Danfoss VLT 5000 Series User manual

VLT®5000/6000/8000 Series
■Contents
Introduction ....................................................................................................... 2
General warning ..................................................................................................... 2
Introduction ........................................................................................................... 3
Transportation and uncrating ................................................................................ 4
Key diagram for VLT 5300-5500 / VLT 6350-6550 / VLT 8350-8550 ................... 6
Technical data ........................................................................................................ 7
Mechanical installation ................................................................................ 11
Mechanical dimensions ......................................................................................... 11
Pre-installation ...................................................................................................... 12
Installation site ....................................................................................................... 12
Cable site .............................................................................................................. 13
Derating for high altitude ........................................................................................ 13
Derating for ambient temperature .......................................................................... 13
Electrical installation .................................................................................... 14
Electrical installation .............................................................................................. 14
Pre-fuses .............................................................................................................. 14
Earthing ................................................................................................................ 14
RFI switch ............................................................................................................. 15
Electrical installation, power cables ........................................................................ 15
Electrical installation, enclosure .............................................................................. 17
Terminal adapter kit .............................................................................................. 18
Tightening-up torques ........................................................................................... 18
Installation of 24 Volt external DCsupply ............................................................... 18
Installation of brake resistor temperature switch ................................................... 18
Cable cross-section and length ............................................................................. 19
Mains connection .................................................................................................. 20
Motor connection .................................................................................................. 21
Brake connection (VLT 5000 Series ONLY) .......................................................... 22
Load sharing connection ...................................................................................... 22
Motor and DC coils connections on IP 00 ............................................................. 23
Control cable routing ............................................................................................ 24
Connection example ............................................................................................. 25
Electrical installation procedures ........................................................................... 27
Electrical installation, control leads ........................................................................ 28
Programming the VLT 5000 .................................................................................. 28
Programming the VLT 6000 and VLT 8000 AQUA ................................................ 28
Motor start ............................................................................................................ 28
MG.56.A2.02 - VLT is a registered Danfoss trademark 1

VLT®5000/6000/8000 Series
■General warning
The voltage of the frequency converter
is dangerous whenever the converter is
connected to mains. Incorrect fitting of the
motor or frequency converter may cause damage to the
equipment, serious injury or death. Consequently, it is
essential to comply with the instructions in this manual
as well as local and national rules and safety regulations.
1. The VLT frequency converter must be disconnected
from mains if repair work is to be carried out. Check
that the mains supply has been disconnected
and that the necessary time has passed before
removing motor and mains plugs.
2. The [STOP/RESET] or [OFF/STOP] key on the
control panel of the VLT frequency converter does
not disconnect the equipment from mains and is
thus not to be used as a safety switch.
3. Correct protective earthing of the equipment
must be established, the user must be protected
against supply voltage, and the motor must be
protected against overload in accordance with
applicable national and local regulations.
4. The earth leakage currents are higher than 3.5 mA.
5. Protection against motor overload is not included
in the factory setting. If this function is desired, set
parameter 128 to data value ETR trip or data value
ETR warning. On VLT 6000, set parameter 117 to
data value ETR trip or data value ETR warning.
Note: The function is initialised at 1.16 x
rated motor current and rated motor frequency
(see Operating manual).
For the North American market: The ETR
functions provide class 20 motor overload
protection in accordance with NEC.
6. Do not remove the plugs for the motor and
mains supply while the VLT frequency converter
is connected to mains. Check that the mains
supply has been disconnected and that the
necessary time has passed before removing
motor and mains plugs.
7. Please note that the VLT frequency converter has
more voltage inputs than L1, L2 and L3, when
loadsharing (linking of DC intermediate circuit) and
external 24 V DC have been installed. Check
that all voltage inputs have been disconnected
and that the necessary time has passed before
repair work is commenced.
■Warning against unintended start
1. The motor can be brought to a stop by
means of digital commands, bus commands,
references or a local stop, while the frequency
converter is connected to mains. If personal
safety considerations make it necessary to
ensure that no unintended start occurs, these
stop functions are not sufficient.
2. While parameters are being changed, the
motor may start. Consequently, the stop key
[STOP/RESET] or [OFF/STOP] must always be
activated, following which data can be modified.
3. A motor that has been stopped may start if faults
occur in the electronics of the frequency converter,
or if a temporary overload or a fault in the supply
mains or the motor connection ceases.
176FA055.11
Warning:
Touching the electrical parts may be fatal - even after the
equipment has been disconnected from mains.
Also make sure that other voltage inputs have been disconnected,
such as external 24 V DC, load-sharing (linkage of DC intermediate
circuit), as well as the motor connection for kinetic back-up.
Using VLT 5300-5500 / 6350-6550 /8350-8550:
wait at least 15 minutes
MG.56.A2.02 - VLT is a registered Danfoss trademark
2

