Danby Premiere DPAC 11010 Assembly instructions

Owner’s Use and Care Guide
Guide d’utilisation et soins de
Propriètaire
Model • Modèle
DPAC 11010
Danby Products Ltd, PO Box 1778, Guelph, Ontario Canada N1H 6Z9
Danby Products Inc, PO Box 669, Findlay, Ohio USA 45839-0669
Version 2.1.09 JF
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE: If the unit changes ownership, be sure this manual
accompanies the unit.
CONSERVER CES INSTRUCTIONS POUR CONSULTATION ULTÉRIEURE: En cas de revente du l’appareil, ce manuel
doit être inclus avec l’appareil.
CAUTION: Read and
follow all safety rules
and operating
instructions before first
use of this product.
MISE EN GARDE:
Veuillez lire
attentivement les
consignes de sécurité et
les directives
d’utilisation avant
l’utilisation de ce
produit.
PORTABLE AIR CONDITIONER
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
CLIMATISEUR PORTATIF
Table des Matières . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

UNIT SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PART IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
IMPORTANT SAFETY INFORMATION
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Energy Saving Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Window Kit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
OPERATION
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
LCD Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Air Conditioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Dehumidifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Auto Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Clock Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
CARE AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
TABLE OF CONTENTS
1

Thank you for choosing a Danby appliance to provide you and your family with all of the “Home
Comfort” requirements of your home, cottage, or office. This Owner’s Use and Care Guide will
provide you with valuable information necessary for the proper care and maintenance of your new
appliance. If properly maintained, your Danby appliance will give you many years of trouble free
operation. Please take a few moments to read the instructions thoroughly and familiarize yourself
with all of the operational aspects of this appliance.
Your Danby Portable Air-Conditioner is a multi-functional room air-exchanging, air-processing
appliance, designed to offer you the functions of; Air Conditioning, Dehumidifying, and Independent
Fan. Each individual mode is featured with “oscillating” air swing capabilities. This unit can be
conveniently moved from room to room within your home and set up in just minutes. Imagine the
convenience of 4 Season Home Comfort at your fingertips, anywhere,
anytime.
For easy reference, may we suggest you attach a copy of your sales slip/receipt to this page, along
with the following information, located on the manufacturers nameplate on the rear panel of the unit.
Model Number:
Serial Number:
Date of Purchase:
This information will be necessary if your unit requires servicing and/or for
general inquiries. To contact a Customer Service Representative, call Danby TOLL FREE:
Tel: 1-800-26-
(1-800-263-2629)
Model Number DPAC11010
Cooling Capacity 12000Btu/h
Noise Level 52.4dB
Fan Speeds 3
Airflow CFM High/Medium/Low 486 / 426 / 366
Power Source 115 V - 60 Hz
Refrigerant R410A
Unit Weight 35kg (77 lb.)
Unit Dimensions (inches) W x D x H 197/10 x 161/3x 323/4
Unit Dimensions (mm) W x D x H 500 x 415 x 830
Remote Control Yes
Time of Day Clock No
Auto-Timer Yes
NOTE: Continuing research results in steady improvement. Therefore, this information and these
specifications are subject to change without notice.
2
WELCOME
UNIT SPECIFICATIONS

READ ALL SAFETY INFORMATION BEFORE USING
1) All wiring must comply with local and national electrical
codes and be installed by a qualified electrician. If you have
any questions regarding the following instructions, contact a
qualified electrician.
2) Check available power supply and resolve any wiring
problems BEFORE installation and operation of this unit.
3) This appliance draws 10.8 nameplate amps under Cooling
Mode and may be used in any properly wired, general purpose
15 amp household grounded receptacle.
4) For your safety and protection, this unit is grounded
through the power cord plug when plugged into a matching
wall outlet. If you are not sure whether the wall outlets in your
home are properly grounded, please consult a qualified
electrician. DO NOT USE PLUG ADAPTERS OR
EXTENSION CORDS WITH THIS UNIT. If it is necessary to
use an extension cord with this unit, use an approved “air
conditioner” extension cord only (available at most local
hardware stores).
5) The manufacturers nameplate is located on the rear panel of
the unit, and contains electrical and other technical data
specific to this unit.
6) To avoid the possibility of personal injury, always
disconnect the power supply to the unit before installing
and/or servicing.
TABLE 1
Suggested Individual Branch Circuit
Nameplate Amps *AWG Wire Size
10.8 16
AWG- American Wire Gauge
*Based on copper wire at 105°C temperature rating.
TABLE 2
Receptacle and Fuse Types
Rated Volts 125
Amps 15
Wall Outlet
Fuse Size 15
Time Delay Fuse Plug Type
(or Circuit Breaker)
Control Panel
Handle
Hole
Castor
Signal
receptor
Air outlet Air intake
(evaporator)
Air outlet
hose
Power supply cord
Water outlet drain
Air intake
hose
ELECTRICAL
SPECIFICATIONS
CAUTION: Do not leave this unit
unattended in a space where people or
animals cannot react to a failed unit are
located. A failed unit can cause extreme
overheating or death in such an enclosed,
unattended space.
3
UNIT PARTS IDENTIFIED
IMPORTANT SAFETY INFORMATION

