DeDietrich Kaliko TWH 200E User manual

Export
KALIKO EN
Thermodynamic water heater
TWH 200E
TWH 300E
TWH 300EH
C003182-C
User Guide
7605313-001-07

Contents
1 Safety instructions and recommendations ..............................................4
1.1 Safety instructions ...............................................4
1.1.1 Installation ...............................................................4
1.1.2 Hydraulic connections .............................................4
1.1.3 Electrical connections .............................................5
1.1.4 Internet Site .............................................................5
1.1.5 Miscellaneous .........................................................6
1.2 Recommendations ................................................6
1.3 Liabilities ...............................................................7
1.3.1 Manufacturer’s liability .............................................7
1.3.2 Installer’s liability .....................................................7
1.3.3 User’s liability ..........................................................8
1.4 Safety data sheet: R-134a refrigerant .................8
1.4.1 Product identification ...............................................8
1.4.2 Hazard identification ................................................8
1.4.3 Composition / Information on the ingredients ..........8
1.4.4 First aid ...................................................................9
1.4.5 Fire prevention measures .......................................9
1.4.6 In the event of accidental spillage ...........................9
1.4.7 Handling ................................................................10
1.4.8 Personal protection ...............................................10
1.4.9 Considerations on disposal ...................................10
1.4.10 Regulations ...........................................................11
2 About this manual ....................................................................................12
2.1 Symbols used .....................................................12
2.2 Abbreviations ......................................................12
3 Technical specifications ..........................................................................13
3.1 Certifications .......................................................13
3.1.1 Electrical compliance / Marking CE .......................13
3.2 Technical specifications ....................................13
3.2.1 Characteristics of the appliance ............................13
4 Technical description ..............................................................................15
4.1 Operating principle .............................................15
4.2 Control panel .......................................................15
4.2.1 Description of the keys ..........................................15
4.2.2 Description of the display ......................................16
4.2.3 Browsing in the menus ..........................................17
101/12/2015 - 7605313-001-07

5 Operating the appliance ..........................................................................18
5.1 Putting the appliance into operation ................18
5.1.1 Commissioning ......................................................18
5.2 Reading out measured values ...........................18
5.2.1 Measurements menu ............................................18
5.2.2 Counters ................................................................19
5.3 Changing the settings ........................................20
5.3.1 Choosing the operating mode ...............................20
5.3.2 Programming an extended absence
(Vacation) ..............................................................21
5.3.3 Setting the time and date ......................................22
5.3.4 Modify an hourly programme ................................23
5.3.5 Modifying the domestic hot water production
parameters ............................................................24
5.3.6 Return to the factory settings ................................25
5.4 Installation shutdown .........................................26
5.5 Antifreeze protection ..........................................26
6 Checking and maintenance .....................................................................27
6.1 General instructions ...........................................27
6.2 Maintenance operations to be performed ........27
6.2.1 Cleaning the casing material .................................27
7 Troubleshooting .......................................................................................28
7.1 Messages (Code type bxx or Exx) .....................28
7.1.1 Messages (type code bXX) ..............................28
7.1.2 Messages (type code EXX) ..............................29
7.2 Message and error history .................................30
7.2.1 Err error display ....................................................30
7.2.2 bL blockage display ...............................................31
7.2.3 Reset error and blockage history ..........................31
8 Warranty ....................................................................................................32
8.1 General ................................................................32
8.2 Warranty terms ...................................................32
9 Appendix – Information on the Ecodesign and Energy Labelling
Directives ..................................................................................................33
Contents
201/12/2015 - 7605313-001-07

