DALCNET CBU-DALI-GATEWAY Application guide

CBU-DALI-GATEWAY
Device Manual
Made in Italy
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) –Italy
Via Lago Garda, 22
Phone [phone]
www.dalcnet.com –[e-mail]
Rev. 21/07/2023 - Pag. 1/12
FIXTURE ID 24810
FEATURES
CONVERTER+CASAMBI+DALI+GATEWAY
Input: DC 12-24-48 Vdc
Command: CASAMBI APP
Local Control programmable from CASAMBI APP: n°1 button Normally Open
Casambi signal to DALI protocol converter and vice versa
Possibility to control devices with DALI control via CASAMBI APP
Ability to Address DALI Devices
Extended temperature range
100% Function Test
PRODUCT DESCRIPTION
The device receives the command signal from the Casambi APP and depending on the fixture set sends the signal in a predetermined
sequence of DALI addresses.
See pag.7 for the DALI Addresses map.
With the "CBU DALI GATEWAY" profile, the device receives commands from an external DALI Master and sends control signals to
the Casambi lamps of the network to which it is associated. Each Casambi lamp has a DALI address.
In the case of Casambi Tunable White or RGB/RBGW devices, these will be recognized by the DALI Master as DALI DT8.
The CASAMBI APP can be downloaded free of charge from the Apple App Store and the Google Play Store.
⇢For the regularly updated manual, consult our website:www.dalcnet.com or QR Code
⇢For the correct functioning of the CASAMBI APP, consult the forum on the Casambi website:
https://support.casambi.com/support/home
PRODUCT CODE
PROTECTIONS
1
DALI bus power is required
2
Address management depends on the configuration of the Casambi module.
3
Protection on control logic
CODE
POWER SUPPLY
COMMAND
INCOMING
COMMAND
OUTGOING
TYPE OF LOCAL
COMMAND
CBU-DALI-GATEWAY1
12-24-48V DC
APP CASAMBI
DALI (DT6 and DT8)2
N° 1 N.O. Push Button
OVP
Over voltage protection 3
✓
UVP
Under voltage protection 3
✓
RVP
Reverse polarity protection 3
✓
VET
Protection with input fuse 3
✓

CBU-DALI-GATEWAY
Device Manual
Made in Italy
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) –Italy
Via Lago Garda, 22
Phone [phone]
www.dalcnet.com –[e-mail]
Rev. 21/07/2023 - Pag. 2/12
TYPE OF PROFILES
PROFILE NAME
# PROFILE
DESCRIPTION
DALI2 BROADCAST*
24810
Default
Basic Dali Broadcast Dimmer.
Dali dimming curve: logarithmic.
Set the power on level at maximum level (100% - 254).
No addressing required.
CBU DALI GATEWAY
24814
Control of Casambi devices from DALI network
W AUTOMATIC
25136
One-channel dimmer:
-Dimmer 1: A0 address
DALI dimming curve: logarithmic.
Set the power level to the maximum level (100% - 254).
The address is automatically assigned to the device, if necessary.
WWWW AUTOMATIC
25139
Four-channel dimmer.
-Dimmer 1: address A0
-Dimmer 2: address A1
-Dimmer 3: address A2
-Dimmer 4: address A3
DALI dimming curve: logarithmic.
Set the power level to the maximum level (100% - 254).
The address is automatically assigned to the device, if necessary.
TW AUTOMATIC
2700-6000K
25140
Two-channel dimmer.
-Dimmer 1: address A0 –Warm White
-Dimmer 2: address A1 –Cold White
DALI dimming curve: linear.
Set the power level to the maximum level (100% - 254).
The address is automatically assigned to the device, if necessary.
RGB AUTOMATIC
25141
Three-channel dimmer.
-Dimmer 1: address A0 –Red
-Dimmer 2: address A1 –Green
-Dimmer 3: address A2 –Blue
DALI dimming curve: linear.
Set the power level to the maximum level (100% - 254).
The address is automatically assigned to the device, if necessary
RGB+W AUTOMATIC
25142
Four-channel dimmer.
-Dimmer 1: address A0 –Red
-Dimmer 2: address A1 –Green
-Dimmer 3: address A2 –Blue
-Dimmer 4: address A3 –White
DALI dimming curve: linear.
Set the power level to the maximum level (100% - 254).
The address is automatically assigned to the device, if necessary.
RGB+TW AUTOMATIC
25137
Five-channel dimmer.
-Dimmer 1: address A0 –Red
-Dimmer 2: address A1 –Green
-Dimmer 3: address A2 –Blue
-Dimmer 4: address A3 –Warm White
-Dimmer 5: address A4 –Cold White
DALI dimming curve: linear.
Set the power level to the maximum level (100% - 254).
The address is automatically assigned to the device, if necessary.
* The Device is certified as DALI2 only with the profile: 24810 –DALI2 BROADCAST

