1 Introduction
1.1 How to Read This Programming Guide
1.1.1 Purpose of the Manual
This programming guide provides information about
controlling the frequency converter, accessing parameters,
programming, and troubleshooting.
The programming guide is intended for use by qualied
personnel who are familiar with the VLT®Midi Drive FC
280 frequency converter.
Read the instructions before programming and follow the
procedures in this manual.
VLT®is a registered trademark.
1.1.2 Additional Resources
Additional resources include:
•VLT
®
Midi Drive FC 280 Operating Instructions
provide the necessary information for getting the
frequency converter up and running.
•VLT
®
Midi Drive FC 280 Design Guide provides
detailed technical information about the
frequency converter and customer design and
applications.
•VLT
®
Midi Drive FC 280 Service Manual provides
information to Danfoss authorized, qualied
technicians on how to service the FC 280
frequency converters.
Contact the local Danfoss supplier or go to vlt-
drives.danfoss.com to download the documentations.
1.1.3 Document and Software Version
This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Table 1.1 shows
the document version and the corresponding software
version.
Edition Remarks Software version
MG07C1 The rst version. 1.0
Table 1.1 Document and Software Version
AC Alternating current
AEO Automatic energy optimization
ACP Application control processor
AWG American wire gauge
AMA Automatic motor adaptation
°CDegrees Celsius
DC Direct current
EEPROM Electrically erasable programmable
read-only memory
EMC Electromagnetic compatibility
EMI Electromagnetic interference
ETR Electronic thermal relay
fM,N Nominal motor frequency
FC Frequency converter
IP Ingress protection
ILIM Current limit
IINV Rated inverter output current
IM,N Nominal motor current
IVLT,MAX Maximum output current
IVLT,N
Rated output current supplied by the
frequency converter
LdMotor d-axis inductance
LqMotor q-axis inductance
LCP Local control panel
MCP Motor control processor
N.A. Not applicable
PM,N Nominal motor power
PCB Printed circuit board
PE Protective earth
PELV Protective extra low voltage
PWM Pulse width modulated
RsStator resistance
Regen Regenerative terminals
RPM Revolutions per minute
RFI Radio frequency interference
SCR Silicon controlled rectier
SMPS Switch mode power supply
TLIM Torque limit
UM,N Nominal motor voltage
XhMotor main reactance
Table 1.2 Abbreviations
Introduction Programming Guide
MG07C102 Danfoss A/S © 12/2015 All rights reserved. 3
11

For compliance with the European Agreement concerning
International Carriage of Dangerous Goods by Inland
Waterways (ADN), refer to ADN-compliant Installation in the
VLT
®
Midi Drive FC 280 Design Guide.
Applied standards and compliance for STO
Use of STO on terminals 37 and 38 requires that the user
satises all provisions for safety including relevant laws,
regulations, and guidelines.
The integrated STO function complies with the following
standards:
•IEC/EN 61508: 2010 SIL 2
•IEC/EN 61800-5-2: 2007 SIL2
•IEC/EN 62061: 2012 SILCL of SIL2
•EN ISO 13849-1: 2008 Category 3 PL d
1.2 Denitions
1.2.1 Frequency Converter
Coast
The motor shaft is in free mode. No torque on the motor.
IVLT,MAX
Maximum output current.
IVLT,N
Rated output current supplied by the frequency converter.
UVLT,MAX
Maximum output voltage.
1.2.2 Input
Control commands
Start and stop the connected motor with LCP and digital
inputs.
Functions are divided into 2 groups.
Functions in group 1 have higher priority than functions in
group 2.
Group 1 Precise stop, coast stop, precise stop and coast
stop, quick stop, DC braking, stop, and [OFF].
Group 2 Start, pulse start, reversing, start reversing, jog,
and freeze output.
Table 1.3 Function Groups
1.2.3 Motor
Motor running
Torque generated on the output shaft and speed from
0 RPM to maximum speed on the motor.
fJOG
Motor frequency when the jog function is activated (via
digital terminals).
fM
Motor frequency.
fMAX
Maximum motor frequency.
fMIN
Minimum motor frequency.
fM,N
Rated motor frequency (nameplate data).
IM
Motor current (actual).
IM,N
Nominal motor current (nameplate data).
nM,N
Nominal motor speed (nameplate data).
ns
Synchronous motor speed
ns=2 × par . 1 −23 × 60s
par . 1 −39
nslip
Motor slip.
PM,N
Rated motor power (nameplate data in kW or hp).
TM,N
Rated torque (motor).
UM
Instantaneous motor voltage.
UM,N
Rated motor voltage (nameplate data).
Introduction VLT®Midi Drive FC 280
4 Danfoss A/S © 12/2015 All rights reserved. MG07C102
11