VLT®5000/6000/8000 Series
Introduction
■Introduction
Manual objectives
The purpose of this manual is to provide the user
with the necessary information to install, program and
start up the Danfoss VLT 5300-5500, VLT 6350-6550
and VLT 8350-8550 frequency converters. This
manual should be read thoroughly before operating,
servicing or initializing the drives. This manual is
intended for use along with the Danfoss Operating
Instructions Manual for the VLT 5000/6000/8000
frequency converters for detailed information.
Who should use this manual
This manual is intended for qualified service
personnel responsible for setting up and servicing
the Danfoss VLT 5300-5500, VLT 6350-6550 and
VLT 8350-8550 frequency converters. Qualified
personnel have previous experience with the
frequency converters and understand electrical
fundamentals, programming procedures, required
equipment and safety precautions.
Organization of the manual
This manual is arranged in equipment installation
and connection sequence. The order of tasks
are arranged as follows:
•Safety instructions
•Transportation and unpacking
•Technical data
•Mechanical installation
•Pre-installation
•Electrical installation guidelines
•Control cable routing
•Connection examples
•Electrical installation procedures
•Motor start
MG.56.A2.02 - VLT is a registered Danfoss trademark 3

VLT®5000/6000/8000 Series
■Transportation and uncrating
To lessen the possibility of damage it is recommended
that the crated VLT frequency converter is
located as close to the final installation site
as possible before uncrating.
Door and ceiling clearances must be considered when
moving and installing the VLT frequency converter.
Seebelowtableforthecratedimensions:
Dimensions mm (inches):
H W D
IP 00 2096
(82.52)
1219
(48.0)
699
(27.52)
Nema 1 (IP
20) / 54
2324
(91.5)
1321
(52.0)
724
(28.5)
Weight kg (lbs):
VLT
5300/6350/
8350/8550
VLT
5350/6400/
8350/8550
VLT
5450/6500/
8350/8550
VLT
5500/6550/
8350/8550
IP 00 548 (1208) 583 (1385) 628 (1385) 653 (1440)
Nema 1
(IP 20)
654 (1442) 689 (1519) 734 (1618) 759 (1673)
IP 54 664 (1464) 699 (1541) 744 (1640) 769 (1695)
A qualified person with a forklift or other similar
lifting device will be needed to remove the VLT
frequency converter from the crate.
To open the crate:
•Remove the metal locking tabs that secure the top
panel of the crate, this will give access to the lifting
rings on the top of the VLT frequency converter.
•On IP 00 versions remove the supporting
brace bolted to the lifting rings.
•A forklift or similar lifting device should be
used at this time to ensure the stability of the
VLT frequency converter while the rest of the
crate is removed. Position the lifting device
to the front side of the crate.
•The VLT frequency converter should be lifted using
a spreader bar or other similar lifting device. Lift the
VLT frequency converter slightly, using all four lifting
rings, distributing the weight as evenly as possible.
MG.56.A2.02 - VLT is a registered Danfoss trademark
4

VLT®5000/6000/8000 Series
Introduction
•Remove the metal locking tabs and the
remaining crate panels.
•On IP 00 versions remove the clear plastic safety
barrier from the front of the unit to prevent
the possibility of breaking during positioning
of the VLT frequency converter.
•The VLT frequency converter is now ready to
be lifted and positioned in the installation site.
NOTE: On IP 00 versions there are inductors
bolted to the bottom of the crate. Lift the
VLT frequency converter high enough to allow
clearance over these inductors.
•Observe cooling and ventilation requirements given
in the "Installation Site" section of this manual.
•Secure to the floor using the four holes provided
in the bottom of the unit. On IP 00 versions
secure to the panel using the four mounting holes
provided in the back. Refer to the dimensional
drawings in this instruction manual.
79.1
(2010)
42.3
(1075)
47.2
(1200)
23.6
(600)
18.7
(475)
4 x ø0.63
(16)
Mounting holes in
bottom panel
Min. free air space
above the drive
15.7
(400)
72.7
(1847)
41.9
(1065)
19.3
(490)
43.3
(1099)
74.6
(1896)
4 x ø0.63
(16)
Mounting holes
in back panel
15.7
(400)
Min. free air space
below the drive 15.7
(400)
Min. free air space
above the drive
MG.56.A2.02 - VLT is a registered Danfoss trademark 5

VLT®5000/6000/8000 Series
■Key diagram for VLT 5300-5500 / VLT 6350-6550 / VLT 8350-8550
Brake terminals 81, 82 and 104-106 are not
available in VLT 6000 HVAC.
MG.56.A2.02 - VLT is a registered Danfoss trademark
6