CBU-DALI-GATEWAY
Device Manual
Made in Italy
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) –Italy
Via Lago Garda, 22
Phone [phone]
www.dalcnet.com –[e-mail]
Rev. 21/07/2023 - Pag. 3/12
PROFILE NAME
# PROFILE
DESCRIPTION
WWWW GROUP
25138
Four DALI groups, dimmer function.
-Dimmer 1: group G0
-Dimmer 2: Group G1
-Dimmer 3: Group G2
-Dimmer 4: Group G3
DALI dimming curve: logarithmic.
Set the power level to the maximum level (100% - 254).
The address must be assigned to the control unit using a DALI Master device
8XW GROUP
25291
Eight DALI groups, dimmer function.
-Dimmer 1: group G0
-Dimmer 2: Group G1
-Dimmer 3: Group G2
-Dimmer 4: Group G3
-Dimmer 5: Group G4
-Dimmer 6: Group G5
-Dimmer 7: Group G6
-Dimmer 8: Group G7
DALI dimming curve: logarithmic.
Set the Power On Level to the maximum level (100% - 254).
The address must be assigned to the control unit using a DALI Master device
DALI DT8 BC TW
25143
1 Address to control 2 TW channels.
Send DALI DT8 BROADCAST commands for devices that support the "Colour
Temperature Tc" function: Dim Level and Colour Temperature.
DALI dimming curve: linear.
Set the power level to the maximum level (100% - 254).
No addressing is required.
DALI DT8 BC RGB
11121
1 Address to control 3 RGB channels.
Send DALI DT8 BROADCAST commands for devices that support the "RGBWAF
colour-type" function: Dim and RGBWAF.
DALI dimming curve: linear.
Set the power level to the maximum level (100% - 254).
No addressing is required.
DALI DT8 BC RGB+W
11545
1 Address to control 4 RGBW channels.
Send DALI DT8 BROADCAST commands for devices that support the
"RGBWAF colour-type" function: Dim and RGBWAF.
DALI dimming curve: linear.
Set the power level to the maximum level (100% - 254).
No addressing required

CBU-DALI-GATEWAY
Device Manual
Made in Italy
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) –Italy
Via Lago Garda, 22
Phone [phone]
www.dalcnet.com –[e-mail]
Rev. 21/07/2023 - Pag. 4/12
REFERENCE STANDARDS
EN 61347-1
Lamp control gear –Part 1: General and safety requirements
EN 55015
Limits or methods of measurement of radio disturbance characteristics of electrical lighting and similar equipment
EN 61547
Equipment for general lighting purpose –EMC immunity requirements
TECHNICAL SPECIFICATIONS
CBU-DALI-GATEWAY
Supply voltage
min: 10,8 Vdc .. max: 52,8 Vdc
Nominal Power4
Min
Max
@12V
61 mW
115 mW
@24V
120 mW
176 mW
@48V
230 mW
296 mW
Power loss in standby mode
<500mW
Operating frequency5
2402 –2480 MHz
Maximum output power5
7dBm
Storage temperature
min: -40 max: +60 °C
Ambient temperature4
min: -10 max: +40 °C
Type of connector
Screw terminals
Wiring
Solid size
2,5mm 2 solid –2,5mm2 stranded –30/12 AWG
Stranded size
Wire strip length
5.5 –6.5 mm
IP protection class
IP10
Casing material
Plastic
Packaging units (pieces/units)
1pcs
Mechanical dimensions
92 x 36 x 62 mm DIN RAIL 2M
Package dimensions
124 x 71 x 48 mm
Weight
88g
4
Maximum value, depending on ventilation conditions
5
The parameters are derived from the configuration of the Casambi module

