Contents
1 Safety 3
1.1.1 High Voltage Warning 3
1.1.2 Safety Instructions 3
1.1.3 Software Version and Approvals 3
1.1.4 General Warning 3
1.1.5 IT Mains 4
1.1.6 Avoid unintended Start 4
1.1.8 Before Commencing Repair Work 4
2 Introduction 5
2.1.1 FC Identification 5
2.1.2 Type Code 6
3 Programming 8
3.1 How to Programme 8
3.1.1 Programming with MCT 10 Set-up Software 8
3.1.2 Programming with the LCP 11 or LCP 12 8
3.2 Status Menu 9
3.3 Quick Menu 10
3.4 Main Menu 10
4 Parameter Descriptions 11
4.1 Parameter Group 0: Operation/Display 11
4.2 Parameter Group 1: Load/Motor 14
4.3 Parameter Group 2: Brakes 19
4.4 Parameter Group 3: Reference/Ramps 21
4.5 Parameter Group 4: Limits/Warnings 25
4.6 Parameter Group 5: Digital In/Out 28
4.7 Parameter Group 6: Analog In/Out 32
4.7.3 6-1* Analog Input 1 32
4.8 Parameter Group 7: Controllers 36
4.9 Parameter Group 8: Communication 37
4.9.6 8-8* Bus communication diagnostics 39
4.10 Parameter Group 13: Smart Logic 40
4.10.1 13-** Programming Features 40
4.11 Parameter Group 14: Special Functions 45
4.12 Parameter Group 15: Drive Information 47
4.12.2 15-4* Drive Identification 47
4.13 Parameter Group 16: Data Readouts 48
Contents VLT®Micro Drive FC 51 Programming Guide
MG02C602 - VLT®is a registered Danfoss trademark 1
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

5 Parameter Lists 50
5.1.1 Conversion Index 54
5.1.2 Change during operation 54
5.1.3 2-Set-up 54
5.1.4 Type 54
5.1.5 0-** Operation/Display 55
5.1.6 1-** Load/Motor 56
5.1.7 2-** Brakes 57
5.1.8 3-** Reference/Ramps 57
5.1.9 4-** Limits/Warnings 58
5.1.10 5-** Digital In/Out 58
5.1.11 6-** Analog In/Out 59
5.1.12 7-** Controllers 59
5.1.13 8-** Comm. and Options 60
5.1.14 13-** Smart Logic 60
5.1.15 14-** Special Functions 61
5.1.16 15-** Drive Information 61
5.1.17 16-** Data Readouts 62
6 Troubleshooting 63
6.1.1 Alarm, Warning and Extended Status Word 65
Index 69
Contents VLT®Micro Drive FC 51 Programming Guide
2 MG02C602 - VLT®is a registered Danfoss trademark
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

1 Safety
1.1.1 High Voltage Warning
WARNING
The voltage of the frequency converter is dangerous
whenever it is connected to mains. Incorrect installation of
the motor or frequency converter may cause damage to
the equipment, serious injury or death. Consequently, it is
essential to comply with the instructions in this manual as
well as local and national rules and safety regulations.
1.1.2 Safety Instructions
CAUTION
Before using functions directly or indirectly influencing
personal safety (e.g. Safe Stop, Fire Mode or other
functions either forcing the motor to stop or attempting to
keep it functioning) a thorough risk analysis and system
test must be carried through. The system tests must
include testing failure modes regarding the control
signaling (analog and digital signals and serial communi-
cation.
NOTE
Before using Fire Mode, contact Danfoss
•Make sure the frequency converter is properly
connected to earth.
•Do not remove mains connections, motor
connections or other power connections while
the frequency converter is connected to power.
•Protect users against supply voltage.
•Protect the motor against overloading according
to national and local regulations.
•The earth leakage current exceeds 3.5 mA.
•The [Off] key is not a safety switch. It does not
disconnect the frequency converter from mains.
1.1.3 Software Version and Approvals
Software Version
Programming Guide
VLT®Micro Drive
FC 51 Series
This Programming Guide can be used for all VLT®
Micro Drive frequency converters with software
version 2.7X.
The software version number can be read in
15-43 Software Version.
Table 1.1
1.1.4 General Warning
WARNING
ELECTRICAL SHOCK HAZARD
Touching the electrical parts may be fatal - even after the
equipment has been disconnected from mains.
Also make sure that other voltage inputs have been
disconnected (linkage of DC intermediate circuit).
Be aware that there may be high voltage on the DC link
even when the LEDs are turned off.
Before touching any potentially live parts of the frequency
converter, wait at least 4 min for all sizes.
Shorter time is allowed only if indicated on the nameplate
for the specific unit.
Safety VLT®Micro Drive FC 51 Programming Guide
MG02C602 - VLT®is a registered Danfoss trademark 3
11
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