Break-away torque
175ZA078.10
Pull-out
rpm
Torque
Illustration 1.1 Break-away Torque
ηVLT
The eciency of the frequency converter is dened as the
ratio between the power output and the power input.
Start-disable command
A start-disable command belonging to the control
commands in group 1. See chapter 1.2.2 Input for more
details.
Stop command
A stop command belonging to the control commands in
group 1. See chapter 1.2.2 Input for more details.
1.2.4 References
Analog reference
A signal transmitted to the analog inputs 53 or 54, can be
voltage or current.
Binary reference
A signal transmitted to the serial communication port.
Preset reference
A dened preset reference to be set from -100% to +100%
of the reference range. Selection of 8 preset references via
the digital terminals.
Pulse reference
A pulse frequency signal transmitted to the digital inputs
(terminal 29 or 33).
RefMAX
Determines the relationship between the reference input at
100% full scale value (typically 10 V, 20 mA) and the
resulting reference. The maximum reference value is set in
parameter 3-03 Maximum Reference.
RefMIN
Determines the relationship between the reference input at
0% value (typically 0 V, 0 mA, 4 mA) and the resulting
reference. The minimum reference value is set in
parameter 3-02 Minimum Reference.
1.2.5 Miscellaneous
Analog inputs
The analog inputs are used for controlling various
functions of the frequency converter.
There are 2 types of analog inputs:
•Current input, 0–20 mA and 4–20 mA.
•Voltage input, 0 to +10 V DC.
Analog outputs
The analog outputs can supply a signal of 0–20 mA, or 4–
20 mA.
Automatic motor adaptation, AMA
The AMA algorithm determines the electrical parameters
for the connected motor at standstill.
Brake resistor
The brake resistor is a module capable of absorbing the
brake power generated in regenerative braking. This
regenerative brake power increases the intermediate circuit
voltage, and a brake chopper ensures that the power is
transmitted to the brake resistor.
CT characteristics
Constant torque characteristics used for all applications
such as conveyor belts, displacement pumps, and cranes.
Digital inputs
The digital inputs can be used for controlling various
functions of the frequency converter.
Digital outputs
The frequency converter features 2 solid-state outputs that
can supply a 24 V DC (maximum 40 mA) signal.
DSP
Digital signal processor.
ETR
Electronic thermal relay is a thermal load calculation based
on present load and time. Its purpose is to estimate the
motor temperature.
FC standard bus
Includes RS485 bus with FC protocol or MC protocol. See
parameter 8-30 Protocol.
Initialising
If initialising is carried out (parameter 14-22 Operation
Mode), the frequency converter returns to the default
setting.
Intermittent duty cycle
An intermittent duty rating refers to a sequence of duty
cycles. Each cycle consists of an on-load and an o-load
period. The operation can be either periodic duty or non-
periodic duty.
LCP
The local control panel makes up a complete interface for
control and programming of the frequency converter. The
control panel is detachable and can be installed up to 3 m
Introduction Programming Guide
MG07C102 Danfoss A/S © 12/2015 All rights reserved. 5
11

from the frequency converter, that is, in a front panel with
the installation kit option.
NLCP
The numerical local control panel interface for control and
programming of the frequency converter. The display is
numerical and the panel is used to show process values.
The NLCP has storing and copy functions.
lsb
Least signicant bit.
msb
Most signicant bit.
MCM
Short for mille circular mil, an American measuring unit for
cable cross-section. 1 MCM = 0.5067 mm2.
On-line/o-line parameters
Changes to on-line parameters are activated immediately
after the data value is changed. Press [OK] to activate
changes to o-line parameters.
Process PID
The PID control maintains speed, pressure, and
temperature by adjusting the output frequency to match
the varying load.
PCD
Process control data.
Power cycle
Switch o the mains until the display (LCP) is dark, then
turn power on again.
Power factor
The power factor is the relation between I1and IRMS.
Powerfactor =  3xUxI1cosϕ1
3xUxIRMS
For VLT®Midi Drive FC 280 frequency converters, cos ϕ 1=
1, therefore:
Powerfactor =  I1xcosϕ1
IRMS
= I1
IRMS

