dB Technologies IS 210L Manual

IS210L 420120422Q REV1.0
QUICK START USER MANUAL SECTION 1
1[email protected]
The box contains:
N°1 IS210L loudspeaker
N°2 front link brackets
N°2 back link brackets
This quick start and warranty documentation
IS210L is the new dB Technologies 2-way passive
line array speaker for professional use. It is equip-
ped with one compression driver (voice coil: 2,4”,
exit: 1.4”) and two 10” neodymium woofers (2.5”
voice coil). The coverage pattern is 90° (H) x 15° (V).
The mechanical design allows an easy, accurate
and quick installation for flyable or stand use in ar-
ray configuration thanks to the included brackets.
•Impressive sound pressure
•Quick installation
•Multiple array configurations
PACKAGE CONTENTS
DESCRIPTION
MAIN FEATURES
TECHNICAL SPECIFICATIONS
DIMENSIONS
Speaker Type 2 Way Passive Loudspeaker
Protection against solid
objects and liquids (IP): 55
Frequency Response
[-6dB] 65 Hz - 17.5 kHz
Usable Bandwith [-10dB] 57 Hz - 18.7 kHz
RMS power 400 W
Rated impedance 8 Ohm
Max SPL (1 m) 133 dB (Fullrange)
Directivity (HxV) 90° x 15°
HF 1.4” exit, 2.4” v.c.
LF 2x 10”, 2.5” v.c.
Crossover Frequency 900 Hz
Signal Input Terminal barrier strip (or speakON®using
the SP-IS accessory panel)
Signal Output Terminal barrier strip (or speakON®using
the SP-IS accessory panel)
Housing Wooden box - black finished
Rigging Points Integrated mechanics
Dimensions (WxHxD) 675x310x400 mm
(26.6x12.2x17.8 in)
Weight 29.2 Kg (64.4 lbs.)
W 674mm (26.5 in)
H1 212mm (8.3 in)
H2 310mm (12.2 in)
D 400mm (15.7 in)
W
D
H1
H2
DRK-1
flybar for
stacked/flyable use
DRK-2
flybar for
stacked/flyable use
LP-6
bracket for
stacked/flyable use
ACCESSORIES
SP-IS
speakON® panel
The warnings in this manual must be observed together with the “User Manual - Section 2”.

IS210L 420120422Q REV1.0
QUICK START USER MANUAL SECTION 1
2[email protected]
CONNECTIONS
MECHANICAL FIXING POINT
Is 210L can be installed in array configuration, on each
side of the loudspeaker the user can find mechanical fixing
points to fasten the loudspeaker to another one or a to
DRK flybar using the included brackets. The (A) fixing poin-
ts allow front link brackets mount; the (B) fixing points al-
low back link brackets mount.
The (C) fixing points allow to fasten another speaker in ar-
ray configuration.
A
C
B
C
AUDIO
SOURCE
PARALLEL
SPEAKER
LINK
INPUT
iInstallation must be performed
complying with user’s manual
information and to related
instruction provided.
BACK LINK BRACKETSFRONT LINK BRACKETS
The front link brackets allows
to link the IS 210L to another
loudspeaker or to a DRK flybar.
Fasten the brackets to the IS
210L (A) fixing points using
the SPK holes (in case of
another loudspeaker mount) or
the DRK holes (in case of DRK
flybar mount).
The back link brackets allows
to link the IS 210L to another
loudspeaker or to a DRK flybar and
adjust the tilt angle from 1° to 15°.
Fasten the brackets to the IS 210L
(B) fixing point using the SPK hole
(in case of another loudspeaker
mount) or the DRK hole (in case of
DRK flybar mount).
PROTECTION AGAINST SOLID OBJECTS AND LIQUIDS (IP RATING)
The speakers are protected against the ingress of solid objects and liquids with a rating of IP55 as defined by
IEC 60529. Please only use cables with the specified diameters:
PG7 => 6 or 6.5mm diameter
PG9 => 7.5 or 8mm diameter
Fasten properly the cable gland using the plastic tightening nut.
WARNING!
Failure to comply with these installation prescriptions could adversely affect the declared protection ratings.

IS210L 420120422Q REV1.0
QUICK START USER MANUAL SECTION 1
3[email protected]
INSTALLATION
On each side fasten the front and back
link brackets to the loudspeaker depen-
ding on loudspeaker or DRK flybar cou-
pling.
DRK-1 FLYBAR MOUNT
Fasten the speaker to the flybar using the holes as shown;
an arrow on the flybar indicate the hole to choose for the
back link bracket fastening. Select the tilt angle from the
back link brackets holes depending on the array configura-
tion.
SPEAKER ARRAY MOUNT
Fasten the speakers using the holes as shown; select the tilt
angle from the back link brackets holes depending on the
array configuration.
DRK-2 FLYBAR MOUNT
Fasten the speaker to the flybar using the holes as shown: Afor positive angle, Bfor negative angle. An arrow on the flybar
indicate the hole to choose for the back link bracket fastening. Select the tilt angle from the back link brackets holes depen-
ding on the array configuration.
BA

IS210L 420120422Q REV1.0
QUICK START USER MANUAL SECTION 1
4[email protected]
LP-6 BRACKETS FLOWN MOUNT
The LP-6 brackets allows to link IS 210L loudspeakers with IS 115S subwoofers in flown or stack configurations. For the flown
installation with LP-6 brackets follow this procedure:
1. First remove the IS 210L side panels and internal link brackets
2. Fasten the LP-6 brackets to the subwoofer
3. Fasten the loudspeaker to the LP-6 brackets
4. The three holes in the back of the LP-6 brackets allow to adjust the tilt angle (-7.5°, 0° or +7.5°).
For more information please refer to LP-6 user manual.
1. 2.
4.
-7.5°
0°
+7.5°
3.

IS210L 420120422Q REV1.0
QUICK START USER MANUAL SECTION 1
5[email protected]
LP-6 BRACKETS STACK MOUNT
For the stack installation with LP-6 brackets follow this procedure:
1. First remove the IS 210L side panels and internal link brackets
2. Fasten the LP-6 brackets to the subwoofer
3. Place the loudspeaker upside down on the subwoofer and fasten to the brackets
4. The three holes in the back of the brackets allow to adjust the tilt angle (-7.5°, 0° or +7.5°).
For more information please refer to LP-6 user manual.
1. 2.
4.
3.

IS210L 420120422Q REV1.0
QUICK START USER MANUAL SECTION 1
6[email protected]
CONFIGURATIONS
FLOWN
DRK-1 flybar
IS 210L
System negative
angle
DRK-2 flybar
IS 210L
System positive
angle
DRK-2 flybar
IS 210L
DRK-1 flybar
LP-4 brackets
IS 115S
LP-6 brackets
IS 210L
For further information regarding max loading and installation requirements, please refer to the accessories user manual.

IS210L 420120422Q REV1.0
QUICK START USER MANUAL SECTION 1
7[email protected]
STACKED
DRK-2 flybar
LP-4 brackets
IS 115S
IS 210L
IS 115S
LP-6 brackets
IS 210L
DRK-2 flybar
LP-4 brackets
IS 115S
DRK-1 flybar
IS 210L
For further information regarding max loading and installation
requirements, please refer to the accessories user manual.

IS210L 420120422Q REV1.0
QUICK START USER MANUAL SECTION 1
8[email protected]
A.E.B. Industriale Srl
Via Brodolini, 8
Località Crespellano
40053 VALSAMOGGIA
BOLOGNA (ITALIA)
Tel. [phone]
Fax [phone]
www.dbtechnologies.com
[email protected]
Scan with your
QR Reader App
to download the
complete User
Manual.
QQRRCCooddeetteexxtthttps://www.dbtechnologies.com/qrcode/001099/
DDaatteeccrreeaatteedd13-07-2022 12:09 07
DDeessccrriippttiioonnproduct name: IS210L
IDnode: 8670
IDlanguage: 267
language: English
field: manual
WARNING: Make sure that the loudspeaker is securely installed in a stable position to avoid any injuries or damages to persons or pro-
perties. For safety reasons do not place one loudspeaker on top of another without proper fastening systems. Before hanging the loud-
speaker check all the components for damages, deformations, missing or damaged parts that may compromise safety during installation.
If you use the loudspeakers outdoor avoid spots exposed to bad weather conditions.
The external wiring connected to speaker output terminals requires installation by qualied personnel only. Once the equipment is instal-
led, prevent access to the connectors to unqualied personnel. Only use the accessories and congurations described in this manual, and
proceed in accordance with the instructions given in the manuals for the accessories. dBTechnologies will not accept any responsibility
for damages caused by inappropriate accessories or additional devices.
Installation and use of this equipment and its accessories must be performed only by “Expert personnel” according to safety standard. To
prevent hazards to people, animals and/or objects, make sure that the installation is stable and secure. Comply with the safety regulations
and laws in force in the country in which you use the product. For safe use, periodically check that all parts are in good working condition
before use. Only authorised personnel may carry out design, calculations, installation, testing and maintenance of professional own or
stacked audio systems.
Check periodically the integrity and the functionality of the accessories and the technical equipments for a safe installation. user should
never apply a load that exceeds the working load limits of any rigging components or equipment here presented. design, calculation,
installation, testing and maintanance of suspension and stack systems for audio equipment must be performed only by qualied and au-
thorized personnel. AEB Industriale s.r.l. denies any and all responsibility for improper installations, in the absence of safety requirements.
Features, specication and appearance of products are subject to change without notice.
dBTechnologies reserves the right to make changes or improvements in design or manufacturing without assuming any obligation to
change or improve products previously manufactured.
WARNINGS