CAUTION
Leakage Current
The earth leakage current from the frequency converter
exceeds 3.5 mA. According to IEC 61800-5-1 a reinforced
Protective Earth connection must be ensured by means of
a min. 10 mm²Cu or an additional PE wire - with the same
cable cross section as the Mains wiring - must be
terminated separately.
Residual Current Device
This product can cause a DC current in the protective
conductor. Where a residual current device (RCD) is used
for extra protection, only an RCD of Type B (time delayed)
shall be used on the supply side of this product. See also
Danfoss Application Note on RCD, MN90GX.
Protective earthing of the frequency converter and the use
of RCDs must always follow national and local regulations.
CAUTION
Motor overload protection is possible by setting 1-90 Motor
Thermal Protection to the value ETR trip. For the North
American market: ETR functions provide class 20 motor
overload protection, in accordance with NEC.
WARNING
Installation in high altitudes:
For altitudes above 2 km, please contact Danfoss regarding
PELV.
1.1.5 IT Mains
CAUTION
IT Mains
Installation on isolated mains source, i.e. IT mains.
Max. supply voltage allowed when connected to mains:
440 V.
As an option, Danfoss offers line filters for improved
harmonics performance.
1.1.6 Avoid unintended Start
While the frequency converter is connected to mains, the
motor can be started/stopped using digital commands, bus
commands, references or via the Local Control Panel.
•Disconnect the frequency converter from mains
to avoid unintended start of any motors.
•To avoid unintended start, always press the [Off]
key before changing parameters.
1.1.7 Disposal Instruction
Equipment containing electrical components
must not be disposed of together with domestic
waste.
It must be separately collected with electrical
and electronic waste according to local and
currently valid legislation.
Table 1.2
1.1.8 Before Commencing Repair Work
1. Disconnect FC 51 from mains (and external DC
supply, if present).
2. Wait for 4 minutes (M1, M2 and M3) and 15 min
(M4 and M5) for discharge of the DC-link.
3. Disconnect DC bus terminals and brake terminals
(if present)
4. Remove motor cable
Safety VLT®Micro Drive FC 51 Programming Guide
4 MG02C602 - VLT®is a registered Danfoss trademark
11
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

2 Introduction
2.1.1 FC Identification
The nameplate sticker is located on the top of each
frequency converter and shows the ratings, serial number,
warnings catalog number, and other relevant data for each
unit. See Table 2.1 for details, how to read the type code
string.
Illustration 2.1 This Example Shows the Nameplate Sticker
Introduction VLT®Micro Drive FC 51 Programming Guide
MG02C602 - VLT®is a registered Danfoss trademark 5
22
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

2.1.2 Type Code
Illustration 2.2
Description Pos. Possible choice
Product group 1-3 Frequency converters
Series and product type 4-6 Micro Drive
Power size 7-10 0.18-7.5 kW
Mains voltage 11-12 S2: Single phase 200-240 V AC
T2: Three phase 200-240 V AC
T 4: Three phase 380-480 V AC
Enclosure 13-15 IP20/Chassis
RFI filter 16-17 HX: No RFI filter
H1: RFI filter class A1/B
H3:RFI filter A1/B (reduced cable length*)
Brake 18 B: Brake chopper included (from 1.5 kW and up)
X: No brake chopper included
Display 19 X: No Local Control Panel
N: Numerical Local Control Panel (LCP)
P: Numerical Local Control Panel (LCP)) with potentiometer
Coating PCB 20 C: Coated PCB
X. No coated PCB
Mains option 21 X: No mains option
Adaptation A 22 X: No adaptation
Adaptation B 23 X: No adaptation
Software release 24-27 SXXX: Latest release - std. software
Table 2.1 Type Code Description
*See VLT
®
Micro Drive Design Guide, MG02K
Introduction VLT®Micro Drive FC 51 Programming Guide
6 MG02C602 - VLT®is a registered Danfoss trademark
22
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

2.1.3 Warnings and Approvals
Symbols used in this Programming Guide.
Symbols
The following symbols are used in this manual.
WARNING
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may
also be used to alert against unsafe practices.
CAUTION
Indicates a situation that may result in equipment or
property-damage-only accidents.
2.1.4 Abbreviations and Standards
Abbreviations Terms SI-units I-P units
a Acceleration m/s2ft/s2
AWG American wire gauge
Auto Tune Automatic Motor Tuning
°CCelsius
I Current A Amp
ILIM Current limit
IT mains Mains supply with star point in transformer floating to ground
Joule Energy J=N∙m ft-lb, Btu
°FFahrenheit
FC frequency converter
f Frequency Hz Hz
kHz Kilohertz kHz kHz
LCP Local Control Panel
mA Milliampere
ms Millisecond
min Minute
MCT Motion Control Tool
M-TYPE Motor Type Dependent
Nm Newton Metres in-lbs
IM,N Nominal motor current
fM,N Nominal motor frequency
PM,N Nominal motor power
UM,N Nominal motor voltage
PELV Protective Extra Low Voltage
Watt Power W Btu/hr, hp
Pascal Pressure Pa = N/m² psi, psf, ft of water
IINV Rated Inverter Output Current
RPM Revolutions Per Minute
s Second
SR Size Related
T Temperature C F
t Time s s,hr
TLIM Torque limit
U Voltage V V
Table 2.2 Abbreviation and Standards Table
Introduction VLT®Micro Drive FC 51 Programming Guide
MG02C602 - VLT®is a registered Danfoss trademark 7
22
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

