ddrum BETA XP2 User manual

ELECTRONIC DRUM SET
USERMANUAL
BETA XP2

Operation Warning
Warning & Caution Signs
WARNING
This sign indicates the risk of serious physical injury or
even death. Please operate the machine according to
instructions.
CAUTION
This sign indicates the risk of serious physical injury and
even death. Please operate the machine according to
instructions.
*Object damage refers to any harm or adverse effects to
household, furniture, pets, and etc.
About Signs
This sign indicates a warning or caution. Please read the accompanied
instruction to prevent any dangers.
This sign indicates any forbidden activity.
This sign indicates an instructional procedure for users to follow with.
ALWAYS FOLLOW THE INSTRUCTIONS
AS DESCRIBED BELOW
2

WARNING
Please read the following instructions
before operation.
Do not open or in any way modify the
machine or adapter.
Do not attempt to repair or replace any
internal parts by yourself, unless
instructed to do so by the manual. In
case of technical assistance, please
contact with your retailer, or their
customer service, or any recognized
retailers printed on the information page.
Do not store or operate the machine
under the following conditions:
• Near areas with extreme
temperature. (For example,in the car
under the sun, near a heat venting
pipe, and etc.)
• In very humid environments. (For
example, in the bathroom or near other
damp environments.)
• Exposing to rain or any other liquids
• In the sand.
• In shaking & unstable environments.
For proper operation, make sure that the
support stands are placed on flat and
stable ground in order to support the
machine safely.
WARNING
Please only use the adapter that is in-
cluded with the unit. Make sure that
the voltage of the socket matches the
voltage indicated on the unit.
Please do not over-twist or over-bend
the power cable, or place any objects
on it. Doing so may result in short-
circuit that can lead to fire and electric
shock.
Should any of the following situations
result, please stop operation and remove
the adapter from the socket, remove the
adapter from the socket, and consult with
your retailer, the nearest customer service,
or any of the recognized retailers listed on
the information page:
• The adapter or the power cable is
damaged.
• An object, or liquid has slipped into
the interior of the machine.
• The module has been exposed in
rain, or has got wet.
• The module is not operating or is
operating with noticeable problems.
3
Please do not operate with high volume
over a long period of time regardless of
using an amplifier or a headphone.
Doing so may prevent damage to your
hearing. Should any hearing discomfort
develop. Stop using and consult a hearing
doctor.

WARNING
If there are children in the household,
the adults should follow the safety
precautions explained in the manual.
Do not share the power supply with
too many adapters at the same time.
When using an extension power
supply, please make sure that the
total power usage does not exceed
the limit stated on the extension power
supply. Doing so may result in melting
of the cables and fire.
When using the module in other coun-
tries, please consult your retailer, the
nearest customer service, or any of
the recognized retailers listed on the
information page to find out correct
voltage for that country.
CAUTION
Always place the module and the
adaptor in areas with good airflow.
When inserting or removing the power
cable into/from the socket or the
machine, always grab the plug instead
of the cable.
If you do not plan to operate the
module for a long period of time,
please remove the adapter from the
socket.
To prevent the cables from tangling,
place the cables out of reach of
children.
Do not place heavy objects on the
module.
When moving the module, or during
insertion/removal of the plug, always
insertion/removal of the plug, always
use dry hands.
Please turn off the power and remove
the adapter from the socket before
cleaning the module.
When there is a risk of lightning strike,
please remove the adapter from the
socket.
4

Power Supply
• Do not share the power supply with other
electronics that can produce cable statics, for
example, electric motors.
• It is normal for direct current (DC) to produce
heat with extended usage, and there is no need
to be worried.
• Before connecting the module to other
electronics, always turn off the power to prevent
damage.
Placement/Location
• Operating the module near a post-amplifier or
machines that use High-power converters, buzzing
may result. To prevent this problem, please
change the module’s facing direction, or place the
machine away from the interrupting sources.
• This machine may interfere with the radios and
televisions. Please do not operate the module
near them.
• Do not place the module under sun, or near any
heat source, as high temperature may cause the
module or components to deform or discolor.
• To prevent permanent damage, please do not
expose the module or components to moist or in
humid environments.
Maintenance
• For normal cleaning, please use soft cloth with
little or no moist for wiping. For tougher spots, use
neutral-pH and wear-free cleaner then use dry soft
cloth to wipe clean.
• Never use volatile oil, diluting solutions, alcohol,
or any other kinds of solvents to prevent the
machine from deforming or discoloring.
Additional Precautions
• During operation, please handle with care to
prevent any damage. Do not hit or press against
the display screen.
• Always grab the heads of cables during in-
sertion/removal to prevent damage to the cables
or the machine.
• To prevent disturbing your neighbors, please
operate the machine at an acceptable volume, or
use a headphone, especially at night.
• Although this electronic drum set is designed to
minimize unwanted noise during operation, the
percussive sound may still pass through the floor
or walls, resulting in unexpected noise.Please be
careful not to let such sound disturb your neighbors,
especially at night.
• When transporting, please use the original or
similar packaging and box.
• Please use official cables for connection. When
using cables from other companies, please note
the following:Some cables may consist of resistors,
which may be incompatible and result in extremely
low volume. For information about the specifications
of cables, please consult with the manufacturer.
• Please do not hit the pads with excessive force to
prevent the risk of hurting your fingers.
Precautions
Please read the following precautions aside from the safety in-
structions
5

