Danfoss 176F1784 User manual

This instruction sheet is for the field installation of the USB extension cable into the door
of F-Frame VLT frequency converters. Note: This kit is applicable to drives built dur-
ing or after Week 40 of 2008. Frequency converters built prior to Week 40, 2008 do not
have the provisions for this kit.
INSTRUCTIONS
INSTALLATION OF USB EXTENSION CABLE INTO F-FRAME VLT®DRIVES
Instruction No: 177R0091 V0 Jan 2009 Page 1 VLT®is a registered trademark of Danfoss A/S
Kit Contents
• USB extension cord
• Tie wraps
• Instruction Sheet 177R0091
Kit Part Number
176F1784
The door on the rectifier section of
F-Frame VLTs are fitted with a
feed-through hole to accommodate
a USB extension cord so that the
controls can be accessed from a
laptop computer without requiring
access to the inside of the VLT.
With the rectifier door open, the
hole is located near the upper right
corner of the door. See Figures 1
and 2.
The feed-through hole is covered
by the decorative label on the out-
side and with a round sticker on the
outside.
Figure 1. Location of USB feed-through hole.
WARNING
The frequency converter contains dangerous voltage. Disconnect power and follow lock-
out/tag-out procedures before working on this equipment.

Instruction No: 177R0091 V0 Jan 2009 Page 2
1. Remove the label shown in Fig-
ure 2 to expose the USB feed-
through hole from the inside of
the door.
2. Carefully cut through the exterior
label to create a hole for the USB
cable. It is recommended that
the hole be located by creating a
hole in the label from the inside of
the door, then cut through the
decorative label from the outside
to prevent the decorative label
from separating from the door.
Figure 3. USB connector retaining nut.
Figure 4. Inserting USB cable into
feed-through hole.
Figure 2. Location of USB feed-through hole.
3. Remove the retaining nut from
the USB cable. See Figure 3.
4. Insert the USB cable into the door.
The gasket should be located on the
outside of the door. See Figure 4.

Instruction No: 177R0091 V0 Jan 2009 Page 3
5. Secure the USB connector onto
the door by using the USB cable
retaining nut from inside the door.
Tighten securely. See Figures 5
and 6.
Figure 5. Securing USB connector with retaining
nut.
Figure 6. USB connector installed on door.

Instruction No: 177R0091 V0 Jan 2009 Page 4
Figure 7. Front cover of cable channel.
7. Route the USB cable along the
same route as the LCP cable.
This is shown by the dotted red
line in Figure 8. Utilize cable ties
to secure the USB cable to the
LCP cable until the cable is inside
the cable channel.
Figure 8. Routing of USB cable in rectifier cabinet.
8. Route the USB cable from the
cable channel to the control card
as shown in Figure 9.
Figure 9. USB cable.
6. Remove the cable-channel cover
from the front of the cable chan-
nel to enable insertion of the USB
cable. See Figure 7.

Instruction No: 177R0091 V0 Jan 2009 Page 5
9. Connect the USB cable to the control card as
shown in Figure 10.
10. Reinstall the cable-channel cover
as shown in Figure 11.
The installation of the USB cable is
now complete.
Figure 10. USB cable connected to
control card.
Figure 11. Front cover of cable channel.