301/12/2015 - 7605313-001-07

1 Safety instructions and
recommendations
1.1 Safety instructions
DANGER
This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have
been given supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved. Children shall
not play with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
1.1.1. Installation
4Allow the space necessary for the correct installation of
the appliance:
¼See chapter Positioning of the appliance
(Installation and Service Manual).
1.1.2. Hydraulic connections
4The appliance is intended to be connected
permanently to the mains water supply.
4Maximum / minimum water pressure at the inlet:
¼See chapter Technical specifications.
4The pressure limiter device must be started up
regularly in order to remove any limescale deposits and
check that it is not blocked.
4Draining: Turn off the domestic cold water inlet. Open
a hot water tap in the system and then open the safety
unit valve. When the water stops flowing, the appliance
has been drained.
TWH 200E TWH 300E TWH 300EH 1. Safety instructions and recommendations
01/12/2015 - 7605313-001-07 4

4A pressure reducer (not provided) is necessary when
the mains pressure exceeds 80% of the calibration of
the safety valve or unit. It will be installed upstream of
the appliance.
4As water may run out of the discharge pipe on the
pressure limiter device, the discharge pipe must be
kept open to the open air.
4Connect the pressure limiter device to a drainage pipe,
kept in the open air, in a frost-free environment, on a
continuous downward slope.
1.1.3. Electrical connections
4Allowance must be made for a means of disconnection
in the fixed pipes in accordance with the regulations on
installations.
4If the mains power lead is damaged it must be replaced
by the original manufacturer, the manufacturer’s dealer
or another competent person to prevent hazardous
situations.
4This appliance must not be powered via an external
switch such as a timer or be connected to a circuit that
is regularly switched on and off by the electricity
supplier.
4Install the appliance according to national regulations
on electrical installation.
4Wiring diagram: ¼See chapter Electrical principle
diagram (Installation and Service Manual).
4Connecting the appliance to the mains electricity:
¼See chapter Electrical connections (Installation
and Service Manual).
4Fuse type and calibre: ¼See chapter Electrical
connections (Installation and Service Manual).
1.1.4. Internet Site
The user guide and the installation manual can
also be found on our internet site.
1. Safety instructions and recommendations TWH 200E TWH 300E TWH 300EH
501/12/2015 - 7605313-001-07

1.1.5. Miscellaneous
DANGER
If smoke is released or in case of refrigerant leak:
1. Do not use a naked flame, do not smoke, do
not operate electrical contacts or switches
( doorbell, light, motor, lift, etc..).
2. Open the windows.
3. Switch the appliance off.
4. Avoid contact with the refrigerant. Danger of
frost injuries.
5. Contact the professional responsible for
maintenance of the boiler.
WARNING
Depending on the settings of the appliance:
4Do not touch the refrigeration connection
pipes with your bare hands while the
appliance is running. Risk of being burnt.
CAUTION
4Do not neglect to service the appliance.
Contact a qualified professional or take out
a maintenance contract for the annual
servicing of the appliance.
4In order to limit the risk of being scalded, the
installation of a thermostatic mixing valve on
the domestic hot water flow piping is
compulsory.
1.2 Recommendations
WARNING
Only certified professionals having received
adequate training are permitted to work on the
appliance and the installation.
WARNING
Before any work, switch off the mains supply to
the appliance.
TWH 200E TWH 300E TWH 300EH 1. Safety instructions and recommendations
01/12/2015 - 7605313-001-07 6

1.3 Liabilities
1.3.1. Manufacturer’s liability
Our products are manufactured in compliance with the
requirements of the various applicable European
Directives. They are therefore delivered with [ marking
and all relevant documentation.
In the interest of customers, we are continuously
endeavouring to make improvements in product quality.
All the specifications stated in this document are therefore
subject to change without notice.
Our liability as the manufacturer may not be invoked in the
following cases:
4Failure to abide by the instructions on using the
appliance.
4Faulty or insufficient maintenance of the appliance.
4Failure to abide by the instructions on installing the
appliance.
1.3.2. Installer’s liability
The installer is responsible for the installation and
commissioning of the appliance. The installer must
respect the following instructions:
4Read and follow the instructions given in the manuals
provided with the appliance.
4Carry out installation in compliance with the prevailing
legislation and standards.
4Perform the initial start up and carry out any checks
necessary.
4Explain the installation to the user.
4If a maintenance is necessary, warn the user of the
obligation to check the appliance and maintain it in
good working order.
4Give all the instruction manuals to the user.
1. Safety instructions and recommendations TWH 200E TWH 300E TWH 300EH
701/12/2015 - 7605313-001-07

