Danby DAC080BFCWDB User manual

DANBY PRODUCTS LIMITED, ONTARIO, CANADA N1H 6Z9
DANBY PRODUCTS INC., FINDLAY, OHIO, USA 45840
OWNER’S MANUAL
MANUEL DU PROPRIÉTAIRE
MANUAL DEL PROPIETARIO
AIR CONDITIONER
Owner’s Manual.............................1 - 12
CLIMATISEUR
Manual du propriétaire.................13 - 24
AIRE ACONDICIONADO
Manual del propietario..................25 - 36
MODEL •MODÈLE •MODELO
DAC080BFCWDB
DAC100BFCWDB
DAC120BFCWDB
2017.09.05

Welcome
Welcome to the Danby family. We are proud of our quality products and we believe in
dependable service. We suggest that you read this owner’s manual before plugging in your new
appliance as it contains important operation information, safety information, troubleshooting and
maintenance tips to ensure the reliability and longevity of your appliance.
Visit www.Danby.com to access self service tools, FAQs and much more. For additional assistance
call 1-800-263-2629.
Note the information below; you will need this information to obtain service under warranty.
You must provide the original purchase receipt to validate your warranty and receive service.
Model Number: _________________________________________________
Serial Number: _________________________________________________
Date of Purchase: _______________________________________________
Need Help?
Before you call for service, here are a few things you can do to help us serve you better.
Read this owner’s manual:
It contains instructions to help you use and maintain your appliance properly.
If you receive a damaged appliance:
Immediately contact the retailer or builder that sold you the appliance.
Save time and money:
Check the troubleshooting section at the end of this manual before calling. This section
will help you solve common problems that may occur.
1-800-26- Danby
(1-800-263-2629)
1

Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS!
ELECTRICAL REQUIREMENTS
All wiring must comply with local and national
codes and must be installed by a qualified
electrician. Check the available power supply and
resolve any wiring problems before installing and
operating this appliance.
This 115 V appliance may be used in any properly
wired, general purpose household receptacle.
The rating plate located on the right side of the
appliance just above the power cord contains
electrical and other technical data.
This appliance is not designed for “through the
wall” installation.
GROUNDING INSTRUCTIONS
This appliance must be grounded. Grounding
reduces the risk of electrical shock by providing an
escape wire for the electrical current.
This appliance has a cord that has a grounding
wire with a 3-prong plug. The power cord must be
plugged into an outlet that is properly grounded.
If the outlet is a 2-prong wall outlet, it must be
replaced with a properly grounded 3-prong wall
outlet.
WARNING - Improper use of the grounding
plug can result in a risk of electric shock.
Consult a qualified electrician or service agent
if the grounding instructions are not completely
understood, or if doubt exists as to whether the
appliance is properly grounded.
Do not connect your appliance to extension
cords or together with another appliance in the
same wall outlet. Do not splice the power cord.
Do not under any circumstances cut or remove the
third ground prong from the power cord. Do not
use extension cords or ungrounded (two prongs)
adapters.
If the power supply cord is damaged, it must be
replaced by the manufacturer, its service agent or
similar qualified person in order to avoid hazard.
2
LOCATION
This air conditioner is designed for easy installation
in single or double hung windows. Since window
designs vary, it may be necessary to make some
modifications for safe installation.
This air conditioner is not designed for vertical,
slider type windows or “through the wall”
installation.
Ensure that the window and frame are structurally
sound and free from dry or rotted wood.
Install the air conditioner in a window on a side
of the building which favors more shade than
sunlight. If the appliance must be in direct sunlight,
it is advisable to provide a shade awning over the
appliance to ensure efficient functioning.
Do not install the appliance where leakage of
combustible gas is suspected.
This appliance is designed to evaporate
condensation under normal conditions. Under
extremely hot or humid conditions, excess
condensation may overflow to the outside. The
appliance should be installed where condensation
cannot drip on pedestrians or neighboring
properties.
Provide sufficient clearance around the appliance
to allow ample air circulation. The rear of the
appliance should be outdoors, it should not be in
a garage or another room. Keep the appliance
away from obstacles and at least 76 cm (30 inches)
above the ground. Ensure that curtains and other
obstructions do not block air flow to the appliance.
76.2 cm
(30 inches)
50.8 cm
(20 inches)
50.8 cm
(20 inches)
12 cm
(30.5 inches)

