Delco KING BRUTE PN 09301 A User manual

Manual Page 1
Pressure Washers
and Accessories
KING BRUTE
( PN 09301 A )
Operators Manual
and Parts Lists
Delco Pressure Washers LIT-KING-DEL
Rev1 11-07

LIMITED WARRANTY
At DELCO®CLEANING SYSTEMS, we distribute top quality industrial / commercial / personal pressure
washers that are designed for heavy-duty use, maximum reliability, durability, and long life. Our pressure
washers are built for all duty applications and steady use due to higher quality levels.
The manufacturer of this product agrees to repair or replace designated parts that prove defective within the
warranty period of one (1) year listed in the chart. Specific limitations/extensions and exclusions apply,
and are listed in the chart on page 3. This warranty covers defects in material and workmanship and not parts
failure due to normal wear; abuse; accidental damage; negligence; improper use, maintenance,
and storage. To make a claim under the terms of the warranty, all parts said to be defective must be available
or returned (if requested) to DELCO®CLEANING SYSTEMS designated Warranty Service Center for
warranty inspection. The judgments and decisions of the Warranty Service Center concerning the validity of
warranty claims are final.
These warranties pass through to the end user. As a factory authorized and trained Warranty Service Center
the factory will honor the terms of all component warranties and satisfy claims of the appropriate warranty
provisions.
Normal wear items include, but are not limited to, Valves and Seals, which are not covered by this warranty.
This Warranty replaces all other warranties, express or implied, including without limitation any warranties of
merchantability or fitness for a particular purpose and all such warranties are hereby disclaimed and excluded
by the manufacturer. The Manufacturer’s warranty obligation is limited to repair and replacement of defective
products as provided herein and the Manufacturer shall not be liable for any further loss, damages, or
expenses – including damages from shipping, accident, abuse, acts of God, misuse, or neglect. Neither is
damage from repairs using parts not purchased from the manufacturer or alterations performed by non-factory
authorized personnel. Failure to install and operate equipment according to the guidelines put forth in the
instruction manual shall void warranty.
This warranty does not cover the following: damage resulting from shipping (claims must be filed with freighter),
accident, abuse, act of God, misuse, or neglect. Neither is damage from repairs or alterations performed by
non-factory authorized personnel or failure to install and operate equipment according to the guidelines put
forth in the instruction manual.
The manufacturer will not be liable to any persons for consequential damage, for personal injury, or for
commercial loss.

LIMITED WARRANTY (cont)
Parts / Components Warranty Period and Details
High Pressure Pumps
Five (5) year limited manufactuer warranty on pump
workmanship and defects in material.
Lifetime on forged brass manifold.
Warranty does not apply to failures on other pump parts due
to:
•Freight damage
•Freeze damage
•Damage caused by parts or accessories not obtained
from / or approved by Delco
•Normal wear of moving parts or components affected
by moving parts.
Electric Motors (if applicable) One (1) year from date of first start up.
Burners (hot water machines) One (1) year from date of first start up.
Hot Water Burner Coil
(hot water machines)
Five (5) years from date of first start up.
Warranty only covers workmanship or defects of material.
Warranty does not apply to:
•Freeze Damage
•Over Pressure burst damage caused by improper
maintenance of safety devices.
Frame One (1) year from date of first start up.
Accessories Ninety (90) days. Includes tips, guns, wands,
injectors, unloaders, hose reel, brushes, foamers,
Engines Covered by engine manufacturer warranty. See engine manual.

