Delfi 9-2200-001BFR User manual

ENGLISH
PTS for Blood Flow
Restriction System
Operator & Maintenance Manual
REF 9-2200-001BFR
delfimedical.com
Pat.:www.delfimedical.com/patents

WARRANTY
1WARRANTY
LIMITED TWO-YEAR WARRANTY (North America only)
SCOPE OF LIMITED WARRANTY
Delfi Medical Innovations Inc. (‘Delfi’) warrants the components of the PTS Personalized Tourniquet System for Blood
Flow Restriction (‘product’) from date of purchase as follows: PTS for BFR instrument and accessories (2 years), Easi-Fit
for BFR Reusable Cuffs (6 months), and rechargeable battery (90 days). During the warranty period, Delfi will repair or
replace, at its option, any product which is defective in materials or workmanship or which fails to meet the published
specification for that model. This Limited Warranty is made only to the original purchaser of the product and is
non-transferable. The remedies described in the Limited Warranty are the exclusive remedies for breach of warranty.
THIS WARRANTY SHALL NOT APPLY TO ANY PRODUCT WHICH HAS BEEN ALTERED, MODIFIED, DISASSEMBLED OR
SERVICED BY ANYONE OTHER THAN DELFI STAFF IN ANY WAY, OR WHICH HAS BEEN SUBJECTED TO MISUSE OR ABUSE.
DISCLAIMER OF IMPLIED WARRANTIES
The foregoing Express Limited Warranty is given in lieu of any and all other express or implied warranties. DELFI MAKES
NO OTHER WARRANTIES INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
LIMITATION OF REMEDIES
In no case shall Delfi Medical Innovations Inc. be liable for any special incidental or consequential damages whether
based on breach of warranty or other legal theory. Some states do not allow limitations on warranties or on remedies for
breach in certain transactions. In such states, the limits in this paragraph and the preceding paragraph do not apply.
WARRANTY CLAIMS
In the event of a warranty claim within the warranty period please take the following steps:
1. Notify Customer Service Department, Delfi Medical Innovations Inc. at 800-933-3022 or email [email protected]m.
Please provide details about the nature of the problem and include the product serial number. Upon receipt of this
information, Delfi will provide a date for service and a return shipping authorization.
2. Upon receipt of the shipping authorization, forward the equipment, freight prepaid, to the location specified in the
shipping authorization.
Your compliance with these steps will help ensure that you receive prompt warranty service for your product.
WARRANTY (Outside North America)
SCOPE OF WARRANTY
Please contact Delfi for warranty information at [email protected].
Unit Serial Number _________________
AC Power Supply Serial Number ________________

CONTENTS
2CONTENTS
1GENERAL INFORMATION ............................... 5
INTENDED USE.....................................................5
INDICATIONS FOR USE .........................................5
CONTRAINDICATIONS ..........................................5
WARNINGS ..........................................................6
PRECAUTIONS IN USE...........................................6
ADVERSE EFFECTS ................................................8
SPECIFICATIONS...................................................8
GENERAL DEVICE FUNCTION ..............................10
EN 60601-1 CLASSIFICATION...............................11
EMISSIONS/IMMUNITY......................................11
2OPERATING INSTRUCTIONS ......................... 12
INITIAL INSPECTION ...........................................12
FEATURES ..........................................................12
TOUCHSCREEN BUTTONS AND ICONS ............................18
INITIAL SETUP ....................................................24
TESTS AND CHECKS ............................................24
AUTOMATIC DIAGNOSTIC AND CALIBRATION CHECKS...25
MANUAL TESTS AND CHECKS.........................................27
OPERATION .......................................................29
SETTINGS...........................................................37
STATS MENU..................................................................37
PROTOCOLS MENU ........................................................37
LEAK TEST ......................................................................43
SYSTEM DEFAULTS MENU..............................................46
PERSONALIZED TOURNIQUET PRESSURE (PTP) ...48
ALARM CONDITIONS..........................................48
PRESSURE ALARMS........................................................48
ALARM/WARNING COLORS AND AUDIBLE TONES .........49
ALARM CONDITION AND ERROR CODE TABLES..............49