CBU-DALI-GATEWAY
Device Manual
Made in Italy
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) –Italy
Via Lago Garda, 22
Phone [phone]
www.dalcnet.com –[e-mail]
Rev. 21/07/2023 - Pag. 5/12
WIRING DIAGRAM
Follow the steps below for product installation as shown in the connection diagram.
Connect the normally open button to the INPUT terminals with the " " symbol.
Be sure not to connect live parts to the INPUT terminals.
Connect the DALI BUS on the "DALI OUT" terminals.
Connect the constant voltage SELV power supply to the DC IN terminal with the "+" and "-" symbols.
Make sure you are not using a power supply with a constant current output and check that the polarity of the cables is
correct.
Like any other product with Bluetooth control, be sure not to place the product inside a metal case or placed near large metal
structures. The metal will greatly block the radio signal important for the operation of the device.

CBU-DALI-GATEWAY
Device Manual
Made in Italy
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) –Italy
Via Lago Garda, 22
Phone [phone]
www.dalcnet.com –[e-mail]
Rev. 21/07/2023 - Pag. 6/12
LOCAL COMMANDS FUNCTIONALITY
N.O. PUSH BUTTON
6
The Casambi app allows you to program the local command with some prearranged functions.
Button No.
Function
1
Controls a luminaire
Click
Long press (>1s)
Tap to turn a luminaire on or off –hold to adjust
luminaire brightness
Controls an element
Click
Long press (>1s)
Tap to turn a device element on or off –hold to adjust
the element value
Control a group
Click
Long press (>1s)
Tap to turn a group on or off –hold to adjust
brightness
Control scene
Click
Long press (>1s)
Tap to turn a scene on or off –hold to adjust scene
brightness
Control all luminaires
Click
Long press (>1s)
Tap to turn all luminaires on or off –hold to adjust
brightness
Cycles scenes
Click
Long press (>1s)
Tap to cycle through the list of scenes –hold to adjust
current scene brightness
Active/Standby
Click
Long press (>1s)
Tap to switch between two scenes –hold to adjust
current scene brightness
Controls a luminaire
Click
Long press (>1s)
Tap to turn a luminaire on or off –hold to adjust
luminaire brightness
Controls an element
Click
Long press (>1s)
Tap to turn a device element on or off –hold to adjust
the element value
Control a group
Click
Long press (>1s)
Tap to turn a group on or off –hold to adjust
brightness
For all other functions, consult the CASAMBI APP documentation at:
https://support.casambi.com/support/home
UNPAIR THE DEVICE FROM THE CASAMBI NETWORK
If the device is already connected to a network for which you don't have the credentials and you wish to associate it with a new
network, please follow the instructions provided in the Casambi APP's "Nearby Devices" section.
Once you have selected the unpair function and started the procedure, turn off the main power of the power supply connected to
the LINE-5CV-CASAMBI and turn it on again after 1 - 2 seconds.
If the main power supply is switched off and on again quickly, unpair may not be done properly. Repeat the unpair sequence by
allowing 1 or 2 more seconds to elapse between the moment you turn off and re-turn on the main power of the power
7
.
A second method to unpair the product is to connect an N.O. push button to an "INPUT" terminal of the LINE-5CV-CASAMBI and
during the decoupling procedure press the button.
6
By default, the button is set as "Control a lamp".
7
The discharge time of the power supply secondary depends on the construction characteristics of the power supply used

CBU-DALI-GATEWAY
Device Manual
Made in Italy
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) –Italy
Via Lago Garda, 22
Phone [phone]
www.dalcnet.com –[e-mail]
Rev. 21/07/2023 - Pag. 7/12




MECHANICAL DIMENSIONS
(Excluding terminals)

CBU-DALI-GATEWAY
Device Manual
Made in Italy
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) –Italy
Via Lago Garda, 22
Phone [phone]
www.dalcnet.com –[e-mail]
Rev. 21/07/2023 - Pag. 8/12
DALI MAP ADDRESSES OF THE CBU-DALI-GATEWAY
CONVERSION CASAMBI SIGNAL TO DALI PROTOCOL AND VICEVERSA
"AUTOMATIC" FIXTURE CONFIGURATION:
The "AUTOMATIC" fixtures of the CBU-DALI-GATEWAY automatically direct the UNADDRESSED devices connected to the DALI BUS.
CBU DALI GATEWAY
Casambi Slider
None
The device appears in the Gateway section of the
Casambi app.
DALI2BROADCAST
Casambi Slider
Dimmer
Address
Command
BROADCAST
Dimmer ALL
WAUTOMATIC
Casambi Slider
Dimmer
Address
Command
A0
Dimmer 0
WWWW AUTOMATIC
Casambi Slider
Dimmer 0
Dimmer 1
Dimmer 2
Dimmer 3
Address
Command
A0
Dimmer 0
A1
Dimmer 1
A2
Dimmer 2
A3
Dimmer 3

CBU-DALI-GATEWAY
Device Manual
Made in Italy
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) –Italy
Via Lago Garda, 22
Phone [phone]
www.dalcnet.com –[e-mail]
Rev. 21/07/2023 - Pag. 9/12
TW AUTOMATIC 2700 -6000K
Casambi Slider
Dimmer
Color temperature
Address
Command
A0
Warm white
A1
Cold white
RGB AUTOMATIC
Casambi Slider
Dimmer
Color
Saturation
Map
Address
Command
A0
R –Red
A1
G –Green
A2
B –Blue
RGBW AUTOMATIC
Casambi Slider
Dimmer
White / Color
Color
Saturation
Map
Address
Command
A0
R –Red
A1
G –Green
A2
B –Blue
A3
W –White
RGB TW AUTOMATIC
Casambi Slider
Dimmer
Color temperature
White / Color
Color
Saturation
Map
Address
Command
A0
R –Red
A1
G –Green
A2
B –Blue
A3
WW –Warm White
A4
CW –Could White

CBU-DALI-GATEWAY
Device Manual
Made in Italy
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) –Italy
Via Lago Garda, 22
Phone [phone]
www.dalcnet.com –[e-mail]
Rev. 21/07/2023 - Pag. 10/12
FIXTURE "GROUP" CONFIGURATION:
The "GROUP" fixtures of the CBU-DALI-GATEWAY send group commands. The DALI devices must be previously addressed and
assigned to the desired group through an external DALI master.
WWWW GROUP
Casambi Slider
Group 0
Group 1
Group 2
Group 3
Address
Command
G0
Group 0
G1
Group 1
G2
Group 2
G3
Group 3
8W GROUP
Casambi Slider
Group 0
Group 1
Group 2
Group 3
Group 4
Group 5
Group 6
Group 7
Address
Command
G0
Group 0
G1
Group 1
G2
Group 2
G3
Group 3
G4
Group 4
G5
Group 5
G6
Group 6
G7
Group 7

CBU-DALI-GATEWAY
Device Manual
Made in Italy
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) –Italy
Via Lago Garda, 22
Phone [phone]
www.dalcnet.com –[e-mail]
Rev. 21/07/2023 - Pag. 11/12
FIXTURE CONFIGURATION "DT8 BC":
The "DT8 BC" fixtures of the CBU-DALI-GATEWAY send broadcast commands to devices compliant with IEC 62386-209 - "Device
Type 8".
DALI DT8 BC TW
Casambi Slider
Dimmer
Color temperature
Address
Command
Broadcast
DT8 Dimming + CCT
DALI DT8 BC RGB
Casambi Slider
Dimmer
Color
Saturation
Map
Address
Command
Broadcast
DT8 Dimming + RGB
DALI DT8 BC RGBW
Casambi Slider
Dimmer
White / Color
Color
Saturation
Map
Address
Command
Broadcast
DT8 Dimming + RGBW

