Deerc D10 User manual
1.0
Disclaimer & Warning
.....................................................................................
2.0
Safety Guidelines
..............................................................................................
3.0 Maintenance .......................................................................................................
4.0 Package Contents .............................................................................................
5.0
Drone Details .....................................................................................................
6.0 Transmitter Details ............................................................................................
7.0 Joystick Mode
..................................................................................................
8.0 Charging
............................................................................................................
9.0 Installation
9.1 Propellers
......................................................................................................
9.2 Drone Battery
.............................................................................................
9.3 Propeller Guard
...........................................................................................
9.4
Transmitter Battery
.....................................................................................
9.5 Phone Holder
...............................................................................................
10.0 Operation Guide
10.1 Download APP
........................................................................................
10.2 Connect to Wi-Fi
.....................................................................................
10.3 Pairing
..........................................................................................................
10.4 Calibrating the Gyroscope
..................................................................
10.5 One Key Takeoff/Landing
...................................................................
11.0 Functions Details
11.1 Emergency Stop ....................................................................................
11.2 Speed Switch
.............................................................................................
11.3 Trimmer Function .................................................................................
11.4 Take Photo/Video ................................................................................
11.5 Altitude-Hold Function .......................................................................
11.6 360° Flip ...................................................................................................
11.7 Circle Fly ...................................................................................................
11.8 Auto-Rotation
............................................................................................
11.9 Headless Mode ......................................................................................
12.0 Specifications ...............................................................................................
13.0 Contact Us ....................................................................................................
14.0 General Information ..................................................................................
Contents
01
01
05
06
07
07
08
09
10
10
11
12
12
13
13
14
15
15
16
16
17
18
19
19
20
20
21
23
25
26
-01-
1. Please read this Disclaimer & Warning and Safety Guidelines carefully
before using our product. This product is not recommended for people
under the age of 14. By using this product, you hereby agree to this
disclaimer and signify that you have read it fully. You agree that you are
responsible for your own conduct and any damages caused while using
this product, and its consequences. You agree to only use this product for
it's designed purposes and in accordance with local laws, regulations and
all applicable policies and guidelines that Deerc may provide.
2. When using this product, please be sure to strictly abide by the specifica-
tion requirements and safety guidelines stated in this document. Any
personal injury, property damage, legal disputes and all other adverse
events caused by the violation of any of the safety instructions or due to any
other factor, WILL NOT be Deerc’s responsibility.
1.0 DISCLAIMER & WARNING
2.0 SAFETY GUIDELINES
① This product is a high precision drone that integrates various electronic
stability and control mechanisms. Please be sure to configure this drone
carefully and correctly to ensure safe, accident-free operation.
② Ensure that the batteries of the drone and transmitter are clean, undam-
aged and fully charged before every use.
③ Ensure that all the propellers are undamaged and are installed in the
correct orientation.
2.1 Check Before Use
-02-
2.2 Flight Environment:
Fly in Open Areas Maintain Line
of Sight
Fly Below
262 feet (80 m)
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
④Ensure to do a thorough check of the product before each use. Inspect
the integrity of the parts, any signs of cracks and wear of the propeller,
battery power and effectiveness of the indicator, etc. If after doing a
complete check of the drone any problems are found, please refrain from
using it until the problem has been resolved.
Avoid flying over or near obstacles, crowds, high voltage power lines, trees,
airports or bodies of water.
DO NOT fly near strong electromagnetic sources such as power lines and
base stations as it may affect the onboard compass.
DO NOT use this drone in adverse weather conditions such as rain, snow,
fog, and wind.
-03-
2.3 Operation Requirements
①DO NOT use this product to follow any moving vehicles.
②During the flight, turn off the motors only in case of an emergency.
③Fly the drone back to you as soon as you are notified that the battery is
running low.
④This product should not be used while drinking alcohol or consuming
drugs, if you are feeling fatigued, taking medicine, or feeling any physical
discomfort.
⑤Be aware of the volume of noise that the drone produces. Please ensure
to keep your distance to avoid ear damage.
2.4 Use of Battery
①Please ensure batteries are fitted in the correct orientation as shown in
the instruction manual.
②Avoid short circuits by fitting the batteries correctly, and do not crush or
squeeze the batteries as this could cause the risk of a fire or explosion.
③DO NOT mix new and old batteries as this can lead to a poor perfor-
mance of the product.
④Please dispose of used batteries carefully, do not litter and recycle where
ever possible.
⑤DO NOT expose dead batteries to heat or fire or they may explode.
⑥If the device is not going to be used for an extended period of time,
please remove batteries to prevent potential damage from to the drone
battery leakage.
⑥Stay away from the rotating
propellers and motors.
⑦ DO NOT fly in any spaces
where drones are prohibited.
Please respect people's right to
privacy by not flying your drone
close to others.
-04-
⑦Only use the USB charging cable that comes with the drone to charge
the battery.
⑧DO NOT connect the battery directly to wall outlets or car cigarette
-lighter sockets as this will damage your battery as they are a different
voltage.
⑨DO NOT attempt to disassemble or modify the battery in any way
⑩DO NOT use the battery if it gives off an odor, generates heat, becomes
discolored, deformed or appears abnormal in any way. If any of these
situations occur while the battery is in use or being charged, remove it from
the device or charger immediately and discontinue use.
DO NOT pierce the battery casing with a nail or any other sharp object,
break it open with a hammer, or step on it! Dispose or recycle this battery as
it may cause personal injury or damage to your drone.
Always charge the batteries on a fireproof surface and away from
combustible materials. DO NOT charge on surfaces that can catch fire. This
includes: wood, cloth, carpet, or on the application's device.
DO NOT immerse the battery in water or get it wet.
DO NOT solder battery terminal in any way.
Keep batteries out of reach of children or pets.
DO NOT short-circuit the battery by connecting wires or any other metal
object to the positive(+) and negative(-) terminals.
12
13
14
15
16
Li-Po Battery Disposal & Recycling
Waste Lithium-polymer batteries must not be placed with household trash.
Please contact local environmental or waste agency or the waste agency
or the supplier of your model or your nearest Li-Po battery recycling center.
11
-05-
3.0 MAINTENANCE
①Clean the product after each use with a clean, soft cloth.
②Avoid prolonged exposure to direct sunlight and avoid buildup of heat
on the drone or batteries.
③This device is not waterproof and must not be submerged or subjected
in water under any circumstance. Failure to keep the device completely dry
will result in the failure and permanent damage to the unit. Be aware that
although it might be dry where you are, droplets of rain or mist from a river
or waterfall could be damaging your drone where it is flying.
④Frequently Check the charging plug and other accessories for signs of
damage. If any part of the device or cables are damaged, avoid use or
charging until the device can be serviced.
-06-
4.0 PACKAGE CONTENTS
Drone Transmitter Drone Battery
Propeller
USB Charging
Cable
Instructions For Use
Propeller Guard
Screwdriver
V 6.0
Instructions For Use
D10
[email protected] (USA)
[email protected] (EU)
[email protected] (JP)
-07-
5.0 DRONE DETAILS
6.0 TRANSMITTER DETAILS
Propeller B
Propeller B
Propeller A
Propeller A
HD Camera
Power Switch
Speed Switch/
Trimmer
Headless Mode
360°Flip
One Key Takeoff/
Landing
Null Button
Power Button
Built-in Phone Holder
Take Photo
(Short press)/
Circle Fly
(Long press)
Record Video
(Short press)/
Auto-Rotation
(Long press)
Emergency
Stop
-08-
Ascend
Descend
Rotate Left Rotate Right
Forward
Backward
Up
Left Right
Up
DownDown
Left Right
Left Joystick Right Joystick
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Fly to
Left
Fly to
Right
7.1 MODE 2 (Left hand throttle MODE 2 will be default setting.)
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
7.2 MODE 1
To enter MODE 1, turn on the transmitter while holding the “Speed
Switch” button. (Please do not release the “Speed Switch” button until
the transmitter is powered on.)
7.0 JOYSTICK MODE
Ascend
Descend
Rotate Left Rotate Right
Forward
Backward
Up
Left Right
Up
Down
Down
Left Right
Left Joystick Right Joystick
Fly to
Left
Fly to
Right
-09-
8.0 CHARGING
USB Adapter
(5V/2.0A)
Power Bank
Before charging, please check the contents of the “ Use of Battery”
section of the “ Safety Guidelines” carefully!
1) When the drone battery runs low, the indicator lights on the drone will
flash continuously.
2) Remove the battery and connect the USB charging cable to the battery.
3) Plug the USB charging cable into a USB charging port on power bank
or USB adapter (5V/2.0A ).
4) The red indicator light on the battery will turn on when the battery is
charging, and will turn green when the battery is fully charged.
5) Charging time: about 90 minutes.