3 Programming
3.1 How to Programme
3.1.1 Programming with MCT 10 Set-up
Software
The frequency converter can be programmed from a PC
via RS-485 com-port by installing the MCT 10 Set-up
Software.
This software can either be ordered using code number
130B1000 or downloaded from the Danfoss Web site:
www.danfoss.com/BusinessAreas/DrivesSolutions/software-
download
Refer to the manual for Motion Control Tools MG10R.
3.1.2 Programming with the LCP 11 or LCP
12
The LCP is divided into four functional groups:
1. Numeric display.
2. Menu key.
3. Navigation keys.
4. Operation keys and indicator lights (LEDs).
Illustration 3.1 LCP 12 with Potentiometer
Illustration 3.2 LCP 11 without Potentiometer
The display
Different information can be read from the display.
Set-up number shows the active set-up and the edit set-
up. If the same set-up acts as both active and edit set-up,
only that set-up number is shown (factory setting).
When active and edit set-up differ, both numbers are
shown in the display (Set-up 12). The number flashing,
indicates the edit set-up.
Illustration 3.3 Indicating Set-up
The small digits to the left are the selected parameter
number.
Illustration 3.4 Indicating Selected Parameter Number
The large digits in the middle of the display show the
value of the selected parameter.
Illustration 3.5 Indicating Value of Selected Parameter
The right side of the display shows the unit of the selected
parameter. This can be either Hz, A, V, kW, HP, %, s or
RPM.
Illustration 3.6 Indicating Unit of Selected Parameter
Programming VLT®Micro Drive FC 51 Programming Guide
8 MG02C602 - VLT®is a registered Danfoss trademark
33
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

Motor direction is shown to the bottom left of the display
- indicated by a small arrow pointing either clockwise or
counterclockwise.
Illustration 3.7 Indicating Motor Direction
Press the [Menu] key to select one of the following menus
Status Menu
The Status Menu is either in Readout Mode or Hand on
Mode. In Readout Mode the value of the currently selected
readout parameter is shown in the display.
In Hand on Mode the local LCP reference is displayed.
Quick Menu
Displays Quick Menu parameters and their settings.
Parameters in the Quick Menu can be accessed and edited
from here. Most applications can be run by setting the
parameters in the Quick Menus.
Main Menu
Displays Main Menu parameters and their settings. All
parameters can be accessed and edited here.
Indicator lights
•Green LED: The frequency converter is on.
•Yellow LED: Indicates a warning. See 6 Trouble-
shooting.
•Flashing red LED: Indicates an alarm. See
6 Troubleshooting.
Navigation Keys
[Back]: For moving to the previous step or layer in the
navigation structure.
[▲] [▼]: For maneuvering between parameter groups,
parameters and within parameters.
[OK]: For selecting a parameter and for accepting changes
to parameter settings.
Pressing [OK] for more than 1 s enters 'Adjust' mode. In
'Adjust' mode, it is possible to make fast adjustment by
pressing [▲] [▼] combined with [OK].
Press [▲] [▼] to change value. Press [OK] to shift between
digits quickly.
To exit 'Adjust' mode, press [OK] more than 1 s again with
changes saving or press [Back] without changes saving.
Operation Keys
Ayellow light above the operation keys indicates the
active key.
[Hand On]: Starts the motor and enables control of the
frequency converter via the LCP.
[Off/Reset]: The motor stops except in alarm mode. In that
case the motor will be reset.
[Auto On]: The frequency converter is controlled either via
control terminals or serial communication.
[Potentiometer] (LCP 12): The potentiometer works in two
ways depending on the mode in which the frequency
converter is running.
In Auto Mode the potentiometer acts as an extra
programmable analog input.
In Hand on Mode the potentiometer controls local
reference.
3.2 Status Menu
After power up the Status Menu is active. Press [Menu] to
toggle between Status, Quick Menu and Main Menu.
[▲] and [▼] toggles between the choices in each menu.
The display indicates the status mode with a small arrow
above “Status”.
Illustration 3.8 Indicating Status Mode
Programming VLT®Micro Drive FC 51 Programming Guide
MG02C602 - VLT®is a registered Danfoss trademark 9
33
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

3.3 Quick Menu
The Quick Menu gives easy access to the most frequently
used parameters.
1. To enter the Quick Menu, press [Menu] key until
indicator in display is placed above Quick Menu.
2. Press [▲] [▼] to select either QM1 or QM2, then
press [OK].
3. Press [▲] [▼] to browse through the parameters
in the Quick Menu.
4. Press [OK] to select a parameter.
5. Press [▲] [▼] to change the value of a parameter
setting.
6. Press [OK] to accept the change.
7. To exit, press either [Back] twice to enter Status,
or press [Menu] once to enter Main Menu.
Illustration 3.9 Indicating Quick Menu Mode
3.4 Main Menu
The Main Menu gives access to all parameters.
1. To enter the Main Menu, press [Menu] key until
indicator in display is placed above Main Menu.
2. Press [▲] [▼] to browse through the parameter
groups.
3. Press [OK] to select a parameter group.
4. Press [▲] [▼] to browse through the parameters
in the specific group.
5. Press [OK] to select the parameter.
6. Press [▲] [▼] to set/change the parameter value.
7. Press [OK] to accept the value.
8. To exit, press either [Back] twice to enter Quick
Menu, or press [Menu] once to enter Status.
Illustration 3.10 Indicating Main Menu Mode
Programming VLT®Micro Drive FC 51 Programming Guide
10 MG02C602 - VLT®is a registered Danfoss trademark
33
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

