Intex 100A User manual

(100IO) AUTO CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 09/03/2011
100A
English
IMP RTANT
SAFETY RULES
Read, understand, and follow all
instructions carefully before installing
and using this product.
Auto Cleaner
Don’t forget to try these other fine Intex products: pools, pool
accessories, inflatable pools and in-home toys, airbeds and boats
available at fine retailers or visit our website.
WWNNEERR’’SS MMAANNUUAALL
For illustrative purposes only.
©2011 Intex arketing Ltd. - Intex Development Co. Ltd. - Intex Trading Ltd.
- Intex Recreation Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle
Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous
licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in
einigen Ländern der Welt in Lizenz von/Intex arketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co.
Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in
the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der
Europäischen Union durch/Intex Trading B.V., P.O. Box nr. 1075 – 4700 BB Roosendaal – The Netherlands
100-*A*-R0-1209

(100IO) AUTO CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 09/03/2011
100A
S AVE THESE INSTRUCTIONS
Page 2
English
Warnings....................................................................... 3
Parts Reference............................................................ 4
Set Up Instructions ..................................................... 5-7
Operating Instructions ................................................ 7
Debris Net Cleaning..................................................... 8
Long Term Storage....................................................... 8
Troubleshooting Guide................................................ 9
General Aquatic Safety................................................ 9
Intex Service Center Locations................................... 10-11
TTAABBLLEE FF CCNNTTEENNTTSS

(100IO) AUTO CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 09/03/2011
100A
S AVE THESE INSTRUCTIONS
Page 3
English
SSAAFFEETTYY RRUULLEESS
IMP RTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefull Before Installing and Using this Product.
WARNING
• TO REDUCE THE RISK OF IN URY, DO NOT PERMIT
CHILDREN TO USE THIS PRODUCT.
• DO NOT OPERATE THE FILTER PUMP WHILE THE POOL IS
OCCUPIED OR IN USE.
• REMOVE THE PRODUCT FROM THE POOL WHILE THE
POOL IS OCCUPIED OR IN USE.
• TURN OFF OR UNPLUG THE FILTER PUMP BEFORE
AD USTING, CLEANING OR SERVICING.
• REMOVE THE PRODUCT FROM THE POOL BEFORE
PLACING A POOL COVER OVER THE POOL.
• STORE THE PRODUCT AND ACCESSORIES IN A DRY AND
SAFE PLACE INDOORS.
• FOR POOL AND FILTER PUMP PROBLEMS REFER TO
THEIR RESPECTIVE OWNER'S MANUAL FOR ADVICE.
FAILURE TO FOLLOW THESE WARNINGS AY RESULT IN
PROPERTY DA AGE, SERIOUS INJURY OR DEATH.
This Filter-Pump system is intended to be used only for the
purposes described in the manual! Failure to follow all product,
package and package insert safety and installation instructions
could result in electric shock, entanglement, other serious injury or
death.
Filter Pump Flow Rate Requirement:
1600 - 4000 gallons/hour (6056 - 15140 liters/hour)

(100IO) AUTO CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 09/03/2011
100A
S AVE THESE INSTRUCTIONS
Page 4
English
PPAARRTTSS RREEFFEERREENNCCEE
PARTS REFERENCE
Before assembling our product, please take a few minutes to check the
contents and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to
scale.
REF.
NO. DESCRIPTION QTY. SPARE
PARTS NO.
1 CLEANER TOP 1 11454
2 SCREW 2 10858
3 BUMPER 2 11455
4 DEBRIS NET 1 10855
5 CLEANER BASE 1 10965
6 HOSE CLAMP 1 10272
7 HOSE ADAPTOR 1 11239
8 HOSE A 1 10850
9 HOSE B 3 10851
10 HOSE C 2 10852
11 HOSE D 1 10957
12 DEAD WEIGHT BLOCK 2 11138
13 BRUSH SUPPORT A (WITH 2 EXTRA) 4 11493
14 BRUSH (WITH 10 EXTRA) 12 11492
15 BRUSH SUPPORT B (WITH 2 EXTRA) 4 11494
1
2
3
4
5
6
789
10 11
12
13
15
14

(100IO) AUTO CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 09/03/2011
100A
S AVE THESE INSTRUCTIONS
Page 5
SETUP INSTRUCTI NS
English
SSEETTUUPP IINNSSTTRRUUCCTTIINNSS
1. If you use filter pump which is 3000 gal ~ 4000 gal, add the dead weight
block (12) at the base. See Fig. 1. But no need it when your filter pump
is 1600 gal ~ 2900 gal.
3. With screws (2), connect the bumpers (3) to the cleaner at both ends.
See Fig. 2.
1
2
4. From inside of the pool, unscrew the nozzle from the water return
connector (upper hose connection). See Fig. 3.
3
Lower Hose
Connection
Upper Hose
Connection
Threaded Strainer
Connector
nozzle
Inside of
the Pool
Wall
12
2. Brush assembly.
(1)
(2)
(3)

