selected tune through your receiver
and the LEDs will flash.
ADVANCED SETUP
Note: You can connect up to 16 Dakota Alert 4000 Series transmitters to your receiver. Each transmitter can
be set to independently sound a tune, flash the LED, or control the 12VDC output and relay outputs for the
selected time.
1. Place your receiver and transmitter(s) next to each other.
Note: Be careful not to activate your transmitter until you select the tune you want. If you do
accidentally activate the transmitter on the wrong tune, reselect a tune and reactivate the transmitter.
1 Ding Dong (high) 5 Alarm/Siren 9 William Tell 13 Beep (high)
2 Ding Dong (low) 6 Coo Coo Clock 10 Cannon in D 14 Beep (low)
3 Westminster 7 Bird Chirping 11 Morning 15 Beep, Beep
4 Fur Elise 8 Twinkle Twinkle 12 Toreador March 16 Beep, Beep,
Beep, Beep

2. Press and hold the MODE button for three seconds until all LEDs flash and start blinking slowly.
3. Set the DIP switches to control the actions when a signal is received:
4. Press the (volume) button repeatedly until you find the tune you want to sound when a transmitter
is activated.
5. After you choose a tune and set the DIP switches to control the outputs, activate the transmitter (for
example, press its button or wave your hand over its motion sensor). The receiver emits a short beep to
confirm the transmitter has been coded.
Note: If you accidentally activate the transmitter on the wrong tune, press the (volume) button to
reselect a tune and reactivate the transmitter.
6. If you are coding more than one transmitter, repeat steps 3–5.
7. After you have coded your transmitter(s), press and hold the MODE button until the LEDs stop
flashing.
8. To test your transmitter tune and outputs, activate the transmitter. You’ll hear the selected tune, the
LEDs will flash for 15 seconds, and the relay and voltage outputs will activate (if these options are
programmed).
DIP 1: LEDs flash - on or off
DIP 2: Chime or tune - on or off
DIP 3: Relay 1 output - on or off
DIP 4: Relay 2 output - on or off
DIP 5: 12VDC output - on or off
DIP 6 & 7: Control the time duration for the Relay 1, Relay 2 or 12 VDC terminals
DIP 6: ‘Off’ and DIP 7 ‘Off’: 1 second
DIP 6: ‘On’ and DIP 7 ‘Off’: 5 seconds
DIP 6: ‘Off’ and DIP 7 ‘On’: 15 seconds
DIP 6: ‘On’ and DIP 7 ‘On’: 5 minutes
1 Ding Dong (high) 5 Alarm/Siren 9 William Tell 13 Beep (high)
2 Ding Dong (low) 6 Coo Coo Clock 10 Cannon in D 14 Beep (low)
3 Westminster 7 Bird Chirping 11 Morning 15 Beep, Beep
4 Fur Elise 8 Twinkle Twinkle 12 Toreador March 16 Beep, Beep,
Beep, Beep

CONNECTING WIRES TO THE TERMINALS
The RE-4k Plus receiver has two relay outputs (NO, COM, NC) and a 12 VDC (+ and –) output terminal.
1. To connect lead wires to the terminals, strip off 3/8” (10 mm) of insulation from the end of the wire.
Note: The terminals work with wire gauges from 22 to 16 AWG (low voltage only).
2. With a small screwdriver, press the orange button to open the terminal.
3. Insert the bare end of the wire into the terminal opening, then release the orange button.
The terminal clamps down on the wire.
4. Pull gently on the wire to make sure that your connection is secure.
ADJUSTING THE VOLUME
Press the (volume) button repeatedly to adjust the volume (four levels and off ). The LEDs show the
volume level for four seconds.
LOW BATTERY INDICATOR
If the RE-4k Plus receiver plays your transmitter’s tune twice and the LED blinks slowly for ten minutes after
the transmitter is activated, your sensor’s battery is low. Replace the battery
CANCELLING OUTPUT SIGNALS
After the RE-4k Plus receives a signal, the relay and voltage outputs activate, the chime sounds, and the LED
flashes for 15 seconds. If you want to stop these actions after they have started, briefly press the MODE
button. The receiver resets and is ready to be activated again.
Back of receiver
Bottom of receiver

DELETING ALL SENSORS
1. Press and hold the MODE button for three seconds until the LEDs flash slowly.
2. Press and hold the MODE and (volume) buttons again for five seconds. The four lights flash
quickly, then turn off. The receiver is reset, and all codes are deleted
Note: To recode transmitters to the receiver, see ‘Basic Setup’ or ‘Advanced Setup’.
MOUNTING THE RECEIVER
Attach two screws (not included) or nails to your wall 6.7cm apart, then hang your receiver.

Freephone New Zealand: 0508 242 333
Phone [phone]
Fax [phone]
PO Box 730, New Plymouth 4342
NEW ZEALAND
Freephone Australia: 1300 588 195
Fax [phone]
AUSTRALIA
SPECIFICATIONS
• Power supply: 12 VDC, 500 mA
• Wireless range: 1.6km*
• Dimensions: 12.7 × 8.3 × 3.2cm
• Operating frequencies: 433 MHz
*Actual range will vary depending on local terrain and obstructions.
TECHNICAL SUPPORT:
If you encounter any difficulty in the operation of this product after reading the manual, please contact us.
We will be happy to answer your questions and help you in any way we can.
WARRANTY:
Dakota Alert warrants this product to be free of defects in material and workmanship for a period of one
year from the date of purchase. This warranty does not cover damage resulting from accident, abuse, act of
God or improper operation. If this product does become defective, simply return it to Target Technology Ltd.
Please include a note describing the troubles along with your name and return address as well as the original
sales receipt. If the product is covered under warranty it will be repaired or replaced at no charge. If it is not
covered by warranty, you will be notified of any charges before work is done.
