Danfoss AB-QM Series User manual

1
Installation Guide
AB-QM DN 125-250
Heating Solutions VI.C6.C4.8Y SMT/SI
Installation / Montering / Einbau / Installation / Installatie / Installation / Asennus / Montaż / Uzstādīšana / Beépítés / Montaj / Монтаж /
Instalace / 安装 / Vgradnja / Instalación / Montavimas
AB-QM DN 125 AB-QM DN 150 AB-QM DN 200/250
+
+
AME 55 QM
AME 85 QM
Code No.: 003Z0696
For latest prices and delivery to your door visit MyTub Ltd - www.mytub.co.uk - [email protected]

2
AB-QM DN 125/150 +
AME 55 QM
AB-QM DN 200/250 +
AME 85 QM
IP 54 IP 54
Installation / Montering / Einbau / Installation / Installatie / Installation / Asennus / Montaż / Uzstādīšana / Beépítés / Montaj / Монтаж /
Instalace / 安装 / Vgradnja / Instalación / Montavimas
Temp. −10 ... 120 °CΔpmax. = 400 kPaPN 16
Installation Guide AB-QM DN 125-250
SMT/SI VI.C6.C4.8Y Heating Solutions
For latest prices and delivery to your door visit MyTub Ltd - www.mytub.co.uk - [email protected]

3
Setting / Indstilling / Einstellung / Réglage / Instelling / Inställning / Asettelu / Wykonywanie nastawy / Iestādījumi / Beállítás /
Ayarlama / Настройка / Nastavení / 设定 / Nastavitev / Ajuste / Nustatymas
Measuring / Måling / Messung / Mesure / Meten / Mätning / Mittaaminen / Wykonywanie pomiarów / Mērīšana / Mérés / Ölçüm /
Измерение / Měření / 测量 / Merjenje / Medida / Matavimas
+
–
Setting 60%
+
–
Note:
DN 125 & 150: 1 turn = 5.0 %
DN 200 & 250: 1 turn = 5.5 %
DN 125 Flow High Flow
L/h L/s GPM L/h L/s GPM
40% 36.000 10,00 158 44.000 12,22 194
45% 40.500 11,25 178 49.500 13,75 218
50% 45.000 22,50 188 55.000 15,28 242
55% 49.500 13,75 218 60.500 16,81 266
60% 54.000 15,00 238 66.000 18,33 290
65% 58.500 16,25 257 71.500 19,86 315
70% 63.000 17,50 277 77.000 21,39 339
75% 67.500 18,75 297 82.500 22,92 363
80% 72.000 20,00 317 88.000 24,44 387
85% 76.500 21,25 337 93.500 25,97 411
90% 81.000 22,50 356 99.000 27,50 436
95% 85.500 23,75 376 104.500 29,03 460
100% 90.000 25,00 396 110.000 30,56 484
105% 95.000 26,39 418 115.000 31,94 506
110% 100.000 27,78 440 120.000 33,33 528
Note: 1 turn = 5,0%
DN 150 Flow High Flow
L/h L/s GPM L/h L/s GPM
40% 58.000 16,11 255 76.000 21,11 334
45% 65.250 18,13 287 85.500 23,75 376
50% 72.500 20,14 319 95.000 26,39 418
55% 79.750 22,15 351 104.500 29,03 460
60% 87.000 24,17 383 114.000 31,67 502
65% 94.250 26,18 415 123.500 34,31 543
70% 101.500 28,19 447 133.000 36,94 585
75% 108.750 30,21 479 142.500 39,58 627
80% 116.000 32,22 510 152.000 42,22 669
85% 123.250 34,24 542 161.500 44,86 711
90% 130.500 36,25 574 171.000 47,50 752
95% 137.750 38,26 606 180.500 50,14 794
100% 145.000 40,28 638 190.000 52,78 836
105% 152.500 42,36 671 209.500 58,19 922
110% 160.000 44,44 704 229.000 63,61 1.008
Note: 1 turn = 5,0%
p1−p3
AB-QM DN 150
AB-QM DN 125
P1 − P3
p1−p3
Installation Guide AB-QM DN 125-250
Heating Solutions VI.C6.C4.8Y SMT/SI
For latest prices and delivery to your door visit MyTub Ltd - www.mytub.co.uk - [email protected]

DN 200 Flow High Flow
L/h L/s GPM L/h L/s GPM
40% 76.000 21,11 334 100.000 27,78 440
45% 85.500 23,75 376 112.500 31,25 495
50% 95.000 26,39 418 125.000 34,72 550
55% 104.500 29,03 460 137.500 38,19 605
60% 114.000 31,67 502 150.000 41,67 660
65% 123.500 34,31 543 162.500 45,14 715
70% 133.000 36,94 585 175.000 48,61 770
75% 142.500 39,58 627 187.500 52,08 825
80% 152.000 42,22 669 200.000 55,56 880
85% 161.500 44,86 711 212.500 59,03 935
90% 171.000 47,50 752 225.000 62,50 990
95% 180.500 50,14 794 237.500 65,97 1.045
100% 190.000 52,78 836 250.000 69,44 1.100
105% 199.500 55,42 878 262.500 72,92 1.155
110% 209.000 58,06 920 275.000 76,39 1.210
115% 218.500 60,69 961 287.500 79,86 1.265
120% 228.000 63,33 1.003 300.000 83,33 1.320
Note: 1 turn = 5,5%
DN 250 Flow High Flow
L/h L/s GPM L/h L/s GPM
40% 112.000 31,11 493 148.000 41,11 651
45% 126.000 35,00 554 166.500 46,25 733
50% 140.000 38,89 616 185.000 51,39 814
55% 154.000 42,78 678 203.500 56,53 895
60% 168.000 46,67 739 222.000 61,67 977
65% 182.000 50,56 801 240.500 66,81 1.058
70% 196.000 54,44 862 259.000 71,94 1.140
75% 210.000 58,33 924 277.500 77,08 1.221
80% 224.000 62,22 986 296.000 82,22 1.302
85% 238.000 66,11 1.047 314.500 87,36 1.384
90% 252.000 70,00 1.109 333.000 92,50 1.465
95% 266.000 73,89 1.170 351.500 97,64 1.547
100% 280.000 77,78 1.232 370.000 102,78 1.628
105% 294.000 81,67 1.294 388.500 107,92 1.709
110% 308.000 85,56 1.355 407.000 113,06 1.791
115% 322.000 89,44 1.417 425.500 118,19 1.872
120% 336.000 93,33 1.478 444.000 123,33 1.954
Note: 1 turn = 5,5%
AB-QM DN 200/250
Measuring / Måling / Messung / Mesure / Meten / Mätning / Mittaaminen / Wykonywanie pomiarów / Mērīšana / Mérés / Ölçüm /
Измерение / Měření / 测量 / Merjenje / Medida / Matavimas
p1−p3
Installation Guide AB-QM DN 125-250
73693690/VI.C6.C4.8Y Produced by Danfoss A/S © 02/2014
