Danfoss VACON 100 flow User guide

Application Guide
VACON® 100 FLOW
drives.danfoss.com

1
1.1
1.2
1.3
1.4
1.5
1.6
1.6.1
2
2.1
2.1.1
2.1.2
2.2
2.3
2.3.1
2.3.2
2.3.3
2.3.4
2.3.5
2.3.5.1
2.3.5.2
2.3.5.3
2.3.5.4
2.3.5.5
2.3.6
2.3.7
2.3.8
2.3.9
2.4
2.4.1
2.4.2
2.4.3
2.4.4
2.4.4.1
2.4.4.2
2.4.4.3
Contents
Introduction 11
Purpose of this Application Guide 11
Manual and Software Version 11
Additional Resources 11
Parameter Table Reading Guide 11
Functions of the AC Drive 12
Start-up Quick Guide 13
Start-Up Wizard 13
User Interfaces 14
Description of the Control Panel 14
Control Panel and the Keypad 14
Displays of the Control Panel 14
Menu Structure 15
Graphical Display 18
Editing the Text Values 18
Editing the Numerical Values 18
Selecting More than 1 Value 19
Resetting a Fault 19
[FUNCT] Button 19
Different Control Places 19
Changing the Control Place 20
Going into the Control Page 20
Changing the Rotation Direction 21
Using the Quick Edit Function 22
Copying the Parameters of an AC Drive 22
Comparing the Parameters 23
Reading Help Texts 24
Using the Favourites Menu 24
Text Display 24
Editing the Text Values 24
Editing the Numerical Values 25
Resetting a Fault 19
[FUNCT] Button 25
Different Control Places 19
Changing the Control Place 25
Going into the Control Page 26
AB298035655957en-000201/DPD01083 | 3Danfoss A/S © 2023.08
Contents
VACON® 100 FLOW
Application Guide

2.4.4.4
2.4.4.5
2.5
3
3.1
3.2
3.3
3.4
3.5
4
4.1
4.1.1
4.1.2
4.1.3
4.1.4
4.1.5
4.2
4.2.1
4.2.2
5
5.1
5.2
5.2.1
5.3
5.3.1
5.3.2
5.3.3
5.3.4
5.4
5.4.1
5.4.2
5.5
5.6
5.7
5.8
5.9
Changing the Rotation Direction 27
Using the Quick Edit Function 22
VACON® Live PC Tool 27
Applications 29
Using the Applications 29
Standard and HVAC Applications 29
PID Control Application 33
Multi-pump (Single Drive) Application 37
Multi-pump (Multidrive) Application 44
Wizards 68
Application Wizards 68
Standard Application Wizard 68
HVAC Application Wizard 68
PID Control Application Wizard 69
Multi-pump (Single Drive) Application Wizard 70
Multi-pump (Multidrive) Application Wizard 72
Function Wizards 73
Wizards in Menu 1.1 73
Fire Mode Wizard 73
Monitor Menu 75
Uses of the Monitor Menu 75
Multimonitor Monitoring 75
Changing the Items to Monitor 75
Trend Curve Monitoring 75
Uses of the Trend Curve 75
Changing the Values in Trend Curve Monitoring 75
Stopping the Progression of the Curve 76
Trend Curve Parameters 77
Basic Monitoring 77
Uses of the Basic Monitoring 77
Basic Monitoring Parameters 78
I/O Monitoring 78
Temperature Inputs 79
Extras and Advanced 79
Timer Functions Monitoring 81
PID Controller Monitoring 81
AB298035655957en-000201/DPD010834 | Danfoss A/S © 2023.08
Contents
VACON® 100 FLOW
Application Guide

