ddrum DD BETA User manual

ELECTRONIC DRUM SET
USER MANUAL
All manuals and user guides at all-guides.com
all-guides.com

Operation Warning
Instruction for Prevention of Fire, Electric Shock, & Physical Injury
About Warning & Caution Signs
WARNING
This sign indicates the risk of serious physical injury or
even death. Please operate the machine according to
instructions.
CAUTION
This sign indicates the risk of serious physical injury and
even death. Please operate the machine according to
instructions.
*Object damage refers to any harm or adverse effects to
household, furniture, pets, and etc.
About Signs
This sign indicates a warning or caution. Please read the accompanied
instruction to prevent any dangers.
This sign indicates any forbidden activity.
This sign indicates an instructional procedure for users to follow with.
ALWAYS FOLLOW THE INSTRUCTIONS
AS DESCRIBED BELOW
2
All manuals and user guides at all-guides.com

WARNING
Please read the following instruction
before operation.
Do not open or, in any way, modify
the machine or adapter.
Do not attempt to repair the machine,
or replace any internal parts by
yourself, unless instructed to do so
by the manual. In case of technical
need, please contact with your
retailer, or their customer service, or
any recognized retailers printed on
the information page.
Do not store or operate the machine
under the following described
conditions:
• Near areas with extreme
temperature. (For example, in the car
under the sun, near a heat venting
pipe, and etc.)
• In very humid environments. (For
example, in the bathroom, in the
toilet, on wet oor, and etc.)
• Exposing to rain.
• In the sand.
• In shaking & unstable
environments.
Operate the machine with the
recommended support stands and
accessories only.
WARNING
For proper operation, make sure that
the support stands are placed on at
and stable ground in order to support
the machine safely and stably.
Use only the included adapter. Make
sure that the voltage of the socket
matches the voltage indicated on
your adapter to prevent damage or
electric shock.
Please do not over-twist or over-
bend the power cable, or place any
objects on it. Doing so may result in
short-circuit that can lead to re and
electric shock.
Please do not operate the machine
with high volume over a long period
of time regardless of using an
amplier or a headphone, to prevent
damage to your hearing. Should
any hearing discomfort results, stop
using the machine and consult a
hearing doctor.
Prevent letting any object like coins
or pins, or any liquid slip inside the
machine.
3
All manuals and user guides at all-guides.com

WARNING
Should any of the following situations
result, please stop operation and
remove the adapter from the socket,
and consult with your retailer, the
nearest customer service, or any of
the recognized retailers listed on the
information page:
• The adapter or the power cable is
damaged.
• An object, or liquid has slipped into
the interior of the machine.
• The machine has been exposed in
rain, or has got wet.
• The machine is not operating or is
operating with noticeable problems.
If there were children in the
household, the adults should be
responsible of ateaching the children
to follow the safety precautions
explained in the manual.
Do not share the power supply with
too many adapters at the same time.
When using an extension power
supply, please make sure that the
total power usage does not exceed
the limit stated on the extension
power supply. Doing so may result
in melting of the cables and re.
When using the machine in other
countries, please consult your
retailer, the nearest customer
service, or any of the recognized
retailers listed on the information
page.
CAUTION
Always place the machine and the
adapter in areas with good airow.
When inserting or removing the
power cable into/from the socket or
the machine, always grab the plug
instead of the cable.
If you plan not to operate the
machine for a long period of time,
please remove the adapter from the
socket.
To prevent the cables from tangling,
place the cables out of reach of
children.
Do not place heavy objects on the
machine.
When moving the machine, or during
insertion/removal of the plug, always
use dry hands.
When moving the machine, or during
insertion/removal of the plug, always
use dry hands.
Please turn off the power and
remove the adapter from the socket
before cleaning the machine.
When there is a risk of lightning
strike, please remove the adapter
from the socket.
4
All manuals and user guides at all-guides.com