The power cord supplied with this air conditioner contains a device that senses damage to
the power cord. To test if your power cord is working properly, you must do the following:
Your Danby appliance is designed to be highly efficient in energy savings. Follow
these recommendations for greater efficiency.
1) Select a thermostat setting that suits your comfort
needs and leave at that chosen setting.
2) The air filter is very efficient in removing airborne
particles. Keep the air filter clean at all times.
3) Use drapes, curtains or shades to keep direct
sunlight from penetrating and heating room, but do not
allow drapes or curtains to obstruct the air flow around
the unit.
4) Start your air conditioner before the outdoor air
becomes hot and uncomfortable, to avoid an initial
period of discomfort while the unit is cooling off the
room. Use of the automatic start/stop programmable
TIMER feature can be a major asset in this regard if
utilized to the fullest extent.
5) When outdoor temperatures are cool enough, turn
the air conditioner off and use the FAN MODE on
HIGH, MED, or LOW. This circulates indoor air,
providing some cooking comfort while utilizing less
electricity.
NOTE: The power cord supplied with this air
conditioner contains a current leakage detection
device designed to reduce the risk of fire. In the event
the power supply cord is damaged, it cannot be
repaired and must be replaced with a new cord from
the product manufacturer.
• Under no circumstances should this device be used
to turn the unit on or off.
• The “RESET” button must always be pushed in
(engaged) for correct operation.
• The power supply cord must be replaced if it fails to
reset when the “TEST” button is pushed in.
1) Connect the power supply cord to an electrical outlet.
2) The power supply cord has two buttons located on
the head of the plug. One button is marked “TEST”,
and the other is marked “RESET”. Press the “TEST”
button; you will hear a click as the “RESET” button
pops out.
3) Press the “RESET” button; you will hear a click as
the button engages.
4) The power supply cord is now energized and
supplying electricity to the air conditioner (on some
products this is also indicated by a light on the plug
head).
POWER
SUPPLY CORD
ENERGY-
SAVING TIPS
4
IMPORTANT SAFETY INFORMATION

ELECTRIC SHOCK HAZARD: To avoid
the possibility of personal injury, disconnect
power to the unit before installing or servicing.
Fig. 1
INSTALLATION ACCESSORIES (FIG. 1)
Flexible Exhaust Hose (13cm) & Exhaust nozzle
connector (2 pcs)... from 17 7/10 (45cm) up to 53 1/6”(135cm)
Adjustable window door slider kit (3 pcs)..... from 28
1/3”(72cm) up to 80” (203cm)
Fixture..... (2 pcs)
Screws...(8 pcs)
NOTE: The exhaust/window kit must be installed at all
times when the unit is operating under AIR
CONDITIONING mode.
INSTALLATION ACCESSORIES
Fig. 2
There should be at least 11.8” (30cm) clearance between the unit and any other objects or building structures,
and should be installed on a level surface. The unit does not have to be vented outside during Dehumidifying
or Fan Only mode operation.
Flexible Exhaust Hose
Exhaust Nozzle
Connector
Fixture
Screws
Adjustable Window Slider Kit:
28 1/3” (72cm)- 80” (203cm)
Back of
Window Panel
Tube Adapters
INSTRUCTIONS FOR ASSEMBLING THE WINDOW
ADAPTER KIT (FIG. 2).
a) Insert tube adapters through the back of the window panel.
b) Secure each tube adapter with four screws through the
front of the window panel.
c) Insert window panel extensions into the window panel.
Lightly tighten the screws in the window panel to hold the
extensions in place.
IMPORTANT
5
INSTALLATION
WARNING
1) Select a suitable location, making sure you
have access to an electrical outlet.
2) Install the flexible hose to the rear side of the
unit. Insert the hose collar on top of the exhaust
opening and twist to lock into position.
3) Install the adjustable Window Slider Kit as
required (see Fig. 3a & 3b).
4) Install the opposite end of the flexible exhaust
hose into the window exhaust adapter.
5) Install the window exhaust adapter into the
opening in the slider section, making sure the
window slider sections are secure.
6) Plug the unit into a 115V/60Hz grounded
electrical outlet.
WINDOW KIT
INSTALLATION
HORIZONTAL
Window Slider Kit:
Min.: 26 5/8” (67.5cm)
Max.: 80” (203cm)
VERTICAL
Window Slider Kit:
Min.: 26 5/8” (67.5cm)
Max.: 80” (203cm)
Fig. 3a Fig. 3b
Your window kit has been designed to fit most standard “vertical”/”horizontal” windows up to
a maximum height of 80” (203cm).For vertical window applications, multi lock positions are
provided on the edge of each slider section to secure each sliding section together.