4 Parameter Descriptions
4.1 Parameter Group 0: Operation/Display
0-03 Regional Settings
Option: Function:
In order to meet the needs for different default
settings in different parts of the world, 0-03
Regional Settings, is implemented in the
frequency converter. The selected setting
influences the default setting of the motor
nominal frequency.
[0 ] *Interna-
tional
Sets default of 1-23 Motor Frequency, to 50 Hz,
shows 1-20 Motor Power in kW.
[1] US Sets default of 1-23 Motor Frequency, to 60 Hz,
shows 1-20 Motor Power in HP.
NOTE
This parameter cannot be changed while
motor runs.
0-04 Operating State at Power-up (Hand Mode)
Option: Function:
This parameter controls whether or not the
frequency converter start running the motor
when powering up after a power down in
Hand mode.
NOTE
If LCP with potentiometer is mounted,
reference is set according to actual
potentiometer value.
[0] Resume Frequency converter starts in same Hand or
Off State as when powered off.
Local reference is stored and used after
power-up.
[1] *Forced
Stop,
Ref=Old
Frequency converter powers up in Off State
meaning that motor is stopped after power
up.
Local reference is stored and used after
power-up.
[2] Forced
Stop, Ref=0
Frequency converter powers up in Off State
meaning that motor is stopped after power
up.
Local reference is set to 0. Thus motor will
not start running before local reference has
been increased.
4.1.1 0-1* Set-up Handling
User-defined parameters and miscellaneous external inputs
(eg. bus, LCP, analog/digital inputs, feedback, etc.) controls
the functionality of the frequency converter.
A complete set of all parameters controlling the frequency
converter is called a set-up. The frequency converter
contains 2 set-ups, Set-up 1 and Set-up 2.
Furthermore, a fixed set of factory settings can be copied
into one or more set-ups.
Some of the advantages of having more than one set-up
in the frequency converter are
•Run motor in one set-up (Active Set-up) while
updating parameters in another set-up (Edit Set-
up)
•Connect various motors (one at a time) to
frequency converter. Motor data for various
motors can be placed in different set-ups.
•Rapidly change settings of frequency converter
and/or motor while motor is running (eg. ramp
time or preset references) via bus or digital
inputs.
The Active Set-up can be set as Multi Set-up where the
active set-up is selected via input on a digital input
terminal and/or via the bus control word.
NOTE
Factory Set-up cannot be used as Active Set-up.
0-10 Active Set-up
Option: Function:
Active Set-up controls the motor.
Shifts between set-ups can only happen when
•the motor is coasted
OR
•the set-ups between which the shift
happens are linked to each other (see
0-12 Linked Set-ups).
If changing between set-ups that are not linked,
the change will not happen before motor is
coasted.
NOTE
The motor is only considered stopped
when it is coasted.
Parameter Descriptions VLT®Micro Drive FC 51 Programming Guide
MG02C602 - VLT®is a registered Danfoss trademark 11
44
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

0-10 Active Set-up
Option: Function:
[1 ] *Set-up 1 Set-up 1 is active.
[2] Set-up 2 Set-up 2 is active.
[9] Multi
Set-up
Select the active set-up via digital input and/or
bus, see 5-1* Digital Inputs choice [23].
0-11 Edit Set-up
Option: Function:
The Edit Set-up is for updating parameters in
the frequency converter from either LCP or
bus. It can be identical or different from the
Active Set-up.
All set-ups can be edited during operation,
independently of the active set-up.
[1 ] *Set-up 1 Update parameters in Set-up 1.
[2] Set-up 2 Update parameters in Set-up 2.
[9] Active Set-
up
Update parameters in set-up selected as
Active Set-up (see 0-10 Active Set-up).
0-12 Link Set-ups
Option: Function:
The link ensures synchronizing of the “not
changeable during operation” parameter values
enabling shift from one set-up to another
during operation.
If the set-ups are not linked, a change between
them is not possible while the motor is running.
Thus the set-up change does not occur until the
motor is coasted.
[0] Not
linked
Leaves parameters unchanged in both set-ups
and cannot be changed while motor runs.
[1 ] *Linked Copy parameters “not changeable during
operation” parameter values into presently
selected Edit Set-up.
NOTE
This parameter cannot be changed while
motor runs.
0-31 Custom Readout Min Scale
Range: Function:
0.00 *[0.00–
9999.00 ]
It is possible to create a customized
readout related to the output frequency of
the unit. The value entered in 0-31 Custom
Readout Min Scale will be shown at 0 Hz.
The readout can be shown in the LCP
display when in Status Mode or it can be
read in 16-09 Custom Readout
0-32 Custom Readout Max Scale
Range: Function:
100.0*[0.00–
9999.00]
It is possible to create a customized readout
related to the output frequency of the unit.
The value entered in 0-32 Custom Readout
Max Scale will be shown at the frequency
programmed in 4-14 Motor Speed High Limit.
The readout can be shown in the LCP
display when in Status Mode or it can be
read in 16-09 Custom Readout
4.1.2 0-4* LCP
The frequency converter can operate in the following three
modes: Hand, Off and Auto.
Hand: The frequency converter is locally operated and does
not allow any remote control. By activating Hand a start
signal is given.
OFF: The frequency converter stops with a normal stop
ramp. When Off is chosen the frequency converter can
only be started by pressing either Hand or Auto on the
LCP.
Auto: In Auto-mode the frequency converter can be
remote controlled (bus/digital).
0-40 [Hand On] Key on LCP
Option: Function:
[0] Disabled [Hand On] key has no function.
[1 ] *Enabled [Hand On] key is functional.
0-41 [Off/Reset] Key on LCP
Option: Function:
[0] Disable Off/Reset [Off/Reset] key has no function.
[1 ] *Enable Off/Reset Stop signal and reset of any faults.
[2] Enable Reset Only Reset only. Stop (Off) function is
disabled.
0-42 [Auto On] Key on LCP
Option: Function:
[0] Disabled [Auto On] key has no function.
[1 ] *Enabled [Auto On] key is functional.
Parameter Descriptions VLT®Micro Drive FC 51 Programming Guide
12 MG02C602 - VLT®is a registered Danfoss trademark
44
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