VLT®5000/6000/8000 Series
Introduction
■Compact, Mains supply 3 x 380 - 500 V
According to international requirements VLT type 5300 5350 5450 5500
Normal overload torque (110 %):
Output current IVLT,N [A] (380-440 V) 480 600 658 745
IVLT, MAX (60 s) [A] (380-440 V) 528 660 724 820
IVLT,N [A] (441-500 V) 443 540 590 678
IVLT, MAX (60 s) [A] (441-500 V) 487 594 649 746
Output SVLT,N [kVA] (380-440 V) 333 416 456 516
SVLT,N [kVA] (441-500 V) 384 468 511 587
Typical shaft output (380-440 V) PVLT,N [kW] 250 315 355 400
Typical shaft output (380-440 V) PVLT,N [HP] 300 350 450 500
Typical shaft output (441-500 V) PVLT,N [kW] 315 355 400 500
Typical shaft output (441-500 V) PVLT,N [HP] 350 450 500 600
High overload torque (150 %):
Output current IVLT,N [A] (380-440 V) 395 480 600 658
IVLT, MAX (60 s) [A] (380-440 V) 593 720 900 987
IVLT,N [A] (441-500 V) 361 443 540 590
IVLT, MAX (60 s) [A] (441-500 V) 542 665 810 885
Output SVLT,N [kVA] (380-440 V) 274 333 416 456
SVLT,N [kVA] (441-500 V) 313 384 468 511
Typical shaft output (380-440 V) PVLT,N [kW] 200 250 315 355
Typical shaft output (380-440 V) PVLT,N [HP] 300 350 450 500
Typical shaft output (441-500 V) PVLT,N [kW] 250 315 355 400
Typical shaft output (441-500 V) PVLT,N [HP] 350 450 500 600
Max. cross-section of copper cable to motor, brake 2x150 2x185 2x240 2x300
and loadsharing (380-440 V) [mm2]5) 3x70 3x95 3x120 3x150
Max. cross-section of copper cable to motor, brake 2x120 2x150 2x185 2x300
and loadsharing (441-500 V) [mm2]5) 3x70 3x95 3x95 3x120
Max. cross-section of aluminium cable to motor, brake 2x185 2x240 2x300
and loadsharing (380-440 V) [mm2]5) 3x120 3x150 3x185 3x185
Max. cross-section of aluminium cable to motor, brake 2x150 2x185 2x240
and loadsharing (441-500) [mm2]5) 3x95 3x120 3x150 3x185
Max. cross-section of copper cable to motor, brake 2x250mcm 2x350mcm 2x400mcm 2x500mcm
and loadsharing (380-440 V) AWG]2) 5) 3x2/0 3x3/0 3x4/0 3x250mcm
Max. cross-section of copper cable to motor, brake 2x4/0 2x300mcm 2x350mcm 2x500mxm
and loadsharing (441-500 V) AWG]2) 5) 31/0 3x3/0 3x3/0 3x4/0
Max. cross-section of aluminium cable to motor, brake 2x350mcm 2x500mcm 2x600mcm 2x700mcm
and loadsharing (380-440 V) AWG]2) 5) 3x4/0 3x250mcm 3x300mcm 3x350mcm
Max. cross-section of aluminium cable to motor, brake 2x300mcm 2x400mcm 2x500mcm 2x600mcm
and loadsharing (441-500 V) AWG]2) 5) 3x3/0 3x4/0 3x250mcm 3x300mcm
1. For type of fuse see section Fuses.
2. American Wire Gauge.
3. Measured using 30 m screened motor cables at rated load and rated frequency.
4. Min. cable cross-section is the smallest cable cross-section allowed to be fitted on the terminals. Always
comply with national and local regulations on min. cable cross-section.
5. Connection stud 2 x M12/3 x M12.
MG.56.A2.02 - VLT is a registered Danfoss trademark 7

