Danfoss IPS 8 User guide

Start-up guide
IPS 8, CE, 230V AC, 1ph, 50Hz, code 084H5001
IPS 8, 230V AC, 1ph, 60Hz, code 084H5002

User Guide |Intelligent Purging System (IPS 8) Ammonia
BC437120335698en-000101 | 2
© Danfoss | Climate Solutions | 2023.07
Contents Mechanical / Refrigeration check.................................................................................................................................................................... 3
Electrical check ........................................................................................................................................................................................................... 3
IPS controller (MCX15B2) setup........................................................................................................................................................................ 4
IPS MCX controller – Quick start ...................................................................................................................................................................... 6
Lifting Procedure ....................................................................................................................................................................................................... 8
Connection points..................................................................................................................................................................................................10
Installation ...................................................................................................................................................................................................................10

User Guide |Intelligent Purging System (IPS 8) Ammonia
3 | BC437120335698en-000101 © Danfoss | Climate Solutions | 2023.07
Mechanical / Refrigeration
check
Electrical check
1) Verify that IPS 8 purger is installed, wired, and piped as per Danfoss instructions
2 )Horizontal alignment requirements must be within 2 degrees to IPS top cover. See Fig. 1
3 )The purger unit should be always kept in an upright position - from receipt to nal
installation, including possible lift to a high nal location. See Fig. 2
4) Leave space around IPS for air circulation ow. Do not install it right up to a wall. See Fig. 3
5) Inspection of possible dirt in gas lines. See Fig. 4
a. For purge point connect gas line a slope towards the IPS8 purger, must be observed.
b. No liquid traps
6) Remember to remove rubber plug. See Fig. 5.
7) Carry out proper vacuum on the purge point connect gas line and R717 side of IPS 8 purger.
The R717 side of IPS 8 purger must be pressurized prior to the IPS 8 being put into operation.
8) Before connecting power supply to IPS let it stand upright for min. 6 hours after it has been
placed at its nal location
9) After mechanical installation, but before connecting power supply IPS, please check:
a. If Danfoss drain valve used (Type SV or ICF with ICFD), then check:
b. SV: See Fig. 6a
i. Check throttle valve Ais opened, and SV is properly assembled.
ii.Check that port Bis closed by bolt.
c. ICFD: See Fig. 6b
i. Check stop valves
ii.Check coil is installed on solenoids (Solenoid for ICF w/ICFD (DO6) – if used)
10) Open stop valves D, as we have vacuumized the pipes before. Open manually one of purge
point solenoids E. See Fig. 6a and 6b
For general mechanical installation guidance/practice. See Fig. 6c
11) Check Main power supply. See Fig. 7
a. 084H5001, IPS 8: 230 V, AC 50 Hz
b.084H5002, IPS 8: 230 V, AC 60 Hz
c. Power to be connected to Main switch: QS1 and Terminal: XT0
i. Terminals on QS1
1. 3, L2 – Line phase
2. 1, L1 – Neutral
ii. Terminal XT0
1. PE – Earth
12) Check connections to eld connected Purge point solenoids and ICFD solenoid (if used)
See Fig. 8a and 8b
a. Coils voltage. Same as Main power supply. No further action needed.
b. At dierent voltage for eld connected solenoids coils. See Fig. 9

User Guide |Intelligent Purging System (IPS 8) Ammonia
BC437120335698en-000101 | 4
© Danfoss | Climate Solutions | 2023.07
IPS controller (MCX15B2)
setup
After Mechanical / Refrigeration check, the conditions for startup must be checked.
See Fig. 10 for overview of Electrical Panel and location of Thermal magnetic miniature circuit breakers
13) Switch ON:
a. QS1, QM2 and QM4. See Fig. 10
14) Before start of compressor, temperatures needs to be checked. Should all be within:
+/-1 K (OK) – if OK then go to 15)
If Temperatures are not within: +/-1 K then check cables and connections of pressure and
temperature sensors. (NOK)
15) Preparation for start compressor
a. Switch ON – See Fig. 10
i. QM1 and QM3
Below (E10, System is OFF and the icon ) inform that MainSwitch is OFF
16) Navigation to Main Switch parameter
a. <Enter>
b. Select “Start”
c. Select “Main Switch ON”and <Enter>

User Guide |Intelligent Purging System (IPS 8) Ammonia
5 | BC437120335698en-000101 © Danfoss | Climate Solutions | 2023.07
Go to Main Screen and watch compressor in operation and pressure/temperature changing.
As compressor is in operation, pressure and temperature is changing, after about 15-25 minutes we
should observe changes as reected on below screens.
See development below from left to right
If the compressor is running for 15-25 minutes, without pressure and temperature really changing
(example below) and compressor then becomes very hot [90 C-110 C] on its surface, - then STOP IPS
and call Danfoss.

