Danfoss KoolKey EKA 200 User manual

Installation Guide
KoolKey
Type EKA 200
© Danfoss | Climate Solutions | 2022.04 AN404130514212en-000201 | 1
080R4218
AN404130514212en-000201
KoolKey is a gateway and programming device to:
• Connect the Danfoss electronic controller to a PC and act as a gateway when working online using
the KoolProg® application on the PC.
• Act as programming key to program parameter settings (conguration) into the Danfoss electronic
controllers in the production and eld.
Supported controller types:
1. ERC 111, 112, 113 2. ERC 211, 213, 214
3. EETc 11, 12, 21, 22 & EETa 2W, 3W 4. EKF 1A, 2A
KoolKey as a Gateway
Gateway mode makes it possible to work online with the connected
controller through KoolProg® on a PC.
KoolProg® allows following functions:
• Set Parameters – Create, view and edit controller settings.
• Copy to Controller – Program settings le created oine to the
connected controller.
• Online service – Monitor real time operations of the controllers and
make adjustments to the parameter settings while connected.
Connection:
• Connect the KoolKey using a standard USB cable to the USB port of
a PC installed with KoolProg® software
• Connect the controller to KoolKey other end using the interface cable
of the respective controller type
• The controller gets power from the PC via connected KoolKey
(Refer to the KoolProg® User Guide for detailed instructions on how to use KoolProg.
Download KoolProg® at: koolprog.danfoss.com)
Danfoss
80G8257
KoolProg®as Programming Key
The programming key function is used for transferring parameter
settings les from the KoolKey to the controller and vice versa.
Transfer or copy the parameter le in below format to KoolKey like
any other storage device.
We recommend to save only the le intended for the target
controller.
Danfoss 80G8274
Standard
Micro-USB
cable
Interface cable
Fig. 2: KoolKey as gateway
Fig. 1: KoolKey EKA 200
Controller File format Naming convention
EETa, EETc .xml 080Nxxxx.xml
ERC 11x .xml / .erc 080Gxxxx.xml / xxxx.erc
ERC 21x .xml / .erc 080Gxxxx.xml / xxxx.erc
EKF1A, EKF2A .xml 080Gxxxx.xml
Supported parameter le formats
Note: xxxx is the last four digits of controller's code no.
a. Steps to program a powered-up controller:
1. Connect the KoolKey to the controller communication port (TTL/di
port) using an interface cable.
2. Power up the controller using 120 V/230 V power supply.
3. Move the slider switch to required position and short press (1 sec)
the start button to transfer data.
4. After successful data transfer, switch o the controller power
supply and remove the KoolKey.
Note: While programming EET compact (EETc) and EKF controllers,
KoolKey requires to be connected to a power source as mentioned in
Fig. 4.
b. Steps to program an unpowered controller
(write function only):
1. Connect a Power bank or a 5 V power supply to KoolKey USB port.
2. Connect the Koolkey to the controller's TTL/di port using an inter-
face cable.
3. Write function gets initiated as soon as the KoolKey is connected
to controller (no need to press the start button).
Danfoss 80G8274
KoolKey
Controller
Fig. 3: Controller with main power
Interface cable
Danfoss
80G8275
KoolKey
Controller
Fig. 4: Controller without main power
To Power bank /
5 V power supply Interface cable
Warning:
1. Ensure to disconnect non-isolated controllers (ERC 11X & EET) from mains power, before connecting to KoolKey.
2. Do not leave the interface cable hanging from powered-up controller.

© Danfoss | Climate Solutions | 2022.04
2 | AN404130514212en-000201
Function Action Illustration LED info
Power-up
KoolKey can be powered up by connecting
to an external power bank (Mass
programming mode) or a powered-up
controller (Copy key mode)1).
1) Not supported by EETc.
Danfoss
80G8262
GreenRed
• The LED will ash red slowly,
indicating that KoolKey is
powered up.
• After a few seconds, the LED will
turn steady green, indicating
successful connection and data
transfer readiness
Write and
Read
function
a. Write function:
• Move the slider switch to“Write” position
• Short press the start button (1 s) to
transfer data from the KoolKey to the
controller
Note: When KoolKey is connected to a
power bank, the write functions get initiated
automatically as soon as the KoolKey is
connected to a controller without pressing
the start button.
Danfoss
80G8263
Yellow
~1 s
Slider switch
Yellow LED ashes rapidly.
Indicating parameter le download
b. Read Function:
• Move the slider switch to“Read”position
• Short press the start button (1 s) to
transfer data from the controller to the
KoolKey
Note: Read function is not supported when
KoolKey is powered up from a power bank.
Danfoss
80G8264
Yellow
~1 s
Slider switch
Yellow LED blinks rapidly.
Indicating parameter le download
File transfer
conrmation
Successful le transfers
(Write function can take up to 10 s and read
function can take 15 – 20 s to successfully
complete)
Danfoss
80G8265
Green
Constant green
Unsuccessful le transfer
(Check connection and ensure compatible
programing le saved in KoolKey).
Danfoss
80G8266
Red
Rapid red ashes
Description Code no.
KoolKey EKA 200 080N0020
Interface cable for EET/EKF -1m 080N0324
Interface cable for ERC21x-1m 080N0326
Interface cable for ERC11x- 1m 080N0328
Parameter le transfer steps and LED indications:
Ordering