5.10
5.11
5.12
5.13
5.14
5.15
6
6.1
6.2
6.3
6.4
6.5
6.6
6.7
6.8
6.9
6.10
6.11
6.12
6.13
6.14
6.15
6.16
6.17
6.18
6.19
6.20
6.21
6.22
7
7.1
7.1.1
7.1.2
7.1.2.1
7.1.2.2
7.1.2.3
7.1.3
External PID Controller Monitoring 82
Multi-pump Monitoring 82
Monitoring of Maintenance Counters 83
Fieldbus Process Data Monitoring 83
Drive Customizer Monitoring 85
Condition-based Monitoring 85
Parameters Menu 88
Group 3.1: Motor Settings 88
Group 3.2: Start/Stop Setup 90
Group 3.3: References 91
Group 3.4: Ramps and Brakes Setup 94
Group 3.5: I/O Configuration 95
Group 3.6: Fieldbus Data 102
Group 3.7: Prohibit Frequencies 104
Group 3.8 Supervisions 104
Group 3.9: Protections 105
Group 3.10: Automatic Reset 108
Group 3.11: Application Settings 109
Group 3.12: Timer Functions 110
Group 3.13: PID Controller 112
Group 3.14: External PID Controller 120
Group 3.15: Multi-pump 123
Group 3.16: Maintenance Counters 125
Group 3.17: Fire Mode 126
Group 3.18: Motor Preheat Parameters 127
Group 3.19: Drive Customizer 127
Group 3.21: Pump Control 127
Group 3.23: Advanced Harmonic Filter 130
Group 3.24: Condition-based Monitoring 130
Diagnostics Menu 135
Faults 135
Uses of the Active Faults Submenu 135
Reset Faults 135
Resetting Faults with the [BACK/RESET] Button 135
Resetting Faults with a Parameter on the Graphical Display 135
Resetting Faults with a Parameter on the Text Display 135
Uses of the Fault History 136
AB298035655957en-000201/DPD01083 | 5Danfoss A/S © 2023.08
Contents
VACON® 100 FLOW
Application Guide

7.1.3.1
7.1.3.2
7.2
7.2.1
7.2.2
7.2.3
7.3
7.4
7.5
8
8.1
8.2
8.3
8.4
8.5
8.6
8.7
8.8
8.9
8.10
9
9.1
9.1.1
9.1.2
9.1.3
9.1.4
9.2
9.2.1
9.2.2
9.2.3
9.3
9.3.1
9.3.2
9.3.3
10
10.1
Examining the Fault History on the Graphical Display 136
Examining the Fault History on the Text Display 137
Counters 137
Using the Counters 137
Total Counters 137
Trip Counters 138
Software Info 139
Drive Info 139
Unit Status 139
I/O and Hardware Menu 140
Basic I/O 140
Option Board Slots 140
Real-time Clock 141
Simple Network Time Protocol (SNTP) 141
Power Unit Settings 142
Keypad 142
Fieldbus 143
Fieldbus General 145
STO 146
Fieldbus Redundancy 146
User Settings, Favourites, and User Level Menus 147
User Settings 147
User Settings Parameters 147
Parameter Back-up Parameters 147
Parameter Compare Parameters 148
License Parameters 148
Favourites 148
Using the Favourites Menu 148
Adding an Item to the Favourites 148
Removing an Item from the Favourites 148
User Levels 149
Using the User Levels Menu 149
The User Level Parameters 149
Changing the Access Code of the User Levels 150
Monitoring Value Descriptions 151
Multimonitor 151
AB298035655957en-000201/DPD010836 | Danfoss A/S © 2023.08
Contents
VACON® 100 FLOW
Application Guide

10.2
10.3
10.4
10.5
10.6
10.7
10.8
10.9
10.10
10.11
10.12
10.13
10.13.1
10.13.2
10.13.3
10.13.4
11
11.2
11.3
11.3.1
11.3.2
11.3.3
11.3.4
11.3.5
11.3.6
11.4
11.4.1
11.5
11.5.1
11.5.2
11.5.3
11.5.4
11.6
11.6.1
11.6.2
11.6.3
11.6.4
Basic 152
I/O 153
Temperature Inputs 154
Extras and Advanced 155
Timer Functions 156
PID Controller 157
External PID Controller 158
Multi-pump 158
Maintenance Counters 159
Fieldbus Data 159
Drive Customizer 162
Condition-based Monitoring 163
Baseline Data 163
Stator Winding Monitor 164
Vibration 164
Load 165
Parameter Descriptions 166
Trend Curve 166
Motor Settings 167
Motor Nameplate Parameters 167
Motor Control Parameters 167
Motor Limits 171
Open Loop Parameters 171
I/f Start Function 174
Torque Stabilator Function 175
Start/Stop Setup 176
Start and Stop Commands in Different Control Places 176
References 184
Frequency Reference 184
Preset Frequencies 185
Motor Potentiometer Parameters 188
Flushing Parameters 189
Ramps and Brakes Setup 189
Ramp 1 189
Ramp 2 190
Start Magnetizing 192
DC Brake 192
AB298035655957en-000201/DPD01083 | 7Danfoss A/S © 2023.08
Contents
VACON® 100 FLOW
Application Guide