User Guide |Intelligent Purging System (IPS 8) Ammonia
BC437120335698en-000101 | 6
© Danfoss | Climate Solutions | 2023.07
Basically, the IPS with the built-in MCX controller, only need one setting, How many Purge points?
See steps below for how to navigate to the parameter for entering how many Purge points which is
connected.
a) Navigate from the Main Menu to Start by <Enter>
b) Select“Main Switch OFF”
c) Go to Main Menu
d) Navigate from the Main Menu to“Login”
e) Enter password“200”
f) Choose“Parameters”
g) Choose“Unit Cong”
h) Choose“Valve Settings”
i) Enter the number of purge solenoid valves connected to the IPS (factory setting is:8)
j) Go back to Start and chose ‘Main Switch ON’, and go back to main screen
See development below from left to right
IPS MCX controller – Quick
start

User Guide |Intelligent Purging System (IPS 8) Ammonia
7 | BC437120335698en-000101 © Danfoss | Climate Solutions | 2023.07
IPS MCX controller – Quick
start
It can be useful during commissioning to quickly move the next Purge point, in order not to wait to
IPS internal time cycle between purge points.
See steps below for how to navigate to the parameter in question.
1. Navigate from the Main Menu to Start by <Enter>
2. Enter password “200”
3. Choose“Start”
4. Choose“Next Purge Point” and <Enter>
5. Press <X>, to go back to main screen
6. Check that Purge Point has been changed to the next one. (below example from Purge Point
3 to Purge Point 4)
See development below from left to right

User Guide |Intelligent Purging System (IPS 8) Ammonia
BC437120335698en-000101 | 8
© Danfoss | Climate Solutions | 2023.07
Fig. 1
It is important that the support
construction is level to ensure the
internal liquid trap is properly lled.
Angle to horizontal < 2 degrees
Lifting Procedure
Fig. 2
.
All 4 lifting eyes must be positioned correctly, to match the actual used lifting gear
All 4 lifting eyes must be used

User Guide |Intelligent Purging System (IPS 8) Ammonia
9 | BC437120335698en-000101 © Danfoss | Climate Solutions | 2023.07
Fig. 3 Installation dimensions
*
Flange for R717 access
Support for 100 kg/ 220 lbs
Service platform
* F
or easy access to the main switch
and ser
vicing, the Purger unit shall be
installed between 0,05 to 1,1 m (2 to 43 in)
above ser
vice platform level.
Min. 900 mm 1051 mm Min. 500 mm
32 mm
446 mm
Min. 300 mm Min. 900 mm
Min. 300 mm
703
* For easy access to the main switch
and servicing, the Purger unit shall be
installed between 0,05 to 1,1 m (2 to 43 in)
above service platform level.

User Guide |Intelligent Purging System (IPS 8) Ammonia
BC437120335698en-000101 | 10
© Danfoss | Climate Solutions | 2023.07
Installation
Fig. 5 Ammonia connection
Enclosed gasket
Flange for NH connection. Remove rubber plug
Enclosed bolts, Torque: 60 Nm
(44.3 ft lb) diagonal tension
Purging pipe OD 17.2 for rubber hose to water bath
Do not unscrew restrictor inside pipe.
Risk of purging high NH₃ concentration
Enclosed weld ange (g. 14)
547
8 x 11 mm (hole) 274
416,4
198
310
155
Connection points
Fig. 4 Multi-point purging from up to 8 purging points
Purge Points
- up to 8 points
ICF 15-4
Be aware of liquid traps
Where slope is
shown above, ensure
downward sloping
pipe owing towards
purger drop leg.
NH gas + NC gases
SVA
SNV
Liquid drain to Low
pressure side
Ammonia Liquid
NH bypass for draining purger
SVA
SNV
SNV
SV3

User Guide |Intelligent Purging System (IPS 8) Ammonia
11 | BC437120335698en-000101 © Danfoss | Climate Solutions | 2023.07
Fig. 6a