CONTENTS
3CONTENTS
ELECTROMAGNETIC COMPATIBILITY (EMC)
GUIDANCE TABLES.............................................59
3BFR CUFF UTILIZATION.................................63
PRODUCT DESCRIPTION..................................... 63
UTILIZATION......................................................63
CUFF INSPECTION BEFORE USE ......................................63
CUFF SIZE .......................................................................63
APPLICATION .................................................................64
PRESSURE SETTING ........................................................66
INFLATION TIME ............................................................66
REMOVAL ......................................................................67
CLEANING ......................................................................67
STORAGE .......................................................................67
4MAINTENANCE.............................................68
GENERAL MAINTENANCE INFORMATION ...........68
PERIODIC MAINTENANCE...................................68
CALIBRATION.....................................................69
LEAK TESTING ................................................................72
BATTERY TESTING AND REPLACEMENT .............. 72
BATTERY TESTING ..........................................................73
BATTERY PACK REPLACEMENT.......................................73
INTERNAL HARDWARE SERVICING ..................... 75
TROUBLE SHOOTING GUIDE...............................75
TROUBLESHOOTING.......................................................75
REPLACEMENT PARTS........................................77
BFR CUFFS......................................................................77
MATCHING LIMB PROTECTION SLEEVES (MLPS).............77
MATCHING LIMB PROTECTION SLEEVES (MLPS)
DISPOSABLE...................................................................77
ACCESSORIES .................................................................78
CONTACT INFORMATION...................................78

CONTENTS
4CONTENTS
5WARNINGS, CAUTIONS & SYMBOLOGY..... 79
WARNINGS, CAUTIONS & SYMBOLOGY ..............79

GENERAL INFORMATION
5GENERAL INFORMATION
1
GENERAL INFORMATION
CAUTION: United States Federal law restricts this device to sale by or on the order of a physician or physician’s
designated licensed healthcare practitioner
NOTES: Use this tourniquet system according to the policies in your practice setting. The following information on
intended use, precautions, contraindications, and adverse effects are offered as a guide to assist in this process
INTENDED USE
This device is intended to be used only with a Delfi BFR Tourniquet Cuff by a physician or physician’s designated licensed
healthcare practitioner to preoperatively and/or postoperatively exert enough pressure on the arterial blood flow in a
patient’s extremity to reduce or totally occlude blood flow into the limb.
INDICATIONS FOR USE
This device is indicated for use on patients for whom a physician or physician’s designated licensed healthcare
practitioner has indicated preoperatively and/or postoperatively blood flow restricted therapy.
The target treatment group shall be drawn from those patients who require or may require perioperative procedures to
affect the structure or function of limbs and/or to treat or mitigate diseases associated with limb anatomy or physiology.
A physician or physician’s designated licensed healthcare practitioner may indicate treatment with the Delfi PTS for BFR
for patients who may be unable to withstand the stresses of high load therapies (e.g. persons recovering from injury,
persons with chronic health conditions, or persons suffering from other musculoskeletal conditions).
NOTES: Physician or physician’s designated licensed healthcare practitioner include but not limited to: physiotherapists
and surgeons, physiotherapy clinics, sports teams with resident physiotherapists/athletic trainers/physicians.
CONTRAINDICATIONS
Delfi recommends that users regularly review published medical literature for factors that warrant careful consideration
before prescribing blood flow restriction techniques. The current list of contraindications has been developed through
current research on blood flow restriction therapy, as well as through the well-established risks for tourniquet use in
surgery which are also contraindicated for use in blood flow restriction. The listed contraindications are:
Cardiovascular disease:
•Unstable and/or severe hypertension
•Compromised vascular circulation (e.g. peripheral vascular disease)
•Hypercoagulable states (blood clotting disorders)
•Varicose veins in the indicated limb for BFR intervention
•Atherosclerotic vessels causing poor blood circulation
•IV drug use in the indicated limb for BFR intervention
Musculoskeletal injury:
•Recent muscle trauma or crush injuries
•Postsurgical excess swelling
•Open fractures
•Skin graft in which all bleeding points must readily be distinguished
•Secondary or delayed procedures after immobilization
•Post-traumatic lengthy hand reconstruction