1.3.3. User’s liability
To guarantee optimum operation of the appliance, the
user must respect the following instructions:
4Read and follow the instructions given in the manuals
provided with the appliance.
4Call on qualified professionals to carry out installation
and initial start up.
4Get your installer to explain your installation to you.
4Ensure the Appliance is serviced in accordance with
the manufacturer’s instructions by a suitable qualified
person.
4Keep the instruction manuals in good condition close
to the appliance.
1.4 Safety data sheet: R-134a refrigerant
1.4.1. Product identification
4Refrigerant name: R-134a
1.4.2. Hazard identification
4Effects harmful to health:
-The vapours are heavier than air and may lead to
asphyxia owing to reduced oxygen levels.
-Liquefied gas: Contact with the liquid may cause
serious frost and eye injuries.
4Product classification: This product is not classified as
a "hazardous preparation" according to European
Union regulations.
CAUTION
If refrigerant is mixed with air, it may lead to
pressure surges in the refrigeration pipes and
cause an explosion and other hazards.
1.4.3. Composition / Information on the
ingredients
4Chemical nature: 1,1,1,2-Tetrafluoroethane R-134a.
TWH 200E TWH 300E TWH 300EH 1. Safety instructions and recommendations
01/12/2015 - 7605313-001-07 8

4Ingredients that may lead to hazardous situations:
Substance name Concentration CAS number CE number Classification GWP
1,1,1,2-Tetrafluoroethane R-134a 100 % 811-97-2 212-377-0 1300
1.4.4. First aid
4If inhaled: Evacuate the subject from the contaminated
area and take him into the open air.
If feeling unwell: Call a doctor.
4In the event of contact with the skin: Treat frost
injuries as burns. Rinse in abundant water, do not
remove clothing (risk of adhesion to the skin).
If skin burns appear, call a doctor immediately.
4In the event of contact with the eyes: Rinse
immediately in water, holding the eyelids well apart (at
least 15 minutes).
Consult an ophthalmologist immediately.
1.4.5. Fire prevention measures
4Appropriate extinguishing agents: All extinguishing
agents can be used.
4Inappropriate extinguishing agents: None to our
knowledge. In the event of fire nearby, use the
appropriate extinguishing agents.
4Specific hazards:
-Rise in pressure.
In the presence of air, an inflammable mixture may
form under certain temperature and pressure
conditions
-Toxic and corrosive vapours may be released by the
effect of the heat.
4Special intervention methods: Cool the volumes
exposed to heat with water spray.
4Protection of the firemen:
-Full facepiece self-contained breathing apparatus
-Complete body protection.
1.4.6. In the event of accidental spillage
4Individual precautions:
-Avoid contact with the skin and eyes
1. Safety instructions and recommendations TWH 200E TWH 300E TWH 300EH
901/12/2015 - 7605313-001-07

-Do not intervene without appropriate protective
equipment
-Do not inhale the vapours
-Evacuate the hazardous area
-Stop the leakage
-Eradicate all sources of ignition
-Ventilate the spillage area mechanically (Risk of
asphyxia).
4Cleaning / Decontamination: Allow residual product to
evaporate.
1.4.7. Handling
4Technical measures: Ventilation.
4Precautions to be taken:
-No smoking
-Prevent the accumulation of electrostatic charges
-Work in a well ventilated place.
1.4.8. Personal protection
4Respiratory protection:
-If insufficient ventilation: AX type cartridge mask
-In confined spaces: Full facepiece self-contained
breathing apparatus.
4Hand protection: Protective gloves in leather or nitrile
rubber.
4Eye protection: Safety glasses with side protection.
4Skin protection: Clothing made mostly of cotton.
4Industrial hygiene: Do not drink, eat or smoke at the
place of work.
1.4.9. Considerations on disposal
4Product waste: Consult the manufacturer or the
supplier for information on recovery or recycling.
4Soiled packaging: Reuse or recycle after
decontamination. Destroy in authorised installations.
WARNING
Disposal must be done in compliance with
prevailing local and national regulations.
TWH 200E TWH 300E TWH 300EH 1. Safety instructions and recommendations
01/12/2015 - 7605313-001-07 10

1.4.10. Regulations
4EC Regulation 842/2006: Fluorinated greenhouse
gases under the Kyoto Protocol.
1. Safety instructions and recommendations TWH 200E TWH 300E TWH 300EH
11 01/12/2015 - 7605313-001-07

2 About this manual
2.1 Symbols used
In these instructions, various danger levels are employed to draw the
user’s attention to particular information. In so doing, we wish to
safeguard the user’s safety, highlight hazards and guarantee correct
operation of the appliance.
DANGER
Risk of a dangerous situation causing serious physical
injury.
WARNING
Risk of a dangerous situation causing slight physical
injury.
CAUTION
Risk of material damage.
Signals important information.
¼Signals a referral to other instructions or other pages in the
instructions.
Before installing and commissioning the device, read
carefully the instruction manuals provided.
2.2 Abbreviations
4HP: Heat pump
4DHW: Domestic hot water
4LP: Low pressure
4HP: High pressure
4CFC: Chlorofluorocarbon
4Qpr: Static losses (Thermal losses from the DHW tank when it is
off for 24 hours)
4COP: Performance coefficient
4HP/HC: Peak hours / Off-peak hours
TWH 200E TWH 300E TWH 300EH 2. About this manual
01/12/2015 - 7605313-001-07 12

3 Technical specifications
3.1 Certifications
3.1.1. Electrical compliance / Marking CE
This product complies to the requirements to the european directives
and following standards:
42006/95/EC Low Voltage Directive
Reference Standard: EN 60.335.1.
42004/108/EC Electromagnetic Compatibility Directive
Reference Standard: EN 50.081.1 / EN 50.082.1 / EN 55.014.
3.2 Technical specifications
3.2.1. Characteristics of the appliance
Model TWH 300 E TWH 300 EH TWH 200 E
Capacity litres 270 260 215
Weight (empty) kg 105 123 92
R134a refrigerant kg 1.45 1.45 1.45
Output (HP) -Air temperature = 15°C W 1700 1700 1700
Electrical resistor output W 2400 2400 2400
Operating pressure bar (MPa) 10 (1,0) 10 (1,0) 10 (1,0)
Power supply voltage V 230 230 230
Circuit breaker A 16 16 16
Ambient air performance
Absorbed electrical power (HP) W 470 470 460
COP (1) - 2.44 2.64 2.55
COP (2) - 3.31 3.26 3.17
Vmax(3) litres 385 380 289
Pes(2)(4) W 42 41 33
Outside air performance
Absorbed electrical power (HP) W 500 500 500
COP (1) - 2.94 2.75 2.9
(1) Value obtained with an air temperature of 7 and a water inlet at 10 °C, as per EN16147 based on Specification LCIE N°103-15/B:2011
(2) Value obtained with an air temperature of 15 and a water inlet at 10 °C, as per EN16147 based on Specification LCIE N°103-15/B:2011
(3) Maximum volume of hot water that can be used at a temperature of 40°C
(4) Power consumption in stabilised regime
(5) The installation of suction and backflow conduits on the heat pump lessens its performance
(6) Domestic cold water input at 10°C - Primary inlet temperature at 80°C
(7) Output: 34.1 kW
3. Technical specifications TWH 200E TWH 300E TWH 300EH
13 01/12/2015 - 7605313-001-07

Model TWH 300 E TWH 300 EH TWH 200 E
Nominal air flow rate (DP = 25 Pa) m3/h 320 320 320
Vmax(3) litres 388 383 282
Pes(4)(1) W 34 36 30
Maximum length of the air connection Diameter 160 mm(5) m 26 26 26
Hydraulic additional heating
Exchanger surface m2- 1.00 -
Continuous output DT = 35 K (6) (7) litres per hour - 955.6 -
Flow rate over 10 minutes with DT = 30 K (6) l/10 mm - 420 -
(1) Value obtained with an air temperature of 7 and a water inlet at 10 °C, as per EN16147 based on Specification LCIE N°103-15/B:2011
(2) Value obtained with an air temperature of 15 and a water inlet at 10 °C, as per EN16147 based on Specification LCIE N°103-15/B:2011
(3) Maximum volume of hot water that can be used at a temperature of 40°C
(4) Power consumption in stabilised regime
(5) The installation of suction and backflow conduits on the heat pump lessens its performance
(6) Domestic cold water input at 10°C - Primary inlet temperature at 80°C
(7) Output: 34.1 kW
TWH 200E TWH 300E TWH 300EH 3. Technical specifications
01/12/2015 - 7605313-001-07 14

4 Technical description
4.1 Operating principle
The thermodynamic DHW tank uses unheated ambient air or outside
air to prepare DHW.
The refrigerant circuit is a closed circuit in which the R-134a
refrigerant plays the role of an energy carrier.
The heat from the intake air is transferred to the refrigerant in the
finned heat exchanger at a low evaporation temperature.
The refrigerant is sucked in by a compressor in vapour form, which
raises it to a higher pressure and temperature and sends it to the
condenser. In the condenser, the heat extracted in the evaporator and
some of the energy absorbed by the compressor are released into
the water.
The refrigerant is depressurised in the thermostatic expansion valve
and is cooled. The refrigerant can again extract the heat contained in
the inlet air into the evaporator.
4.2 Control panel
4.2.1. Description of the keys
( - )Browse keys
MODE Operating mode selection key
MENU Key to access the various menus
C003197-B
MENUMODE
4. Technical description TWH 200E TWH 300E TWH 300EH
15 01/12/2015 - 7605313-001-07

4.2.2. Description of the display
!Quantity of domestic hot water available (depending on
the set point input)
JParameter settings
!Alarm
KComfort period active or Clock programming
88[8
8
Display of the date (day:month) or the time (hour:minutes)
depending on the selected menu
1 2 3 4 5
6 7
Display of the day of the week (1=Monday, 2=Tuesday,
etc.)
888 Digital display
;pt Optimsation function active
LNumber of baths available (40 °C)
XQuantity of water (litres)
(Reduces set values
)Increases set values
BConfirm key
VReset the control system after a breakdown
MAutomatic mode or Comfort mode
%Eco mode
WBoost mode
> C Holiday mode
M + WBoost function active via the HP/HC inlet
% + WBoost function active via the HP/HC inlet
> C
+ W
Boost function active via the HP/HC inlet
nDHW production mode indicator
The main display indicates the domestic hot water production mode.
Display Domestic hot water
production
Description
C003487-B
Heat pump The 2 segments of the tank flash simultaneously when domestic hot water production
is handled by the heat pump
C003484-B
Electrical back-up The right-hand segment of the tank flashes when domestic hot water production is
handled by electrical back-up
C003485-B
Hydraulic additional heating The left-hand segment of the tank flashes when domestic hot water production is
handled by hydraulic back-up (EH Version)
C003486-A
Heat pump + Electrical back-
up + Hydraulic additional
heating
The 2 segments of the tank flash alternately when domestic hot water production is
handled by the heat pump, by electrical back-up and by hydraulic backup (EH version)
1
2
3
4
5
°C
6
7
14
34
12
MENU
C003186-I
MODE
TWH 200E TWH 300E TWH 300EH 4. Technical description
01/12/2015 - 7605313-001-07 16