11.6.5
11.7
11.7.1
11.7.1.1
11.7.1.2
11.7.1.3
11.7.1.4
11.7.1.5
11.7.1.6
11.7.1.7
11.7.2
11.7.3
11.7.4
11.7.5
11.7.6
11.7.7
11.8
11.9
11.10
11.11
11.11.1
11.11.2
11.11.3
11.11.4
11.11.5
11.11.6
11.12
11.13
11.14
11.14.1
11.14.2
11.14.3
11.15
11.15.1
11.15.2
11.15.3
11.15.4
11.15.5
Flux Braking 192
I/O Configuration 193
Programming of Digital and Analog Inputs 193
General Information on the Programming 193
Programming of Digital Inputs 194
Programming of Digital Inputs in the Graphical Display 196
Programming of Digital Inputs in the Text Display 196
Programming of Analog Inputs 197
Programming of Analog Inputs in the Graphical Display 199
Programming of Analog Inputs in the Text Display 199
Descriptions of Signal Sources 199
Default Functions of Programmable Inputs 200
Digital Inputs 200
Analog Inputs 205
Digital Outputs 209
Analog Outputs 212
Fieldbus Data 215
Prohibit Frequencies 217
Supervisions 219
Protections 219
General 219
Motor Thermal Protections 221
Motor Stall Protection 224
Underload (Dry Pump) Protection 225
Quick Stop 227
AI Low Protection 228
Automatic Reset 229
Application Settings 232
Timer Functions 232
Introduction to Timer Functions 232
Time Channels, Intervals, and Timers 233
Editing an Interval 235
PID Controller 236
Basic Settings 236
Setpoints 238
Feedback 239
Feedforward 239
Sleep Function 240
AB298035655957en-000201/DPD010838 | Danfoss A/S © 2023.08
Contents
VACON® 100 FLOW
Application Guide

11.15.6
11.15.7
11.15.8
11.15.9
11.15.10
11.15.11
11.16
11.17
11.17.1
11.17.1.1
11.17.2
11.17.3
11.17.4
11.17.5
11.17.6
11.17.7
11.18
11.18.1
11.19
11.19.1
11.20
11.21
11.22
11.22.1
11.22.2
11.22.3
11.22.4
11.22.5
11.22.6
11.23
11.24
11.24.1
11.24.1.1
11.24.6
11.24.7
11.24.8
11.24.9
11.25
Feedback Supervision 243
Pressure Loss Compensation 245
Soft Fill 246
Input Pressure Supervision 247
Sleep Function When No Demand Is Detected 250
Multi-setpoint 251
External PID Controller 252
Multi-pump Function 253
The Multi-pump Function 253
Commissioning Multi-pump (Multidrive) 253
System Configuration 254
Interlocks 259
Feedback Sensor Connection in a Multi-pump System 259
Overpressure Supervision 266
Pump Run-time Counters 267
Advanced Settings 268
Maintenance Counters 269
The Maintenance Counters 269
Fire Mode 270
The Fire Mode Function 270
Motor Preheat Function 273
Drive Customizer 274
Pump Control 274
Auto-Cleaning 274
Jockey Pump 276
Priming Pump 277
Anti-blocking Function 278
Frost Protection 278
Flow Switch 279
Advanced Harmonic Filter 280
Condition-based Monitoring 280
Introduction to Condition-based Monitoring 280
Stages of Condition-based Monitoring 281
Manual Run 282
Stator Winding Monitoring 283
Threshold Value 283
Warning and Alarm/Fault Stages 284
Default Values of Parameters in the Different Applications 289
AB298035655957en-000201/DPD01083 | 9Danfoss A/S © 2023.08
Contents
VACON® 100 FLOW
Application Guide