4.1.3 0-5* Copy/Save
0-50 LCP Copy
Option: Function:
The detachable LCP of the frequency
converter can be used for storing setups,
and thus for transferring data when
moving parameter settings from one
frequency converter to another.
NOTE
LCP Copy can only be activated from
the LCP and ONLY when the motor
is coasted.
[1] All to LCP Copy all setups from the frequency
converter into the LCP.
[2] All from LCP Copy all setups from LCP to frequency
converter.
[3] Size independent
from LCP
Copy non motor size dependent data
from LCP to frequency converter.
0-51 Set-up Copy
Option: Function:
Use this function to copy a set-up content
into the Edit Set-up.
In order to be able to make a set-up copy
ensure that
•the motor is coasted
•0-10 Active Set-up, Active Set-up, is
set to either [1] Set-up 1 or [2] Set-
up 2
NOTE
The keyboard/parameter database are
blocked while Set-up Copy is running.
[0 ] *No Copy Copy function is inactive
[1] Copy from
Set-up 1
Copy from Set-up 1 to edit set-up chosen in
0-11 Edit Set-up.
[2] Copy from
Set-up 2
Copy from Set-up 2 to edit set-up chosen in
0-11 Edit Set-up.
[9] Copy from
Factory Set-
up
Copy from Factory Settings to edit set-up
chosen in 0-11 Edit set-up.
4.1.4 0-6* Password
0-60 (Main) Menu Password
Range: Function:
Use password for protection against unintended
change of sensitive parameters, eg. motor
parameters.
0 *[0-999] Enter the password for access to Main Menu via
the [Main Menu] key. Select the number that
should allow for changing other parameter values.
0means there is no password.
NOTE
A password has affect on the LCP - not on the bus
communication.
NOTE
Pressing [Menu], [OK] and [▼] will unlock the password.
This will automatically enter the parameter editing screen
in Quick Menu or Main Menu.
0-61 Access to Main/Quick Menu w/o Password
Option: Function:
[0] *Full access Select [0] Full Access to disable the
password in 0-60 (Main) Menu Password.
[1] LCP: Read Only Select [1] Read Only to block unauthorized
editing of Main/Quick menu parameter.
[2] LCP: No Access Select [2] No Access to block unauthorized
editing and viewing of Main/Quick menu
parameter.
Parameter Descriptions VLT®Micro Drive FC 51 Programming Guide
MG02C602 - VLT®is a registered Danfoss trademark 13
44
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

4.2 Parameter Group 1: Load/Motor
1-00 Configuration Mode
Option: Function:
Use this parameter for selecting the
application control principle to be used when
a Remote Reference is active.
NOTE
Changing this parameter will reset 3-00
Reference Range, 3-02 Minimum Reference
and 3-03 Maximum Reference to their
default values.
NOTE
This parameter cannot be adjusted
while motor runs.
[0 ] *Speed
Open Loop
For normal speed control (References).
[3] Process
Closed
Loop
Enables process closed loop control. See
parameter group 7-3* Process PI Control for
further information on PI-controller.
1-01 Motor Control Principle
Option: Function:
[0] U/f Is used for parallel connected motors and/or special
motor applications. The U/f settings are set in 1-55
U/f Characteristic -U and 1-56 U/f Characteristic -F.
NOTE
When running U/f control slip- and load
compensations are not included.
[1] *VVC+ Normal running mode, including slip- and load
compensations.
1-03 Torque Characteristics
Option: Function:
With more torque characteristics it is
possible to run low energy consuming, as
well as high torque applications.
[0 ] *Constant
Torque
Motor shaft output provides constant
torque under variable speed control.
[2] Automatic
Energy Optimi-
sation
This function automatically optimizes
energy consumption in centrifugal pump
and fan applications. See 14-41 AEO
Minimum Magnetisation.
1-05 Hand Mode Configuration
Option: Function:
This parameter is only relevant when 1-00
Configuration Mode is set to [3] Process Closed
Loop. The parameter is used for determining
the reference or setpoint handling when
changing from Auto Mode to Hand Mode on
the LCP.
[0] Speed
Open
Loop
In Hand Mode the drive always runs in Open
Loop configuration regardless of setting in 1-00
Configuration Mode. Local potentiometer (if
present) or Arrow up/down determines output
1-05 Hand Mode Configuration
Option: Function:
frequency limited by Motor Speed High/Low
Limit (4-14 Motor Speed High Limit and 4-12
Motor Speed Low Limit).
[2] *As config-
uration in
1-00
Configu-
ration
Mode.
If 1-00 Configuration Mode is set to [1] Open
Loop function is as described above.
If 1-00 Configuration Mode is set to [3] Process
Closed Loop changing from Auto mode to Hand
mode results in a setpoint change via local
potentiometer or Arrow up/down. The change
is limited by Reference Max/Min (3-02 Minimum
Reference and 3-03 Maximum Reference).
4.2.1 1-2* Motor Data
Enter the correct motor nameplate data (power, voltage,
frequency, current and speed).
Run AMT, see 1-29 Automatic Motor Tuning (AMT).
Factory settings for advanced motor data, parameter group
1-3* Adv. Motor Data, are automatically calculated.
NOTE
Parameters in parameter group 1-2* Motor Data cannot be
adjusted while motor runs.
1-20 Motor Power [kW]/[HP] (Pm.n)
Option: Function:
Enter motor power from nameplate
data.
Two sizes down, one size up from
nominal VLT rating.
[1] 0.09 kW/0.12 HP
[2] 0.12 kW/0.16 HP
[3] 0.18kW/0.25 HP
[4] 0.25 kW/0.33 HP
[5] 0.37kW/0.50 HP
[6] 0.55 kW/0.75 HP
[7] 0.75 kW/1.00 HP
[8] 1.10 kW/1.50 HP
[9] 1.50 kW/2.00 HP
[10] 2.20 kW/3.00 HP
[11] 3.00 kW/4.00 HP
[12] 3.70 kW/5.00 HP
[13] 4.00 kW/5.40 HP
[14] 5.50 kW/7.50 HP
[15] 7.50 kW/10.0 HP
[16] 11.00 kW/15.00 HP
[17] 15.00 kW/20.00 HP
[18] 18.50 kW/25.00 HP
[19] 22.00 kW/29.50 HP
[20] 30.00 kW/40.00 HP
Parameter Descriptions VLT®Micro Drive FC 51 Programming Guide
14 MG02C602 - VLT®is a registered Danfoss trademark
44
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