KEY PAD FUNCTIONS
POWER SWITCH:Turns unit ON/OFF
MODE: Allows you to scroll through and select
desired operating mode.
FAN: Select from three different fan settings;
High, Medium, and Low.
AUTO-TIMER
AUTO-TIMER Adjust:
Auto off- With machine in running mode, press timer
button to set timer control. Press or buttons to
select number of hours you would like the unit to run
before it automatically shuts off.
Auto on- With machine in stand by mode, press timer
button to set timer control. Press or buttons to
select number of hours before the unit automatically
starts running in air conditionning mode.
NOTE: The time is adjustable between 1-24 hours.
TEMPERATURE Adjust:
• Used for adjusting the thermostat.
• The default display is room temperature.
• In cooling mode, when button is pressed,
the set temperature is displayed and may be adjusted.
After 15 seconds the display will revert back to room
temperature. Temperature is only adjustable in cool
mode.
Timer & Temp. Display
Room Temp.
Temp. Set
Timer Set
MODE INDICATOR LIGHTS
Cooling Mode
When cool mode is selected, the indicator light will
shine GREEN. During the cooling mode, the air is
cooled and hot air is exhausted outside through the
exhaust tube. Adjust fan speed to suit your desired
comfort level.
Note: The air exchange h ose must vent outside the
room when using cool mode.
Dehumidify Mode
When dehumidify mode is selected, the indicator
light will shine ORANGE. Air is dehumidified as it
passes through the unit, without being in full
cooling mode. The fan will operate on med. speed.
If room temperature is >25°C (77°F), fan speed can
be adjusted; otherwise fan speed is fixed to “low”.
Note: The warm air exchange hose must vent inside
the room when using Dehumidify Mode, not outside
as it does when cooling. If the unit is vented outside,
some cooling will occur.
Fan Mode
When fan mode is selected, the indicator will shine
YELLOW. Air is circulated throughout the room
with no cooling.
Note: The unit does not need to be vented in Fan
mode.
• During Fan/Dehumidifier mode, the temperature
cannot be set.
FAN SPEED INDICATOR LIGHTS
High Fan
Medium Fan
Low Fan
NOTE: By pressing both buttons at the
same time for more than 3 seconds, the display will
toggle between Celsius and Fahrenheit.
STATUS DISPLAY
Warning Light
Condensed water may accumulate in the unit. If the
internal tank becomes full, the Warning signal in the
LCD Display will light up and the unit will not operate
until the unit has been drained.
NOTE: AFTER SWITCHING THE AIR CONDITIONER OFF, YOU MUST WAIT 3 MINUTES
BEFORE SWITCHING IT BACK ON AGAIN.
6
OPERATING INSTRUCTIONS
FEATURES
OF THE
CONTROL
PANEL

IMPORTANT: The exhaust hose must be properly
vented (outdoors) during air conditioning mode.
1) Press the POWER SWITCH key (Fig. A) to switch on the unit, and the previous
set temperature will be shown in the temperature display area of the control panel.
2) Press the MODE key (Fig. B) until the COOL indicator light illuminates on the
control panel (Fig.C). Each depression of the MODE key will advance to a different
mode setting (Cool-Dehumidifier-Fan-Heat-Auto)
3) Press the appropriate increase or decrease buttons (Fig. D) to select a
suitable operating temperature setting. Temperature settings are adjustable between
16°C (61°F) to 32°C (89°F).
4) Press the FAN key (Fig. E) to select the desired fan speed setting (Auto-High-
Med.-Low). Your selection will appear on the control panel (each depression of the
fan key will advance to a different setting).
• Cooling stops automatically when the set temperature is achieved. Cooling resumes
when the room temp. rises above the “set” temperature level.
Note: During dehumidifier mode, the exhaust hose does not
have to be vented outdoors.
1) Press the ON/OFF key pad to switch the unit on (Fig. A)
2) Press the MODE key (Fig. B) until the DRY indicator illuminates on the
control panel (Fig.G). Each press of the MODE key will advance to a different
mode setting (Cool-Dehumidifier-Fan-Heat-Auto).
3) If room temperature is >25°C (77°F), fan speed can be adjusted. Press the
FAN key (Fig. E) to select the desired FAN SPEED setting. Your selection will
appear on the control. Each depression of the fan key will advance to a
different fan speed as shown in Fig. F. Otherwise fan speed is fixed to “low”.
NOTE: The warm air exchange hoses must vent inside the room when using
Dehumidify Mode, not outside as in Cooling Mode.
DEHUMIDIFIER
7
OPERATING INSTRUCTIONS (cont’d)
AIR CONDITIONING Fig. A
Fig. B
Fig. C Green
Fig. F
Fig. D Fig. E High
Medium
Low
Fig. G
Orange
Fig. H
Fig. I
Fig. J
Yellow
Fig. K Fig. L
Medium
High
Low
FAN NOTE: During Fan Mode, the exhaust hose does not have to be
vented outdoors.
1) Press the POWER SWITCH key to turn the unit on (Fig. H).
2) Press the MODE key (Fig. I) until the FAN indicator illuminates on the
control panel (Fig. J). Each press of the MODE key will advance to a different
mode setting (Cool-Dehumidifier-Fan-Heat-Auto).
3) Press the FAN Key (Fig. K) to select the desired FAN SPEED setting. Your
selection will appear on the control panel. Each press of the fan key will
advance to a different fan speed (High- Med- Low) as shown in Fig. L.