GENERAL INFORMATION
6GENERAL INFORMATION
1
•Direct peripheral nerve injury
Other factors:
•Uncontrolled diabetes mellitus
•Sickle cell disease or trait (relative contraindication, see Precautions in Use under Section 1 General Information)
WARNINGS
This device is not indicated for use on patients during surgery.
Caution should be exercised when prescribing BFR therapy for patients with compromised cardiac function including
silent myocardial ischemia or left ventricular dysfunction.
If serious adverse effects are seen while performing BFR therapy, the intervention should be stopped. The physician or
physician’s designated practitioner shall use their discretion throughout use of the BFR therapy to identify any serious
adverse effects which may require the patient to stop the therapy. Such serious adverse effects include but are not
limited to excessive limb swelling or signs of nerve injury.
This product is subject to wear and deteriorates with use. It is essential to inspect this device before each use. Refer to
Utilization under Section 3 BFR Cuff Utilization. If the cuff fails to pass inspection, it is no longer usable and must be
discarded. Use of a damaged cuff could result in one or more of the following events: loss of cuff pressure; release of the
cuff from around the patient’s limb; movement of the cuff on the patient’s limb; excessive leakage of the cuff pressure; or
pinching of tissue under the cuff.
The cuff should only be connected to a tourniquet instrument known to be in an operable condition. Refer to Section 4
Maintenance for information on testing and maintenance.
PRECAUTIONS IN USE
Delfi recommends that users regularly review published medical literature for factors that warrant careful consideration
before performing blood flow restricted techniques. The following clinical conditions have been cited in publications as
factors that should be carefully considered before performing blood flow restricted therapy and/or for which there is not
sufficient clinical evidence to be a listed contraindication:
Cardiovascular conditions:
•Coronary heart disease
•Existing or at increased risk for venous thromboembolism
•At increased risk of hemorrhagic stroke
•At increased risk of exercise induced rhabdomyolysis
•At increased risk of atrial fibrillation or heart failure
•Prior use of medications known to increase blood clotting risk
•Induration/Marfan syndrome
•Vascular endothelia dysfunction
•Prior Hemophilia
•Cardiopulmonary conditions
•Silent myocardial ischemia
•Left ventricular dysfunction

GENERAL INFORMATION
7GENERAL INFORMATION
1
Musculoskeletal conditions:
•Existing compartment syndrome
•Open soft tissue injuries
•Extremity infections
Patient considerations:
•Pediatric patients
•History of smoking
•Pregnancy
•Dehydration
•History of cancer
System Handling:
•The tourniquet system must be well calibrated and in operable condition. Accessories should be checked regularly
for leaks and other defects.
•The tourniquet cuff must never be punctured; therefore, any sharp objects which may be used near the system
must be handled with care.
•When cleaning, carefully follow the cleaning and assembly instructions for the tourniquet cuff and instrument.
Patient Considerations:
•Prolonged ischemia may lead to temporary or permanent damage to tissues, blood vessels, and nerves. Tourniquet
paralysis may result from either excessive or insufficient pressure. Prolonged tourniquet time can also produce
changes in the coagulability of the blood with an increase in clotting time.
•When using a tourniquet on patients with sickle-cell disease or trait, severe post-use pain may result in the applied
limb which may be caused by sickling of cells. Test for hemoglobin type and level before using a tourniquet on
patients with sickle cell disease or trait. When the tourniquet is used for these patients, closely monitor the patient’s
PO2 and pH since sickling is dependent on oxygen tension and pH.
Application and Use:
•Select the proper cuff size to allow for the overlap recommended by Delfi Medical Innovations Inc. Refer to the Cuff
Size guide under Section 3 BFR Cuff Utilization. Too much or too little overlap may cause cuff rolling and telescoping,
unexpected release of the cuff from the limb, and/or undesired pressure distribution on the limb.
•The skin under the tourniquet cuff may be protected from mechanical injury by smooth, wrinkle free application of
the cuff Follow the Delfi’s recommendation for limb protection material under the cuff; refer to the Application
guide under Section 3 BFR Cuff Utilization. In general, a limb protection sleeve designed specifically for the cuff
provides the best protection.
•The tourniquet cuff must be applied in the proper location on the limb. Tourniquet pressure and the time the
tourniquet is inflated on the limb should both be minimized. There is additional potential risk to superficial nerves
in unprotected areas; never apply a tourniquet over an area where major nerves may be directly compressed
against bone (e.g. peroneal nerve near the proximal head of the fibula). Never apply a tourniquet over the joints of
the limb. Do not readjust an already inflated cuff by rotating it because this produces shearing forces which may
damage the underlying tissue.
•Limb Occlusion Pressure (LOP) is defined in the medical literature as the minimum pressure required to stop the
flow of arterial blood into the limb distal to the tourniquet cuff, at a specific time in a specific tourniquet cuff applied
to a specific patient’s limb at a specific location. For each patient, the tourniquet pressure should be set to a
percentage of the LOP as recommended by the supervising physician or physician’s designated licensed health care
practitioner.