NOTE
Changing this parameter affects parameters 1-22 Motor
Voltage to 1-25 Motor Frequency, 1-30 Stator Resistance, 1-33
Stator Leakage Reactance and 1-35 Main Reactance.
1-22 Motor Voltage (U_m.n)
Range: Function:
230/400 V [50-999 V] Enter motor voltage from nameplate
data.
1-23 Motor Frequency (f_m.n)
Range: Function:
50 Hz*[20-400 Hz] Enter motor frequency from nameplate
data.
1-24 Motor Current (I_m.n)
Range: Function:
M-type dependent*[0.01-100.00 A] Enter motor current from
nameplate data.
1-25 Motor Nominal Speed (n_m.n)
Range: Function:
M-type Dependent*[100-9999 RPM] Enter motor nominal
speed from nameplate
data.
1-29 Automatic Motor Tuning (AMT)
Option: Function:
Use AMT to optimize motor performance.
NOTE
This parameter cannot be changed while
motor runs.
1. Stop the frequency converter - make
sure motor is at standstill
2. Choose [2] Enable AMT
3. Apply start signal
- Via LCP: Press [Hand On]
- Or in Remote On mode: Apply start
signal on terminal 18
[0] *Off AMT function is disabled.
[2] Enable
AMT
AMT function starts running.
NOTE
To gain optimum tuning of the frequency
converter, run AMT on a cold motor.
4.2.2 1-3* Adv. Motor Data
Adjust advanced motor data using one of these methods:
1. Run AMT on cold motor. The frequency converter
measures value from motor.
2. Enter X1value manually. Obtain value from motor
supplier.
3. Use Rs, X1, and X2default setting. The frequency
converter establishes setting based on motor
nameplate data.
NOTE
These parameters cannot be changed while the motor
runs.
130BA375.11
RS
P 1-30
R1s Xh
P1-35
R1
X2
X1
U1
I1
Illustration 4.1
1-30 Stator Resistance (Rs)
Range: Function:
Depending on motor data*[Ohm] Set stator resistance value.
1-33 Stator Leakage Reactance (X1)
Range: Function:
Depending on motor
data*
[Ohm] Set stator leakage reactance
of motor.
1-35 Main Reactance (X2)
Range: Function:
Depending on motor data*[Ohm] Set motor main reactance.
4.2.3 1-5* Load Independent Setting
This parameter group is for setting the load independent
motor settings.
1-50 Motor Magnetization at Zero Speed
Range: Function:
This parameter enables different thermal
load on motor when running at low speed.
100 %*[ 0-300%] Enter a percentage of rated magnetizing
current. If setting is too low, motor shaft
torque may be reduced.
Parameter Descriptions VLT®Micro Drive FC 51 Programming Guide
MG02C602 - VLT®is a registered Danfoss trademark 15
44
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