12
12.1
12.2
12.3
12.4
12.4.1
12.4.2
12.4.3
12.4.4
12.4.5
12.4.6
Fault Tracing 295
Fault Types 295
Alarms and Warnings 295
Fault Codes 295
Total and Trip Counters 321
Operating Time Counter 321
Operating Time Trip Counter 321
Run Time Counter 322
Power on Time Counter 322
Energy Counter 323
Energy Trip Counter 324
AB298035655957en-000201/DPD0108310 | Danfoss A/S © 2023.08
Contents
VACON® 100 FLOW
Application Guide

•
•
•
•
•
1 Introduction
1.1 Purpose of this Application Guide
This Application Guide provides information for configuring the system, controlling the AC drive, accessing parameters, program-
ming, and troubleshooting of the AC drive. It is intended for use by qualified personnel. Read and follow the instructions to use the
drive safely and professionally. Pay particular attention to the safety instructions and general warnings that are provided in this
manual and other documentation delivered with the drive.
1.2 Manual and Software Version
This manual is regularly reviewed and updated. All suggestions for improvement are welcome.
The original language of this manual is English.
Table 1: Manual and Software Version
Edition
Software version
DPD01083I
FW0159V028
1.3 Additional Resources
Other resources are available to understand advanced AC drive functions and operation.
VACON®100 Wall-mounted Drives Operating Guide
VACON®100 Enclosed Drives Installation Manual
VACON®100 IP00 Drive Modules Installation Manual
VACON®100 X Installation Manual
Instructions for operation with option boards and other optional equipment.
Supplementary publications and manuals are available from Danfoss.
For US and Canadian markets:
NOTE! Download the English and French product guides with applicable safety, warning and caution information from https://
www.danfoss.com/en/service-and-support/.
REMARQUE Vous pouvez télécharger les versions anglaise et française des guides produit contenant l'ensemble des informations
de sécurité, avertissements et mises en garde applicables sur le site https://www.danfoss.com/en/service-and-support/.
1.4 Parameter Table Reading Guide
This manual includes a large quantity of parameter tables. These instructions tell you how to read the tables.
Index
Min Max Unit Default
ID Description
Parameter
e30bg858.10
A
B
C
D E F G H
Illustration 1: Parameter Table Reading Guide
A
The location of the parameter in the menu, that is,
the parameter number.
B
The name of the parameter.
C
The minimum value of the parameter.
D
The maximum value of the parameter.
E
The unit of the value of the parameter. The unit
shows if it is available.
F
The value that was set in the factory.
G
The ID number of the parameter.
H
A short description of the values of the parameter
and/or its function.
AB298035655957en-000201 / DPD01083 | 11Danfoss A/S © 2023.08
Introduction
VACON® 100 FLOW
Application Guide

•
-
-
•
-
-
•
-
-
•
•
-
-
-
-
•
•
-
-
-
-
-
-
-
•
-
-
-
-
-
-
•
-
-
-
-
•
•
•
•
-
-
-
1.5 Functions of the AC Drive
Easy setup functions
Applications with preset parameters and I/O configuration for your process: Standard, HVAC, PID control, Multi-pump
Start-up wizards for fast and easy parameterization
Navigation functions
The [FUNCT] button for an easy change between the local and the remote control place (I/O or fieldbus)
A control page to operate and monitor of the most important values quickly
Advanced monitoring functions
Multimonitor
Trend curve
Fieldbus and I/O control
Motor control
Open loop control with frequency reference
Support for induction, permanent magnet, and synchronous reluctance motors
Identification run for setup of motor parameters
Flux and DC brake
Start and stop logic configuration
Reference selection and handling
8 preset frequencies
Motor potentiometer functions
A flush function
2 programmable ramp times
2 supervisions
3 ranges of prohibited frequencies
A forced stop
PID control
An external PID controller is available. Use it, for example, to control a valve with the I/O of the AC drive.
A sleep mode function that automatically enables and disables the operation of the drive to save energy
A 2-zone PID controller with 2 different feedback signals: minimum and maximum control
2 setpoint sources for the PID control. Selection to be made with a digital input.
A function for PID setpoint boost
A feedforward function to make the response to the process changes better
Pump control
A multi-pump control for the single drive and multidrive systems
The multimaster and multifollower modes in the multidrive system
A multi-pump system that uses a real time clock to autochange the pumps
Priming pump control, jockey pump control, pump impeller auto-cleaning, pump input pressure supervision, and frost pro-
tection function
Mechanical brake control
Timer functions and a real-time clock and (an optional battery is necessary)
Fire mode
Diagnostic and maintenance functions
Variety of configurable protection functions including user-defined faults
Supervision functions for frequency and motor variables and analog inputs
Motor overload protections
AB298035655957en-000201 / DPD0108312 | Danfoss A/S © 2023.08
Introduction
VACON® 100 FLOW
Application Guide