Manual Page 4
IMPORTANT SAFETY PRECAUTIONS
IMPORTANT:
Please read the following instructions before installing and operating this equipment.
DANGER
THIS EQUIPMENT CAN BE HAZARDOUS TO OPERATOR SAFETY AND ONLY AUTHORIZED
PERSONNEL WHO HAVE READ AND UNDERSTAND THE INSTALLATION AND OPERATION
MANUAL SHOULD
BE PERMITTED TO OPERATE THIS EQUIPMENT. DO NOT LEAVE WAND UNATTENDED
WHILE EQUIPMENT IS RUNNING.
Failure to follow all cautionary warnings and procedures may result in serious or fatal injury and/or
property damage including, but not limited to: fire, severe burns, concussion from explosion,
electrocution, scalding, penetration by pressurized water, chemical reaction, asphyxiation, cuts,
contusions, laceration, and loss of body parts and/or life.
DO’S
1. ALWAYS WEAR SAFETY GLASSES, GOGGLES or FULL FACE SHIELD; GLOVES, and when
spraying acids WEAR RAIN GEAR. NEVER RUN ACIDS THROUGH THE PUMP ON THIS
EQUIPMENT.
2. USE ONLY THE SAME SIZE NOZZLE SUPPLIED WITH THIS EQUIPMENT.
3. CHECK YOUR BATTERY FOR WATER LEVELS AND MAINTAIN A GOOD CHARGE.
4. USE ¾" (inch) x 50' (foot) GARDEN HOSE FOR WATER SUPPLY-.
5. USE A CLEAN FUEL CAN FOR REFUELING UNIT.
6. USE CLEAN DIESEL FUEL OR KEROSENE. NO ADDITIVES. Fill fuel tank each evening. This
will help minimize condensation in fuel tank, and prolong fuel pump life.
7. Always follow chemical manufacturer’s recommendations in use of chemicals with this
equipment. Immediately after using chemical solutions through this equipment, flush thoroughly
with clear water.
8. Disconnect all electrical power before performing any maintenance on this equipment.
9. Make sure positive is always positive and negative is always negative to keep from shorting out.
10. When storing this equipment in freezing weather conditions, this equipment must be drained
thoroughly; and the plumbing system charged with a 50% solution of permanent type antifreeze.
Antifreeze should be used when the equipment is not in service for prolonged periods or is being
transported in freezing weather. NOTE: Antifreeze must be flushed out of equipment thoroughly
before any cleaning project begins. Failure to do so could result in damage to paint or chemical
attack on painted surfaces.
11. Use a water softener on your water system if it is high in mineral content (HARDNESS). Failure
to do so will result in lime build-up in plumbing systems.
12. Use only manufacturer approved components when replacing parts on this equipment. Failure
to do so may create operating conditions that are hazardous to personal health, safety, and will
void the warranty.
13. Use only recommended oil in pump.

Manual Page 5
14. Always cool down coil.
DO NOT’S
DO NOT - UNDER ANY CIRCUMSTANCES - POINT THE HIGH PRESSURE NOZZLE AT
YOURSELF, OTHER PEOPLE, OR ANIMALS!
1. DO NOT use an undersized discharge nozzle.
2. DO NOT disconnect the pressure hoses or wand while the equipment is HOT, PRESSURIZED or
RUNNING.
3. DO NOT operate this equipment without sufficient water supply to the pump.
4. DO NOT operate this equipment without proper ventilation or in a closed space.
5. DO NOT use any type of fuel other than # 2 diesel, kerosene or # 1 home heating oil.
6. DO NOT leave wand unattended while equipment is running.
7. DO NOT point the stream of water from nozzle toward any person or animal (including the
operator).
8. DO NOT touch exhaust stack, metal wand and hose on HOT WATER UNIT. THEY GET VERY
HOT!
9. DO NOT obstruct the exhaust stack.
10. DO NOT run engine or burner within 25 feet of flammable materials or dust.
11. DO NOT use this equipment around or near explosive environment of any kind. (Gas, paint,
solvents, etc.)
12. DO NOT screw the pop-off valve all the way in to prevent leaking or dripping.
13. DO NOT adjust the unloader-regulator valve (on trigger control units) to a pressure in excess of
200 PSI of equipments motor or pump rating.
14. DO NOT secure trigger gun in the open position (ON). Operate ONLY with your hand during
operation to prevent injury.
15. DO NOT allow air into the water system through soap valve or loose fittings.
16. DO NOT operate the machine if the water pressure drops or is low.
17. DO NOT continue to operate this machine if burner fails to shut off when trigger is released
(closed).
18. DO NOT continue to operate this machine if burner fails to light.
19. DO NOT smoke or operate this machine while filling or emptying fuel tank(s), or
connecting/disconnecting tanks and fittings.
20. DO NOT operate this machine if coil becomes clogged or soothed.
21. DO NOT alter machine from manufacturer’s design.
22. DO NOT attempt to pull beyond normal length.
23. DO NOT attempt to service this machine without first disconnecting the electrical service. Failure
to do so may cause severe or fatal electrical shock.
24. DO NOT BY-PASS ANY SAFETY DEVICE ON THIS MACHINE!