1-52 Min. Speed Normal Magnetizing [Hz]
Range: Function:
Use this parameter along with 1-50 Motor
Magnetizing at Zero Speed.
0.0 Hz*[0.0-10.0 Hz] Set frequency required for normal
magnetizing current. If frequency is set
lower than motor slip frequency, 1-50
Motor Magnetizing at Zero Speed is
inactive.
Magn. current
130BD016.10
Hz
Par.1-50
Par.1-51
100%
Par.1-52 RPM
Illustration 4.2
1-55 U/f Characteristic - U
Range: Function:
This parameter is an array parameter [0-5]
and is only functional when 1-01 Motor
Control Principle is set to [0] U/f.
0.0 V*[0.0-999.9 V] Enter voltage at each frequency point to
manually form a U/f characteristic
matching motor. Frequency points are
defined in 1-56 U/f characteristics - F.
1-56 U/f Characteristic - F
Range: Function:
This parameter is an array parameter [0-5]
and is only functional when 1-01 Motor
Control Principle is set to [0] U/f.
0.0
Hz*
[0.0-1000.0
Hz]
Enter frequency points to manually form a
U/f characteristic matching motor. Voltage
at each point is defined in 1-55 U/f
Characteristic - U.
Make a U/f characteristic based on 6
definable voltages and frequencies, see
Illustration 4.3.
Simplify U/f characteristics by merging 2
or more points (voltages and frequencies),
respectively, are set equal.
Motor Voltage
Par 1-55 [x]
Output Frequency
Par 1-56 [x]
1-55[5]
1-55[4]
1-55[3]
1-55[2]
1-55[1]
1-55[0]
1-56
[0]
1-56
[1]
1-56
[2]
1-56
[3]
1-56
[4]
1-56
[5]
130BD017.10
Illustration 4.3 U/f Characteristics
NOTE
For 1-56 U/f characteristics - F the following applies
[0] ≦[1] ≦[2] ≦[3] ≦[4] ≦[5]
4.2.4 1-6* Load Dependent Setting
Parameters for adjusting the load-dependent motor
settings.
1-60 Low Speed Load Compensation
Range: Function:
Use this parameter to gain optimum U/f
characteristic when running at low speed.
100 %*[0-199 %] Enter percentage in relation to load when
motor runs at low speed.
Change-over point is automatically
calculated based on motor size.
130BD018.10
60%
0%
100%
U
m
Changeover
fout
Par.1-60 Par.1-61
Illustration 4.4
Parameter Descriptions VLT®Micro Drive FC 51 Programming Guide
16 MG02C602 - VLT®is a registered Danfoss trademark
44
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

1-61 High Speed Load Compensation
Range: Function:
Use this parameter to obtain optimum load
compensation when running at high speed.
100 %*[0-199 %] Enter percentage to compensate in relation
to load when motor runs at high speed.
Change-over point is automatically
calculated based on motor size.
1-62 Slip Compensation
Range: Function:
100 %*[-400-399
%]
Compensation for load dependent motor
slip.
Slip compensation is calculated automat-
ically based on rated motor speed, nM,N.
NOTE
This function is only active when
1-00 Configuration Mode, is set to [0]
Speed Open Loop and when 1-01
Motor Control Principle, is set to [1]
VVCplus
1-63 Slip Compensation Time
Range: Function:
0.10 s [0.05-5.00 s] Enter slip compensation reaction speed. A
high value results in slow reaction whereas
a low value results in quick reaction.
If low-frequency resonance problems arise,
use longer time setting.
4.2.5 1-7* Start Adjustments
Considering the need for various start functions in different
applications, it is possible to select a number of functions
in this parameter group.
1-71 Start Delay
Range: Function:
The start delay defines the time to pass from
astart command is given until the motor
starts accelerating.
Setting start delay to 0.0 s disables 1-72 Start
Function, when start command is given.
0.0 s*[0.0-10.0
s]
Enter the time delay required before
commencing acceleration.
1-72 Start Function is active during Start delay
time.
1-72 Start Function
Option: Function:
[0] DC Hold/Delay
Time
Motor is energised with DC holding
current (2-00 DC Hold Current) during
start delay time.
[1] DC Brake/Delay
Time
Motor is energised with DC braking
current (2-01 DC Brake Current) during
start delay time.
[2] *Coast/Delay
Time
Inverter is coasted during start delay time
(inverter off).
1-73 Flying Start
Option: Function:
The Flying Start parameter is used to catch a
spinning motor after eg. mains drop-out.
NOTE
This function is not suitable for hoisting
applications.
[0] *Disabled Flying start is not required.
[1] Enabled Frequency converter enabled to catch spinning
motor.
NOTE
When flying start is enabled 1-71 Start Delay,
and 1-72 Start Function, have no function.
4.2.6 1-8* Stop Adjustments
To meet the need for various stop functions in different
application these parameters offer some special stop
features for the motor.
1-80 Function at Stop
Option: Function:
The selected function at stop is active in following
situations:
•Stop command is given and output
speed is ramped down to Min. Speed for
Function at Stop.
•Start command is removed (standby),
and output speed is ramped down to
Min. Speed for Function at Stop.
•DC-brake command is given, and DC-
brake time has passed
•While running and calculated output
speed is below Min. Speed for Function at
Stop.
[0] *Coast The inverter is coasted.
[1] DC
hold
The motor is energised with a DC current. See
2-00 DC Hold Current for more information.
1-82 Min. Speed For Function at Stop [Hz]
Range: Function:
0.0 Hz*[0.0-20.0 Hz] Set the speed at which to activate 1-80
Function at Stop.
Parameter Descriptions VLT®Micro Drive FC 51 Programming Guide
MG02C602 - VLT®is a registered Danfoss trademark 17
44
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