CBU-DALI-GATEWAY
Device Manual
Made in Italy
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) –Italy
Via Lago Garda, 22
Phone [phone]
www.dalcnet.com –[e-mail]
Rev. 21/07/2023 - Pag. 12/12
TECHNICAL NOTE
INSTALLATION
•CAUTION: The product may only be connected and installed by a qualified electrician. All applicable regulations, legislation, and
building codes must be observed. Incorrect installation of the product can cause irreparable damage to the product and the
connected LEDs.
•Maintenance must be performed only by a qualified electrician in compliance with current regulations.
Pay attention when connecting the LEDs: polarity reversal results in no light output and often damages the LEDs.
•The product is designed and intended to operate LED loads only. Powering non-LED loads may push the product outside its
specified design limits and is, therefore, not covered by any warranty.
Operating conditions of the product may never exceed the specifications as per the product datasheet.
•The product must be installed inside a switchgear/controlgear cabinet and/or junction box protection against overvoltage.
•The product must be installed in a vertical or horizontal position with the label/top cover facing upwards or vertically. Other
positions are not permitted. The bottom position is not permitted (label/top cover facing down).
•Keep separated 230Vac (LV) circuits and not SELV circuit from safety extra low voltage (SELV) circuit and from any connection
with this product. It is absolutely forbitten to connect, for any reason whatsoever, directly or indirectly, the 230Vac mains voltage
to the product (terminal block of BUS included).
•The product must be dissipated correctly.
•The use of the product in harsh environments could limit the output power.
•For built-in components inside luminaires, the ta ambient temperature range is a guideline given for the optimum operating
environment. However, integrator must always ensure proper thermal management (i.e. correct mounting of the device, air flow
etc.) so that the tc point temperature does not exceed the tc maximum limit in any circumstance. Reliable operation and lifetime
are only guaranteed if the maximum tc point temperature is not exceeded under the conditions of use.
POWER SUPPLY
•Only use SELV power supplies with limited current for device power supply, short circuit protection and the power must be
dimensioned correctly.
In the case of power supplies equipped with ground terminals, it is mandatory to connect ALL protective ground points (PE=
Protection Earth) to a properly and certified protection earth.
•The connection cables between the very low voltage power source and the product must be properly dimensioned and must be
insulated from any wiring or part at non-SELV voltage. Use double insulated cables.
•Dimension the power of the power supply in relation to the load connected to the device. In case the power supply is oversized
compared to the maximum absorbed current, insert a protection against over-current between the power supply and the device.
COMMAND
•The length of the cables connecting between the local commands (N.O. Push button or other) and the product must be less than
10m. The cables must be properly dimensioned and must be insulated from any non-SELV wiring or voltage. It is recommended
to use double insulated cables, if deemed appropriate also shielded.
•ALL device and control signal connected to the local command “N.O. Push button” with symbol, they must not supply
any type of voltage.
•The length and type of cables connecting to the bus (DALI or other) must comply with the specifications of the respective protocols
and the regulations in force. They must be insulated from any non-SELV wiring or voltage parts. It is recommended to use double
insulated cables.
•ALL device and control signal connect at the BUS (DALI or other) must be SELV type (the device connected must be SELV or supply SELV
signal).
ONLY CASAMBI/BLUETTOTH PRODUCT
•WARNING: For optimal functionality of the Casambi signal, do not put the device into metal or aluminium boxes and do not shield
the device. As any other Casambi product, should not be placed in a metal enclosure or next to large metal structures. Metal will
effectively block all radio signals which are crucial to the operation of the product.
WARNINGS
•To guarantee the best performances and the full use of functions, make sure to download on your device the last release of
CASAMBI APP.
•Whenever CASAMBI APP requires an upgrade of the profile installed in the LED Dimmers, follow the instruction to do it. This allows
you to stay always up to date and benefit of new functions released.
•Functionality test are done on all dimmers to ensure the right working. In case the device is still paired to “Dalcnet network”, you
are asked to unpair it by following the instructions on CASAMBI APP and in paragraph “UNPAIR DEVICE FROM THE CASAMBI
NETWORK”.