-10-
9.0 INSTALLATION
9.2 Drone Battery
9.1 Propellers
A B
B A
HEAD
The drone will not fly unless the correct propeller is installed on the correct
motor shaft. See illustration above. An “A” or “B” is printed on the each
propeller. Lock the propeller to the motor shaft with screw rotating each
screw clockwise.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
2
1
Installation: Push the battery into the battery compartment at the rear of
the drone. Make sure the battery is in place to ensure that the battery is
jammed in the battery compartment. (Pic.1)
Removal: Press and hold the lock on the battery at the same time while
pulling backwards to remove the battery. (Pic.2)
Pic.2Pic.1
-11-
9.3 Propeller Guard
Installation: Line up the protruding points on the propeller guard with the
sunken grooves on the drone and insert them together. Tightly press both
sides of the propeller guard into place after the sunken grooves and
protruding points have completely interlocked.
Removal: Lightly pull on the clip on one of the ends of the propeller guard
outwards until it has separated from the inside of the drone, at which point
the propeller guard can be fully removed.
-12-
9.4 Transmitter Battery
3 x 1.5V AA
(Not included)
As shown above, insert the battery into the battery compartment. Please
pay attention to the positive and negative polarity of the battery to ensure
the correct installation of the battery.
Battery Cover
9.5 Phone Holder
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
21
As shown above, pull the phone holder down and insert the phone.
-13-
10.1 Download APP
10.0 OPERATION GUIDE
Scan the QR code, corresponding to either App Store™ or Google Play™
Store and download the Deerc FPV app for free.
Required Operating Systems: iOS 12.0 or later/Android 4.4 or later.
iOS Android APP on Google play
10.2 Connect to Wi-Fi
Connect your phone to the Wi-Fi network created by the drone. You can
check the drone’s status on the DEERC FPV App.
①Make sure to turn off Bluetooth, Mobile Data, and VPN. Enter your
phone’s Wi-Fi settings and click Wi-Fi to search for the Wi-Fi of the drone.
(Make sure to turn on the drone before going to the Wi-Fi settings on your
phone)
②Select the Wi-Fi network: DeercFPV-******.
③Wait for a couple of seconds for your phone to connect to the drone’s
Wi-Fi.
④Enter the DEERC FPV application.
> The connection between your phone and the drone is established
automatically.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Attention: The Wi-Fi network created by the drone does not access the
Internet.
-14-
10.3 Pairing
②Place the drone on a flat and level
surface with the head forward and
the tail towards the pilot.
① Press and hold the power button
to turn on the drone and the
indicator lights on the drone begins
to flash.
④Push the left joystick up then down
to pair the drone with the transmitter.
The indicator lights on the drone and
the transmitter will turn solid if the
drone is paired successfully.
③ Press the power button on the
transmitter to turn it on and you will
hear “Di Di”, then the indicator light
on the transmitter will flash.
HEAD
·All of the following operations on this manual takes MODE 2 for
example.
-15-
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
10.4 Calibrating the Gyroscope
Push the left and right joystick simultaneously to the lower left corner to
calibrate the gyro. When the indicator lights on the drone change from
flashing quickly to solid, it indicates that the calibration has been completed.
Tips:
To ensure a stable flight, we suggest that the pilot calibrates the
gyro every time after pairing the drone and after a crash.
10.5 One Key Takeoff/Landing
① Short press the One Key Takeoff/Landing button, the drone will
automatically take off and hover at 5 feet altitude.
②When the drone is flying, short press the same button again, the drone
will automatically land on the ground.
-16-
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
11.0 FUNCTION DETAILS
11.1 Emergency Stop
The Emergency Stop function can be only used in case of emergen-
cy during the flight to avoid any of damage or injury.
11.2 Speed Switch
This drone comes with 3 speed levels
(Low/Medium/High). Press the
Speed Switch button on the trans-
mitter to switch the speed.
“Di” indicates Low Speed, “Di Di”
indicates Medium Speed and “Di Di
Di” indicates High Speed.
(The Low Speed is default speed
mode.)
Press and hold the Emergency Stop
button for about 2 seconds, the
motors will stop immediately.
-17-
11.3 Trimmer Function
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
F/B Sideways Drift Trim: If the drone tends to drift forward, hold down the
“Speed Switch” button and do not release it while pushing the direction
joystick down to re-balance the drone. If the drone tends to drift backwards,
hold down the“Speed Switch” button and do not release it while pushing
the direction joystick up to re-balance the drone.
L/R Sideways Dip Trim: If the drone tends to drift left, hold down the
“Speed Switch” button and do not release it while pushing the direction
joystick right to re-balance the drone. If the drone tends to drift right, hold
down the “Speed Switch” button and do not release it while pushing the
direction joystick left to re-balance the drone.
Table of contents
Other Deerc Drone manuals
