Danfoss Old ICAD 600 series User manual

© Danfoss A/S (RC-CMS/MWA), 11-2005 DKRCI.PI.HV0.A2.02 / 520H0546 1
027R9778027R9778
Fig. 1Fig. 2Fig. 3Fig. 4ICAD 600ICAD 900ICAD 600ICAD 900Fig. 5a, ICM + ICAD 600 Fig. 5b, ICM + ICAD 900mmin.H451.77L3251NmLB-feet32.52.5 mm Instruction Actuator ICAD 600 / ICAD 900

2 DKRCI.PI.HV0.A2.02 / 520H0546 © Danfoss A/S (RC-CMS/MWA), 11-2005 Terminal boxControl cableSupply cableICADICADTerminal boxICAD 600/900 - Analog I/O for modulating controlFig. 6Fig. 7Fig. 8ReferenceColorDescriptionAWhite–Common AlarmBBrown–ICM fully openCGreen–ICM fully closedDYellow–GND groundEGrey+0/4 - 20 mA InputFPink+0/2 - 10 V InputGBlue+0/4 - 20 mA OutputIWhite+Fail safe supplyBattery / UPS* 19 V d.c.IIBrown+Supply voltage24 V d.c.IIIGreen–
}
}
Digital OuputAnalog In/OutputICADTerminal boxICAD 600/900 - Digital I/O for ON/OFF valve operationICAD 600/900* Uninterruptible Power SupplyOnly possible with EKC 347Auxiliary relays

© Danfoss A/S (RC-CMS/MWA), 11-2005 DKRCI.PI.HV0.A2.02 / 520H0546 3InstallationUseICAD 600 and ICAD 900 can be used together with the following Danfoss valves (fig. 1, 5a and 5b).ICAD 600ICAD 900ICM 20ICM 40ICM 25ICM 50ICM 32ICM 65Electrical dataSupply voltage is galvanically isolated from in-/output.Supply voltage24 V d.c., +10% / -15%Load ICAD 600: 1.2 A ICAD 900: 2.0 AFail safe supplyMin. 19 V d.c.Load ICAD 600: 1.2 A ICAD 900: 2.0 AAnolog input - Current or VoltageCurrent0/4 - 20 mALoad: 200 Ω
Voltage0/2 - 10 V d.c.Load: 10 kΩ
Analog output0/4 - 20 mALoad: ≤ 250 Ω
Digital input - Digital ON/OFF input by means of voltfree contact (Signal/Telecom relays with gold-plated contacts recommended) – Voltage input used
ON: contact impedance < 50 Ω)OFF: contact impedance > 100 kΩ
Digital output - 3 pcs. NPN transistor outputExternal supply: 5 - 24 V d.c. (same supply as for ICAD can be used, but please note that the galvanically isolated system will then be spoiled).Output load: 50 Ω
Load: Max. 50 mATemperature range (ambient)–30°C/+50°C (–22°F/122°F)EnclosureIP 65 (~NEMA 4)Cable connection
Two 1.8 m. (70.7 in.) cables premounted
Supply cable3 x 0.25 mm2 (3 x ~24 AWG) (fig. 6) I: White (+) 19 - 24 V d.c. fail safe supply (optional). II: Brown (+) 24 V d.c. III: Green (–) 24 V d.c.
ENGLISH
Control cable7 x 0.25 mm2 (7 x ~24 AWG) (fig. 7) A: White (–) Digital output. Common Alarm. B: Brown (–) Digital output. ICM fully open. C: Green (–) Digital output. ICM fully closed. D: Yellow (–) GND - Ground. E: Grey (+)
Analog input 0/4-20 mA.
F: Pink (+) Analog input 0/2-10 V / Digital ON/OFF input. G: Blue (+)
Analog output 0/4-20 mA.
Electrical installationGeneral procedure for ICAD 600/900 installed on all ICM valves.All necessary electrical connections to be made. Analog or digital operation of ICM valve.Fig. 6Analog operation - 7 wired cable (A-G) Modulation control. ICM valve to be controlled from Danfoss electronics, type EKC (fig. 7), or third party electronics (like e.g. PLC).Connect analog input signals. Currrent (mA) or Voltage (V). See Parameter list for configuration of analog input signals.Grey (+) and Yellow (GND) are used for current (mA) input. orPink (+) and Yellow (GND) are used for Voltage (V) input.Blue (+) and Yellow (GND) are used for current (mA) output (optional, not mandatory). Fig. 6Digital operation - 7 wired cable (A-G) ON/OFF ICM solenoid valve operation. ICM valve to be controlled by means of a digital voltfree contact.Connect digital input signals (fig. 8). See Parameter list for configuration of digital input signals.Pink (+) and Yellow (GND) are connected to a voltfree contact.Digital output signals are optional, not mandatory.White (–) and Yellow (GND) are connected to auxiliary relay for Common Alarm.Brown (–) and Yellow (GND) are connected to an auxiliary relay indicating ICM fully open.Green (–) and Yellow (GND) are connected to an auxiliary relay indicating ICM fully closed.Supply voltage - 3 wired cable (I, II, III) ICAD must be connected to a normal 24 V d.c. supply. As an option, a fail safe supply is possible by means of a battery or UPS (Uninterruptible Power Supply). When voltage is applied as described below, ICAD is ready to be configurated. See Parameter list. ICAD configuration can be done independently whether the ICAD is installed on the ICM valve or not. See Mechanical installation.Connect the Brown (+) and Green (–) to a 24 V d.c. supply voltage (fig. 6).
Fail safe supply as an option (not mandatory).
Connect the White (+) and Green (–) to a fail safe supply.Mechanical installationGeneral procedure for ICAD 600/900 installed on all ICM valves (fig. 3).Check that the three socket set screws are fully unscrewed counter clockwise with a 2.5 mm Hexagon key.Mount ICAD by slowly lowering it on top of the ICM valve.The magnet coupling will drag the ICM and ICAD together and in position.Push ICAD in place.Fasten ICM and ICAD with the three socket set screws using a 2.5 mm Hexagon key.Special moisture seal is damaged if screws are removed (fig. 3, pos. A)StartupWhen voltage is applied for the first time the display on the ICAD (fig. 2) will alternate between showing: Actual opening degree and A1.A1 indicates an alarm which corresponds to: No ICM valve selected. See Alarms for further information.Please observe that when the correct ICM valve is entered in parameter ¡26 (see p. 5 for Parameter list) an automatic calibration is carried out. I.e it is not necessary to carry out another calibration in parameter ¡05.See Parameter list for selecting the correct It is important to select and verify correct valve.

