DECK DOLLY AutoConnect JD 7 Series User manual

1
ASSEMBLY INSTRUCTIONS
(To be used with the following model)
JDx7xx AutoConnect
May fit other models

2
IMPORTANT!!
After assembly, please be sure to operate the Deck Dolly on hard
surfaces only. Standing the Deck Dolly in the upright position on
soft or uneven surfaces may lead to injury and/or damage.
Please read through the instructions before beginning assembly.
Note that we are constantly improving the Deck Dolly so parts included may not be
exactly as described in instructions but the basic instructions still apply.
Assembly Instructions
1) Open packaging and inspect to ensure contents are complete.
2) Contents should be as pictured below:
2 - 7” Tires
Bottom Cross Support, Tube,
and 4 Brackets with hardware.
2 - Base Plates with hardware
Upper Deck Support,
2 Brackets, & Hardware

3
2 Uprights with end plugs.
Lower Bracket Assembly 2 Upright Legs
3) Preassemble the bottom cross support tube and brackets as shown below while
leaving the nuts loose.

4
4) Preassemble the Upper Deck Support as shown below.
5) Preassemble the Base Plates and Tires as shown below. The regular nut should be on
the inside and the serrated nut should be to the outside of the base plate. Take care to
tighten the bolt and nuts to allow the tire to spin freely but not be loose on the bolt.
6) Tap ends caps into Uprights as shown below.

5
7) Assemble the pieces as shown below hand tight.
8) The Base Plate may be tightened when assembled as shown below.
The Dolly should look as shown below at this point.

6
9) Assemble the bottom bracket parts and tighten the 5/8” bolt and make a mirror image
pair.
9) Assemble the brackets as shown below leaving bolts loose at this time.
10) With the Deck Dolly preassembled, lay the unit over the deck and align the bottom
bracket 5/8”bolt with the decks factory auto connect mounts. Depending on how it fits
you may have to flip the brackets to the other side of the Upright as shown below.
Usually this happens if the deck’s factory bracket touches the Deck Dolly’s wheel. The
point here is to carry the deck as low as possible without interfering with the Dolly.
Once satisfied with the fit, you may now tighten the bracket bolts. See picture below.

7
Be sure to set the width of the dolly to hold the dolly as shown below to hold the deck
mount as close to the bracket as possible.
11) Align the Upper Deck Support into the front deck mount leaving about an 1/8” of
space between the ½” rod and the top of the deck mount. This is to insure that when in
the upright position the weight of the deck is on the lower mounts. Tighten these bolts.
Dolly should appear as shown below.

8
12) Once you are satisfied with the fit of the Dolly on your deck you may tighten the
lower cross support tube when the brackets are centered. Beginning from the bottom,
tighten all bolts while insuring alignment.
13) Check all bolts for tightness before operating the Deck Dolly.
14) Please take care to watch the lower deck wheels when operating the Dolly for the
first time. You may have to raise and turn the wheels, so they do not catch on the
ground. Assembly is complete.
