Edge 600 Series
The Dell EMC SD-WAN Edge 600 Series (610, 620, 640, and 680) is a purpose-built, high-
value uCPE platform to host virtual networking functions (VNFs).
For detailed installation information, including instructions for the wall mount and optional
dual rackmount tray installation, see the Dell EMC SD-WAN Edge 600 Series Installation
Guide at www.dell.com/support.
After unpacking the Edge 600 Series, inspect the device and immediately report any
damage to your Dell EMC sales representative.
Topics:
• Installation instructions
•Specications
Installation instructions
Information icon denitions:
• The Warning icon signals information about hardware handling that could result in injury.
• The Caution icon signals information about situations that could result in equipment
damage or lost of data.
• The Note icon signals important operational information.
Install the device
WARNING: To avoid electrostatic discharge (ESD) damage, wear grounding wrist
straps when handling this equipment.
WARNING: This device has optical transceivers, which comply with the limits of
Class 1 laser radiation. When working with optical bers, follow all warning labels
and always wear eye protection.
4 Edge 600 Series

WARNING: When no cable is connected, visible and invisible laser radiation may be
emitted from the aperture of the optical transceiver ports. Avoid exposure to laser
radiation and do not stare into open apertures.
Install the device in an area that meets the following safety requirements:
• Near a properly grounded AC power outlet.
• In a temperature-controlled room with a continuous temperature range from 0°C to
40°C (32°F to 104°F)
• In a dry, clean, and well-ventilated room away from heat sources such as hot air vents or
direct sunlight
• Away from severe electromagnetic noise
• Away from direct view within the workplace
The numbers one through four in the following gure correspond to the setup procedure:
1 Connect the power adapter to the AC power outlet. Connect the other end of the
power adapter to the power port on the Edge. When the Edge powers ON, verify that
the status LED on the front of the Edge is on.
NOTE: Connect the device to a properly wired earth-ground AC power
outlet.
2 Connect one of the default WAN ports (GE3-6 or SFP1-2) to an available Internet
connection. SFP modules are not included.
Edge 600 Series 5

a 1—SFP 1-2 b 2—GE 3-6
NOTE: By default, the Edge gets a DHCP IP address from the ISP on the
WAN uplink. When the WAN connection is fully operational, the cloud LED
on the front of the Edge is green.
3 If you received an email from your IT administrator, follow the instructions in the email
to complete the Edge activation.
If you did not receive an email, request the setup instructions from your IT
administrator or nd more information at the Dell EMC support site at www.dell.com/
support.
4 Connect local devices such as computers and switches to the GE1 or GE2 ports, or
through the Edge WiFi.
• GE1 or GE2 ports
6Edge 600 Series

After following these instructions, if you are still unable to activate the Edge, contact your IT
administrator or open a Dell EMC support request.
Specications
Table 1. Edge 600 Series specications
Feature Specication
Size 8.1 in x 7.9 in x 2.0 in (W x D x H)
20.8 cm x 20.0 cm x 5.20 cm (W x D x H)
Weight, depending on the product
NOTE: Platform weight does not
include power adapter weight.
2.87 lb to 3.11 lb
1.30 Kg to 1.41 Kg
AC power input 100 VAC–240 VAC, 50/60 Hz
AC maximum current draw per system 100 VAC: 2.0 A
240 VAC: 1.0 A
Typical power consumption 16 core: 40 W
8 core: 35 W
4 core: 20 W
2 core: 16 W
Maximum power consumption 16 core: 50 W
8 core: 45 W
4 core: 30 W
2 core: 26 W
RoHS information Go to: Restricted Material Compliance.
Edge 600 Series 7

Table 2. Edge 600 Series temperatures
Feature Specication
Operating temperature 0°C to 40°C (32°F to 104°F)
Storage temperature –40°C to 70°C (-40°F to 158°F)
Operating relative humidity 5% to 85% (RH), non-condensing
continuously
5% to 90% (RH), non-condensing short
term (< 1% of operational hour per year)
Storage relative humidity 5% to 90% (RH)
Operating altitude Maximum: 10,000 feet (3,048 meters)
No performance degradation up to 3,117 feet
(950 meters)
