Dell EMC Edge Gateway 3200 User manual

Dell EMC Edge Gateway 3200
Service Manual
Regulatory Model: EGW-3200
Regulatory Type: EGW-3200-NA
August 2022
Rev. A00

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid
the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2022 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc. or its
subsidiaries. Other trademarks may be trademarks of their respective owners.

Preface......................................................................................................................................... 4
Part I: Installation procedure for 4G and 5G LTE modules..............................................................5
Part II: Installation procedure for 2x RS-422/485 uFM module.................................................... 23
Part III: Installation procedure for 2x RS-232 uFM module...........................................................35
Part IV: Installation procedure for 2x GbE with PoE out...............................................................47
Part V: Installation procedure for 2x GbE LAN............................................................................. 62
Part VI: Installation procedure for 2x Canbus uFM module...........................................................76
Part VII: Installation procedure for 8x DI/O uFM module............................................................. 90
Contents
Contents 3

Table 1. Expansion modules overview
Module Interface details Reference link
M.2
WiFi Intel WiFi AX210 M.2 2230 https://www.intel.com/content/www/us/en/products/docs/
wireless/wi-fi-6e-ax210-module-brief.html
4G Sierra EM7565 M.2 3042 https://www.sierrawireless.com/iot-solutions/products/em7565/
5G Thales MV31-W M.2 3042 https://www.thalesgroup.com/en/markets/digital-identity-and-
security/iot/iot-connectivity/products/iot-products/mv31-w-ultra-
high
mPCIe
Isolated RS-422
and RS-485
EMP2-X4S2 https://www.innodisk.com/en/products/embedded-peripheral/
communication/emp2-x4s2
Isolated RS-232 EMP2-X2S1 https://www.innodisk.com/en/products/embedded-peripheral/
communication/emp2-x2s1
Isolated GbE
with PoE out
EMPL-G2P1 https://www.innodisk.com/en/products/embedded-peripheral/
communication/empl-g2p1
Isolated GbE
LAN
EMPL-G202 https://www.innodisk.com/en/products/embedded-peripheral/
communication/empl-g202
Isolated Canbus EMUC-B202 https://www.innodisk.com/en/products/embedded-peripheral/
communication/emuc-b202
I2C
Isolated DI/O Internal I2C wafer N/A
Preface
4 Preface

Installation procedure for 4G and 5G LTE
modules
About this task
Installation of the 4G/5G expansion module requires an additional heat sink to ensure performance.
Use the paddle-style antennas that are included with the expansion kit. The following figure shows the dimensions of the
antenna.
42.0±0.3
184.0±1.0
38.5±0.5
210.0±1.0
13.0±0.3
13.0 ±0.3
A
A
Figure 1. 4G/5G/LTE antenna (dimensions in mm)
Table 2. Expansion module packing list - 4G
Item Quantity Notes
Screw M2.5 x 6L 2 Torque required: 3.5 kgf.cm
Screw M3 x 4L 1 Torque required: 3.5 kgf.cm
Screw M2.5 x 2.5L 1 Torque required: 3.5 kgf.cm
Standoff M2.5 H3.2 1 Torque required: 4.5 kgf.cm
Bracket 1 -
4G M.2 1 -
SMA cable 3 -
Antenna 2 -
I
Installation procedure for 4G and 5G LTE modules 5

Table 2. Expansion module packing list - 4G (continued)
Item Quantity Notes
4G label 1 -
4G heat sink 1 -
Thermal pad 1 -
Table 3. Expansion module packing list - 5G
Item Quantity Notes
Screw M2.5 x 6L 2 Torque required: 3.5 kgf.cm
Screw M3 x 4L 1 Torque required: 3.5 kgf.cm
Screw M2.5 x 2.5L 1 Torque required: 3.5 kgf.cm
Standoff M2.5 H3.2 1 Torque required: 4.5 kgf.cm
Bracket 1 -
5G M.2 1 -
SMA cable 4 -
Antenna 4 -
5G label 1 -
5G heat sink 1 -
Thermal pad 1 -
Steps
1. Remove the five screws from the rear panel using a #2 screwdriver.
Figure 2. Rear panel screw locations
2. Remove the rear panel.
6Installation procedure for 4G and 5G LTE modules

