Dancover EXPERT User manual

29-10-2020
Manual
for
Patio Cover Expert
3x5m

2
Legend & Expert
Patio Cover
Dear customer,
Thank you for purchasing one of our patio covers. This
manual
familiar with the product. We kindly ask you to
read this
manual is intended for the end user and the
installer.
This is the original manual. Keep this manual safe!
patio cover
or unwise use.
and you have to purchase it yourself.
..x..
(..x)
underneath.
This product is intended for outdoor use and may get wet.
- Stanley knife or scissors
- Hacksaw
- Cartridge gun with sealant for outside
- Pencil
- Hammer
- Dowels
- Shovel
- Spirit level
•
•
•
patio cover
improper use may cause damage to, or a defect in, the
product. The warranty is void if the product and/or the
electronic components are damaged through improper
and/or using the product.
•
purchased separately.
•
• Contact your supplier if a part is missing or damaged.
• Clean the product every 6 months to ensure a longer
product life.
packaging indicates that this product may not
EU and in other European countries that have separate
the waste device. Recycling materials helps to conserve
natural resources. Do not dispose of your old electrical and

Legend & Expert
1
2 cm
Ø 5 mm
7 cm 7 cm
2 cm 2 cm7 cm
10 cm
1
2
3
10 cm10 cm ±50 cm±50 cm ±50 cm ±50 cm

4
Legend & Expert
15 cm
Ø 5 mm
Ø 5 mm
Ø 5 mm
15 cm
Ø 5 mmØ 5 mm
15 cm15 cm ±50 cm±50 cm ±50 cm ±50 cm
a
4
Ø 5 mm
5 6
angle plate.
Go to step 7 if you want to install spotlights. Go to step 9 if you
are not installing spotlights.
7
9
X

Legend & Expert
82 mm
55 mm
55 mm
7
8
9
32 mm

6
Legend & Expert
1
2
1
2
10 11
12 13
Unscrew the leaf trap nut.
14

7
Legend & Expert
1
2
1
2
Standard
GIGA
15 16
Apply sealant to the leaf trap.
17 18
Apply sealant to the leaf trap.
19

Legend & Expert
1 cm
1 cm
1 cm
20
21
22

9
Legend & Expert
1 cm
1 cm
23
24

Legend & Expert
2Assembly
1
2 3
4
Y
X
56 cm
42 cm 28 cm 14 cm

11
Legend & Expert
4.2x19
(6x)
5 6
7
8

12
Legend & Expert
4.2x19
(1x)
4.2x19
(1x)
9
10
w

Legend & Expert
4.2x19
(7x)
3
2
1
3
2
1
2
1
3
2
1
3
11
12 13
patio cover
14
A

14
Legend & Expert
1 m
2 m
3 m
4 m
56 cm
42 cm 28 cm 14 cm
15 16
Connect the RWP to the sewer.
17 18
Determine the length of the RWP post.
19 20

Legend & Expert
xx mm
xx mm
21
Install the coupling sleeve.
22 23
Determine the length of the drainpipe.
24 25
Insert the drainpipe into the post.

16
Legend & Expert
xx mm
xx mm
4.2x19
(2x)
4.2x19
(1x)
26 27
drainpipe.
28 29
Determine the height of the other posts.
30 31

17
Legend & Expert
4.2x19
(1x)
4.2x19
(1x)
32 33
34 35
36 37

Legend & Expert
X mm
X mm =
xx mm
38
39 40
so that there is a half roof panel width from the middle. Place
the middle of the patio cover.
41
4.2x19
(4x)

19
Legend & Expert
42
43
44
xxx mm
xx mm

Legend & Expert
2
6
5
1
4
3
2
6
5
1
4
3
45
46
47
Please note! Do not place a click frame at the power point yet if you are installing spotlights.
remain
remain