GENERAL INFORMATION
8GENERAL INFORMATION
1
•Observe the cuff during inflation and periodically while inflated to ensure the cuff is not migrating on the limb. If the
tourniquet cuff migrates on the limb during use, deflate and reapply the cuff. Inflate the cuff and observe for
migration. If migration persists, replace the cuff.
•In case of incomplete or improper inflation, the tourniquet cuff must be fully deflated before cuff reinflation.
•The deflated cuff and any underlying limb protection material should be completely removed as soon as tourniquet
pressure is released and the prescribed blood flow restriction therapy protocol is complete.
ADVERSE EFFECTS
Possible adverse effects which may occur from performing blood flow restriction techniques using a pneumatic
tourniquet include bruising at the site of the cuff, numbness, cold feeling, venous thrombus, fainting/dizziness, delayed
onset muscle soreness, increased perceived exertion/pain/discomfort, stiffness, weakness, skin discoloration, exercise-
induced rhabdomyolysis. Symptoms of tourniquet paralysis are motor paralysis and loss of sense of touch, pressure, and
proprioceptive responses.
SPECIFICATIONS
AC Power Adapter
Use only supplied AC adapter / power cord assembly, Delfi
(REF 7-2200-020)
~ AC Power Mains Line Voltage Range
100-240 ~ (AC), 50/60 Hz. Auto switching
Line Current
175 mA RMS @ 120V ~ (AC) typical, Delfi (REF 7-2200-020)
Input Power
100 watts maximum (REF 7-2200-020)
AC Power Plug (North America)
Hospital grade, 3 prong straight blade, 15 amp
Power Cord
Medical grade NEMA 5-15P, type SJT, AWG 18, 2.45 m (8 ft)
or international equivalent
Battery Type
15.2V Lithium-ion internally protected 3000 mAh pack. Use
only Delfi (REF 7-2200-046) battery pack
Battery Discharge Time
10.0 hours (typical)
Battery Recharge Time
3.0 hours (typical)
Limb Occlusion Pressure Measurement Range
90 –300 mmHg
Personalized Tourniquet Pressure Calculation
Range
30% - 140% of LOP, User Adjustable
Cuff Pressure Range
20 –350 mmHg, 1 mmHg increments
Cuff Pressure Accuracy
± 2 mmHg

GENERAL INFORMATION
9GENERAL INFORMATION
1
Pressure Regulation
± 6 mmHg of set-point (10-second average under non-transient
conditions without external leaks
Inflation Timer Set-point Range
1-30 minutes, 1-minute increments
Lockout Timer Set-point Range
1-10 minutes, 1-minute increments
Timer Accuracy
0.1% of elapsed time
Inflation Rate
34-inch cuff applied to a 30-inch thigh inflates to 350 mmHg in less
than 5 seconds
Deflation Rate
34-inch cuff applied to a 30-inch thigh deflates to less than 10 mmHg in
less than 10 seconds
Internal Diagnostics
Program, memory, watchdog timer, transducer calibration, improper
valve actuation
Display
Color 480x800 LCD Backlit
Status Indicator
Blue –Charging
Red Constant –Technical alarm
Red Flashing –High priority alarm
Yellow Flashing –Medium priority alarm
Yellow Constant –Low priority alarm
Controls
640 mm x 1080 mm touch screen and ON/STANDBY button located on
the front panel
Size
Height: 180 mm (7.0 in)
Width: 120 mm (4.7 in)
Depth: 110 mm (4.3 in)
Weight: 1.263 kg (44.5 oz)
Indicated Tourniquet Cuffs for Use
(provided with system unless indicated)
PTS BFR Easi-Fit 18" Tourniquet Cuff (RED)
PTS BFR Easi-Fit 24" Tourniquet Cuff (GREEN)
PTS BFR Easi-Fit 34" Tourniquet Cuff (BLUE)
PTS BFR Easi-Fit 44" Tourniquet Cuff (BROWN) Order separately
Indicated Matching Limb Protection Sleeves
(MLPS) for Use
(provided with system unless indicated)
MLPS - for PTS BFR Easi-Fit 18" reusable cuff (RED)
MLPS - for PTS BFR Easi-Fit 24" reusable cuff (GREEN)
MLPS - for PTS BFR Easi-Fit 34" reusable cuff (BLUE)
MLPS - for PTS BFR Easi-Fit 44" reusable cuff (BROWN) Order separately