INSTALLATION INSTRUCTIONS
REQUIRED TOOLS
• Screwdrivers: Phillips and flat head.
• Power Drill: 3.2mm (1/8in.) diameter drill bit
• Pencil
• Measuring Tape
• Scissors
• Carpenter’s Level
ACCESSORIES
The following accessories are included with
the appliance and should be used during the
installation.
1. 13 mm (1/2 inch) screws (x7)
2. 9.5 mm (3/8 inch) screws (x4) (Factory installed
on some models.)
3. Safety Lock (x1)
4. Adhesive Foam Seal (x1)
5. Regular Foam Seal (x1)
6. “L” shaped mounting bracket (x1) (Factory
installed on some models.)
7. Curtain Bracket (x2)
8. Weather Stripping (x5)
9. Foam Insert (x2)
10.Side Curtains (x2)
1
2
3
4
5
6
7
8
9
10
ASSEMBLY
Note: Images in this manual are for instructional
purposes only. The actual shape of the appliance
may vary slightly.
Install the “L” Shaped Bracket
Attach the “L” shaped bracket to the top of the
cabinet as shown below using the provided 9.5 mm
(3/8 inch) screws (x4).
Note: The “L” shaped bracket may come factory
installed on some models.
Install the Side Curtains
Attach the side curtains to the cabinet by sliding the
curtain frame into the side channel of the cabinet as
shown below.
The curtains are labeled “left” and “right on the
frames. This refers to the left and right sides of the
appliance when facing the front of the appliance.
3

INSTALLATION INSTRUCTIONS
INSTALLATION
Cut the regular foam seal to fit the area of the
window sill that the air conditioner will rest on.
Place the air conditioner into the window with the
“L” shaped mounting bracket positioned in front of
the upper sash. The bottom of the cabinet should be
positioned on the recessed portion of the window
frame. Pull the upper window sash down until it
rests just behind the front flange of the “L” shaped
mounting bracket.
Expand the side curtains on each side and secure
the top of the frames to the window sash using one
13 mm (1/2 inch) screw on each side of the “L”
shaped mounting bracket.
Attach the clamps on the lower part of each curtain
to the window sill using one 13 mm (1/2 inch)
screw on each side of the cabinet.
Place the adhesive foam seal into the opening
between the inside and outside windows and
attached the safety lock to the outside window frame
using two 13 mm (1/2 inch) screws.
4
Check the Tilt Angle
The air conditioner should be tilted downward
towards the outside approximately 3° to 4°. This
tilt will encourage any condensed water to drain
to the outside. If any condensed water leaks to the
inside of the house, check the tilt angle and adjust
as necessary.
Measure the tilt angle from the front of the cabinet’s
edge. The difference in height between the front and
the back of the appliance, labeled “A” on the image
below, should be approximately 19 mm - 2.5 cm
(3/4 inch - 1 inch).
A
Install the Foam Inserts
The foam inserts can block any cracks or spaces
in the side curtains and help maintain the energy
efficiency of the appliance.
After the appliance is installed in the window,
measure the width of the side curtains from the side
of the appliance to the edge of the curtain.
If necessary, cut the foam insert to the correct size
and then slide the foam insert into the slots in the
side curtain. The supplied weather stripping can
be used to block any other cracks or spaces as
required.
12345678910 12
1113
14 15
56
1234