Power Supply
• Do not share the power supply with other
electronics that can produce cable statics, for
example, electric motors.
• It is normal for direct current (DC) to produce
heat with extended usage, and there is no
need to be worried.
• Before connecting the machine to other
equipments, always turn off the power to
prevent damage.
Placement/Location
• Operating the machine near a post-
amplier or machines that use high-power
converters, buzzing may result. To prevent this
problem, please change the machine’s facing
direction, or place the machine away from the
interrupting sources.
• This machine may interfere with the radios
and televisions. Please do not operate the
machines near them.
• Do not place the machine under sun, or near
any heat source, as high temperature may
cause the machine to deform or discolor.
• To prevent permanent damage, please do
not expose the machine to moist or in humid
environments.
Maintenance
• For normal cleaning, please use soft cloth
with little or no moist for wiping. For tougher
spots, use neutral-pH and wear-free cleaner
then use dry soft cloth to wipe clean.
• Never use volatile oil, diluting solutions,
alcohol, or any other kinds of solvents to
prevent the machine from deforming or
discoloring.
Additional Precautions
• During operation, please handle with care to
prevent any damage.
• Do not hit or press against the display screen.
• Always grab the heads of cables during
insertion/removal to prevent damage to the
cables or the machine.
• To prevent disturbing your neighbors, please
operate the machine at an acceptable volume,
or use a headphone, especially at nights.
• Although the machine is designed to
minimize unwanted noise during operation, the
percussive sound may still pass through the
oor or walls, resulting in unexpected noise.
Please be careful not to let such sound disturb
your neighbors, especially at nights.
• When transporting the machine, please use
the original or similar stufng and box.
• Please use ofcal cables for connection.
When using cables from other companies,
please note the following:
Some cables may consist of resistors, which
may be incompatible and result in extremely
low volume. For information about the
specications of cables, please consult with
the manufacturers.
• Please do not hit the pads with excessive
force to prevent the risk of hurting your ngers.
Precautions
Please read the following precautions aside from the safety
instructions
5
All manuals and user guides at all-guides.com

6
Accessories
A1 A2 A3 B1 B2
Sound Module Pad Cymbal Drum Stick
(1 set)
Headphones
x1 x4 x3 x1 x1
L1 L2 L3 B3 B4
Adapter L-L Mono
Sound Cable
(Black)
L-L Streao
Sound Cable
(Red)
Cable Tie User
Manual
x1 x6 x3 x2 x1
A4 A5 B5
Hi-Hat
Controller
Bass Drum
Controller Velcro
x1 x1 x6
All manuals and user guides at all-guides.com
all-guides.com

7
Spare Parts Connectors
P4~P7 C1 C2 C3 C4
Ø2.22 Pad
Connector
Ø1.27 Pad
Connector Adjustable Bar
U-shape Plate &
Double Screws
x2 x2 x2 x2 x1
Parts
P1 P2 P3 P4 P5 P6 P7
Floor Pad
Ø3.81 (cm)
Stopper
Ø2.22 (cm)
Stopper Bolt Washer Bolt Nut
x4 x2 x8 x14 x14 x8 x22
Support Stand
S1 Ø3.81 x40 (cm) x1 x2
S2 Ø3.81 x57 (cm) x1
S3 Ø3.81 x40 (cm) x1 x2
S4 Ø3.81 x75 (cm) x1 x3
S5 Ø2.22 x65 (cm) x1 x4
S6 Ø3.81 x75 (cm) x1 x2
S7 Ø2.22 x40 (cm) x1 x1
S8 Ø2.22 x40 (cm) x2
S9 Ø1.27 x40 (cm) x2
S10 Ø1.27 x20 (cm) x3
All manuals and user guides at all-guides.com

8
Step 1
S1
X1
S2 X1
S3
X1
S4
X1
S5
X1
S6
X1
S7
X1
P1
X4
(40 cm)
(57 cm)
(40 cm)
(75 cm)
(65 cm)
(75 cm)
(40 cm)
All manuals and user guides at all-guides.com

9
S5
S6
S1
S2
S4
S7 S3
P1
P1
P1
P1
All manuals and user guides at all-guides.com

10
5
6
7
14
2
1
3
4
13
12
11
10
9
8
Step 2
C3
X2
S8 Ø2.22 x40 (cm) x2
S9 Ø1.27 x40 (cm) x2
S10 Ø1.27 x20 (cm) x3
C3
C3
S8
S8
S9
S10
S10
S10
S9
All manuals and user guides at all-guides.com

11
① ② ③ ④
⑤ ⑥ ⑦ ⑫ ⑬
⑧ ⑨ ⑩ ⑪ ⑭
Step 3
P4 x14
P5 x14
P7 X14
P4
P4
P4
P5
P5
P5
P4P5P7
P7
P7
P7
All manuals and user guides at all-guides.com
all-guides.com

12
Step 4
A2 x4
P6 x8
P7 x8
C1 x2
C2 x2
Depression
Convex
Below are examples of wrong assembly.
P6
P6
C1
C2
P7
P7
A2
All manuals and user guides at all-guides.com

13
Step 5
A2 x4
A3 x3
P2 X2
P3 X8
A3
A3
A3
A2 A2
A2 A2
P3
P2
All manuals and user guides at all-guides.com

14
Mounting on the stand
A1 x1
C4 x1
Position the Sound
Module onto the Bar and
fold the U-Shape Plate
upwards around the bar.
Secure the U-Shape
Plate to the back of
the Sound Module with
Screws.
A1
C4
All manuals and user guides at all-guides.com