The power factor indicates to which extent the frequency
converter imposes a load on the mains supply.
The lower the power factor, the higher the IRMS for the
same kW performance.
IRMS =  I1
2+I5 2+I7 2 + .. + In 2
In addition, a high power factor indicates that the dierent
harmonic currents are low.
The built-in DC coils produce a high power factor,
minimising the imposed load on the mains supply.
Pulse input/incremental encoder
An external, digital pulse transmitter used for feeding back
information on motor speed. The encoder is used in
applications where great accuracy in speed control is
required.
RCD
Residual current device.
Set-up
Save parameter settings in 2 set-ups. Change between the
2 parameter set-ups and edit 1 set-up while another set-up
is active.
SFAVM
Acronym describing the switching pattern stator ux-
oriented asynchronous vector modulation.
Slip compensation
The frequency converter compensates for the motor slip by
giving the frequency a supplement that follows the
measured motor load, keeping the motor speed almost
constant.
Smart logic control (SLC)
The SLC is a sequence of user-dened actions executed
when the associated user-dened events are evaluated as
true by the smart logic controller (parameter group 13-**
Smart Logic Control).
STW
Status word.
THD
Total harmonic distortion states the total contribution of
harmonic distortion.
Thermistor
A temperature-dependent resistor placed where the
temperature is monitored (frequency converter or motor).
Trip
A state entered in fault situations, for example, if the
frequency converter is subject to overvoltage or when it is
protecting the motor, process, or mechanism. Restart is
prevented until the cause of the fault has disappeared, and
the trip state is canceled by activating reset or, sometimes,
by being programmed to reset automatically. Do not use
trip for personal safety.
Trip lock
A state entered in fault situations when the frequency
converter is protecting itself and requiring physical
intervention, for example, if the frequency converter is
subject to a short circuit on the output. A locked trip can
only be cancelled by cutting o mains, removing the cause
of the fault, and reconnecting the frequency converter.
Restart is prevented until the trip state is cancelled by
activating reset or, in some cases, by being programmed to
reset automatically. Do not use trip lock for personal safety.
VT characteristics
Variable torque characteristics used for pumps and fans.
VVC+
If compared with standard voltage/frequency ratio control,
voltage vector control (VVC+) improves the dynamics and
stability, both when the speed reference is changed and in
relation to the load torque.
60°AVM
Refers to the switching pattern 60
° asynchronous vector
modulation.
Introduction VLT®Midi Drive FC 280
6 Danfoss A/S © 12/2015 All rights reserved. MG07C102
11

1.3 Electrical Wiring - Control Cables
1.3.1 Overview
130BE202.12
3-phase
power
input
Switch mode
power supply
Motor
Analog output
interface
(PNP) = Source
(NPN) = Sink
ON = Terminated
OFF = Open
Brake
resistor
91 (L1)
92 (L2)
93 (L3)
PE
50 (+10 V OUT)
53 (A IN) **
54 (A IN)
55 (COM A IN)
0/4−20 mA
12 (+24 V OUT)
13 (+24 V OUT)
18 (D IN)
10 V DC
15 mA 100 mA
+ - + -
(U) 96
(V) 97
(W) 98
(PE) 99
(A OUT) 42
(P RS485) 68
(N RS485) 69
(COM RS485) 61
0 V
5 V
S801
0/4−20 mA
RS485
RS485
03
+10 V DC
0−10 V DC
24 V DC
02
01
24 V (NPN)
0 V (PNP)
0 V (PNP)
24 V (NPN)
19 (D IN)
24 V (NPN)
0 V (PNP)
27 (D IN/OUT)
24 V
0 V
0 V (PNP)
24 V (NPN)
29 (D IN)
24 V (NPN)
0 V (PNP)
0 V (PNP)
24 V (NPN)
33 (D IN)
32 (D IN)
38 (D IN)****
37 (D IN)****
95
P 5-00
21
ON
(+DC/R+) 89
(-BR) 81
0−10 V DC
(-DC) 88
RFI
0 V
250 V AC, 3 A
Relay 1
*
***
Illustration 1.2 Basic Wiring Schematic Drawing
A=Analog, D=Digital
* Built-in brake chopper is only available on 3-phase units.
** Terminal 53 can also be used as digital input.
*** Switch S801 (bus terminal) can be used to enable termination on the RS485 port (terminals 68 and 69).
Introduction Programming Guide
MG07C102 Danfoss A/S © 12/2015 All rights reserved. 7
11