VLT®5000/6000/8000 Series
■Compact, Mains supply 3 x 380 - 500 V
According to international requirements VLT type 5300 5350 5450 5500
Rated input current
110% IL,MAX [A] (400 V) 467 584 648 734
IL,MAX [A] (460 V) 431 526 581 668
Rated input current
150% IL,MAX [A] (400 V) 389 467 584 648
IL,MAX [A] (460 V) 356 431 526 581
Max. cross-section of copper cable 2x150 2x185 2x240 2x300
to power (380-440 V) [mm2]5) 3x70 3x95 3x120 3x150
Max. cross-section of copper cable 2x120 2x150 2x185 2x300
to power (441-500 V) [mm2]5) 3x70 3x95 3x95 3x120
Max. cross-section of aluminium cable 2x185 2x240 2x300
to power (380-440 V) [mm2]5) 3x120 3x150 3x185 3x185
Max. cross-section of aluminium cable 2x150 2x185 2x240
to power (441-500 V) [mm2]5) 3x95 3x120 3x150 3x185
Max. cross-section of copper cable 2x250mcm 2x350mcm 2x400mcm 2x500mcm
to power (380-440 V) [AWG]2) 5) 3x2/0 3x3/0 3x4/0 3x250mcm
Max. cross-section of copper cable 2x4/0 2x300mcm 2x350mcm 2x500mcm
to power (441-500 V) [AWG]2) 5) 31/0 3x3/0 3x3/0 3x4/0
Max. cross-section of aluminium cable 2x350mcm 2x500mcm 2x600mcm 2x700mcm
to power (380-440 V) [AWG]2) 5) 3x4/0 3x250mcm 3x300mcm 3x350mcm
Max. cross-section of aluminium cable 2x300mcm 2x400mcm 2x500mcm 2x600mcm
to power (441-500 V) [AWG]2) 5) 3x3/0 3x4/0 3x250mcm 3x300mcm
Max. pre-fuses (mains) [-]/UL1) [A] 630/600 700/700 800/800 800/800
Integral pre-fuses (softcharge circuit)
[-]/UL6) [A] 9/9 9/9 9/9 9/9
Integral pre-fuses (snubber resistors)
[-]/UL7) [A] 15/15 15/15 15/15 15/15
Integral pre-fuses (SMPS) [-]/UL8) [A] 5.0/5.0 5.0/5.0 5.0/5.0 5.0/5.0
Efficiency 0.97 0.97 0.97 0.97
Weight IP 00 kg (lb) 480 (1058)515 (1135)560 (1235)585 (1290)
Weight Nema 1 kg (lb) 595 (1132) 630 (1389) 675 (1488) 700 (1543)
Weight IP 54kg (lb) 605 (1334) 640 (1411) 685 (1510) 710 (1565)
Power loss at max. load [W] 7500 9450 10650 12000
Enclosure IP 00 / Nema 1 (IP 20) / IP 54
1. For type of fuse see section Fuses.
2. American Wire Gauge.
3. Measured using 30 m screened motor cables at rated load and rated frequency.
4. Min. cable cross-section is the smallest cable cross-section allowed to be fitted on the terminals. Always
comply with national and local regulations on min. cable cross-section.
5. Connection stud 2 x M12/3 x M12.
6. If UL/cUL is to be complied with, AC Littelfuse type KLK, Danfoss ordering no. 175L3489 must be used.
7. If UL/cUL is to be complied with, DC Littelfuse type KLKD, Danfoss ordering no. 176F1147 must be
used.
8. If UL/cUL is to be complied with, Bussmann type KTK-5, Danfoss ordering no. 175L3437 must be used.
MG.56.A2.02 - VLT is a registered Danfoss trademark
8

VLT®5000/6000/8000 Series
Introduction
■Mains supply 3 x 380-500 V
According to international
requirements VLT type 6350 6450 6500 6550
8350 8450 8500 8550
Output
current IVLT,N [A] (380-415 V) 480 600 658 745
IVLT, MAX (60 s)[A](380-415 V) 528 660 724 820
IVLT,N [A] (440-460 V) 443 540 590 678
IVLT, MAX (60 s)[A](440-460 V) 487 594 649 746
Output SVLT,N [kVA] (380-415 V) 333 416 456 516
SVLT,N [kVA] (440-460 V) 384 468 511 587
Typical shaft output (380-415 V) PVLT,N [kW] 250 315 355 400
Typical shaft output (380-415 V) PVLT,N [HP] 300 350 450 500
Typical shaft output (440-460 V) PVLT,N [kW] 315 355 400 500
Typical shaft output (440-460 V) PVLT,N [HP] 350 450 500 600
Max. cross-section of copper cable to motor, 2 x 150 2 x 185 2 x 240 2 x 300
brake and loadsharing (380-415 V) [mm2]5) 3x70 3x95 3x120 3x150
Max. cross-section of copper cable to motor 2 x 120 2 x 150 2 x 185 2 x 300
and loadsharing (440-460 V) [mm2]5) 3 x 70 3 x 95 3 x 95 3 x 120
2 x 185 2 x 240 2 x 300
Max. cross-section of aluminium cable to
motor and loadsharing (380-415 V) [mm2]5) 3 x 120 3 x 150 3 x 185 3 x 185
2 x 150 2 x 185 2 x 240
Max. cross-section of aluminium cable to
motor and loadsharing (440-460) [mm2]5) 3 x 95 3 x 120 3 x 150 3 x 185
2x250mcm 2x350mcm 2x400mcm 2x500mcm
Max. cross-section of copper cable to motor
and loadsharing (380-415 V) AWG]2) 5) 3 x 2/0 3 x3/0 3 x 4/0 3x250mcm
2 x 4/0 2x300mcm 2x350mcm 2x500mcm
Max. cross-section of copper cable to motor
and loadsharing (440-460 V) AWG]2) 5) 3 x 1/0 3 x 3/0 3 x 3/0 3 x 4/0
2x350mcm 2x500mcm 2x600mcm 2x700mcm
Max. cross-section of aluminium cable to
motor and loadsharing (380-415 V) AWG]2) 5) 3 x 4/0 3x250mcm 3x300mcm 3x350mcm
2x300mcm 2x400mcm 2x500mcm 2x600mcm
Max. cross-section of aluminium cable to
motor and loadsharing (440-460 V) AWG]2) 5) 3 x 3/0 3 x 4/0 3x250mcm 3x300mcm
1. For type of fuse see section Fuses.
2. American Wire Gauge.
3. Measured using 30 m screened motor cables
atratedloadandratedfrequency.
4. Min. cable cross-section is the smallest cable
cross-section allowed to be fitted on the terminals.
Always comply with national and local regulations
on min. cable cross-section.
5. Connection stud 2 x M12/3 x M12.
6. If UL/cUL is to be complied with, AC
Littelfuse type KLK, Danfoss ordering no.
175L3489 must be used.
7. If UL/cUL is to be complied with, DC
Littelfuse type KLKD, Danfoss ordering no.
176F1147 must be used.
8. If UL/cUL is to be complied with, Bussmann type
KTK-5, Danfoss ordering no. 175L3437
must be used.
MG.56.A2.02 - VLT is a registered Danfoss trademark 9