-
-
-
•
•
•
•
•
•
•
1.
2.
3.
4.
5.
6.
7.
8.
-a.

-
An automatic reset
Different preheat modes to prevent condensation problems
Maintenance counters
Drive Customizer for custom logic programming
Control, parametrization, and diagnostics via PC-tools
1.6 Start-up Quick Guide
There are 5 applications available for the product. When an application is selected, a group of parameters get their preset values.
The selection of the application makes the commissioning of the drive easy and reduces the manual work with the parameters. It is
also possible to edit these parameters later.
WARNING
ACCIDENTAL START BECAUSE OF CHANGE OF SETTINGS
Running the Startup wizard, changing the application or the software can cause the I/O functions to change.
Disconnect the motor from the drive if an accidental start can be dangerous.
The available applications:
Standard application (3.2 Standard and HVAC Applications)
HVAC application (3.2 Standard and HVAC Applications)
PID control application (3.3 PID Control Application)
Multi-pump (single drive) application (3.4 Multi-pump (Single Drive) Application)
Multi-pump (double drive) application (3.5 Multi-pump (Multidrive) Application)
Wizards make it more convenient to use the AC drive. There is a start-up wizard (see 1.6.1 Start-Up Wizard), 5 applications wizards
(see 4.1 Application Wizards), and 1 function wizard (see 4.2.2 Fire Mode Wizard).
1.6.1 Start-Up Wizard
The Start-up wizard asks for necessary data for the drive to control the procedure.
Procedure
Select language (P6.1).
If a battery is installed, the steps 2–5 are shown.
Set daylight saving time (P5.5.5). (Russia, US, EU, or OFF)
Set time (P5.5.2).
Set year (P5.5.4).
Set date (P5.5.3).
Run Startup wizard?
If the selection is No, the Start-up wizard ends.
Select an application (P1.2 Application, ID 212).
Run the Application wizard?
To continue to the application wizard, set the selection to Yes and push the [OK] button. See the description of the
different application wizards in chapter 4.1 Application Wizards.
After these selections, the Start-up wizard is completed. To start the Start-up wizard again, there are 2 alternatives.
Go to the parameter P6.5.1 Restore Factory Defaults or to the parameter B1.1.1 Start-up Wizard. Then set the value
to Activate.
AB298035655957en-000201 / DPD01083 | 13Danfoss A/S © 2023.08
Introduction
VACON® 100 FLOW
Application Guide

•
•
•
2 User Interfaces
2.1 Description of the Control Panel
2.1.1 Control Panel and the Keypad
The control panel is the interface between the AC drive and the user. With the control panel, it is possible to control the speed of a
motor and monitor the status of the AC drive. It is also possible to set the parameters of the AC drive.
e30bu012
A
B C
I
H D
G
F E
Illustration 2: Buttons of the VACON®100 Keypad
A
The [BACK/RESET] button. Use it to move back in the
menu, exit the Edit mode, reset a fault.
B
The arrow button UP. Use it to scroll up the menu
and to increase a value.
C
The [FUNCT] button. Use it to change the rotation
direction of the motor, access the control page, and
change the control place.
D
The arrow button RIGHT.
E
The START button.
F
The arrow button DOWN. Use it to scroll the menu
down and to decrease a value.
G
The STOP button.
H
The arrow button LEFT. Use it to move the cursor
left.
I
The [OK] button. Use it to go into an active level or
item, or to accept a selection.
2.1.2 Displays of the Control Panel
There are 2 display types: the graphical display and the text display. The control panel always has the same keypad and buttons.
The display shows this data.
The status of the motor and the drive.
Faults in the motor and in the drive.
Your location in the menu structure.
If the text in the text display is too long for the display, the text scrolls to show the full text string. Some functions are only available
in the graphical display.
AB298035655957en-000201 / DPD0108314 | Danfoss A/S © 2023.08
User Interfaces
VACON® 100 FLOW
Application Guide