4 DKRCI.PI.HV0.A2.02 / 520H0546 © Danfoss A/S (RC-CMS/MWA), 11-2005 ICM valve.General OperationICAD is equipped with an MMI (Man Machine Interface) from which it is possible to see and change different parameters to adapt the ICAD and the corresponding ICM to the actual refrigeration application. The operation of parameters is done by means of the integrated ICAD MMI (fig. 2) and consists of:123Down arrow push button
(fig. 2, pos. 1) decreases parameter number by 1 for each activationEnter push button (fig. 2, pos. 2)Gives access to the Parameter list by keeping the push button activated for 2 seconds. A Parameter list is shown below (parameter ¡08):Gives access to change a value once the Parameter list has been accessed.Acknowledge and save change of value of a parameter.To exit from the Parameter list and return to the display of Opening Degree (OD) keep the push button activated for 2 seconds.Up arrow push button (fig. 2, pos. 3)Increases parameter number by 1 for each activationDisplay (fig. 2, pos. 4)Normally the Opening Degree (OD) 0 - 100 % of the ICM valve is displayed. No activation of push buttons for 20 seconds means that the display will always show OD. Like below:Displays the parameterDisplays the actual value of a parameter.
Displays the status by means of text (fig. 2, pos. 4)
Mod represents that ICAD is positioning the ICM valve according to an analog input signal (Current or Voltage).Low represents that ICAD is operating the ICM valve like an ON/OFF solenoid valve with low speed according to a digital input signal.Med represents that ICAD is operating the ICM valve like an ON/OFF solenoid valve with medium speed according to a digital input signal.High represents that ICAD is operating the ICM valve like an ON/OFF solenoid valve with high speed according to a digital input signal. Like below:AlarmsICAD can handle and display different alarms.DescriptionICMalarm textCommentsNo valve type selectedA1At start-up
A1 and CA will be displayed
Controller faultA2Internal fault inside electronicsAIl input errorA3
Not active if ¡01 = 2 or ¡02 = 2When ¡03 = 1 and AI A > 22 mAWhen ¡03 = 2 and AI A > 22 mAor AI A < 2 mAWhen ¡03 = 3 and AI A >12 VWhen ¡03 = 4 and AI A >12 Vor AI A < 1 V
Low voltage of fail safe supplyA4If 5 V d.c. < Fail safe supply < 18 V d.c.Check Supply to ICADA5If supply voltage < 18 V d.c.If an alarm has been detected the display at ICAD (fig. 2) will alternate between showing:Actual alarm and present Opening Degree.If more than one alarm is active at the same time only the alarm with the highest priority will appear. A1 has the highest priority, A5 the lowest.Any active alarm will activate the Common Digital Alarm output (Normally Open).All alarms will automatically reset them-selves when they physically disappear.Old alarms (alarms that have been active, but have physically disappeared again) can be found in parameter ¡11.Disposal Note The Product contains electrical components And may not be disposed together with domestic waste. Equipment must be separate collected with Electrical and Electronic waste. According to Local and currently valid legislation.