(100IO) AUTO CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 09/03/2011
100A
S AVE THESE INSTRUCTIONS
Page 6
SETUP INSTRUCTI NS (continued)
English
SSEETTUUPP IINNSSTTRRUUCCTTIINNSS
5. Screw the hose adaptor (7) to hose
A (8). See Fig. 4.
6. Screw the end of hose A (8) with
adaptor to the threaded strainer
connector, from inside of the pool.
See Fig. 5.
7. Connect the rest of the hoses together outside the pool, in the order of
hose description (Fig. 6), B-C-B-C-B-D or B-C-B-D.
4
7
8
5
Threaded Strainer
Connector
8
6
(B) (C) (B) (C) (B) (D)
(D)
(B) (C) (B)
For pool size above 18':
For pool size 18' and below:
8. With hose clamp (6), fasten the
end of hose D (11) to the top
connection of cleaner. A small
coin can be used to tighten the
hose clamp. See Fig. 7.
9. Place auto cleaner into the water.
Fill up the hose assembly with
water by submerging the hose
into the water to remove all of the
entrapped air from the hose.
7
6
11

(100IO) AUTO CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 09/03/2011
100A
S AVE THESE INSTRUCTIONS
Page 7
SETUP INSTRUCTI NS (continued)
PERATING INSTRUCTI NS
English
S
SE
ET
TU
UP
P I
IN
NS
ST
TR
RU
UC
CT
TI
I
N
NS
S &
&
P
PE
ER
RA
AT
TI
IN
NG
G I
IN
NS
ST
TR
RU
UC
CT
TI
I
N
NS
S
10. Connect hose B (9) from the hose assembly to the hose A (8) which
was already installed in step 4. See Fig. 8.
I PORTANT: Run the filter pump for 10-15 minutes before connecting
the auto cleaner to the water return connector.
11. Set up the Filter Pump following the Filter Pump owner's manual. The
auto cleaner is now ready to use.
98
8
1. The filter pump is an airtight system. In a counter-clockwise motion turn
the top air release valve 1 – 2 turns to open it.
2. When water starts flowing out of the air release valve hole, screw in the
air release valve back into the filter housing cover. Do not over tighten
the valve.
3. Connect the filter pump to the power outlet and turn ON the pump.
4. Hold the auto cleaner upside down below the water surface to jet out
the water. See Fig. 9. This will evacuate all the air in the hose and
auto cleaner, so the cleaner will sink to the bottom and keep the pool
clean.
5. The auto cleaner will change direction each time one of the bumpers
touches the pool sidewall.
9

(100IO) AUTO CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 09/03/2011
100A
S AVE THESE INSTRUCTIONS
Page 8
DEBRIS NET CLEANING
English
MMAAIINNTTEENNAANNCCEE
1. Make sure the filter pump is turned off, and disconnect the power cord
from the electrical outlet. Remove the auto cleaner from the pool.
2. Unlock four buckles located on the four sides. See Fig. 10.
3. Remove the debris net (4) from the cleaner base (5). If debris is on the
debris net and cleaner base, use garden hose to flush the debris off.
Use the brush if necessary. See Fig. 11.
4. Reassemble auto cleaner reversing steps 1, 2 and 3.
L NG TERM ST RAGE
1. Make sure the filter pump is turned off, and disconnect the power cord
from the electrical outlet.
2. Using the Set Up instructions in reverse, disassemble the auto cleaner.
3. Clean and air dry all the accessories and parts thoroughly.
4. Keep the hoses straight during storage.
5. Remove the brushes and keep them flat and straight during storage.
6. The original packaging can be used for storage. Store in a dry, cool
storage location.
10
11
4
5