GENERAL INFORMATION
10 GENERAL INFORMATION
1
PTS Roll Stand (Optional)
Height: 127.6 cm (50.25 in)
Pole Diameter: 3.175 cm (1.25 in)
Base Diameter: 55.88 cm (22 in)
Environmental Conditions
Operating temperature: 10 °C to 40 °C (50 °F to 104 °F)
Storage temperature: 20 °C to 40 °C (-4 °F to 104 °F)
Relative humidity: Max 80 % non-condensing
GENERAL DEVICE FUNCTION
The Personalized Tourniquet System for Blood Flow Restriction (PTS for BFR) and Accessories provide temporary
reduction of arterial blood flow for a predetermined length of time. The system is designed to assist a trained and
licensed physician or physician’s designated healthcare practitioner in the treatment for the structure and function of a
patient’s limb(s) by reducing blood flow to a patient’s extremities combined with or without muscle activation, to
stimulate biological processes which reduce muscular atrophy and increase muscle strength.
The Delfi PTS for BFR has the capability of determining a patient’s Personalized Tourniquet Pressure (PTP) as a
percentage of the patient’s Limb Occlusion Pressure (LOP) by automatically measuring LOP. The PTS for BFR maintains
the cuff pressure at the pressure set-point for the time period(s) required for a BFR therapy session.
The Delfi PTS for BFR has the capability of measuring the patient’s Limb Occlusion Pressure (LOP) and recommend a
Personalized Tourniquet Pressure (PTP) based on the LOP for use during a BFR therapy session.
LOP is the lowest pressure required for a specific cuff to stop the flow of blood in the extremity of a specific patient at a
specific time and location. It is personalized to the patient and accounts for patient’s physiology, limb characteristics, cuff
properties and cuff application. PTP is a personalized pressure that is a percentage of the LOP. The percentage of LOP
used for PTP depends on the BFR therapy prescribed by the physician or physician’s designated licensed healthcare
practitioner.
There are two types of BFR therapy: standard “BFR”, and “Cyclic BFR”.
Standard BFR therapy involves restricting arterial blood flow into an extremity of a patient while the patient performs
low-intensity movements (aerobic or resistive). BFR rehabilitation may involve the patient performing exercise
repetitions for a number of repetition sets (sets) for strength gain, or may involve the patient performing walking or
cycling exercise for a longer duration for increasing the patient’s endurance. Owens Recovery Science (ORS), a leader in
BFR rehabilitation, recommends strength protocols with 30 reps, 15 reps, 15 reps, and 15 reps (REPs) with 30 seconds
rest periods in between (Rest Time). Typically, strength protocols require 6-8 minutes and endurance protocols require
15-20 minutes of inflated time (Inflation Time). ORS recommends setting PTP to 50% or 80% of LOP when performing BFR
rehabilitation on an upper limb or lower limb, respectively.
Cyclic BFR (C-BFR) therapy involves the cyclical application of arterial restriction or occlusion, and reperfusion of a
patient’s extremity. PTP, duration at which the cuff is inflated (Inflated Time) and deflated (Deflated Time), and the
number of inflation cycles (Inflation Cycles) may be adjusted based on the prescription of the physician or physician’s
designated licensed healthcare practitioner. During C-BFR, the patient may perform low-intensity exercise or may remain
inactive.
Delfi PTS for BFR provides twelve selectable BFR protocols for BFR or C-BFR therapies. Six of these protocols are based on
ORS recommendations with restricted adjustment capabilities. The remaining six protocols are fully customizable within
the instrument’s limits.