nIndicator of the water volume available
When producing domestic hot water, the display indicates the number
of baths available and the level to which the tank is filled (quantity of
hot water available).
4The number of baths is calcuated based on a domestic hot water
temperature of 40°C.
4The level to which the tank is filled is calculated according to the
set point temperature.
4.2.3. Browsing in the menus
1. Press the MENU key. The SE nS 1 menu is displayed
(Temperature measurement).
2. Use the ( and ) keys to scroll through the menus (See table
below).
3. To access the selected menu, press the MODE key (B).
4. To go back to the previous display, press the key MENU.
5. To go back ty the main display, press once key MENU.
Accessing the menu Menu Description See chapter
1x MENU SE nS
1
Measurements menu ¼ "Reading out measured values", page 18
1x )CL OC
2
Setting the time and the date ¼ "Setting the time and date", page 22
2x )Pr oG
3
Modify an hourly programme ¼ "Modify an hourly programme", page 23
3x )Co un
4
Meters ¼ "Counters", page 19
4x )PA rA
5
Setting parameters ¼ "Reading out measured values", page 18
5x )Er bL
6
Failure history ¼ "Message and error history", page 30
6x )Co dE
7
Installer parameters ¼Refer to the installation and service manual
C003493-B
14
34
12
C003203-E
1x
3
14
34
12
MENUMODE
C003204-B
1x
2x
3x
.
.
.
14
34
12
MENUMODE
4. Technical description TWH 200E TWH 300E TWH 300EH
17 01/12/2015 - 7605313-001-07

5 Operating the appliance
5.1 Putting the appliance into operation
5.1.1. Commissioning
CAUTION
Initial commissioning must be done by a qualified
professional.
CAUTION
After positioning the appliance, wait one hour before
starting it up.
Carry out the commissioning operations in the following order:
1. Connect to the mains.
2. Check that no error codes or messages are shown on the display.
The domestic hot water set point temperature is set to 55°C in
comfort mode.
3. Select the Boost operating mode.
¼See chapter: "Choosing the operating mode", page 20
4. The compressor starts up after 120 seconds if DHW production is
required.
5.2 Reading out measured values
5.2.1. Measurements menu
1. Press once the MENU key. The SE nS 1 menu is displayed.
2. Press the MODEB key to go to the Measurements menu. The SE
01 menu is displayed.
TWH 200E TWH 300E TWH 300EH 5. Operating the appliance
01/12/2015 - 7605313-001-07 18

3. Use the ( and ) keys to switch from one measurement to
another.
Parameters Description Unit
SE 01 Top DHW temperature sensor °C
SE 02 Middle DHW temperature sensor °C
SE 04 Room sensor °C
SE 05 Evaporator temperature sensor °C
SE 06 Electricity tariff:
4HP1: Peak hours
4HC0: Off-peak hours
St Su Operating status / sub-status of the control system
sequence
SP 1 Back-up setpoint °C
SP 2 Compressor setpoint °C
5.2.2. Counters
nDisplaying the counters
1. Press once the MENU key. The SE nS 1 menu is displayed.
2. Press the ) key 3 times. The Co un 4 menu is displayed.
3. Press the MODE B key to go to the Counters menu. The number
of the counter is shown to the right of the display.
4. Use the ( and ) keys to switch from one counter to another (See
table below).
5. To exit this menu, press the MODE B key.
6. To go back to the main display, press the MENU button.
Meter Description Unit
1 Total electric energy consumed for DHW production kWh
2 Electric energy consumed by the compressor in the last 24 hours
The counter is reset at 00:00 hours every day
Wh
3 Electric energy consumed by the electrical back-up in the last 24 hours
The counter is reset at 00:00 hours every day
Wh
C003206-D
1x
2x
3x
.
.
.
14
34
12
MENUMODE
C004186-A
14
34
12
MENUMODE
C003210-C
1
14
34
12
MENUMODE
5. Operating the appliance TWH 200E TWH 300E TWH 300EH
19 01/12/2015 - 7605313-001-07