Control Buttons:
1) Power Switch
2) Mode
3) Fan Speed
4) On / Off Timer
5) Time / Temperature Set
• Used for adjusting the timer and temperature.
• The default display on control panel is room temperature.
• When key is pressed in cool mode, the set
temperature is displayed and may be adjusted. After 10 seconds the
display will revert back to room temperature.
• Timer setting is available from 1-24 hours by pressing the
key
To operate the hand held remote control you will require two “AAA”
Alkaline batteries (included).
Batteries should be replaced when:
a) No signal (beep) is heard when attempting to program the main unit.
b) The main unit does not respond to a command issued by the remote
control.
Battery replacement:
1) Slide the rear cover on the remote in the direction of the arrow.
Continue pulling (gently) until the cover separates completely from the
unit.
Notes:
1) Do not drop the remote control.
2) Do not place the remote control in a location exposed to direct sunlight.
3) The remote control should be placed about 1 meter or more away from TV, or any electrical appliances.
This Class B digital apparatus complies with canadian ICES-003.
The functions work the same as your dehumidifier’s touch controls.
Batteries: Remove the cover on the back of the remote control and insert the batteries with the (+) and (-)
poles pointing in the proper direction.
CAUTION: Use only AAA or IEC R03 1.5 V batteries.
• Remove the batteries if the remote control is not used for a month or longer.
• Do not attempt to recharge the supplied batteries.
• All batteries should be replaced at the same time.
• Do not dispose of batteries in a fire as they may explode.
PLACING BATTERIES
IN REMOTE COTROL
REMOTE CONTROL FEATURES
8
2) Insert (2) batteries (AAA) following the same orientation (polarity) depicted inside the battery chamber (+ / -).
3) Re-install rear cover.
4) If the remote control will not be used for extended periods of time (vacations, etc.),
batteries should be removed.
The remote operates within a range of 8 meters (26 ft.) from the receiver located inside the main unit. Any
obstruction between the receiver and remote may cause signal interference, limiting the ability to program the
unit.

CAUTION: Before cleaning or servicing this unit, disconnect from any electrical supply outlet.
1) DO NOT use gasoline, benzene, thinner, or any other chemicals to clean this unit, as these substances may
cause damage to the finish and deformation of plastic parts.
2) Never attempt to clean the unit by pouring water directly over any of the surface areas, as this will cause
deterioration of electrical components and wiring insulation.
3) Unplug the unit.
4) Clean the unit by wiping off any dirt/dust with a soft damp cloth or vacuum cleaner, then wipe dry with a
dry soft cloth.
5) Clean the air intake grill and replace.
CAUTION: Always store the unit in vertical position. DO NOT put heavy objects on top of the unit.
If the air filter becomes clogged with dust/dirt, air flow is restricted, which
reduces cooling efficiency. The air filter should be cleaned every two (2)
weeks. More frequent cleaning may be necessary depending on indoor air
quality.
NOTE: The air filter is located at the upper rear side of the unit.
1) To remove the air filter: Pull the air filter cover upward in the direction of
the arrow (Fig.4) and remove the air filter.
2) Dust/dirt clogged in the filter can be removed by vacuum cleaning the
soiled areas.
3) The filter can also be washed in lukewarm, soapy water while rubbing it
lightly with a brush. A mild detergent (diswashing liquid) is recommended.
4) Rinse the filter well using clean water. Allow time to dry before
reinstalling into the unit.
5) Replace the air filter and cover.
6) Replacement air filter information is available by contacting the Customer
Service Department at:
1-800-26-
1-800-263-2629
CAUTION: Never operate this unit without the air filter in place, as this may result
in damage to the unit.
Fig. 4
CLEANING
THE UNIT
CLEANING THE
AIR FILTER
CARE AND MAINTENANCE
9