In rare cases, long control cables and analog signals could
result in 50/60 Hz ground loops due to noise from mains
supply cables. If this occurs, break the screen or insert a
100 nF capacitor between screen and chassis.
The digital and analog inputs and outputs must be
connected separately to the common inputs (terminal 55)
of the frequency converter to avoid ground currents from
both groups to aect other groups. For example, switching
on the digital input could disturb the analog input signal.
Input polarity of control terminals
130BE730.10
12 13 18 19 27 29 32 33 55
+24 VDC
0 VDC
PNP (Source)
Digital input wiring
Illustration 1.3 PNP (Source)
NPN (Sink)
Digital input wiring
12 13 18 19 27 29 32 33 55
+24 VDC
0 VDC
130BE731.10
Illustration 1.4 NPN (Sink)
NOTICE
Control cables must be shielded/armoured.
See the section Using Shielded Control Cables in the design
guide for the correct termination of control cables.
130BA681.10
Illustration 1.5 Grounding of Shielded/Armoured Control
Cables
1.3.2 Start/Stop
Terminal 18 = parameter 5-10 Terminal 18 Digital Input [8]
Start.
Terminal 27 = parameter 5-12 Terminal 27 Digital Input [0]
No operation (Default coast inverse).
130BE732.10
12 13 18 322719 29 33
P 5-12 [2] P 5-10 [8]
Start/Stop
+24V
Speed
Start/Stop
[18]
Illustration 1.6 Start/Stop
Introduction VLT®Midi Drive FC 280
8 Danfoss A/S © 12/2015 All rights reserved. MG07C102
11

1.3.3 Pulse Start/Stop
Terminal 18 = parameter 5-10 Terminal 18 Digital Input[9]
Latched start.
Terminal 27 = parameter 5-12 Terminal 27 Digital Input [6]
Stop inverse.
12 18 19
130BD370.10
322927 31 33 20
P 5 - 12 [6] P 5 - 10[9]
+24V
Speed
Start Stop inverse
Start (18)
Start (27)
Illustration 1.7 Pulse Start/Stop
1.3.4 Speed Up/Down
Terminals 29/32 = Speed up/down
Terminal 18 = parameter 5-10 Terminal 18 Digital
Input [9] Start (default).
Terminal 27 = parameter 5-12 Terminal 27 Digital
Input [19] Freeze reference.
Terminal 29 = parameter 5-13 Terminal 29 Digital
Input [21] Speed up.
Terminal 32 = parameter 5-14 Terminal 32 Digital
Input [22] Speed down.
FC
+24 V
D IN
D IN
D IN
D IN
D IN
D IN
D IN
+10 V
A IN
A IN
COM
A OUT
12
18
19
27
29
32
33
31
50
53
54
55
42
130BD069.11
Illustration 1.8 Speed Up/Down
1.3.5 Potentiometer Reference
Voltage reference via a potentiometer
Reference source 1=[1] Analog input 53 (default).
Terminal 53, low voltage=0 V.
Terminal 53, high voltage=10 V.
Terminal 53, low ref./feedback=0 Hz.
Terminal 53, high ref./feedback=50 Hz.
Parameter 6-19 Terminal 53 mode=[1] Voltage.
130BD381.11
555042 53 54
Speed
P 6-15
1 kΩ
+10V/30mA
Ref. voltage
P 6-11 10V
Illustration 1.9 Potentiometer Reference
Introduction Programming Guide
MG07C102 Danfoss A/S © 12/2015 All rights reserved. 9
11