© Danfoss A/S (RC-CMS/MWA), 11-2005 DKRCI.PI.HV0.A2.02 / 520H0546 5Parameter listDescriptionDisplay nameMin.Max.Factory settingUnitCommentsICM OD (Opening Degree)-0100-%ICM valve Opening Degree is displayed during normal operation.Running display value (see ¡01, ¡05).Main Switch¡01121-Internal main switch1: Normal operation2: Manual operation. Valve Opening Degree will be flashing. With the down arrow and the up arrow push buttons the OD can be entered manually. Mode¡02121-Operation mode1: Modulating – ICM positioning according to Analog Input (see ¡03)2: ON/OFF - operating the ICM valve like an ON/OFF solenoid valve controlled via Digital Input. See also ¡09.Analog Input signal¡03142-Type of Analog Input signal from external controller1: 0 - 20 mA2: 4 - 20 mA3: 0 - 10 V4: 2 - 10 VSpeed at ON/OFF and Modulating Mode¡041100100%Speed can be decreased. Max. speed is 100 %Not active when ¡01 = 2If ¡02 = 2 the display will indicate speed in display. Low, Med and High also means ON/OFF operation.If ¡04 < = 33, Low is displayed33 < If ¡04 < = 66, Med is displayedIf ¡04 > = 67 High is displayedAutomatic calibration¡05010-Not active before ¡26 has been operated.Always auto reset to 0.CA” will flash in the display during calibration, if Enter push button has been activated for two seconds. Analog Output signal¡06022-Type of A0 signal for ICM valve position0: No signal1: 0 - 20 mA2: 4 - 20 mAFail safe¡07141-Define condition at power cut when fail safe is installed.1: Close valve2: Open valve3: Maintain valve position4: Go to OD given by ¡12Digital Input function¡09121Define function when DI is ON (short circuited DI terminals) when ¡02 = 21: Open ICM valve (DI = OFF = > Close ICM valve)2: Close ICM valve (DI = OFF = > Open ICM valve)Password¡1001990-Enter number to access password protected parameters: ¡26Password = 11Old Alarms¡11A1A99--Old alarms will be listed with the latest shown first. Alarm list can be reset by means of activating down arrow and up arrow at the same time for 2 seconds.OD at powercut¡12010050-Only active if ¡07 = 4If fail safe supply is connected and powercut occurs ICM will go to entered OD.ICM configuration¡26060NB: Password protected. Password = 11At first start up A1 will flash in display. Enter valve type0: No valve selected. Alarm A1 will become active.1: ICM20 with ICAD 6002: ICM25 with ICAD 6003: ICM32 with ICAD 6004: ICM40 with ICAD 9005: ICM50 with ICAD 9006: ICM65 with ICAD 900ServiceDescriptionDisplay nameMin.Max.Factory settingUnitCommentsOD %¡500100-%ICM valve Opening DegreeAI [mA]¡51020-mAAnalog Input signalAI [V]¡52010-VAnalog Input signalAO [mA]¡53020-mAAnalog Output signalDI¡5401--Digital Input signalDO Close¡5501--Digital Output Closed status. ON when OD < 3 %DO Open¡5601--Digital Output Open status. ON when OD > 97 %DO Alarm¡5701--Digital Output alarm status. ON when an alarm is detectedMAS mP SW ver. ¡580100--Software version for MASTER MicroprocessorSLA mP SW ver. ¡590100--Software version for SLAVE MicroprocessorReset to factory setting:1. Remove the power supply.2. Activate down arrow and up arrow push buttons at the same time.3. Connect the power supply.4. Release down arrow and up arrow push buttons.5. When the display on ICAD (fig. 2) is alternating between showing: CA and A1 the factory resetting is complete.

6 DKRCI.PI.HV0.A2.02 / 520H0546 © Danfoss A/S (RC-CMS/MWA), 11-2005

© Danfoss A/S (RC-CMS/MWA), 11-2005 DKRCI.PI.HV0.A2.02 / 520H0546 7

8 DKRCI.PI.HV0.A2.02 / 520H0546 © Danfoss A/S (RC-CMS/MWA), 11-2005 Name and Address of Manufacturer within the European CommunityDanfoss Industrial RefrigerationStormosevej 10 DK-8361 Hasselager DenmarkDeclarationWe hereby declare that below-mentioned equipment is in conformity with below mention directives, standards or othernormative documents, provided it is used according to our instructions.Description of EquipmentActuator for ICM valvesType ICAD 600 / ICAD 900DECLARATION OF CONFORMITYAuthorised Person for the Manufacturer within the European Community Name: Michael Breumsoe Title: Production ManagerSignature: Date: 02/11/2005 References of other Technical Standards and Specifications used CE according to 89/336 EEC (EMC)Emission : EN61000-6-3Immunity: EN61000-6-2