VLT®5000/6000/8000 Series
According to international
requirements VLT type6350 6450 6500 6550
8350 8450 8500 8550
Rated input
current IL,N [A] (400 V) 467 584 648 734
IL, N (460 V) 431 526 581 668
2 x 150 2 x 185 2 x 240 2 x 300
Max. cross-section of copper cable to power
(380-415 V) [mm2]5) 3x70 3x95 3x120 3x150
2 x 120 2 x 150 2 x 185 2 x 300
Max. cross-section of copper cable to power
(440-460 V) [mm2]5) 3 x 70 3 x 95 3 x 95 3 x 120
2 x 185 2 x 240 2 x 300
Max. cross-section of aluminium cable to
power (380-415 V) [mm2]5) 3 x 120 3 x 150 3 x 185 3 x 185
2 x 150 2 x 185 2 x 240
Max. cross-section of aluminium cable to
power (440-460 V) [mm2]5) 3 x 95 3 x 120 3 x 150 3 x 185
2x250mcm 2x350mcm 2x400mcm 2x500mcm
Max. cross-section of copper cable to power
(380-415 V) AWG]2) 5) 3 x 2/0 3 x3/0 3 x 4/0 3x250mcm
2 x 4/0 2x300mcm 2x350mcm 2x500mcm
Max. cross-section of copper cable to power
(440-460 V) AWG]2) 5) 3 x 1/0 3 x 3/0 3 x 3/0 3 x 4/0
2x350mcm 2x500mcm 2x600mcm 2x700mcm
Max. cross-section of aluminium cable to
power (380-415 V) AWG]2) 5) 3 x 4/0 3x250mcm 3x300mcm 3x350mcm
2x300mcm 2x400mcm 2x500mcm 2x600mcm
Max. cross-section of aluminium cable to
power (440-460 V) AWG]2) 5) 3 x 3/0 3 x 4/0 3x250mcm 3x300mcm
Max. pre-fuses (mains)[-]/UL1)[A] 630/600 700/700 800/800 800/800
Integral pre-fuses (softcharge circuit)[-]/UL6)[A] 9/9 9/9 9/9 9/9
Integral pre-fuses (snubber resistors)[-]/UL7)[A] 15/15 15/15 15/15 15/15
Integral pre-fuses (SMPS) 5.0/5.0
Efficiency 0.97
Weight IP 00 kg (lb) 480
(1058)
515
(1135)
560
(1235)
585
(1290)
Weight Nema 1 (IP 20) kg (lb) 595
(1132)
630
(1389)
675
(1488)
700
(1543)
Weight IP 54 kg (lb) 605
(1334)
640
(1411)
685
(1510)
710
(1565)
Power loss atmax. load[W] 7500 9450 10650 12000
Enclosure IP 00 / Nema 1 (IP 20) / IP 54
1. For type of fuse see section Fuses.
2. American Wire Gauge.
3. Measured using 30 m screened motor cables
at ratedloadandratedfrequency.
4. Min. cable cross-section is the smallest cable
cross-section allowed to be fitted on the terminals.
Always comply with national and local regulations
on min. cable cross-section.
5. Connection stud 2 x M12/3 x M12.
6. If UL/cUL is to be complied with, AC
Littelfuse type KLK, Danfoss ordering no.
175L3489 must be used.
7. If UL/cUL is to be complied with, DC
Littelfuse type KLKD, Danfoss ordering no.
176F1147 must be used.
8. If UL/cUL is to be complied with, Bussmann type
KTK-5, Danfoss ordering no. 175L3437
must be used.
MG.56.A2.02 - VLT is a registered Danfoss trademark
10