2 Safety
2.1 Safety Symbols
The following symbols are used in this document:
WARNING
Indicates a potentially hazardous situation that could
result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation that could
result in minor or moderate injury. It can also be used to
alert against unsafe practices.
NOTICE
Indicates important information, including situations that
can result in damage to equipment or property.
2.2 Qualied Personnel
Correct and reliable transport, storage, installation,
operation, and maintenance are required for the trouble-
free and safe operation of the frequency converter. Only
qualied personnel are allowed to install or operate this
equipment.
Qualied personnel are dened as trained sta, who are
authorized to install, commission, and maintain equipment,
systems, and circuits in accordance with pertinent laws and
regulations. Also, the personnel must be familiar with the
instructions and safety measures described in this guide.
2.3 Safety Precautions
WARNING
HIGH VOLTAGE
Frequency converters contain high voltage when
connected to AC mains input, DC supply, or load sharing.
Failure to perform installation, start-up, and maintenance
by qualied personnel can result in death or serious
injury.
•Only qualied personnel must perform instal-
lation, start-up, and maintenance.
WARNING
UNINTENDED START
When the frequency converter is connected to AC mains,
DC supply, or load sharing, the motor may start at any
time. Unintended start during programming, service, or
repair work can result in death, serious injury, or
property damage. The motor can start with an external
switch, a eldbus command, an input reference signal
from the LCP, via remote operation using MCT 10 Set-up
Software, or after a cleared fault condition.
To prevent unintended motor start:
•Disconnect the frequency converter from the
mains.
•Press [O/Reset] on the LCP before
programming parameters.
•Completely wire and assemble the frequency
converter, motor, and any driven equipment
before connecting the frequency converter to
AC mains, DC supply, or load sharing.
WARNING
DISCHARGE TIME
The frequency converter contains DC-link capacitors,
which can remain charged even when the frequency
converter is not powered. High voltage can be present
even when the warning LED indicator lights are o.
Failure to wait the specied time after power has been
removed before performing service or repair work can
result in death or serious injury.
•Stop the motor.
•Disconnect AC mains and remote DC-link
supplies, including battery back-ups, UPS, and
DC-link connections to other frequency
converters.
•Disconnect or lock PM motor.
•Wait for the capacitors to discharge fully. The
minimum waiting time is specied in Table 2.1.
•Before performing any service or repair work,
use an appropriate voltage measuring device to
make sure that the capacitors are fully
discharged.
Safety VLT®Midi Drive FC 280
10 Danfoss A/S © 12/2015 All rights reserved. MG07C102
22

Voltage [V] Power range
[kW (hp)]
Minimum waiting time
(minutes)
200–240 0.37–3.7 (0.5–5) 4
380–480 0.37–7.5 (0.5–10) 4
11–22 (15–30) 15
Table 2.1 Discharge Time
WARNING
LEAKAGE CURRENT HAZARD
Leakage currents exceed 3.5 mA. Failure to ground the
frequency converter properly can result in death or
serious injury.
•Ensure the correct grounding of the equipment
by a certied electrical installer.
WARNING
EQUIPMENT HAZARD
Contact with rotating shafts and electrical equipment
can result in death or serious injury.
•Ensure that only trained and qualied personnel
perform installation, start-up, and maintenance.
•Ensure that electrical work conforms to national
and local electrical codes.
•Follow the procedures in this guide.
CAUTION
INTERNAL FAILURE HAZARD
An internal failure in the frequency converter can result
in serious injury when the frequency converter is not
properly closed.
•Ensure that all safety covers are in place and
securely fastened before applying power.
Safety Programming Guide
MG07C102 Danfoss A/S © 12/2015 All rights reserved. 11
22

3 Programming
3.1 Local Control Panel Operation
The frequency converter supports numerical local control
panel (NLCP), graphic local control panel (GLCP), and blind
cover. This chapter describes the operations with NLCP and
GLCP.
NOTICE
The frequency converter can also be programmed from
the MCT 10 Set-up Software on PC via RS485 communi-
cation port. This software can be ordered using code
number 130B1000 or downloaded from the Danfoss
website: www.danfoss.com/BusinessAreas/DrivesSolutions/
softwaredownload.
3.1.1 Numeric Local Control Panel (LCP)
The numerical local control panel (NLCP) is divided into 4
functional sections.
A. Numeric display.
B. Menu key.
C. Navigation keys and indicator lights (LEDs).
D. Operation keys and indicator lights (LEDs).
130BC506.10
Setup 1
A
B
C
D
5
12
13 14 15
10
11
10
9
6
7
8
4
1
2
3
Menu
Status Quick
Menu
Main
Menu
Hand
On
O
Reset
Auto
On
Back
OK
On
Warn
Alarm
Illustration 3.1 View of the NLCP
A. Numeric display
The LCD-display is back-lit with 1 numeric line. All data is
shown in the NLCP.
1 The set-up number shows the active set-up and the edit
set-up. If the same set-up acts as both active and edit set-
up, only that set-up number is shown (factory setting).
When active and edit set-up dier, both numbers are
shown in the display (for example set-up 12). The number
ashing indicates the edit set-up.
2 Parameter number.
3 Parameter value.
4 Motor direction is shown in the bottom left of the display.
A small arrow indicates the direction.
5 The triangle indicates whether the LCP is in Status, Quick
Menu, or Main Menu.
Table 3.1 Legend to Illustration 3.1, Section A
130BD135.10
Setup 1234
INDEX
AHP
VkW
srpm
Hz%
n2n1 n3
p5 p4 p3 p2 p1
Illustration 3.2 Display Information
B. Menu key
To select between Status, Quick Menu, or Main Menu,
press [Menu].
C. Indicator lights (LEDs) and navigation keys
Indicator Light Function
6 On Green ON turns on when the frequency
converter receives power from the
mains voltage, a DC bus terminal, or a
24 V external supply.
7 Warn Yellow When warning conditions are met, the
yellow WARN light turns on, and text
appears in the display area identifying
the problem.
8 Alarm Red A fault condition causes the red alarm
light to ash and an alarm text is
shown.
Table 3.2 Legend to Illustration 3.1, Indicator Lights (LEDs)
Programming VLT®Midi Drive FC 280
12 Danfoss A/S © 12/2015 All rights reserved. MG07C102
33