(100IO) AUTO CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 09/03/2011
100A
S AVE THESE INSTRUCTIONS
Page 9
TR UBLESH TING GUIDE
English
TTRRUUBBLLEESSHHTTIINNGG GGUUIIDDEE && SSAAFFEETTYY GGUUIIDDEELLIINNEESS
If you continue to experience difficulty, please contact our Consumer
Service Department for assistance. See back cover for contact information.
I PORTANT
Water recreation is both fun and therapeutic. However, it involves inherent risks of
injury and death. To reduce your risk of injury, read and follow all product, package
and package insert warnings and instructions. Remember, however, that product
warnings, instructions and safety guidelines cover some common risks of water
recreation, but do not cover all risks and or dangers.
For additional safeguards, also familiarize yourself with the following general
guidelines as well as guidelines provided by nationally recognized Safety
Organizations:
• Demand constant supervision. A competent adult should be appointed as a “lifeguard”
or water watcher, especially when children are in and around the pool.
• Learn to swim.
• Take the time to learn CPR and first aid.
• Instruct anyone who is supervising pool users about potential pool hazards and about
the use of protective devices such as locked doors, barriers, etc.
• Instruct all pool users, including children what to do in case of an emergency.
• Always use common sense and good judgement when enjoying any water activity.
• Supervise, supervise, supervise.
Q. What should I do if Auto Cleaner doesn’t move or movement is very slow?
A. 1. Pull the cleaner’s hose and lift auto cleaner off from the wrinkles.
2. Check the circulation line:
i. Ensure the filter pump is turned on.
ii. Ensure the plunger valves are opened.
iii. Clean or replace cartridge.
iv. If using a sand filter, ensure the sand media is clean by backwashing it.
Q. What should I do if Auto Cleaner lifts off from the pool floor?
A. Release air from the auto cleaner by following the “Owner’s Manual”.
Q. What is the easiest way to carry the Auto Cleaner out from the pool after used?
A. Release the water inside the auto cleaner by following the steps below:
1. Make sure the filter pump is turned off, and disconnect the power cord from the
electrical outlet.
2. Pull the cleaner’s hose slowly and lift the auto cleaner up just right below the
water surface.
3. Hold the hose with one hand, and lift the auto cleaner up slowly with an angle
(either head or tail up) by carrying the cleaner bottom with another hand.
4. After the water has been fully released from the auto cleaner, carry the auto
cleaner out with both hands. DO NOT lift the hose or bumper which could be
damaged.
Q. What should I do if the Auto Cleaner can not pick up the leaves from the pool floor?
A. 1. Remove the brushes from the underside and put the Auto Cleaner back into the
pool.
2. Clean all the debris from the Auto Cleaner after running for 2-3 hours
continuously.
GENERAL AQUATIC SAFETY

(100IO) AUTO CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 09/03/2011
100A
S AVE THESE INSTRUCTIONS
Page 10
English
For service questions or to order replacement parts, please contact the
appropriate office listed below or visit www.intexdevelopment.com for answers to
most frequently asked questions.
AREAS L CATI N AREAS L CATI N
• ASIA INTEX DEVELOPMENT CO. LTD.
9TH FLOOR,
DAH SING FINANCIAL CENTRE,
108 GLOUCESTER ROAD,
WANCHAI, HONG KONG
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
Website: www.intexdevelopment.com
• EUROPE INTEX TRADING B.V.
POSTBUS 1075, 4700 BB ROOSENDAAL,
THE NETHERLANDS
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
Website: www.intexcorp.nl
• FRANCE UNITEX / INTEX SERVICE FRANCE S.A.S
Z.A. DE MILLEURE
BOIS DU BAN - N°4
71480 LE MIROIR
TEL: [phone] (0,15€/min)
FAX: [phone]
Website: www.intex.fr
• GERMANY STEINBACH VERTRIEBSGMBH
C/O WEBOPAC LOGISTICS GMBH
INTER-LOGISTIK-PARK 1-3
87600 KAUFBEUREN
TEL: [phone]
(0,14€/min aus dem Festnetz, Mobilfunk max. 0,42€/min)
FAX: + 43 (7262) 61439
E-mail: [email protected]
Website: www.intexcorp.de
• ITALY A & A MARKETING SERVICE
VIA RAFFAELLO SANZIO 19
20852 VILLASANTA (MB)
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
Website: www.intexitalia.com
• UK OHN ADAMS LEISURE LTD
MARKETING HOUSE,
BLACKSTONE ROAD,
HUNTINGDON, CAMBS.
PE29 6EF. UK
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
Website: www.intexspares.com
• SWITZERLAND GWM AGENCY
GARTEN-U. WOHNMÖBEL,
RÄFFELSTRASSE 25,
POSTFACH,
CH-8045 ZURICH/SWITZERLAND
TEL: [phone] or [phone]
FAX: [phone]
E-mail: [email protected]
Website: www.gwm.ch, www.gwmsale.ch
• SPAIN / Nostrum Iberian Market S.A.
PORTUGAL Av. de la Albufera, 321
28031 Madrid, Spain
TEL: [phone]
FAX for Spain: [phone]
Email for Spain: [email protected]
FAX for Portugal: [phone]
Email for Portugal: [email protected]
Website: www.intexiberian.com
• AUSTRALIA HUNTER PRODUCTS PTY LTD
LEVEL 1, 225 BAY STREET,
BRIGHTON, VICTORIA,
AUSTRALIA
TEL: [phone] or 1800-224-094
FAX: [phone]
E-mail: [email protected]
Website: www.hunterproducts.com.au
• NEW ZEALAND HAKA NEW ZEALAND LIMITED
UNIT 4, 11 ORBIT DIVE, ALBANY,
AUCKLAND 0757, NEW ZEALAND
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
Website: www.hakanz.co.nz
• MIDDLE EAST
FIRST GROUP INTERNATIONAL
REGION AL MOOSA GROUP BUILDING, 1ST
FLOOR, OFFICE 102 & 103, UMM HURAIR
ROAD, KARAMA, DUBAI, UAE
TEL: [phone]INTEX(46839) / [phone]
FAX: [phone]
E-mail: [email protected]
Website: www.firstgroupinternational.com
• SOUTH AFRICA WOOD & HYDE
15-17 PACKER AVENUE, INDUSTRIA 2,
CAPE TOWN, SOUTH AFRICA 7460
TEL: [phone] (Toll Free) or 27-21-505-5500
FAX: [phone]
E-mail: [email protected]
• CHILE / URUGUAY COMEXA S.A.
EL UNCAL 100, PARQUE INDUSTRIAL
PORTEZUELO, QUILICURA,
SANTIAGO, CHILE.
TEL: [phone]
E-mail: [email protected]
• ARGENTINA ARSE INDUSTRIAL Y COMERCIAL S.A
MANUEL GARCIA 124 (CP1284)
CIUDAD AUTÓNOMA DE BUENOS AIRES,
ARGENTINA.
TEL: [phone] (interno 139);
TEL: [phone]( interno 145)
E-mail: Martín Cosoleto: [email protected]
E-mail: Daniel Centurion: [email protected]
Website: www.jarse.com.ar
• PERU COMEXA S.A.
AVENIDA COMANDANTE ESPINAR 142,
MIRAFLORES, LIMA, PERÚ
TEL: [phone]