VLT®5000/6000/8000 Series
Mechanical installation
■Mechanical installation
■Mechanical dimensions
VLT 5300-5500 380-500 Volt, VLT 6350-6550 380-460 Volt and VLT 8350-8550 380-480 Volt
VLT type A mm (in) B mm (in) C mm (in) ab mm (in) l/r mm (in)
5300-5500/6350-6550/
8350-8550 IP 00 1896 (74.65) 1099 (43.27) 494 (19.45) 400 (15.75) 0
5300-5500/6350-6550/
8350-8550 Nema 1 (IP 20) 2010 (79.13) 1200 (47.24) 600 (23.62) 400 (15.75) 0
5300-5500/6350-6550/
8350-8550 IP 54 2010 (79.13) 1200 (47.24) 600 (23.62) 400 (15.75) 0
ab: Min. space above enclosure.
l/r: Min. distance between VLT frequency converter
and other plant components, left and right sides.
VLT 5300-5500, VLT 6350-6550 and VLT 8350-8550
must be fastened to the floor with bolts. The
drawing shows the dimensions.
MG.56.A2.02 - VLT is a registered Danfoss trademark 11

VLT®5000/6000/8000 Series
■Pre-installation
The most important part of the mechanical
instal-lation is the pre-installation planning. Neglecting
this planning may very well result in extra work
during and after the installation
Before you install your VLT frequency converter you
should select the best possible operational site.
Consider the following in the pre-installation plan:
•Ambient operating temperature.
•Installation method.
•The position of the VLT frequency converter.
•The cable routing.
•Ensure that the power source supplies the
correct voltage and necessary current.
•If the VLT frequency converter is without
built-in mains disconnector and fuses, ensure
that the external disconnector or fuses have
the correct current rating.
■Installation site
The VLT frequency converter must be
installed vertically.
The VLT frequency converter is cooled by means of
air circulation. For the unit to be able to release its
cooling air, the minimum distance over the unit must
be as shown in the table under Mechanical Dimension.
To protect the unit from overheating, it must be
ensured that the ambient temperature does not rise
above the max. temperature stated for the VLT
frequency converter and that the 24-hour average
temperature is not exceeded. The max. tempe-rature
and 24-hour average can be seen from the General
Technical Data in the Operating Instructions.
If the ambient temperature is in the range of
45 -55 C, derating of the VLT frequency
converter will become relevant, see Derating
for ambient temperature.
The service life of the VLT frequency converter will
be reduced if derating for ambient temperature
is not taken into account.
■Installation of VLT 5300-5500 380-500 V, VLT 6350-6550 380-460 V and VLT 8350-8550
380-480 Volt Nema 1 (IP 20) and IP 54
Cooling
All units in the above-mentioned series require a
minimum space of 400 mm (15.75 in) above the
enclosure and must be installed on a plane floor. This
applies to both Nema 1 (IP 20) and IP 54 units.
Side-by-side
Nema 1 (IP 20) and IP 54
All Nema 1 (IP 20) and IP 54 units in the
above-mentioned series can be installed side by
side without any space between them, since these
units do not require cooling on the sides.
MG.56.A2.02 - VLT is a registered Danfoss trademark
12

VLT®5000/6000/8000 Series
Mechanical installation
■Cable site
The drawing and table show the mechanical setup
of the cable which can be done before the VLT
frequency converter is installed.
VLT type Mains terminal
VLT 5300-5500/6350-6550/8350-8550 969 mm (38.15 in)
VLT 5300-5500/6350-6550/8350-8550 with RFI 516 mm (20.31 in)
VLT 5300/6350/8350 with RFI/Disconnector 626 mm (24.65 in)
VLT 5350-5500/6400-6550/8350-8550 with RFI/Disconnector 516 mm (20.31 in)
■Derating for high altitude
Below 1000 m altitude no derating is necessary for
VLT 5300-5500, VLT 6350-6550 or VLT 8350-8550.
Above 1000 m the ambient temperature (TAMB)or
max. output current (IVLT,MAX) must be derated in
accordance with the diagram below:
1. Derating of output current versus altitude
at TAMB = max. 45 C
2. Derating of max. TAMB versus altitude at
100% output current.
■Derating for ambient temperature
The ambient temperature (TAMB,MAX) is the maximum
temperature allowed. The average (TAMB,AVG)
measured over 24 hours must be at least 5ºC lower.
If VLT 5300-5500, VLT 6350-6550 or VLT 8350-8550
is operated at temperatures above 45 ºC, a derating
of the continuous output current is necessary.
MG.56.A2.02 - VLT is a registered Danfoss trademark 13