Key Function
9 [Back] For moving to the previous step or layer
in the navigation structure.
10 Arrows [▲] [▼]For switching between parameter groups,
parameters, and within parameters, or
increasing/decreasing parameter values.
Arrows can also be used for setting local
reference.
11 [OK] Press to access parameter groups or to
enable a selection.
12 [►]Press to move from left to right within
the parameter value to change each digit
individually.
Table 3.3 Legend to Illustration 3.1, Navigation Keys
D. Operation keys and indicator lights (LEDs)
Key Function
13 Hand On Starts the frequency converter in local control.
•An external stop signal by control input or
serial communication overrides the local
hand on.
14 O/Reset Stops the motor but does not remove power
to the frequency converter or resets the
frequency converter manually after a fault has
been cleared.
15 Auto On Puts the system in remote operational mode.
•Responds to an external start command by
control terminals or serial communication.
Table 3.4 Legend to Illustration 3.1, Section D
WARNING
ELECTRICAL HAZARD
Even after pressing the [O/Reset] key, voltage is present
at the terminals of the frequency converter. Pressing the
[O/Reset] key does not disconnect the frequency
converter from mains. Touching live parts can result in
death or serious injury.
•Do not touch any live parts.
3.1.2 The Right-key Function on NLCP
Press [►] to edit any of the 4 digits on the display
individually. When pressing [►] once, the cursor moves to
the rst digit, and the digit starts ashing as shown in
Illustration 3.3. Press the [▲] [▼] to change the value.
Pressing [►] does not change the value of the digits, or
move the decimal point.
130BC440.10
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Illustration 3.3 Right-key Function
[►] can also be used for moving between parameter
groups. When in Main Menu, press [►] to move to the rst
parameter in the next parameter group (for example, move
from parameter 0-03 Regional Settings [0] International to
parameter 1-00 Conguration Mode [0] Open loop).
NOTICE
During start-up, the NLCP shows the message LCP ON.
When this message is no longer shown, the frequency
converter is ready for operation. Adding or removing
options can extend the duration of start-up.
Programming Programming Guide
MG07C102 Danfoss A/S © 12/2015 All rights reserved. 13
33

3.1.3 Quick Menu on NLCP
The Quick Menu gives easy access to the most frequently
used parameters.
1. To enter Quick Menu, press [Menu] until the
indicator in display is placed above Quick Menu.
2. Press [▲] [▼] to select either QM1 or QM2, then
press [OK].
3. Press [▲] [▼] to browse through the parameters in
Quick Menu.
4. Press [OK] to select a parameter.
5. Press [▲] [▼] to change the value of a parameter
setting.
6. Press [OK] to accept the change.
7. To exit, press either [Back] twice (or 3 times if in
QM2 and QM3) to enter Status, or press [Menu]
once to enter Main Menu.
Programming VLT®Midi Drive FC 280
14 Danfoss A/S © 12/2015 All rights reserved. MG07C102
33

