DediProg NuProg-E User manual

NuProg-E
Engineering UFS/EMMC
Programmer User Manual
Version 1.4
DediProg User Manual 12/2017
©DediProg Technology Co., Ltd 2017 All rights reserved.

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 2
Table of Contents
I. INTRODUCTION ............................................................................................................................... 4
II. PRODUCT INFORMATION................................................................................................................. 4
III. SYSTEM REQUIREMENT ................................................................................................................... 5
IV. PRODUCT DESCRIPTIONS ................................................................................................................. 6
4.1 EXTERIOR ................................................................................................................................................. 6
4.2 INSTALL SOCKET ADAPTOR........................................................................................................................... 8
V. DEDIWARE QUICK INSTALLATION .................................................................................................... 9
5.1 SOFTWARE INSTALLATION............................................................................................................................ 9
5.2 INSTALL NUPROG-E PROGRAMMER............................................................................................................. 12
5.3 NUPROG_UFS INSTALLATION GUIDE. ......................................................................................................... 12
5.3.1 NuProg_UFS icon......................................................................................................................... 12
5.3.2 Software Introduction (UFS Part) ................................................................................................ 13
A. Main Menu and Functions..................................................................................................................... 13
B. LOG Window.......................................................................................................................................... 27
C. Programmer Information ...................................................................................................................... 27
D. IC Information........................................................................................................................................ 28
E. CheckSum Data...................................................................................................................................... 28
F. Batch Config Setting .............................................................................................................................. 28
5.3.3 Examples ..................................................................................................................................... 29
5.4 PRECAUTIONS WHEN USING NUPROG-E (FOR UFS) SOFTWARE ........................................................................ 37
5.5 NUPROG_EMMC INSTALLATION GUIDE ...................................................................................................... 38
5.5.1 NuProg_eMMC............................................................................................................................ 38
5.5.2 Software Introduction (eMMC part) ...................................................................................... 38
A. Main Menu and Functions..................................................................................................................... 39
B. LOG Window.......................................................................................................................................... 50
C. Programmer Information ...................................................................................................................... 50
D. IC Information........................................................................................................................................ 50
E. CheckSum Data...................................................................................................................................... 51
F. Batch Setting ......................................................................................................................................... 51
VI. REVISED EDITION ........................................................................................................................... 52

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 3
Important notice:
This document is provided as a guideline and must not be disclosed without consent of
DediProg. However, no responsibility is assumed for errors that might appear. DediProg
reserves the right to make any changes to the product and/or the specification at any
time without notice. No part of this document may be copied or reproduced in any
form or by any means without prior written consent of DediProg.

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 4
I. Introduction
This user manual is mainly introducing the hardware specifications, applications and the
software quick installation. NuProg-E is an engineering programmer that is innovated for
programming mass flash storage, such as UFS and eMMC. For UFS, it provides the basic
LUN and RPMB read and write as well as the settings for descriptors, attributes and flags.
As for eMMC, it supports User Area, Boot 1/2 and RPMB basic read and write; also
supports ExtCSD, GPP1~4 partition, read and write, as well as enhanced mode setting.
With the high speed USB 3.0, the NuProg-E is the finest programmer for UFS and eMMC
development. For more information, please visit our website.
www.dediprog.com/download
II. Product Information
High Speed Programming
With high speed processor, programming speed will increase greatly.
UFS Write speeds: 20~50MB/s; Read speeds: 50~80MB/s (Depends on computer and IC
performance).
Time reference: It will only take 25 seconds to program a 1GB file into a Toshiba UFS IC
Support UFS and EMMC/EMCP Settings and Programs
UFS part
1. Support Descriptors, Attributes, Flags settings
2. Support LUN configured and advance settings
3. RPMB
EMMC part
1. Support User Area, Boot1/2 Partition and Extend CSD
2. Support RPMB, GPP1~4 and Enhanced mode
Support all IC package
Support standard package of UFS and EMMC (BGA153 (11.5x13mm)) or special package of
EMCP.
Regular Software Update
Palm Size and Space Saving
Dimension: 132 x 75 x 30 mm Weight: 104g
Support USB 2.0 and USB 3.0 (Power adapter is required)

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 5
III. System Requirement
CPU:
Intel i5 or Above
OS:
Windows 7 / 8 / 8.1 / 10
USB Port:
USB 2.0 and USB 3.0
Free Dish Space:
At least twice of the programming memory.
CD ROM:
It is necessary for installing the software.
*Since UFS and EMMC have mass volumes, please reserve enough space for buffering.
*Computer performances will affect the read and write of UFS, please choose a computer that
has higher CPU and better performance.

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 6
IV. Product Descriptions
4.1 Exterior
A. Power Signal Light
E. Power Connector
C. Programming Socket Sites
D. Start Button
B. Operation Lights
F. USB 3.0 Port
Fig. 4-1
Fig. 4-2

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 7
A. Power Signal Light
The light indicates the programmer is powered on.
B. Operation Lights
Red LED (Error): Error; programming has failed.
Yellow LED (Busy): The programmer is operating.
Green LED (Pass): Passed; the programming has completed successfully.
C. Programming Socket Sites
Built-in high speed connector, which is for installing the socket adaptor
D. Start Button
Not available now.
E. Power Connector
External power inputs (In order to make it more stable, please make
sure the power adapter is connected.)
F. USB 3.0 Port
For connecting programmer with the computer.