VLT®5000/6000/8000 Series
■Electrical installation
The voltage on the frequency converter
is dangerous when the unit is
connected to mains.
Incorrect installation of the motor or VLT
frequency converter may lead to material damage
or serious injury or it may be fatal.
Consequently, the instructions in this manual
as well as national and local rules and safety
regulations must be complied with.
Touching the electrical parts may be fatal, even
after the mains supply has been disconnected.
Wait at least 15 minutes if using VLT 5300-5500,
VLT 6350-6550 or VLT 8350-8550.
NB!:
It is the user’s or certified electrician’s
responsibility to ensure correct earthing and
protection in accordance with applicable
national and local norms and standards.
All terminals for the control cables and power cables
are located behind the protective cover of the VLT
frequency converter. The protective cover can be
removed by means of a screwdriver.
Once the protective cover has been removed, the
actual EMC-correct installation can start.
■Pre-fuses
For VLT type 5300-5500, VLT type 6350-6550
and VLT 8350-8550, external pre-fuses must be
installed in the mains supply to the VLT frequency
converter or ordered with built-in pre-fuses and
a mains disconnect switch.
UL compliance
To comply with UL/cUL approvals, pre-fuses according to the table below must be used.
Bussmann SIBA Littel fuse Ferraz-Shawmut
5300/6350/8350 FWH-600 206xx32-600 L50S-600 A50-P600
5350/6450/8450 FWH-700 206xx32-700 L50S-700 A50-P700
5450/6500/8500 FWH-800 206xx32-800 L50S-800 A50-P800
5500/6550/8550 FWH-800 206xx32-800 L50S-800 A50-P800
Non UL compliance
If UL/cUL is not to be complied with, we recommend
the above mentioned fuses or type gR.
Not following the recommendation may result
in unnecessary damage of the drive in case of
malfunction. Fuses must be designed for protection
in a circuit capable of supplying a maximum of
100000 Arms (symmetrical), 500 V maximum.
■Earthing
The following basic issues need to be considered
when installing a frequency converter, so as to
obtain electromagnetic compatibility (EMC).
•Safety earthing: Please note that the frequency
converter has a high leakage current and must
be earthed appropriately for safety reasons.
Apply local safety regulations.
•High-frequency earthing: Keep the earth wire
connections as short as possible.
Connect the different earth systems at the lowest
possible conductor impedance. The lowest possible
conductor impedance is obtained by keeping
the conductor as short as possible and by using
the greatest possible surface area.
The metal cabinets of the different devices are
mounted on the cabinet rear plate using the lowest
possible HF impedance. This avoids having different
HF voltages for the individual devices and avoids the
risk of radio interference currents running in connection
cables that may be used between the devices. The
radio interference will have been reduced.
In order to obtain a low HF impedance, use the
fastening bolts of the devices as HF connection to
the rear plate. It is necessary to remove insulating
paint or similar from the fastening points.
MG.56.A2.02 - VLT is a registered Danfoss trademark
14

VLT®5000/6000/8000 Series
Electrical installation
■RFI switch
Mains supply isolated from earth:
If the VLT frequency converter is supplied from an
isolated mains source (IT mains), the RFI switch
can be turned off (OFF). In OFF position, the
internal RFI capacities (filter capacitors) between
the chassis and the intermediate circuit are cut off
to avoid damage to the intermediate circuit and
to reduce the earth capacity currents (according
to IEC 1800-3). See position of RFI switch by
Electrical installation, enclosures.
NB!:
The RFI switch is not to be operated with
mains connected to the unit. Check that
the mains supply has been disconnected
before operating the RFI switch.
NB!:
Open RFI switch is only allowed at factory
set switching frequencies.
NB!:
The RFI switch disconnects the capacitors
galvanically; however, transients higher
than approx. 1,000 V will be bypassed
by a spark gap.
Mains supply connected to earth:
The RFI switch must be in ON position in order for the
frequency converter to comply with the EMC-standard.
■Electrical installation, power cables
Compact Nema 1 (IP 20)/IP 54
Without disconnector and mains fuses VLT 5300-5500
VLT 6350-6550
VLT 8350-8550
MG.56.A2.02 - VLT is a registered Danfoss trademark 15

VLT®5000/6000/8000 Series
Compact Nema 1 (IP 20)/IP 54
With disconnector and mains fuses VLT 5300-5500
VLT 6350-6550
VLT 8350-8550
Brake terminals 81, 82 and 104-106 are not
available in VLT 6000 HVAC.
MG.56.A2.02 - VLT is a registered Danfoss trademark
16