User Guide |Intelligent Purging System (IPS 8) Ammonia
BC437120335698en-000101 | 12
© Danfoss | Climate Solutions | 2023.07
Fig. 6b
ICF 20-4 with ICFD
Solenoid coil to be connected
in IPS Electrical panel to:
Terminal Block: QG-XT2
Terminal numbers:
1 and 21: ICFD valve (DO6)
Fig. 6C

User Guide |Intelligent Purging System (IPS 8) Ammonia
13 | BC437120335698en-000101 © Danfoss | Climate Solutions | 2023.07
Classified as Business
C
C
C
l
l
l
a
a
a
ss
ss
ss
i
i
i
fi
fi
fi
e
e
e
d
d
d
a
a
a
s
s
s
B
B
B
u
u
u
s
s
s
i
i
i
n
n
n
e
e
e
s
s
s
s
s
s
Fig. 7a Controller box internal

User Guide |Intelligent Purging System (IPS 8) Ammonia
BC437120335698en-000101 | 14
© Danfoss | Climate Solutions | 2023.07
Classified as Business
C
C
C
l
l
l
a
a
a
ss
ss
ss
i
i
i
fi
fi
fi
e
e
e
d
d
d
a
a
a
s
s
s
B
B
B
u
u
u
s
s
s
i
i
i
n
n
n
e
e
e
s
s
s
s
s
s
QM3 for
XT2
see Fig. 8b
Fig. 8a Controller box internal

User Guide |Intelligent Purging System (IPS 8) Ammonia
15 | BC437120335698en-000101 © Danfoss | Climate Solutions | 2023.07
Terminal numbers:
1 and 2: ICFD valve (DO6)
3 and 4: Purge valve no. 1 (DO7)
5 and 6: Purge valve no. 2 (DO8)
7 and 8: Purge valve no. 3 (DO9)
9 and 10: Purge valve no. 4 (DO10)
11 and 12: Purge valve no. 5 (DO11)
13 and 14: Purge valve no. 6 (DO12)
15 and 16: Purge valve no. 7 (DO13)
17 and 18: Purge valve no. 8 (DO14)
19 and 20: Bubbler (DO15)
Fig. 8b XT2 terminal block
XT2 terminal block
for eld connected solenoids

User Guide |Intelligent Purging System (IPS 8) Ammonia
BC437120335698en-000101 | 16
© Danfoss | Climate Solutions | 2023.07
At dierent voltage for eld connected
solenoids coils:
Remove connection between terminal:
1 and 3
2 and 4
Install transformer GD2 for supply of eld
connected solenoids coils.
Observe: GD2 not included with standard IPS
Classified as Business
C
C
C
l
l
l
a
a
a
ss
ss
ss
i
i
i
fi
fi
fi
e
e
e
d
d
d
a
a
a
s
s
s
B
B
B
u
u
u
s
s
s
i
i
i
n
n
n
e
e
e
s
s
s
s
s
s
Fig. 9 Controller box internal
Classified as Business
C
C
C
l
l
l
a
a
a
ss
ss
ss
i
i
i
fi
fi
fi
e
e
e
d
d
d
a
a
a
s
s
s
B
B
B
u
u
u
s
s
s
i
i
i
n
n
n
e
e
e
s
s
s
s
s
s
GD1:Powersupply
115-230V/24 VDC
QM1: Thermalmagnetic miniaturecircuit breaker; Compressor,Condenser,
ExtractionAir Fan,Crankcase Heater
QM2: Thermalmagnetic miniaturecircuit breaker; 24 VDCfor MCX15B2I/O,
Front panellightsand Main Purgevalve (YV1)
QM3: Thermalmagnetic miniaturecircuit breaker; Fieldconnected solenoid
coils
QM4: Thermalmagnetic miniaturecircuit breaker; 230 VACtoMCX15B2
controller
QS1: Main switch;IPS panel
XT2terminalblock foreldconnected solenoid coilsfor:
Up to8Purgepoint solenoid coils
ICFD on ICF 20-4. ICFE 20 solenoid coil (optional)
Bubbler water valve (optional)
XT4 terminal block for communication:
MODbus
CANbus
GD2, transformer (optional)
For alternativevoltagesupplytoeldconnected solenoid coils
MCX15B2controller
KL1: relay
For compressor and Heater
LLS 4000
External Mainswitch
Fig. 10 Controller box internal
XT3 terminal block

17 | BC437120335698en-000101 © Danfoss | Climate Solutions | 2023.07