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 8
4.2 Install Socket Adaptor
Place an IC into the socket adaptor and attach the adaptor to the
socket site.
Fig. 4-3
Socket Adaptor
Socket Site

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 9
The software is provided with the purchase of NuProg-E programmer. The
newest version will also be available on our website. www.dediprog.com
5.1 Software Installation
5.1.1 Install DediWare
V. Dediware Quick Installation
Fig. 5-1

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 10
5.1.2 When you install NuProg-E software for the first time, please install
the USB Driver. Otherwise, the computer will not be able to recognize the
programmer.
Fig. 5-3
Fig. 5-2

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 11
5.1.3 After installation, Dediware, NuProg_UFS and NuProg_eMMC icons
will appear on the desktop. The Dediware icon is for StarProg and
ProgMaster series programmer while the NuProg_UFS and NuProg_eMMC
are for NuProg-E programming.
There is another icon called DediWare_CLI; it is the Command Line software
for StarProg Series programmers, so it does not support NuProg series.
StarProg/ProgMaster
NuProg-E
Fig. 5-４
Fig. 5-5

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 12
5.2 Install NuProg-E Programmer
5.2.1 Place an IC into the socket adaptor and attach it to the socket site.
5.2.2 Connect NuProg-E to the computer (USB 3.0 is recommended).
5.2.3 Once you open Dediware, it will detect a programmer automatically
and will be available for programming.
※Using multiple USBs on the same computer may affect the charging currents, so it is
REQUIRED to connect the USB with our power adapter for stable programming.
5.3 NuProg_UFS Installation Guide.
5.3.1 Double Click NuProg_UFS icon.
Fig. 5-6

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 13
5.3.2 Software Introduction (UFS Part)
A. Main Menu and Functions
Fig. 5-8
Fig. 5-7
Log Window
Main Menu and
Functions
Programmer
Information
IC
Information
Batch Config
Setting
CheckSum
data

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 14
A-1. Main Menu- Advance
Language: English, Simplified Chinese and Traditional Chinese are provided.
Log in: Set up the IP address for remote controls.
General options: Set up a temporary file for saving buffers. Since large volume IC
has a great demand of storage. Therefore, if C drive does not have enough space,
please choose other drive.
Fig. 5-10
Fig. 5-9

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 15
A-2. Main Menu- Help
Firmware Manual Update: Update the firmware version of the NuProg-E. Update
the firmware and restart the programmer.
Launch Calculator: It opens the calculator.
User Manual: It links to DediProg’s user manuals.
Fig. 5-11

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 16
A-3. Functions (From Top to Bottom; Left to Right)
Detect: Detect IC or choose the model number manually. If the data list has the
corresponding model number that is supported, software will automatically import
the values of the UFS, and the Log will appear as below (Fig. 5-13). If the IC model
number that you need are not listed (Fig. 5-14), please feel free to contact us.
Fig. 5-13
Fig. 5-12

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 17
Load: Import the programming file and set the values according to your requirements.
Fig. 5-15
Fig. 5-14

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 18
Value Descriptions:
File Format: The format of the programming file.
File Checksum: The file checksum’s calculation method.
File Offset: Appoint an address to start loading the buffer.
File Path: Assign a path for the programming file.
Skip Blank Value: Enable this function to analyze and skip the blank data
before programming, which will write more efficiently and reduce the
programming time.
Partition Name: It depends on the partitioned sections.
Note: This partition here will only show the amounts and settings according the
IC that has been detected.
Sector Index: Set up the sector starting point
Sector Count: Set up total programming sectors.
AutoSetFileOffset:When setting the Sector Index, this function can
automatically calculate the File Offset.
+: When there is more than one programming file, please press “+” to add the
files to the data list.
Show Images and Hide Images: Open and close the data list.
Load Prj: Import previous programming files (Not Supported Yet).
Save Prj: Save all the settings as a programming file (Not supported yet).

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 19
Buffer: Temporary files.
Select a partition to display the LUN and the related Option values of the UFS.
Buffer Checksum: It will calculate the assigned Partition checksum.
Goto: Assign a Buffer address
Fig. 5-16

NuProg-E Engineering UFS/EMMC Programmer User Manual
www.dediprog.com 20
Config: Programming Settings. It will read the contents of
Descriptors/Attribute/Flags from the UFS and display on each window.
Batch Setting: Double click the programming options that are listed in the Batch
Operation box or click >> or << to move the options to the Operation Selected box.
The AutoBatch will program according to the listed order in the Operation Selected
box.
Note: You can add Write Flag and Write Attributes before or after Wipe LUN/Blank
Check/Program Chip/Checksum Verify. When executing the Attributes, it is recommended
to arrange the Write Attributes to the last step (especially when setting the frequency clock
bRefClkFreq of UFS), shown as Fig 5-17.
Fig. 5-17