130BC445.12
1-22 XXXX V
Motor nominal speed
QM 1
0-01 [0]
1-10 [0]
1-24 XXXX A
Language Motor Type PM Motor Asynchronous Motor
1-20 XXXX kW Motor power
Motor voltage
Motor Cont. Rated Torque 1-26 XXXX 1-23 XXXX Hz
Stator Resistance
Motor frequency
1-25 XXXX rpm
(Rs) 1-30 XXXX
1-39 XXXX 1-40 XXXX
1-37 XXXX
1-25 XXXX rpm
1-24 XXXX AMotor Current
3-02 XXXX Hz 3-03 XXXX Hz
3-41 XXXX S
3-42 XXXX S
5-12 [2]
1-29 [1]
Minimum Reference Maximum Reference Ramp 1 Ramp up Time Ramp 1 Ramp Down Time Terminal 27 Digital input AMA
Motor Poles Back EMF at 1000 RPM
d-axis Inductance (Ld)
Basic Motor Setup Adv. Motor Setup Encoder Setup
QM 2
BMS AMS ES
5-70 XXXX
5-71 [0]
1-30 XXXX 1-39 XXXX
1-90 [0]
2-10 [0]
4-16 XXXX %
4-17 XXXX %
4-18 XXXX %
1-00 [0]
1-01 [1]
1-10 [0]
1-24 XXXX A1-20 XXXX kW
1-22 XXXX V
Motor nominal speed
PM Motor Asynchronous Motor
Motor power Motor voltage
Motor Cont. Rated Torque
1-26 XXXX 1-23 XXXX Hz
Stator Resistance
Motor frequency
1-25 XXXX rpm
(Rs) 1-30 XXXX
1-40 XXXX 1-37 XXXX
1-25 XXXX rpm
1-24 XXXX AMotor Current
Motor Poles
Back EMF at 1000 RPM
d-axis Inductance (Ld)
1-39 XXXX
4-19 XXXX Hz
4-14 XXXX Hz
Stator Resistance (Rs) Motor Poles Motor Thermal Protection Brake Function Torque Limit Motor Mode Torque Limit Generator Mode
Current Limit
Term 32/33 Pulses per Revolution Term 32/33 Encoder Direction
QM 3
QM 4 QM 5
L10C SFS
Last 10 Changes Since Factory Setting
Changes Made
Alarm Log TBD
Motor Current
Motor nominal speed
Motor nominal speed
Motor Current
Mode Motor Control Principle
Motor Type
Motor Speed High Limit [Hz] Max Output Frequency
Illustration 3.4 Quick Menu Structure
Programming Programming Guide
MG07C102 Danfoss A/S © 12/2015 All rights reserved. 15
33

3.1.4 Main Menu on NLCP
The Main Menu gives access to all parameters.
1. To enter Main Menu, press [Menu] until the
indicator in the display is placed above Main
Menu.
2. [▲] [▼]: Browse through the parameter groups.
3. Press [OK] to select a parameter group.
4. [▲] [▼]: Browse through the parameters in the
specic group.
5. Press [OK] to select the parameter.
6. [►] and [▲] [▼]: Set/change the parameter value.
7. Press [OK] to accept the value.
8. To exit, press either [Back] twice (or 3 times for
array parameters) to enter Main Menu, or press
[Menu] once to enter Status.
See Illustration 3.5, Illustration 3.6, and Illustration 3.7 for the
principles of changing the value of continuous,
enumerated, and array parameters, respectively. The
actions in the illustrations are described in Table 3.5,
Table 3.6, and Table 3.7.
130BC446.10
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
1
2
3
4
5
6
7
10
11
12
OK
OK
Back
8
Back
Setup 1
2 x
+
OK
9
OK
Illustration 3.5 Main Menu Interactions - Continuous
Parameters
Programming VLT®Midi Drive FC 280
16 Danfoss A/S © 12/2015 All rights reserved. MG07C102
33