GENERAL INFORMATION
11 GENERAL INFORMATION
1
EN 60601-1 CLASSIFICATION
Note: This device is not suitable for use in the presence of flammable anesthetic or gases.
Medical Equipment with respect to electrical shock, fire and mechanical hazards and electromagnetic compatibility only.
In accordance with CAN/CSA –C22.2 No. 60601:14, ANSI/AAMI ES60601-1:2005 and A2 (R)2012 and A1. Medical
Equipment with respect to electromagnetic compatibility only. In accordance with ANSI/AAMI/IEC 6060-1-2:2014.
Type of protection against electric shock
Class I or Internally Powered Equipment*
Degree of protection against electric
shock
Type B applied part
Mode of operation
Continuous operation
*When the unit is operating on backup battery, the type of protection against electric shock changes to
internally powered equipment
EMISSIONS/IMMUNITY
The Delfi PTS for BFR complies with EMC criteria set forth in EN 60601-1-2. The user of this device should be aware that
precautions should be taken in regards to EMC. The device should be installed and used according to the EMC
information provided in the instructions for use. See Electromagnetic Compatibility under Section 2 Operating
Instructions.
Cable
Maximum length
~ AC Power Mains power cord
2.45 m (8 ft)
WARNING: use of an ~ AC Power Mains power cord with a length other than those specified may result in increased
emissions and decreased immunity

OPERATING INSTRUCTIONS
12 OPERATING INSTRUCTIONS
2
OPERATING INSTRUCTIONS
INITIAL INSPECTION
Unpack the PTS for BFR upon receipt and inspect the unit for any obvious damage that may have occurred during
shipment. We recommend that this inspection be performed by a qualified biomedical engineer or other person
thoroughly familiar with electronic medical devices. If the unit is damaged, notify the carrier and Delfi immediately. If
the initial inspection results are satisfactory, a functional and calibration check should be performed after a 5-hour
charge. The attention label covering the pressure/time display window may be removed and discarded after the initial 5-
hour charge.
FEATURES
The PTS for BFR has a variety of features, as described below:
FRONT
1
2
3
4
To Cuff
5
Metal connector
to Instrument

OPERATING INSTRUCTIONS
13 OPERATING INSTRUCTIONS
2
BACK
10
9
6
11
To Instrument
7
8
12

OPERATING INSTRUCTIONS
14 OPERATING INSTRUCTIONS
2
MAIN SCREEN –DEFLATED & PTP NOT DETERMINED
PRESSURE
Button / Indicator
TIME
Button / Indicator
PTP Button
Power Status
Indicator
PROTOCOL
Button / Indicator
REPs Indicator
INFLATE
Button
SETTINGS
Button

OPERATING INSTRUCTIONS
15 OPERATING INSTRUCTIONS
2
MAIN SCREEN –INFLATED & PTP DETERMINED
PRESSURE
Button / Indicator
TIME
Button / Indicator
DEFLATE Button
Power Status
Indicator
PROTOCOL
Button / Indicator
REPs Indicator
REST TIME
Indicator
PTP Indicator
LOP Indicator

OPERATING INSTRUCTIONS
16 OPERATING INSTRUCTIONS
2
Feature
What it does
1
Touch Screen GUI
Touchscreen based graphical user interface (GUI) for interacting with
and controlling most of the PTS for BFR’s functions
2
Status Indicator
Indicates the status of the PTS for BFR
Blue –Charging
Red Constant –Technical alarm
Red Flashing –High priority alarm
Yellow Flashing –Medium priority alarm
Yellow Constant –Low priority alarm
3
ON/STANDBY Button
Turns the unit ON or sets the unit to STANDBY (powered off)
CAUTION: Ensure cuff is fully deflated and has been removed from
the patient as well as the Matching Limb Protection Sleeve (MLPS)
prior to setting the unit to STANDBY
NOTE: This button will not set the unit to STANDBY when the cuff
pressure is at a non-zero value
NOTE: During STANDBY, the power to the PTS for BFR and all
instrument functions (i.e. inflation, deflation, etc.) are OFF but power
continues to supply the battery charging circuitry anytime ~ AC
Power Mains is present
4
Hose Connector
The PTS for BFR hose assembly (see below) leading to the Delfi Easi-Fit
BFR Tourniquet Cuff plugs in to the PTS for BFR at the hose connector.
The hose connector makes an audible ‘click’ when properly connected
5
Hose Assembly
A PTS for BFR hose assembly is supplied with each PTS for BFR. The
male metal connector on the hose plugs into the female metal
Positive Locking Connector on the PTS for BFR (see above). The other
end of the hose has a male quick-connect connector that plugs into a
female quick-connect connector on the Easi-Fit BFR Cuff. The PTS for
BFR is designed, tested, and for use with only with Delfi Easi-Fit BFR
Tourniquet Cuffs having female quick-connect connectors. Use the
supplied PTS for BFR hose assembly only
To engage the Positive Locking Connector on the PTS for BFR, fully
depress and then release the metal locking button. Carefully slide
the connectors together. An audible ‘click’ can be heard when the
connectors are properly connected and locked. To disengage, fully
depress and hold the metal locking button. Carefully separate the
connector while holding the metal locking button. Excessive force is
not required. To prevent O-ring damage the metal locking button