4.2.7 1-9* Motor Temperature
With an estimated motor temperature monitor the
frequency converter is able to estimate motor temperature
without having a thermistor mounted. It is thus possible to
receive a warning or an alarm, if motor temperature
exceeds upper operational limit.
1-90 Motor Thermal Protection
Option: Function:
Using ETR (Electronic Terminal Relay) the
motor temperature is calculated based on
frequency, speed and time. Danfoss
recommends using The ETR function, if a
thermistor is not present.
NOTE
ETRElectronic Overload calculation is
based on motor data from parameter
group 1-2* Motor Data.
[0] *No Protection Disables temperature monitoring.
[1] Thermistor
Warning
A thermistor connected to either digital or
analog input gives a warning if upper limit
of motor temperature range is exceeded,
(see 1-93 Thermistor Resource).
[2] Thermistor
Trip
A thermistor connected to either digital or
analog input gives an alarm and makes the
frequency converter trip if upper limit of
motor temperature range is exceeded, (see
1-93 Thermistor Resource.
[3] ETR Warning If calculated upper limit of motor
temperature range is exceeded, a warning
occurs.
[4] ETR Trip If 90% of calculated upper limit of motor
temperature range is exceeded, an alarm
occurs and the frequency converter trips.
NOTE
When the ETR function has been selected the drive will
store the recorded temperature at power down and this
temperature will resume at power up regardless of the
elapsed time. Changing 1-90 Motor Thermal Protection back
to [0] No Protection will reset the recorded temperature.
1-93 Thermistor Resource
Option: Function:
Select the thermistor input terminal.
[0] *None No thermistor is connected.
[1] Analog
Input 53
Connect thermistor to analog input terminal
53.
NOTE
Analog input 53 cannot be selected for
other purposes when selected as
thermistor resource.
[6] Digital
input 29
Connect thermistor to digital input terminal 29.
While this input functions as thermistor input,
it will not respond to the function chosen in
5-13 Digital Input 29. The value of 5-13 Digital
Input 29 remains however unchanged in
parameter database while function is inactive.
Input Digital/
Analog
Supply
Voltage
Threshold Cut-
out
Values
Digital 10 V <800 Ω ⇒2.9
kohm
Analog 10 V <800 Ω ⇒2.9
kohm
Table 4.1
Parameter Descriptions VLT®Micro Drive FC 51 Programming Guide
18 MG02C602 - VLT®is a registered Danfoss trademark
44
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

4.3 Parameter Group 2: Brakes
4.3.1 2-** Brakes
4.3.2 2-0* DC-Brake
The purpose of DC-brake function is to brake a rotating
motor by applying DC-current to the motor.
2-00 DC Hold Current
Range: Function:
This parameter either holds the motor (holding
torque) or pre-heats the motor.
The parameter is active if DC Hold has been
selected in either 1-72 Start Function or 1-80
Function at Stop.
50%*[0-100%] Enter a value for holding current as a
percentage of the rated motor current set in
1-24 Motor Current. 100% DC holding current
corresponds to IM,N.
NOTE
Avoid 100% current too long as it may overheat the motor.
2-01 DC Brake Current
Range: Function:
50
%*
[0-150%] Set DC-current needed to brake rotating
motor.
Activate DC-brake in one of the four following
ways:
1. DC-brake command, see 5-1* Digital
Inputs choice [5]
2. DC Cut-in function, see 2-04 DC-Brake
Cut-in Speed
3. DC-brake selected as start function,
see 1-72 Start Function
4. DC-brake in connection with Flying
Start, 1-73 Flying Start.
2-02 DC-Braking Time
Range: Function:
DC-braking time defines the period during
which DC-brake current is applied to the
motor.
10.0 s*[0.0-60 s] Set the time DC-braking current, set in 2-01
DC Brake Current, must be applied.
NOTE
If DC-brake is activated as start function, DC-brake time is
defined by start delay time.
2-04 DC-Brake Cut-in Speed
Range: Function:
0.0 Hz*[0.0-400.0 Hz] Set DC-brake cut-in speed to activate
DC braking current, set in 2-01 DC Brake
Current, when ramping down.
When set to 0 the function is off.
4.3.3 2-1* Brake Energy Function
Use the parameters in this group for selecting dynamic
braking parameters.
2-10 Brake Function
Option: Function:
Resistor Brake:
The resistor brake limits voltage in the
intermediate circuit when the motor acts as
generator. Without brake resistor, the frequency
converter eventually trips.
The resistor brake consumes surplus energy
resulting from motor braking. A frequency
converter with brake, stops a motor faster than
without a brake, which is used in many
applications. Requires connection of external
brake resistor.
An alternative to the resistor brake is the AC
brake.
NOTE
Resistor brake is only functional in
frequency converters with integrated
dynamic brake. An external resistor must
be connected.
AC Brake:
The AC brake consumes surplus energy by
creating power loss in the motor.
It is important to keep in mind that an increase
in power loss causes motor temperature to rise.
[0] *Off No brake function.
[1] Resistor
Brake
Resistor brake is active.
[2] AC Brake AC brake is active.
2-11 Brake Resistor (Ohm)
Range: Function:
5 Ω*[5-5000 Ω] Set brake resistor value.
2-16 AC Brake, Max Current
Range: Function:
100.0%*[0.0-150.0%] Enter max. permissible current for AC-
braking to avoid overheating of motor.
100% equals motor current set in 1-24
Motor Current.
Parameter Descriptions VLT®Micro Drive FC 51 Programming Guide
MG02C602 - VLT®is a registered Danfoss trademark 19
44
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx
