dB Technologies VIO X Series User manual

21
Cod. 420120280 REV. 0.1
VIO X10 - VIO X12 - VIOX15
TABLE OF CONTENTS
English
TABLE OF CONTENTS
1. GENERAL INFORMATION............................................................................................................ 22
WELCOME! ................................................................................................................................ 22
PRODUCT OVERVIEW ............................................................................................................... 22
USER REFERENCE....................................................................................................................... 22
MECHANICAL AND ACOUSTICAL FEATURES............................................................................ 23
DIMENSIONS........................................................................................................................ 23
SOUND COVERAGE .............................................................................................................23
FEATURES OF THE AMPLIFIER AND CONTROL SECTIONS....................................................... 24
INPUT, OUTPUT, RDNET AND CONTROL SECTION.............................................................25
POWER SUPPLY UNIT SECTION...........................................................................................26
2. FIRST POWER-UP.......................................................................................................................... 27
PACKAGE CONTENTS................................................................................................................. 27
USE ............................................................................................................................................. 27
INPUT CONNECTIONS .........................................................................................................27
POWER SUPPLY CONNECTION............................................................................................28
CONNECTING THE OUTPUTS OF MULTIPLE SPEAKERS (audio daisy chain) ....................28
CONNECTING THE POWER SUPPLY OF MULTIPLE SPEAKERS ...........................................28
3. REMOTE CONTROL AND RDNET CONNECTION ....................................................................... 29
4. USAGE EXAMPLES........................................................................................................................ 30
BRACKETS................................................................................................................................... 30
WEDGE (MONITORING) USE .................................................................................................... 31
5. ACCESSORIES................................................................................................................................ 32
6. TROUBLESHOOTING.................................................................................................................... 33
7. SPECIFICATIONS ........................................................................................................................... 34
GENERAL..............................................................................................................................34
ACOUSTICAL SPECIFICATIONS............................................................................................. 34
AMPLIFIER............................................................................................................................34
PROCESSOR..........................................................................................................................35
USER INTERFACE..................................................................................................................35
INPUTS & OUTPUTS.............................................................................................................35
POWER SUPPLY SPECIFICATIONS (ABSORPTION / INSTALLATION) ................................... 35
DIMENSIONS........................................................................................................................ 36

22
VIO X10 - VIO X12 - VIOX15 Cod. 420120280 REV. 0.1
English
1. GENERAL INFORMATION
WELCOME!
PRODUCT OVERVIEW
USER REFERENCE
Thanks for purchasing a product designed and developed in Italy by dBTechnologies! This ergonomic and versatile
active speaker is the result of a long experience in the sound reinforcement industry, making use of optimized
sound, electronic and material research solutions.
The new professional VIO X loudspeakers are equipped with a 1” driver (coil: 1.75”) for model VIO X10, and a
1.4”driver (coil: 2.5”) for models VIOX12 and VIOX15. In the three models, the LF section is respectively controlled
by a 10” (voice coil: 2.5”), a 12” (voice coil:3”) and a 15” (voice coil:3”) neodymium woofer. These speakers main
features include:
To make the most of your VIO X speaker, we recommend that you:
• an ergonomic, professional and versatile project that can be used in monitoring for live contests
• wooden box with black polyurea nish, for the higest acoustic performance
• digital reliable and silent amplier that does not require active ventilation
• balanced In/LINK input and output audio connections
• presets selectable with different equalisations for different types of use, thanks to the DSP with FIR
lters
• RDNet onboard board for the professional remote control through the interfaces Control2, Control 8
and the integration on the AURORA NET software
• read the quick start user manual included in the package and this user manual thoroughly and keep
this manual during the whole life of the product.
• Register your product at http://www.dbtechnologies.com under “SUPPORT”.
• keep proof of purchase and WARRANTY (User manual “section 2”).
English

23
Cod. 420120280 REV. 0.1
VIO X10 - VIO X12 - VIOX15
MECHANICAL AND ACOUSTICAL FEATURES
DIMENSIONS
SOUND COVERAGE
The VIO X series has been designed with the intent to optimise weight and dimensions.
The cabinet is light but resistant, and features 2 handles, one on the side or one at the top, for easy handling.
For a quick comparison of the 3 models, the overall dimensions are the following:
VIO X10 - 280 mm (L), 550 mm (H), 375 mm (D)
VIO X12 - 340 mm (L), 650 mm (H), 445 mm (D)
VIO X15 - 400 mm (L), 750 mm (H), 475 mm (D)
The horn directivity ensures a covering of:
90°x40° (VIO X10)
60°X40° (VIO X12-VIOX15)
Take this into account for the different types of available installation.
E.g.: the special cabinet design and the DSP-controlled presets allow using WEDGE as stage monitor
English

24
VIO X10 - VIO X12 - VIOX15 Cod. 420120280 REV. 0.1
FEATURES OF THE AMPLIFIER AND CONTROL SECTIONS
DIGIPRO G3 amplier can deliver 900 W RMS for all the 3
models.
The system is silent and does not require a fan cooling. The
system is controlled by a dedicated powerful DSP that manages
the different parameters.
The DIGIPRO G3 panel is made up of:
WARNING!
• Protect the unit from moisture.
• Never attempt to disassemble the amplier in
any way.
• In the event of a malfunction, remove power
supply immediately by disconnecting the
unit from the power mains and contact an
authorised repair centre.
• I/O, RDNet and Control Section
• Power Supply Unit Section
• Never remove the front grille protecting the product.
To prevent the danger of electric shock, in case of accidental damage or replacement of the pro-
tection grille (to be carried out at the service), disconnect power supply immediately.
Never connect mains power supply when the grille is removed.
WARNING!
POWER SUPPLY UNIT SECTION I/O, RDNET AND CONTROL SECTION
English
English

25
Cod. 420120280 REV. 0.1
VIO X10 - VIO X12 - VIOX15
INPUT, OUTPUT, RDNET AND CONTROL SECTION
5. DSP PRESET - ROTARY
The presets that can be directly selected are the following ones: Fullrange, HPF (80, 85, 90, 100, 110) and wedge.
Please note that these are immediate selections to be made directly on the control panel. With the real time
remote control ensured by AURORA NET software (RDNet connections) it is possible to congure even the
smallest details of the functions of the speakers.
1. INPUT AND OUTPUT LINK (“Balanced audio”)
Input and output compatible with balanced XLR cables.
In particular, "Input" is used to connect with the audio
signal coming from the mixer or from another loudspeaker,
"Output Link" is used to link the signal to other
loudspeakers. Daisy-chain conguration.
2. INPUT SENSITIVITY
Allows adjusting the attenuation of the speaker using the
input volume.
3. INPUT AND NETWORK CONNECTION LINK RDNet
Section compatible with network cables with etherCON/RJ45
connectors.
In particular, "Data in" must be connected to devices such
as RDNet Control 2 or Control 8; "Data Out" is used to
link the network to additional loudspeakers in daisy-chain
conguration.
6. STATUS LEDs
LEDs relating to speaker operation. See explanatory table in the following page.
7. CONTROL LEDs
LEDs relating to module network operation (RDNet).
In particular, if "Link" is on the RDNet network is active and has acknowledged the device, if "Active" is ashing
there is data trafc, if "Remote Preset Active" is on all local control on the amplier panel are by-passed by the
RDNet remote control.
8. SERVICE DATA USB PORT
It is a USB B port to be used only for product rmware update. For further information refer to "FIRMWARE
UPDATE".
4. INPUT SENSITIVITY “Mic/Line” SWITCH
Set the switch to “Mic” in case of microphone input and to “Line” in case of signal coming from a mixer or from
another loudspeaker.
English

26
VIO X10 - VIO X12 - VIOX15 Cod. 420120280 REV. 0.1
POWER SUPPLY UNIT SECTION
10. “MAINS LINK” POWER DAISY CHAIN
Compatible with powerCON TRUE1 connector for power daisy chain to other speakers.
To nd the maximum number of modules that can be connected in a re-linked system, see the TECHNICAL
SPECIFICATIONS section.
9. “MAINS INPUT” POWER CONNECTOR
Compatible with powerCON TRUE1 connector, the power supply features an auto-range function. It
automatically recognises the voltage within the range [100-120V~] or [220-240V~].
11. MAINS FUSE
Housing for the mains fuse.
English

27
Cod. 420120280 REV. 0.1
VIO X10 - VIO X12 - VIOX15
2. FIRST POWER-UP
PACKAGE CONTENTS
USE
INPUT CONNECTIONS
Check that the package content of the VIO X loudspeaker is complete.
The package contains:
• VIO X speaker
• power cable
• quick start user manual and warranty documents
• 1 fuse
MIXER / LINE MICROPHONE
It is possible to connect 1 input in the input and control section at the back of the speaker. In particular, in case of
microphone input, set switch 4 to "MIC".
English

28
VIO X10 - VIO X12 - VIOX15 Cod. 420120280 REV. 0.1
POWER SUPPLY CONNECTION
POWER SUPPLY
CONNECTING THE OUTPUTS OF MULTIPLE SPEAKERS (audio daisy chain)
CONNECTING THE POWER SUPPLY OF MULTIPLE SPEAKERS
FIRST SPEAKER SECOND SPEAKER
POWER SUPPLY
LINK - OUTPUT LINK - INPUT
CABLE WITH POWERCON CONNECTORS
AUDIO INPUT LINK - OUTPUT LINK - INPUT
CABLE WITH XLR CONNECTORS
It is possible to link an audio signal by connecting the Output Link to the Input of a second VIO X. In the second
speaker, Audio Input Sensitivity must be set to “Line”.
It is possible to connect 1 input in the input and control section at the back of the speaker. In particular, in case of
microphone input, set switch 4 to "MIC".
FIRST SPEAKER SECOND SPEAKER
English

29
Cod. 420120280 REV. 0.1
VIO X10 - VIO X12 - VIOX15
• All speaker parameters can be adjusted with the remote control, once the RDNet connections have
been properly made, using the free AURORA NET software (in Beta version at the date of release of
this manual). When using the remote control, the local controls on the speaker are by-passed. Using
this software, you can control a larger number of parameters (for more information, please refer to
the full AURORA NET manual).
AURORA NET, in particular, is:
• multi-platform (Windows /MAC OS X)
• allows a more accurate control of the parameters and their history
• allows a more exible management even in the case of large xed/live installations (with advanced
group control)
• is optimized for usability and speed of data displaying.
3. REMOTE CONTROL AND RDNET CONNECTION
RDNET CONTROL 2/8PC/MAC
NETWORK CABLE
English

30
VIO X10 - VIO X12 - VIOX15 Cod. 420120280 REV. 0.1
4. USAGE EXAMPLES
• Types of installation other than those here described are not allowed.
• Never use the handles to suspend the speaker
• Always check that the positioning is stable and that the installation does not pose a danger to
people, animals or property.
• Perform the installation on a at, not tilted surface, otherwise an additional safety fastening is
mandatory.
VIO X models can be installed on a wall in horizontal position using the accessory
WB-VIOX10H, WB-VIOX12H, WB-VIOX 15H (for VIOX10, VIOX12, VIOX15, respectively).
They can also be installed on a wall in vertical position, as well as be hung or xed to a pole using accessory
Please see the related instructions for further information.
BRACKETS
English

31
Cod. 420120280 REV. 0.1
VIO X10 - VIO X12 - VIOX15
The VIO X series speakers can be used as monitors for live contests. In this case, lay
them horizontally on the tilted side. Be reminded of the sound coverage features
reported in the relevant section. Use the suitable DSP settings as indicated in the
"DSP preset" table in WEDGE mode..
WEDGE (MONITORING) USE
English

32
VIO X10 - VIO X12 - VIOX15 Cod. 420120280 REV. 0.1
To completion of the series, the following accessories are provided as options:
• Wall brackets (see the pictures below)
• SSB2, set of tripod stands with diameter 35 mm
• Rain Cover RC-M1, valid for all models
RC-M1 (RAIN COVER)
Please read the corresponding manuals for more details.
• Never suspend the speaker from the handles!
WARNING!
For all updates on accessories, refer to the website www.dbtechnologies.com
SSB2 (PAIR OF TRIPOD STANDS)
5. ACCESSORIES
HORIZONTAL BRACKETS
VERTICAL BRACKETS
English
English

33
Cod. 420120280 REV. 0.1
VIO X10 - VIO X12 - VIOX15
6. TROUBLESHOOTING
1. Check that power supply is present upstream of the installation.
2. Ensure that the power supply cable is properly plugged in.
1. Check that the input connection of the audio signal is correctly performed.
2. Check the cables for damage.
3. Ensure that the mixer or audio source is on and an output signal is present.
4. Check that the input level is appropriate.
1. Adjust the rst source volume, then set the input gain to an adequate level. Check the cables for
damage and replace them as required (a damaged cable may lead to signal loss or alteration).
2. Check that the selection settings of the input (Mic/Line) are correct with respect to the source
3. Check that the "DSP preset" settings are suitable for the use selected.
The loudspeaker will not turn on:
The speaker turns on but produces no sound:
Speaker sound is distorted or not sufcient:
English

34
VIO X10 - VIO X12 - VIOX15 Cod. 420120280 REV. 0.1
7. SPECIFICATIONS
GENERAL
ACOUSTICAL SPECIFICATIONS
AMPLIFIER
Type:
Frequency response [-10dB]:
Type:
HF compression driver (exit):
Max SPL:
Coverage (HxV):
LF Voice coil:
Frequency response [-6dB]:
Amplication class:
LF:
HF voice coil:
Crossover frequency (24 dB/oct):
2-way active professional speaker
73- 21.4 kHz (X10) / 62 - 22 kHz (X12) / 55 -22kHz (X15)
Digipro© G3
1” (X10) / 1.4” (X12) / 1.4” (X15)
130 dB (X10) / 132 dB (X12) / 133.5 (X15)
90° x 40° (X10) / 60° x 40° (X12) / 60° x 40° (X15)
2.5” (X10) / 3” (X12) / 3” (X15)
82- 20 kHz (X10) / 79 - 21 kHz (X12) / 72 -21kHz (X15)
Class D
10” (X10) / 12” (X12) / 15” (X15)
1.75” (X10) / 2.5” (X12) / 2.5” (X15)
1600 Hz (X10) / 1000 Hz (X12) / 1000 Hz (X15)
PowerCON TRUE1 connector
Power supply
English
English

35
Cod. 420120280 REV. 0.1
VIO X10 - VIO X12 - VIOX15
RMS amplier power:
Controls:
Peak power:
900 W
Input switch and level, DSP preset rotary
1800 W
PROCESSOR
INPUTS & OUTPUTS
Internal controller:
Inputs:
Outputs:
A/D D/A converter:
28/56-bit DSP
1 balanced audio input (with Line/Mic selection), 1 RDNet input
24 bit/48 kHz
1x XLR Link OUT, 1 RDNet output
Peak, RMS, Thermal
Limiter:
Power supply: powerCON TRUE1 IN/LINK
USER INTERFACE
Absorption at 1/8th of power in
medium use conditions (*): 1.3 A (230 V) - 2.1 A (115 V)
Absorption at 1/3rd of power in
maximum use conditions (**): 2.6 A (230 V) - 4.4 A (115 V)
Absorption with speaker on in
no-signal condition (idle): 19 W
Inrush current: 46 A
Number of linkable speakers: 6 (1+5) (230 V) / 3 (1+2) (115 V)
POWER SUPPLY SPECIFICATIONS (ABSORPTION / INSTALLATION)
* NOTE FOR INSTALLER: Values refer to 1/8th of power, under average operating conditions (music programme with occasional or no
clipping). For any type of conguration we recommend to consider them as minimum sizing values.
** NOTE FOR INSTALLER: Values refer to 1/3rd of power, under heavy operating conditions (music programme with frequent clipping and
limiter activation). In case of professional installations and tours we recommend sizing according to these values.
English

36
VIO X10 - VIO X12 - VIOX15 Cod. 420120280 REV. 0.1
DIMENSIONS
Material: Wooden box / black polyurea nished
Grille:
Provisions for brackets:
Full CNC-machined
Yes
Width:
Handles:
Depth:
Height:
Pole mount:
Weight:
280 mm (X10) / 340 mm (X12) / 400 (X15)
2 (on side, on top)
375 mm (X10) / 445 mm (X12) / 475 (X15)
550 mm (X10) / 650 mm (X12) / 750 (X15)
Yes, 36 mm
16.6 kg (X10) / 20.7 kg (X12) / 25.4 kg (X15)
Product features, specications and appearance are subject to changes without prior notice. dBTechnologies
reserves the right to make changes or improvements in design or manufacture without any obligation to
incorporate such changes or improvements in products manufactured before their introduction.
A.E.B. Industriale Srl
Via Brodolini, 8
Località Crespellano
40053 VALSAMOGGIA
BOLOGNA (ITALY)
Tel [phone]
Fax [phone]
www.dbtechnologies.com
[email protected]
English