VLT®5000/6000/8000 Series
Electrical installation
■Electrical installation, enclosure
Compact Nema 1 (IP 20) / IP 54
VLT 5300-5500
VLT 6350-6550
VLT 8350-8550
Brake terminals 81, 82 and 104-106 are not
available in VLT 6000 HVAC.
MG.56.A2.02 - VLT is a registered Danfoss trademark 17

VLT®5000/6000/8000 Series
■Terminal adapter kit
The terminal adapter kit is an optional kit for VLT
5300-5500, VLT 6350-6650 and VLT 8350-8550.
The terminal adapter kit makes it possible to connect
the power wires with the power terminals i.e. the
mains-, motor-, load sharing and brake terminals.
The ordering numbers of the terminal adapter kit are:
VLT 5300-5500/6350-6550 EX, DX 176F1815
VLT 5300-5500 EB, DE 176F1816
VLT 8350-8550 EX, DX 175F1815
■Tightening-up torques
The table shows the torque required when fitting
terminals to the VLT frequency converter.
For VLT 5300-5500, VLT 6350-6550 and VLT
8350-8550 the cables must be fastened with
bolts or the terminal adapter kit. These figures
apply to the following terminals:
Mains terminals Nos R, L1, 91
S, L2, 92
T, L3, 93
Motor terminals Nos U, T1, 96
V, T2, 97
W, T3, 98
Earth terminal No 95
Brake resistor R- 81
terminals R+ 82
Loadsharing DC- 88
DC+ 89
VLT type Tightening-up
torque
Bolt
size
VLT 5300-5500 1) 42 Nm
(31 lb-ft)
M12
VLT 6350-6550 42 Nm
(31 lb-ft)
M12
VLT 8350-8550 42 Nm
(31 lb-ft)
M12
1) For the brake terminals, the tightening-up torque
is 11.3 (8.33 lb-ft) Nm and the bolt size M8.
■Installation of 24 Volt external DCsupply
Torque: 0.5 - 0.6 Nm
Screw size: M3
No. Function
35, 36 24 V external DC supply
24 V external DC supply can be used as low-voltage
supply to the control card and any option cards
installed. This enables full operation of the LCP
(incl. parameter setting) without connection to mains.
Please note that a warning of low voltage will be
given when 24 V DC has been connected; however,
there will be no tripping. If 24 V external DC supply
is connected or switched on at the same time as
the mains supply, a time of min. 200 msec. must
be set in parameter 120 Start delay.
A pre-fuse of min. 6 Amp, slow-blow, can be
fitted to protect the external 24 V DC supply.
The power consumption is 15-50 W, depending
on the load on the control card.
NB!:
Use 24 V DC supply of type PELV to ensure
correct galvanic isolation (type PELV) on the
control terminals of the VLT frequency converter.
■Installation of brake resistor temperature switch
Torque: 0.5-0.6 Nm
Screw size: M3
No. Function
106, 104,
105
Brake resistor temperature switch.
MG.56.A2.02 - VLT is a registered Danfoss trademark
18

VLT®5000/6000/8000 Series
Electrical installation
NB!:
This function is only available on VLT
5300-5500 units.
If the temperature of the brake resistor
gets too high and the KLIXON switch drops out,
the VLT frequency converter will stop braking.
The motor will start coasting.
A KLIXON switch must be installed that can either be
normally closed’or normally open’. Ifthisfunctionisnot
used, 106 and 104 must be short-circuited together.
■Cable cross-section and length
See Technical data for correct sizing of motor
cable and mains cable cross-section. Always
comply with national and local regulations on cable
cross-sections. It is important to keep the motor
cableasshortaspossiblesoastoreducethenoise
level and leakage currents to a minimum.
Max. motor cable length for screened cable
is 150 m (500 ft.).
Max. motor cable length for unscreened
cable is 300 m (1000 ft.).
MG.56.A2.02 - VLT is a registered Danfoss trademark 19

VLT®5000/6000/8000 Series
■Mains connection
Mains must be connected to terminals R/L1/91,
S/L2/92, T/L3/93.
NB!:
Check the name plate to ensure that the
mains voltage of the VLT frequency converter
matches the power supply of your plant.
Ensure that the power supply can supply
the necessary current to the VLT frequency
converter, see Technical data.
If the unit is without built-in mains disconnector and
fuses, ensure that the appropriate disconnector or
fuses have the correct current rating.
See Technical data for correct sizing of
cable cross-sections.
See Electrical installation prodedures for how install
the mains connections to the VLT frequency converter.
Mains connection from the side without
built-in disconnector and fuses
Mains connection from the bottom without
built-in disconnector and fuses
Mains connection from the side with built-in
disconnector and fuses
MG.56.A2.02 - VLT is a registered Danfoss trademark
20