(100IO) AUTO CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 09/03/2011
100A
S AVE THESE INSTRUCTIONS
Page 11
English
For service questions or to order replacement parts, please contact the
appropriate office listed below or visit www.intexdevelopment.com for answers to
most frequently asked questions.
AREAS L CATI N AREAS L CATI N
• SAUDI ARABIA SAUDI ARABIAN MARKETING &
AGENCIES CO. LTD.
PRINCE AMIR MA ED STREET,
AL-SAFA DISTRICT. EDDAH,
KINGDOM OF SAUDI ARABIA
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
Website: www.samaco.com.sa
• AUSTRIA STEINBACH VERTRIEBSGMBH
AISTINGERSTRAßE 2
4311 SCHWERTBERG
TEL: 0820 - 200 100 200
(0,145€/min aus allen Netzen)
FAX: + 43 (7262) 61439
E-mail: [email protected]
Website: www.intexcorp.at
• CZECH REPUBLIC INTEX TRADING S.R.O.
/EASTERN EUROPE BENESOVSKA 23,
101 00 PRAHA 10,
CZECH REPUBLIC
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
• BELGIUM N.V. SIMBA-DICKIE BELGIUM S.A.
MOESKROENSESTEENWEG 383C,
8511 AALBEKE, BELGIUM
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
E-mail: [email protected]
Website: www.nicotoy.be/downloads.htm
• DENMARK K.E. MATHIASEN A/S
SINTRUPVE 12, DK-8220
BRABRAND, DENMARK
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
Website: www.intexnordic.com
• SWEDEN LEKSAM AB
BRANDSVIGSGATAN 6,
S-262 73 ÄNGELHOLM,
SWEDEN
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
Website: www.intexnordic.com
• NORWAY NORSTAR AS
PINDSLEVEIEN 1,
N-3221 SANDEF ORD,
NORWAY
TEL: [phone]
FAX: [phone]
E-mail: [e-mail]
Website: www.intexnordic.com
• FINLAND NORSTAR OY
SUOMALAISTENTIE 7,
FIN-02270 ESPOO,
FINLAND
TEL: [phone]
FAX: [phone]
E-mail: [e-mail]
Website: www.intexnordic.com
• RUSSIA LLC BAUER
KIEVSKAYA STR., 20,
121165 MOSCOW, RUSSIA
TEL: [phone]/9802
FAX: [phone]
E-mail: [email protected]
Website: www.intex.su
• POLAND KATHAY HASTER
UL. LUTYCKA 3, 60-415 POZNAN
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
Website: www.intexpoland.pl
• HUNGARY RECONTRA LTD./RICKI LTD.
H-1113 BUDAPEST, DARÓCZI ÚT 1-3,
HUNGARY
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
• BRASIL KONESUL MARKETING & SALES LTDA
RUA ANTONIO DAS CHAGAS,
1.528 - CEP. 04714-002,
CHÁCARA SANTO ANTONIO - SÃO
PAULO - SP - BRASIL
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
• ISRAEL ALFIT TOYS LTD
MOSHAV NEHALIM,
MESHEK 32, 49950, ISRAEL
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