15
Hi-Hat
reverse side
Hi-Hat
label:
A4
Bass Drum
reverse side
Bass Drum
label:
A5
B5
reverse side
Velcro
oor mat
(no provide)
A3
choke effect
Controller
A4
Hi-Hat
Controller
x1
A5
Bass Drum
Controller
x1
B5
Velcro
X6
Choke Effect
A3 x2
④ CYMBAL1
⑦ CYMBAL2
All manuals and user guides at all-guides.com

16
(Black)
② SNARE
③ TOM1
⑧ TOM2
⑨ TOM3
(Red)
① HI-HAT
④ CYMBAL1
⑦ CYMBAL2
(Black)
⑤ HI-HAT CTRL
⑥ BASS DRUM CTRL
①③
④
⑤ ⑥
⑦
⑧
⑨②
Sound Cable
L2 (Black) x6
L3 (Blue) x3
Connect the Sound
Cables to the Drum
Pads,Pedals and Sound
Module.
Black: mono
Red: stereo
L2
L2
L3
All manuals and user guides at all-guides.com
all-guides.com

17
① HI-HAT ④ CYMBAL1 and ⑦ CYMBAL2 must use Stereo Sound Cables
(red, 2 parallel black lines at the tip) for connection to the Sound Module.
NOTE
Conecting the Pads
⑧ TOM2
⑨ TOM3
⑦ CYMBAL2
⑦
⑨
⑧
DC IN
LINE IN
MIDI OUT
⑤ HI-HAT
CTRL
⑥ BASS DRUM
CTRL
① HI-HAT
② SNARE
③ TOM1
④ CYMBAL1
①
③
⑤
②
④
⑥
PHONES
(Red)
(Black)
mobile
phone
music
player
⑩ BASS DRUM
⑩
optional
All manuals and user guides at all-guides.com

18
Console Control Introduction
① DC IN (DC 5V1A)
For connection of the power adapter.
② PHONES (3.5mm stereo)
For connection of a headphone.
③ POWER
Switch power on/o󰘯.
④ VOLUME
For adjusting the system volume
NOTE
To prevent damage to speakers,
always turn down the volume before
inserting or removing sound cables.
⑤ LINE IN (3.5mm stereo)
For connection of a sound input
source like a portable music player,
a mobile phone, other instruments or
another sound source. The sound is
directed to PHONES.
⑥ MIDI OUT (5-pin DIN)
For transmitting MIDI data.
About MIDI
MIDI (Musical Instrument Digitable
Interface) is an industry-standard
protocol that enables electronic
musical instruments, computers, and
other equipment to communicate,
control, and synchronize with each
other. MIDI allows computers,
synthesizers, MIDI controllers,
sound cards, samplers and drum
machines to control one another,
and to exchange system data.
②
③ POWER
①
⑤
⑥
④ VOLUME
mobile
phone
music
player
All manuals and user guides at all-guides.com

19
Console Operation
Percussion Sound Module
Press these buttons to Select a Drum Style.
The Selected Drum Style will be displayed on
the left side of the Sound Module’s screen;
the picture of the Sound Module, above,
displays Selection of ROCK Style. When the
Sound Module is turned on, the setting will
default to ROCK Style.
Available Drum Styles: ROCK/ JAZZ/
METAL/ BLUES/ POWER/ TECHNO/
MARCH/ LATIN/ TAIKO/ TIMBALE/
FUSION
Drum Styles
Percussion Sound Module
& Metronome
Remove the protector rst,
it may cause unexpected
damage.
All manuals and user guides at all-guides.com

20
NOTE Refer to the Styles & Sounds List page for specic percussion sounds.
Press this button to Select a Sound Set
for the current Drum Style. There are
up to 4 Sound Sets per Drum Style.
TECHNO, MARCH, and TAIKO Styles
only have 1 Sound Set. The Selected
Sound Set Number will be displayed to
the right of a hyphen on the right side
of the screen; the picture of the Sound
Module, above, displays Selection of
Sound Set 1. When the Sound Module
is turned on, the setting will default to
Sound Set 1.
Sound Set
Press this button to Toggle Reverb
On or Off. The function of Reverb is
to simulate the component of sound
that results from reections from
surrounding walls or objects, like an
echo. An will be displayed
to the right of the Sound Set Number
to designate Reverb On. If the Sound
Module’s screen only displays a Drum
Style and a Sound Set, this designates
Reverb Off. When the Sound Module
is turned on, the setting will default to
Reverb Off.
Reverb
All manuals and user guides at all-guides.com