OPERATING INSTRUCTIONS
17 OPERATING INSTRUCTIONS
2
Feature
What it does
must always be in the open position before connectors are engaged
or disengaged
To engage the quick-connect connector to the Easi-Fit BFR cuff
carefully slide the connectors together. An audible ‘click’ can be
heard when properly connected and locked. To disengage carefully
separate the connectors by pulling them apart. Excessive force is not
required
6
Power Receptacle
The power receptacle is located on the left of the battery
compartment from a rear view of the PTS for BFR. The PTS for BFR is
designed for use with the supplied AC power supply (see below) only;
do not use any other type of connection to AC power
7
~ AC Power Supply
An AC power supply adapter is supplied with every PTS for BFR. It is a
sealed unit designed specifically for the PTS for BFR. Contact Delfi if
your power supply needs service or replacement. Plug the connector
on the AC power supply cord into the AC power receptacle on the PTS
for BFR (see above) and plug the AC power cord into a power outlet
(see below) whenever using the unit where AC power is easily
accessible
To isolate the PTS for BFR from external AC power disconnect the AC
power supply adapter from the power outlet
8
~ AC Power Cord
An AC power cord with a hospital grade plug is supplied with every
PTS for BFR. Plug the socket end of the cord into the AC power
supply and the plug end into an easily accessible AC power outlet
9
Information Port
The information port is used for servicing purposes only
10
Pole Mount Bracket Attachment
Points
Used to secure the PTS for BFR to a Delfi PTS Roll Stand (REF 9-2200-
550). Use only Delfi (REF 9-2200-008) bracket
11
Battery Compartment
Compartment that holds the PTS for BFR battery
12
Pole Mount Bracket
Used to secure the PTS for BFR to a Delfi PTS Roll Stand
(REF 9-2200-550)

OPERATING INSTRUCTIONS
18 OPERATING INSTRUCTIONS
2
TOUCHSCREEN BUTTONS AND ICONS
Various colored buttons and icons are used in the PTS for BFR and described below.
Button/Indicator
Title
Description
PROTOCOL
Button / Indicator
Indicates the protocol currently being used
The selected protocol establishes the protocol
parameters when the cuff gets inflated. Protocol
parameters include BFR or C-BFR mode, PTP, REPs,
pressure and time set-points
Touch to change protocol
NOTE: If a pressure or battery low alarm is present,
the PROTOCOL indicator will be replaced by the
Warning indicator
Warning Indicator
Indicates a warning condition or system failure
Alarm Paused Indicator
Indicates an alarm is paused
High Pressure Warning
Indicator
Indicates a high-pressure warning (cuff pressure is
more than 15 mmHg greater than the pressure set-
point)
Low Pressure / Cuff Leak
Warning Indicator
Indicates a low-pressure warning (cuff pressure is
more than 15 mmHg lower than the pressure set-
point)
OR
Indicates a cuff leak warning (unit has to
continuously pump to maintain pressure for more
than 7-seconds, even if the unit is maintaining the
cuff pressure within 15 mmHg of the pressure set-
point)
Cuff Not Deflated Warning
Indicator
Indicates a cuff-not-deflated warning (user attempts
to set the unit to STANDBY when the cuff pressure is
at a non-zero value)
OR
Indicates a cuff-not-deflated warning (unit is
