Davey Maverick User manual
Wheeled Suction Pool Cleaner
Owner’s Manual
for the Installation and Service of the
Maverick Tune Up Kit
Replacement Wearable Parts
Should the installer or owner be unfamiliar with the correct installation
or operation of this type of equipment you should contact the
distributor/manufacturer for the correct advice before proceeding
with the installation or operation of this product. The pump
operator or owner must be provided with this owner’s manual.
The only tool required is a 5mm Allen Key or Screwdriver with a 5mm Hex Bit.
Instructions
1. Undo the cover clip.
Tools Required
2. Detach the top cover to expose the cleaner internals.
3. Remove the turbine cover.
4. Insert allen-key into wheel screw and turn anti-clockwise. Remove both wheels.
5. Remove reversing drive assembly and drive shaft.
6. Remove forward drive gear.
7. Remove forward drive shaft and one of two bearings. 8. Remove second bearing.
9.Assemble forward drive kit, like so:
10. Insert forward drive kit.
11. Insert forward drive gear.
12. Insert reversing drive assembly and drive shaft.
13. Push reversing drive assembly in, so that wheel engages with cam.
14. Install turbine cover.
15. Replace cover and clip on.
Davey Water Products Pty Ltd
Member of the GUD Group
ABN 18 066 327 517
® Davey is a trademark of Davey Water Products Pty Ltd. © Davey Water Products Pty Ltd 2019.
NORTH AMERICA
Ph: 1-877-885-0585
Email: [email protected]
Website: daveyusa.com
AUSTRALIA
Head Office
6 Lakeview Drive,
Scoresby, Australia 3179
Ph: +613 9730 9124
Fax: +613 9753 4248
Email: [email protected]
Website: davey.com.au
NEW ZEALAND
7 Rockridge Avenue,
Penrose, Auckland 1061
Ph: 0800 654 333
Fax: 0800 654 334
Email: [email protected]
Website: daveynz.co.nz
EUROPE
ZAC des Gaulnes
355 Avenue Henri Schneider
69330 Meyzieu, France
Ph: +33 (0) 4 72 13 95 07
Fax: +33 (0) 4 72 33 64 57
Email: [email protected]
Website: daveyeurope.eu
MIDDLE EAST
Ph: +971 50 6368764
Fax: +971 6 5730472
Email: [email protected]
Website: daveyuae.com
* Installation and operating instructions are included with the product when purchased new.
They may also be found on our website.
DWP1755