Figure 3. Remove rear panel
3. Remove the four screws from the top panel using a #2 screwdriver, then open the top panel.
Figure 4. Top panel screws removed
Installation procedure for 4G and 5G LTE modules 7

Figure 5. Open top panel
4. Replace the long, narrow thermal pad, as shown in the following figure.
Figure 6. Thermal pad replacement
5. Disconnect cables from the inside of the top panel. This includes disconnecting the switch cable and power cable from their
wire mounts, and disconnecting the switch cable and power cable connectors.
8Installation procedure for 4G and 5G LTE modules

Figure 7. Switch cable wire mount
Figure 8. Switch cable connector and power cable wire mount
Installation procedure for 4G and 5G LTE modules 9

Figure 9. Power cable connector
6. Remove the four rubber inserts from the antenna holes, then assemble the four antenna connectors using an 8 mm hex
socket.
10 Installation procedure for 4G and 5G LTE modules

Figure 10. Antenna locations (ANT3 through ANT6)
7. Secure the antenna cables in the wire mount on the main board. Use the following figure and table to route the cables to the
correct antenna connectors.
Installation procedure for 4G and 5G LTE modules 11

Figure 11. Antenna cables in wire mount
Table 4. Antenna labeling
Antenna Indicator
ANT3 White label
ANT4 Red label
ANT5 (5G only) No label
ANT6 No label
8. Install the thermal pad, then use a 5 mm hex socket to secure the LTE bracket to the standoff.
12 Installation procedure for 4G and 5G LTE modules

Figure 12. Thermal pad and LTE bracket
9. Route the antenna cables (three for 4G, four for 5G) under the LTE bracket, then insert the M.2 module.
Installation procedure for 4G and 5G LTE modules 13

Figure 13. Antenna cables under LTE bracket
10. Use a #1 screwdriver to tighten the screw to secure the M.2 module to the LTE bracket.
14 Installation procedure for 4G and 5G LTE modules

Figure 14. Module screwed to bracket
11. Connect the antenna cables to the M.2 module, as described in the following figure and table.
Figure 15. Antennas - top view
Installation procedure for 4G and 5G LTE modules 15

Table 5. Antenna usage
Antenna WiFi6E/BT 4G 5G
ANT1 WiFi main WiFi main WiFi main
ANT2 WiFi/BT aux WiFi/BT aux WiFi/BT aux
ANT3 N/A 4G aux Ant0 (Tx/Rx)
ANT4 N/A 4G main Ant2 (Tx/Rx)
ANT5 N/A N/A Ant1 (Rx)
ANT6 N/A GNSS Ant3 (Rx)
12. Install the LTE heatsink on the M.2 module, positioning the heatsink below the COM cable and above the antenna cables.
Then remove the plastic film.
Figure 16. Heatsink installed
13. Use a #1 screwdriver to tighten the three screws to secure the heatsink to the main board and the side panel.
16 Installation procedure for 4G and 5G LTE modules

Figure 17. Heatsink secured
14. Place the COM cables in the LTE heatsink gap and reconnect the power cable connector.
Installation procedure for 4G and 5G LTE modules 17

Figure 18. COM cables and power cable connector
15. Secure the power cable in the wire mount.
18 Installation procedure for 4G and 5G LTE modules

Figure 19. Power cable in wire mount
16. Reconnect the switch cable connector.
Figure 20. Switch cable connector
Installation procedure for 4G and 5G LTE modules 19

17. Secure the switch cable in the wire mount.
Figure 21. Switch cable in wire mount
18. Put the top panel back into position, beginning with the front of the device, then the rear. Ensure that the top panel does
not press down on any cables.
Figure 22. Reposition top panel
19. On the front panel, ensure that the DC power connector and remote power button connector are not recessed behind the
panel, as shown in the following figure.
20 Installation procedure for 4G and 5G LTE modules