STOP
READY
I/O
Main Menu
A
B C D E
F
H
G
Quick Setup
( 17 )
Monitor
( 5 )
Parameters
( 12 )
M1ID:
e30bu013.10
Illustration 3: Graphical Display of the Control Panel
A
The first status field: STOP/RUN
B
The rotation direction of the motor
C
The second status field: READY/NOT READY/FAULT
D
The alarm field: ALARM/-
E
The control place field: PC/I/O/KEYPAD/ FIELDBUS
F
The location field: the ID number of the parameter
and the current location in the menu
G
An activated group or item
H
The number of items in the group in question
A B
F
C
D
E
e30bu014.10
Illustration 4: Text Display of the Control Panel
A
The indicators of status
B
The indicators of alarm and fault
C
The name of the group or item of the current loca-
tion
D
The current location in the menu
E
The indicators of the control place
F
The indicators of the rotation direction
2.2 Menu Structure
The data of the AC drive is in menus and submenus. To move between the menus, use the arrow buttons Up and Down in the
keypad. To go into a group or an item, push the [OK] button. To go back to the previous level, push the [BACK/RESET] button.
On the display, current location in the menu shows, for example M3.2.1. The display also shows the name of the group or item in the
current location.
AB298035655957en-000201 / DPD01083 | 15Danfoss A/S © 2023.08
User Interfaces
VACON® 100 FLOW
Application Guide

Table 2: Menu Structure
Menu
Function
M1 Quick setup
Wizards (Content depends on P1.2 Application.)
M2 Monitor
Multimonitor
Trend curve
Basic
I/O
Temperature inputs
Extras/Advanced
Timer functions
PID controller
External PID controller
Multi-pump
Maintenance counters
Fieldbus data
Drive customizer
Condition-based monitoring
M3 Parameters
Motor settings
Start/Stop setup
References
Ramps and brakes
I/O Configuration
Fieldbus data
Prohibit frequencies
Supervisions
Protections
Automatic reset
Application settings
Timer functions
PID controller
External PID controller
Multi-Pump
Maintenance counters
Fire mode
AB298035655957en-000201 / DPD0108316 | Danfoss A/S © 2023.08
User Interfaces
VACON® 100 FLOW
Application Guide

Menu
Function
Motor preheat
Drive customizer
Pump control
Advanced harmonic filter
Condition-based monitoring
M4 Diagnostics
Active faults
Reset faults
Fault history
Total counters
Trip counters
Software info
Drive info
Unit status
M5 I/O and Hardware
Basic I/O
Slot C
Slot D
Slot E
Real-time clock
Power unit settings
Keypad
RS485
Ethernet
Fieldbus general
M6 User settings
Language selections
Parameter back-up
Drive name
Parameter compare
Licenses
M7 Favourites
See 9.2.1 Using the Favourites Menu.
M8 User levels
See 9.3.1 Using the User Levels Menu.
AB298035655957en-000201 / DPD01083 | 17Danfoss A/S © 2023.08
User Interfaces
VACON® 100 FLOW
Application Guide

1.
2.

3.

4.
1.
2.
3.

4.
2.3 Graphical Display
2.3.1 Editing the Text Values
This topic gives instructions on how to edit the text values on the graphical display.
Procedure
Find the parameter with the arrow buttons.
To go to the Edit mode, push the [OK] button 2 times or push the arrow button Right.
STOP
READY I/O
Rem Control Place
M3.2.1
ID:
Edit
Help
Add to favourites
e30bu017.10
To set a new value, push the arrow buttons Up and Down.
STOP
READY I/O
Rem Control Place
M3.2.1ID:
FieldbusCTRL
I/O Control
e30bu018.10
To accept the change, push the [OK] button. To ignore the change, use the [BACK/RESET] button.
2.3.2 Editing the Numerical Values
This topic gives instructions on how to edit the numerical values on the graphical display.
Procedure
Find the parameter with the arrow buttons.
To go to the Edit mode, push the [OK] button 2 times or push the arrow button Right.
Move from digit to digit with the arrow buttons Left and Right. Change the digits with the arrow buttons Up and Down.
STOP
READY I/O
MinFreqReference
P3.3.1.1
ID:101
0.00 Hz
Min: 0.00Hz
Max: 50.00Hz
e30bu020.10
To accept the change, push the [OK] button. To ignore the change, use the [BACK/RESET] button.
AB298035655957en-000201 / DPD0108318 | Danfoss A/S © 2023.08
User Interfaces
VACON® 100 FLOW
Application Guide

1.