FEATURES
1. Cabinet
2. Exterior Air Inlet
3. Interior Air Outlet
4. Interior Air Inlet
5. Control Panel
6. Air Filter (not pictured)
1
23
4
5
CONTROL PANEL
1. Up and Down Arrows: Used to adjust the set
temperature and the timer function.
2. Display Panel: Displays the set temperature, the
ambient temperature and the timer settings. To
change the temperature scale being displayed,
press the up and down buttons at the same time.
3. Timer Button: Used to set the auto on and auto
off timer.
4. Filter Button: The indicator light will illuminate
as a reminder to check the filter. Once the filter
has been cleaned, use this button to resume
operation.
5. Sleep Button: Used to set the Sleep function.
6. Ionizer Button: Used to set the ionizer function.
7. Mode Button: Used to choose the operating
mode.
8. Fan Button: Used to set the fan speed. The fan
can be set to Low, Medium, High and Auto.
9. Remote Control Receiver: Ensure this receiver
is not obscured by curtains or other items as it
could impact remote control functioning.
10.Energy Saver Button: Used to set the energy
saver function.
11.Power Button: Used to turn the appliance on or
off.
12.Follow Me Indicator Light: Illuminates when the
Follow Me function is active. Follow Me can only
be set from the remote control.
OPERATING INSTRUCTIONS
12
3
45
6
78
9
10 11
12
5

6
OPERATING INSTRUCTIONS
REMOTE CONTROL
1. Mode Button: Used to choose the operating
mode.
2. Energy Saver Button: Used to set the energy
saver function.
3. Ionizer Button: Used to set the ionizer function.
4. Follow Me Button: Used to set the Follow Me
function.
5. Sleep Button: Used to set the Sleep function.
6. LED Button: Press to turn the LED back light on
or off.
7. Clock Button: Press and hold the button for
3 seconds in order to set the clock. Press the
Up and Down Arrows to adjust the time in 10
minute intervals
Note: The clock feature is only available on the
remote, the appliance does not have a clock. The
remote clock is a 24 hour clock only.
1
2
3
45 6 7
8
9
10
11
12 13
8. Cancel Button: Cancels current Timer settings.
9. Timer Button: Used to set the auto on and auto
off timer.
10.Fan Button: Used to set the fan speed. The fan
can be set to Low, Medium, High and Auto.
11.Up and Down Arrows: Used to adjust the set
temperature and the timer function.
12.Default Button: Press to restore the remote
control default settings.
13.Lock Button: Press this button to lock the remote
control and prevent the settings from being
inadvertently changed.

OPERATING INSTRUCTIONS
This Class B digital apparatus complies with the
Canadian ICES-003 standard. CAN ICES-3 (B)
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against interference in a residential installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation.
If this equipment does cause interference to radio
or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment
and receiver.
3. Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio/TV
technician for help.
Changes or modifications not approved by the
party responsible for FCC compliance could void
the user’s authority to operate the equipment.
This appliance complies with Part 15 of the FCC
Rules.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference
received, including interference that may cause
undesired operation.
REMOTE CONTROL BATTERIES
The remote control requires two AAA alkaline
batteries (included). Batteries should be replaced
when:
a) No sound is heard when attempting to program
the appliance.
b) The appliance does not respond to a command
issued by the remote control.
Battery replacement:
1. Slide the rear cover on the remote in the
direction of the arrow.
2. Insert two AAA batteries following the same
orientation depicted inside the battery chamber
(+/-).
3. Reinstall the rear cover.
4. If the remote control will not be used for
extended periods of time, the batteries should be
removed.
Notes:
• Protect the remote control from high
temperatures, and keep it away from radiation
exposure.
• Keep the control panel receiver out of direct
sunlight.
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (ni-cad, ni-mh,etc) batteries.
• The remote operates within a range of 8 meters
(26 ft.) from the receiver located inside the main
appliance. Any obstruction between the receiver
and remote may cause signal interference,
limiting the ability to program the main unit.
7

