Danfoss VLT FC Series User manual

Items Supplied
•
VLT
®
Wireless Communication Panel LCP 103.
•
Gasket
Illustration 1.1 VLT
®
Wireless Communication Panel LCP 103
Compatible Drive Series
NOTICE
Compatible drives have a white USB port.
•
VLT
®
HVAC Drive FC 102
•
VLT
®
Refrigeration Drive FC 103
•
VLT
®
AQUA Drive FC 202
•
VLT
®
AutomationDrive FC 301/FC 302
•
VLT
®
Lift Drive LD 302
Compatible software versions
-FC 102: 5.10
-FC 103: 2.10
-FC 202: 3.10
-FC 30x: 8.03
Approvals and Certications
FCC ID: 2ANSELCP-103
NOTICE
FCC COMPLIANCE NOTICE
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by 1 or more
of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment
and receiver.
•
Connect the equipment into an outlet on a circuit
dierent from that to which thereceiver is
connected.
•
Consult the dealer or an experienced radio/
television technician for help.
Modications: Any modications made to this device that
are not approved by Danfoss may void the authority
granted to the user by the FCC to operate this equipment.
RF EXPOSURE COMPLIANCE
This portable transmitter with its antenna has shown
compliance with FCC’s SAR limits for general population/
uncontrolled exposure. The maximum listed SAR level is 0.22
W/kg (body). The antenna used for this device must not be
co-located or operating in conjunction with any other
antenna or transmitter.
Installation Instructions
VLT®Wireless Communication Panel LCP 103
VLT®FC Series FC 102, FC 103, FC 202,
FC 301/FC 302, and LD 302
Danfoss A/S © 08/2018 All rights reserved. MI38V402

Installation
NOTICE
The VLT
®
Wireless Communication Panel LCP 103 is hot-
pluggable and can be connected when the drive is powered
on.
1. Mount the LCP 103 in the LCP input plug on the
drive.
2. Search for MyDrive
®
Connect in Google Play or Apple
Store.
Illustration 1.2 MyDrive
®
Connect Launch Icon
3. Download and install the MyDrive
®
Connect App.
NOTICE
Start pairing within the rst 10 minutes after the instal-
lation. Failing to do so closes the broadcast or wireless
identication due to security limits with default passwords.
To reconnect, power cycle the drive, or remove and
reconnect the LCP 103.
Connection Procedure
NOTICE
The wireless SSID is the Danfoss serial ID of the drive. For
example, Danfoss_019223G455 is the default wireless SSID
for a drive with the serial number 019223G455. The serial
number is on the product nameplate, but is also visible in
parameter 15-51 Frequency Converter Serial Number.
Wireless SSID Danfoss_019223G455
Default password Danfoss1933
1. Open the app and establish the Wi-Fi connection, see
Table 1.1 for descriptions of the white Wi-Fi LED.
2. When prompted, change the default password due to
security restrictions. The password must be at least 8
and maximum 48 characters.
3. Re-plug the LCP 103 for the password to change into
eect. Failing to do so allows the LCP 103 to keep
broadcasting.
4. Disconnect the app, navigate to smart device
settings, and forget the network.
5. Search for the wireless network and connect with the
new password.
NOTICE
If the password is not changed, it leaves only 10 minutes for
connecting and performing Drive operations. After this, the
wireless connection closes.
Reset password
If the wireless SSID and password are forgotten, access
parameter group 30-9* Wi LCP via MCT 10 Set-up Software or
LCP 102.
LED Pattern
LED Pattern Description
On Solid
green
The drive is powered on (normal operation).
Wi-Fi
Flashing
white
Connection pairing successful.
Solid
white
The smart device is connected and communi-
cation is OK.
Alarm Flashing
red
An alarm has occurred.
Warn Solid
yellow
A warning has occurred.
MS,
NS1,
NS2
1)
Flashing
orange
Identication of the drive when initiated through
a winking command.
Flashing
orange
Incompatible drive (LED ashes 3 times and then
remains on).
Table 1.1 Descriptions, LED Indicators
1) MS=module status, NS1=network status 1, NS2=Network status 2.
Safe Control
The safe control parameter allows the drive to decide the
motor behavior if the smart device, for example a tablet,
communication is lost. If the limits are set to [1] Stop motor,
the motor stops. If the limits are set to [0] Do nothing, the
motor continues to run. This is only applicable when the
motor is in Run state and if the motor has been started from
the app.
The communication happens between the MyDrive
®
Connect
App and the VLT
®
Wireless Communication Panel LCP 103.
Parameter Limits/options
Parameter 30-97 Wi Timeout Action [0] Do nothing
[1] Stop motor
Installation Instructions
VLT
®
Wireless Communication Panel LCP 103
VLT
®
FC Series FC 102, FC 103, FC 202,
FC 301/FC 302, and LD 302
2 Danfoss A/S © 08/2018 All rights reserved. MI38V402

Specications
Standards IEEE 802.11 b/g
Frequency range 2.4~2.4835 Ghz
Antenna PCB-mounted chip antenna
Security WPA2
Operating temperature -25
° C to +50 ° C (-13 ° F to
+122
° F)
Operating humidity 5–95% RH, non-condensing
Operating mode Access point
Ingress protection IP20 (IP55 with gasket)
Electrical rating 5 V, 250 mA
Internal memory size 14 MB
Dimensions (LxWxD) [mm (in)] 131.2 x 66.6 x 23 (5.1 x 2.6 x 0.9)
Weight [g (oz)] 85.3 (2.88)
Firmware update MCT 10 Set-up Software version
4.10 or higher
Installation Instructions
VLT
®
Wireless Communication Panel LCP 103
VLT
®
FC Series FC 102, FC 103, FC 202,
FC 301/FC 302, and LD 302
MI38V402 Danfoss A/S © 08/2018 All rights reserved. 3

Illustration 1.3 EU Declaration of Conformity for VLT
©
Wireless Communication Panel LCP 103, Page 1
Installation Instructions
VLT
®
Wireless Communication Panel LCP 103
VLT
®
FC Series FC 102, FC 103, FC 202,
FC 301/FC 302, and LD 302
4 Danfoss A/S © 08/2018 All rights reserved. MI38V402

Illustration 1.4 EU Declaration of Conformity for VLT
©
Wireless Communication Panel LCP 103, Page 2
Installation Instructions
VLT
®
Wireless Communication Panel LCP 103
VLT
®
FC Series FC 102, FC 103, FC 202,
FC 301/FC 302, and LD 302
MI38V402 Danfoss A/S © 08/2018 All rights reserved. 5