2.
3.

•
•
•
•
2.3.3 Selecting More than 1 Value
With some parameters, more than 1 value can be selected. Select a checkbox at each necessary value.
Procedure
Find the parameter. There is a symbol on the display when a checkbox selection is possible.
STOP
READY
I/O
P3.12.1.3ID:1466
Interval 1
00:00:00
00:00:00
ON Time
OFF Time
Days 0
A
e30bu023.10
A
The symbol of the checkbox selection
To move in the list of values, use the arrow buttons Up and Down.
To add a value into your selection, select the box that is next to it with the arrow button Right.
STOP
READY I/O
M 3.12.1.3.1
ID: Days
Monday
Tuesday
Wednesday
Thursday
Friday
Sunday
e30bu025.10
2.3.4 Resetting a Fault
To reset a fault, use the [BACK/RESET] button or the parameter Reset Faults. See 7.1.2 Reset Faults.
2.3.5 [FUNCT] Button
The [FUNCT] button can be used for 4 functions.
To have access to the Control page.
To change easily between the Local and Remote control places.
To change the rotation direction.
To edit quickly a parameter value.
2.3.5.1 Different Control Places
The selection of the control place determines from where the AC drive takes the start and stop commands. All the control places
have a parameter for the selection of the frequency reference source. The Local control place is always Keypad. The Remote control
place is I/O or Fieldbus. The status bar of the display shows the current control place.
It is possible to use I/O A, I/O B, and Fieldbus as Remote control places. I/O A and Fieldbus have the lowest priority. Select them with
P3.2.1 (Remote Control Place). I/O B can bypass the Remote control places I/O A and Fieldbus with a digital input. Select the digital
input with parameter P3.5.1.7 (I/O B Control Force).
Keypad is always used as a control place when the control place is Local. Local control has higher priority than Remote control. For
example, if parameter P3.5.1.7 bypasses the control place with a digital input, and Local is selected in Remote control, Keypad be-
comes the control place. Use the [FUNCT] button or P3.2.2 Local/Remote to change between the Local and Remote control.
AB298035655957en-000201 / DPD01083 | 19Danfoss A/S © 2023.08
User Interfaces
VACON® 100 FLOW
Application Guide

1.
2.

3.

4.

1.
2.

3.
2.3.5.2 Changing the Control Place
This topic gives instructions on how to change the control place on the control panel.
Procedure
Anywhere in the menu structure, push the [FUNCT] button.
To select Local/Remote, use the arrow buttons Up and Down. Push the [OK] button.
STOP
READY Keypad
ID:1805 Choose action
Control page
Change direction
Local/Remote
e30bu027.10
To select Local or Remote, use the arrow buttons Up and Down again. To accept the selection, push the [OK] button.
STOP
READY Keypad
ID:211 Local/Remote
Remote
Local
e30bu028.10
If Remote control place is changed to Local, that is, Keypad, give a keypad reference.
After the selection, the display goes back into the same location where it was when the [FUNCT] button was push-
ed.
2.3.5.3 Going into the Control Page
It is easy to monitor the most important values in the Control page.
See more information about Keypad Reference in 6.3 Group 3.3: References. If other control places or reference values are used, the
display shows the frequency reference, which cannot be edited. The other values on the page are Multimonitor values. These values
can be selected (see 5.2.1 Changing the Items to Monitor).
Procedure
Anywhere in the menu structure, push the [FUNCT] button.
To select the Control page, push the arrow buttons Up and Down. Go in with the [OK] button.
The Control page opens.
With the Local control place and the keypad reference selected, P3.3.1.8 Keypad Reference can be set with the [OK] button.
AB298035655957en-000201 / DPD0108320 | Danfoss A/S © 2023.08