8
OPERATING INSTRUCTIONS
FUNCTION INSTRUCTION
Operating Modes
There are four operating modes to choose from.
Press the Mode Button repeatedly to choose the
desired mode. The adjacent indicator light will
illuminate to show which mode has been selected.
• Cool Mode
Choose Cool Mode to set the cooling function. Use
the Up and Down Arrows to choose the desired
temperature. When Cool Mode is selected, the fan
speed can be adjusted by pressing the fan button.
• Dry Mode
Choose Dry Mode to remove excess moisture
from the air during periods of high humidity. All
water pulled from the air will condense inside the
appliance and drain out the back. The fan speed
will be automatically set and cannot be modified in
Dry Mode.
• Fan Mode
Choose Fan Mode to run the internal fan without
engaging the cooling function. Press the fan button
repeatedly to choose the fan speed, Low, Med, High
or Auto.
• Auto Mode
Auto Mode is a pre-set factory program that
automatically defines the mode (Cool or Dry)
and fan speed based on the set temperature, the
ambient temperature and the ambient humidity.
Up and Down Arrows
The Up and Down Arrows will modify the set
temperature in 1°increments.
The Up and Down Arrows will modify the set time of
the timer function in 0.5 hour increments up to 10
hours and then in 1 hour increments up to 24 hours
maximum.
Timer Function
The Timer Function can be used to turn the
appliance on or off after a set period of time.
Auto On Function
1. Press the Timer Button once and the Auto On
indicator light will illuminate.
2. Use the Up and Down Arrows to select the
desired amount of time before the appliance
should turn on.
3. Use the Mode Button to select the desired mode.
4. Use the Fan Button to select the desired fan
speed.
5. The time selected will appear on the display
panel and will count down until the appliance
turns on.
Auto Off Function
1. Press the Timer Button twice and the Auto Off
indicator light will illuminate.
2. Use the Up and Down Arrows to select the
desired amount of time before the appliance
should turn off.
3. The time selected will appear on the display
panel and will count down until the appliance
turns off.
Using Auto On and Auto Off Simultaneously
If there is a need for the appliance to turn on, run
for a set period of time and then turn off, the Auto
On and Auto Off functions can be used at the same
time by first setting one and then the other. Both
indicator lights will illuminate and the display will
count down to the appliance either turning off or
on, whichever function was set first.
Note: The timer will not cycle the appliance on and
off indefinitely. The Auto On and Auto Off timers
will function one time and then the appliance will
return to regular functioning.
Turning the appliance off, pressing the default
button on the remote or unplugging the appliance
will clear all memory settings, including the timer.

OPERATING INSTRUCTIONS
Follow Me Function
There is a temperature sensor built into the remote
control that will continuously collect the current
room temperature. Keep the remote control with
you and the appliance will automatically adjust the
set temperature based on the current temperature
where you are located to reach the most
comfortable condition and temperature.
Press the Follow Me button to activate the Follow
Me function. The remote will display the current
temperature at its location. The remote will send
a signal to the air conditioner every 3 minutes, so
long as you remain within range of the appliance.
The Follow Me light on the control panel of the
appliance will illuminate for 5 seconds every three
minutes to indicate that it has received a signal
from the remote. If the appliance does not receive a
signal from the remote during any 7 minute interval,
it will beep to indicate that the Follow Me mode has
ended.
The maximum distance for the Follow Me feature is
8 meters (26 feet). This feature is available in Cool
and Auto modes.
Sleep Function
The Sleep Function can be used to conserve energy
during sleeping hours.
When selected, the set temperature will increase
by 1°C/2°F every half hour for one full hour. The
appliance will hold the new set temperature for
6 hours before automatically returning to normal
operation.
The Sleep Function can be canceled at any time by
pressing the Sleep Button.
Energy Saver Function
The Energy Saver Function will automatically cycle
the fan on and off when the compressor is not in
use to minimize how often the compressor needs to
turn on. This function is available in Cool, Dry, Auto
Cool and Auto Fan modes.
The fan will continue to run for 3 minutes after the
compressor turns off. The fan will then cycle on for
2 minutes in 10 minute intervals until the ambient
temperature is above the set temperature, at which
point the compressor will turn on and cooling will
resume.
Ionizer Function
The Ionizer Function is a form of air purification that
negatively charges the air. Dust particles, pollen
and other particles in the air cannot pass through
the filter when they are negatively charged. This
ensures that the maximum amount of dust and dirt
are removed from the air. Additionally, the ionizer
function helps to remove unwanted odors from the
air.
9
