Dakota Alert WPT-3000 User manual

Dakota Alert™
WPT-3000
Wireless Probe
Transmitter
Owner’s Manual

2.
Warnings
This device complies with Part 15 of the FCC rules, operation of this device is subject to the
following conditions: 1. This device may not cause harmful interference. 2. This device must
accept any interference, including interference that may cause undesired operation.
Installation:
The WPT-3000 transmitter is used with the Dakota Alert WR-3000 receiver. The WPT-3000
transmitter uses a magnetic probe and 50 feet of direct burial cable to detect vehicles at the
monitored location. When the transmitter detects a vehicle it will send a signal to the receiver
which will sound one of 4 different tones (Classical , Westminster Chime, Ding Dong, Whistle)
for a few seconds. The transmitter can be used to monitor driveways, drive-up windows, etc.
NOTE: Test the WPA-3000 system before burying the probe. Place the probe above ground
where it will be installed, then test it by having a car drive by.
Operation:
1. Connect a 9 volt alkaline battery to the transmitter. (figure 1)
2. Set the dip switches 1-8 on the transmitter module to match the receiver.
3. Set dip switches 9 &10 to control the desired zone, tune and relay output.
4. Bury the probe next to the driveway and bury the wire over to a tree or post.

5. Mount the transmitter box
on a tree or post about 3 to 4
feet off the ground.
For maximum range between
the transmitter and receiver, the
transmitter should be mounted
on a wooden post or tree (steel
posts may cause interference
with the radio signal). Although
the maximum range is about
3000 feet, things such as hills,
trees, metal siding and stucco
can all reduce the range.
Coding the transmitter:
1. Locate the dip switches in
the WPT-3000 transmitter.
2. The first 8 dip switches are for the frequency setting (256 combinations)  (figure 1).
Set the first 8 switches to match the 8 switches in the receiver.
3.
figure 1
12
{
{
3

3. Switches 9 & 10 are for the zone/channel
setting on the transmitter  (Figure 1).
The four zones are as follows: (see table
at right)
Mounting the transmitter:
1. The probe will detect vehicles up to
about 10 feet away. Lay the probe beside
the driveway, then test the unit by having
a car drive by. Once the unit is tested, the probe can be buried. The probe should be buried to
a depth of 12 inches, laying parallel to the drive. If your driveway is one car wide, bury the probe
right next to the drive (figure 2). If your driveway is two or more cars wide, bury the probe in the
middle of the drive.
2. If the probe and wire will be in a high traffic area, it is best to bury both in conduit. The
wire should be at least 3 inches below the surface to keep it from being damaged by garden
equipment such as edgers, trimmers, etc.
3. In order to protect the wire, it would also be best to have it in conduit where it is exposed
above ground below the transmitter box.
4. Mount the transmitter box on a wooden post or a tree.
5. For best result the transmitter should be at least 3 to 4 feet off the ground.
4.
Switch
9
Switch
10
Channel 12-volt
DC output
Tune
On On 1 Yes Classical
Off On 2 No Westminster
On Off 3 No Ding Dong
Off Off 4 No Whistle

5.
3 to
4 ft
figure 2 Coding the receiver:
1. Open the receiver case by inserting a small
screw driver into one of the pry notches
on the side of the case. (refer to receiver
manual)
2. Gently lift off the front cover.
3.
Locate the 8 dip switches on the receiver
and make sure they are set identically to the
first 8 dip switches on the transmitter. Note:
If more than one transmitter is used with the
receiver, the first 8 dip switches of all trans-
mitters must match the 8 dip switches of the
receiver.
NOTE: Whenever a change is made to the
time jumper or the dip switches, the receiver
must be turned “OFF” and then back “ON” to
operate properly.
Test probe by placing in the area to be monitored, and
having a car pass by. Do this before burying the probe.

6.
Troubleshooting the WPT-3000
Although the WPT-3000 should be very reliable, there are occasions when you might have
false alarms or a failure to alert. If you are getting false alarms, please try this:
• Make sure that the probe is at least 50 feet from any main roads.
• Turn the sensitivity (figure 1) down (counter-clockwise).
• Check the wire for damage to the insulation.
If the transmitter is not detecting, try one of these:
• Change the battery in the transmitter.
• Make sure the transmitter and receiver are coded alike.
• Turn the sensitivity (figure 1) up (clockwise).
• Move the transmitter closer to the receiver.
• Keep the transmitter away from large metal objects that may interfere with the radio signal.
Frequency: 433.92 MHz
Operating voltage: 12VDC
12 volt DC output current: 400 mA maximum
Relay output rating: 24VDC at 3 Amp

7.
TECHNICAL SUPPORT
If you encounter any difficulty in the operation of this product after reading the manual,
please contact us. You can reach us by phone at 605-356-2772 from 8:30 AM to 5:00 PM
Monday through Friday (Central Standard Time). We will be happy to answer your questions
and help you in any way we can.
WARRANTY
Dakota Alert warrants this product to be free of defects in material and workmanship for a
period of one year from the date of purchase. This warranty does not cover damage result-
ing from accident, abuse, act of God or improper operation.
If this product does become defective, simply return it to Dakota Alert. Please include a note
describing the troubles along with your name and return address as well as the original sales
receipt. If the product is covered under warranty it will be repaired or replaced at no charge.
If it is not covered by warranty, you will be notified of any charges before work is done.

Dakota Alert, Inc.
109 W. Main Street
P0 Box 130
Elk Point, SD 57025
Phone: [phone]
Fax: [phone]
Web: www.dakotaalert.com