Accessories
B1 B2 B3 B4 B5
User
Manual
Cable Tie Drum Stick
(1 set)
Drum Key Headphones
x2
A8
drum throne
x1 x2 x1 x1 x1
Parts
P2 P4 P5
Ø3.81(cm)
Stopper
Wing Bolt Nut
x4
P3
Ø2.22(cm)
Stopper
x2 x22+2 x21+2
Accessories
A1 A2 A3 A4 A5 A6 A7
Sound Module Snare Pad Tom Pad Cymbal Hi-hat
Controller
Kick Pedal Bass Drum&
Double Slip Resistant Tape
x1 x1 x3 x3 x1 x1 x1
6
WARNING
L1 L3
Adapter L-L Mono
Sound Cable
x1 x1
L4
L-L Streao
Sound Cable
(Red) (Black)
x3
Please note:
whenever you insert
or pull the plug out
of a socket or adapter,
hold the plug. Do not
pull on the cable.
L5
L-L Streao
Sound Cable
(Red)
x1
L2
L-L Mono
Sound Cable
(Black)
x4
P1
Floor Pad
x4
Connectors
Connectors
C1
C2 C3
Adjustable Bar
x3
Ø1.27(cm) Pad
Connector
Ø3.81(cm)
U-shape Plate &
Double Screws
x4 x1
B6
Vel cro
x6
P6
Ø3.81 - Ø2.22
Connector
x1
Adjustable
Spare Parts
(1/4” jack) (3.5mm jack)

S1
S2
S3
S4
S5
S6
S7
x1
x1
x2
S8
S9
S10
S11
40 cm ×1
57 cm ×1
40 cm ×1
40 cm ×1
40 cm×1
40 cm×1
75 cm×1
57 cm ××1
75 cm×1
Ø3.81cm
x1
x1
x1
x1
(Red)
(Red)
40 cm×3
20 cm×4
Ø2.22cm
Ø1.27cm
x2
x1
x1
x1
x1x1
Support Stand
S1
S2
S3
S4
S5
S6
S7
S8
S9
40 cm ×1
57 cm ×1
40 cm ×1
40 cm ×1
40 cm×1
40 cm×1
75 cm×1
57 cm ××1
75 cm×1
(Red)
(Red)
Step 1
7

P1
Step 1
x4
P1
P1
P1
P1
S1
S8 S7
S2
S6S5
S3
S9
S4
8

11
12
13
15
14
1
2
4
5
9
S10 S11
S11 S11
S10
S10
S11
C1
C1
C1
3
6
7
8
10
16
S10
S11
40 cm×3
20 cm×4
Ø2.22cm
Ø1.27cm
Step 2
x3
x1
C1
P6
9

T1T2
8 9 13 15
12 14
x12
x12
P4
P5
Step 3
16
2
1 3
4
5 10
6 7 11
Attention: When assembling
this connector, tighten each
of the bolts in a square
pattern. Do not tighten one
bolt at a time. This will cause
the connector to be uneven. 10

x4
x1
x3
A2
Step 4
A3
x8
x8
P4
P5
C2
Depression
Below are examples of wrong assembly.
Convex
P4
C2
A3
P4P5
P5
11

SNARE 1/4" jack
A2
GrooveConvex
Match the convex side of pad with the groove side of connector .
A2
P4
P4P5
P5
C1
12

Step 5
A2 x1
x3
A4 x3
P2 X4
P3 X2
tighten
loosen
A4
loosen
A4
A3 A3
A2
A3
A4
NOTE Loosen or tighten the nut to adjust cymbal.
loosen tighten
P2
P3
P2
A3
13

Bass Drum
x1 A6 X1 T1 x2
A7
x1 T2 x1
T1
A7
The slip resistant tape compensate for varying kick pedal heights.
or
A7
T1
T2
A6
14

Mounting on the stand
A1 x1
C3 x1
Position the sound module
onto the bar and bring the
U-Shape plate upwards
around the bar.
Secure the U-Shape plate to
the back of the sound
module with the screws
provided.
Remove the protective film
from the display screen.
A1
C3
15

B6
Velcro
(no provide)
A4
choke
Controller
A5 x1
B6 X6
A4 x3
④ CYMBAL 1
⑦ CYMBAL 2
① HI-HAT
16

Sound Cable
L5 x1
L3 x3
② SNARE
L4
1/4" jack
③ TOM1
⑧ TOM2
⑨ TOM3
① HI-HAT
④ CYMBAL 1
⑦ CYMBAL 2
L3
⑤ HI-HAT CTRL
L5
⑩ BASS DRUM
L2
( )
( )Black
( )Red
L4 x1
( )Red
L2 x4
( )Black
Black
( )
Red
( )
Black
( )
Black
( )
Red
L2
WARNING
Please note: whenever you
insert or pull the plug out of
a socket or adapter,
hold the plug. Do not pull
on the cable.
Connect the sound cables
to the drum pads, pedals
and sound module.
Stereo cable
(two black lines)
17

① Hi-Hat
② Snare
③ Tom 1
④ Cymbal 1
⑤ Hi-Hat Controller
⑥ Bass Drum Controller
(optional, controller only)
⑦ Cymbal 2
⑧ Tom 2
⑨ Tom 3
⑩ Bass Drum
①
②
③
④
⑤
①
②
③
④
⑤
⑦
⑧
⑨
⑦
⑧
⑨
⑩
10
18

Cable Tie
B2 x2
Lead the cable along the
mounting rack and stabilize
it with the included cable tie.
19