1 [OK]: The rst parameter in the group is shown.
2Press [▼] repeatedly to move down to the parameter.
3 Press [OK] to start editing.
4[►]: First digit ashing (can be edited).
5[►]: Second digit ashing (can be edited).
6[►]: Third digit ashing (can be edited).
7[▼]: Decreases the parameter value, the decimal point
changes automatically.
8[▲]: Increases the parameter value.
9 [Back]: Cancel changes, return to 2.
[OK]: Accept changes, return to 2.
10 [▲][▼]: Select parameter within the group.
11 [Back]: Removes the value and shows the parameter group.
12 [▲][▼]: Select group.
Table 3.5 Changing Values in Continuous Parameters
For enumerated parameters, the interaction is similar, but
the parameter value is shown in brackets because of the
digits limitation (4 large digits) on NLCP, and the enum can
be greater than 99. When the enum value is greater than
99, the LCP can only show the rst part of the bracket.
130BC447.11
Setup 1
Setup 1
Setup 1
1
2
3
4
5
6
OK
OK
Back
7
OK
Back
Illustration 3.6 Main Menu Interactions - Enumerated
Parameters
1 [OK]: The rst parameter in the group is shown.
2 Press [OK] to start editing.
3[▲][▼]: Change parameter value (ashing).
4 Press [Back] to cancel changes or [OK] to accept changes
(return to screen 2).
5[▲][▼]: Select a parameter within the group.
6 [Back]: Removes the value and shows the parameter group.
7[▲][▼]: Select a group.
Table 3.6 Changing Values in Enumerated Parameters
Array parameters function as follows:
130BC448.10
1
2
4
5
6
7
8
9
10
OK
Back
Back
Back
5 x
Setup 1
Setup 1
Setup 1
Setup 1
%
INDEX
%
INDEX
%
INDEX
Setup 1
INDEX
%
OK
OK
OK
Illustration 3.7 Main Menu Interactions - Array Parameters
1 [OK]: Shows parameter numbers and the value in the rst
index.
2 [OK]: Index can be selected.
3[▲][▼]: Select index.
4 [OK]: Value can be edited.
5[▲][▼]: Change parameter value (ashing).
6 [Back]: Cancels changes.
[OK]: Accepts changes.
7 [Back]: Cancels editing index, a new parameter can be
selected.
8[▲][▼]: Select parameter within the group.
9 [Back]: Removes parameter index value and shows the
parameter group.
10 [▲][▼]: Select group.
Table 3.7 Changing Values in Array Parameters
Programming Programming Guide
MG07C102 Danfoss A/S © 12/2015 All rights reserved. 17
33

3.1.5 GLCP Layout
The GLCP is divided into 4 functional groups (see
Illustration 3.8).
A. Display area
B. Display menu keys
C. Navigation keys and indicator lights (LEDs)
D. Operation keys and reset
130BD598.10
Auto
on Reset
Hand
on Off
Status Quick
Menu
Main
Menu
Alarm
Log
Back
Cancel
Info
OK
Status 1(1)
36.4 kW
Auto Remote Ramping
0.000
On
Alarm
Warn.
A
7.83 A
799 RPM
B
C
D
53.2 %
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18 19 20 21
Illustration 3.8 Graphic Local Control Panel (GLCP)
A. Display area
The display area is activated when the frequency converter
receives power from the mains voltage, a DC bus terminal,
or a 24 V DC external supply.
The information shown on the LCP can be customized for
user applications. Select options in the Quick Menu Q3-13
Display Settings.
Display Parameter number Default setting
1 0-20 [1602] Reference [%]
2 0-21 [1614] Motor Current
3 0-22 [1610] Power [kW]
4 0-23 [1613] Frequency
5 0-24 [1502] kWh Counter
Table 3.8 Legend to Illustration 3.8, Display Area
B. Display menu keys
Menu keys are used for menu access for parameter set-up,
toggling through status display modes during normal
operation, and viewing fault log data.
Key Function
6 Status Shows operational information.
7 Quick
Menu
Allows access to programming parameters
for initial set-up instructions and many
detailed application instructions.
8 Main Menu Allows access to all programming
parameters.
9 Alarm Log Shows a list of current warnings, the last 10
alarms, and the maintenance log.
Table 3.9 Legend to Illustration 3.8, Display Menu Keys
C. Navigation keys and indicator lights (LEDs)
Navigation keys are used for programming functions and
moving the display cursor. The navigation keys also
provide speed control in local operation. There are also 3
frequency converter status indicator lights in this area.
Key Function
10 Back Reverts to the previous step or list in the
menu structure.
11 Cancel Cancels the last change or command as long
as the display mode has not changed.
12 Info Press for a denition of the function being
shown.
13 Navigation
Keys
To move between items in the menu, use the
4 navigation keys.
14 OK Press to access parameter groups or to
enable a selection.
Table 3.10 Legend to Illustration 3.8, Navigation Keys
Indicator Light Function
15 On Green ON turns on when the frequency
converter receives power from the
mains voltage, a DC bus terminal,
or a 24 V external supply.
16 Warn Yellow When warning conditions are met,
the yellow WARN light turns on,
and text appears in the display
area identifying the problem.
17 Alarm Red A fault condition causes the red
alarm light to ash, and an alarm
text is shown.
Table 3.11 Legend to Illustration 3.8, Indicator Lights (LEDs)
Programming VLT®Midi Drive FC 280
18 Danfoss A/S © 12/2015 All rights reserved. MG07C102
33
