Dell P98G User guide

Dell Latitude 5411
Setup and specifications guide
Regulatory Model: P98G
Regulatory Type: P98G008

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2020 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its
subsidiaries. Other trademarks may be trademarks of their respective owners.
Rev. A00

1 Set up your Latitude 5411.............................................................................................................. 5
2 Create a USB recovery drive for Windows.......................................................................................7
3 Chassis overview..........................................................................................................................8
Chassis view variables...........................................................................................................................................................8
4 System information.....................................................................................................................12
System specifications.......................................................................................................................................................... 12
Processors.......................................................................................................................................................................12
Chipset.............................................................................................................................................................................12
Memory............................................................................................................................................................................13
Ports and connectors.................................................................................................................................................... 13
Storage............................................................................................................................................................................ 14
Dimensions and weight..................................................................................................................................................14
Operating system........................................................................................................................................................... 14
Communications.............................................................................................................................................................15
Mobile broadband...........................................................................................................................................................15
Audio................................................................................................................................................................................ 16
Media-card reader..........................................................................................................................................................16
Keyboard......................................................................................................................................................................... 16
Camera.............................................................................................................................................................................17
Touchpad.........................................................................................................................................................................17
Battery............................................................................................................................................................................. 18
Power adapter................................................................................................................................................................ 19
Display..............................................................................................................................................................................19
Fingerprint reader.......................................................................................................................................................... 20
Video............................................................................................................................................................................... 20
Computer environment.................................................................................................................................................20
Security............................................................................................................................................................................21
Security options—Contacted smartcard reader........................................................................................................21
Security options—Contactless smartcard reader.....................................................................................................22
Security Software..........................................................................................................................................................23
Support policy...................................................................................................................................................................... 24
Keyboard shortcuts.............................................................................................................................................................24
5 Software................................................................................................................................... 25
Downloading Windows drivers...........................................................................................................................................25
6 System setup.............................................................................................................................26
Boot menu............................................................................................................................................................................26
Navigation keys....................................................................................................................................................................26
Boot Sequence.....................................................................................................................................................................27
System setup options..........................................................................................................................................................27
Contents
Contents 3

General options.............................................................................................................................................................. 27
System information....................................................................................................................................................... 28
Video............................................................................................................................................................................... 29
Security...........................................................................................................................................................................30
Secure boot.....................................................................................................................................................................31
Intel Software Guard Extensions..................................................................................................................................31
Performance...................................................................................................................................................................32
Power management...................................................................................................................................................... 32
POST behavior...............................................................................................................................................................33
Manageability................................................................................................................................................................. 34
Virtualization support.................................................................................................................................................... 34
Wireless...........................................................................................................................................................................35
Maintenance screen......................................................................................................................................................35
System logs.................................................................................................................................................................... 35
Updating the BIOS in Windows ........................................................................................................................................ 35
Updating BIOS on systems with BitLocker enabled..................................................................................................36
Updating your system BIOS using a USB flash drive................................................................................................36
System and setup password.............................................................................................................................................. 37
Assigning a system setup password............................................................................................................................37
Deleting or changing an existing system setup password........................................................................................38
7 Getting help...............................................................................................................................39
Contacting Dell.................................................................................................................................................................... 39
4Contents

Set up your Latitude 5411
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
1. Connect the power adapter and press the power button.
NOTE: To conserve battery power, the battery might enter power saving mode. Connect the power adapter and
press the power button to turn on the computer.
2. Finish Windows setup.
Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you:
• Connect to a network for Windows updates.
NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when
prompted.
• If connected to the internet, sign-in with or create a Microsoft account. If not connected to the internet, create an offline account.
• On the Support and Protection screen, enter your contact details.
3. Locate and use Dell apps from the Windows Start menu—Recommended
1
Set up your Latitude 5411 5

Table 1. Locate Dell apps
Resources Description
My Dell
Centralized location for key Dell applications, help articles, and other important information about your
computer. It also notifies you about the warranty status, recommended accessories, and software updates
if available.
SupportAssist
Pro-actively checks the health of your computer’s hardware and software. The SupportAssist OS Recovery
tool troubleshoots issues with the operating system. For more information, see the SupportAssist
documentation .
NOTE: In SupportAssist, click the warranty expiry date to renew or upgrade your warranty.
Dell Update
Updates your computer with critical fixes and latest device drivers as they become available. For more
information about using Dell Update, see the knowledge base article SLN305843
Dell Digital Delivery
Download software applications, which are purchased but not pre-installed on your computer. For more
information about using Dell Digital Delivery, see the knowledge base article 153764 .
4. Create recovery drive for Windows.
NOTE: It is recommended to create a recovery drive to troubleshoot and fix problems that may occur with Windows.
For more information, see Create a USB recovery drive for Windows.
6Set up your Latitude 5411

Create a USB recovery drive for Windows
Create a recovery drive to troubleshoot and fix problems that may occur with Windows. An empty USB flash drive with a minimum
capacity of 16 GB is required to create the recovery drive.
NOTE: This process may take up to an hour to complete.
NOTE: The following steps may vary depending on the version of Windows installed. Refer to the Microsoft support site
for latest instructions.
1. Connect the USB flash drive to your computer.
2. In Windows search, type Recovery.
3. In the search results, click Create a recovery drive.
The User Account Control window is displayed.
4. Click Yes to continue.
The Recovery Drive window is displayed.
5. Select Back up system files to the recovery drive and click Next.
6. Select the USB flash drive and click Next.
A message appears, indicating that all data in the USB flash drive will be deleted.
7. Click Create.
8. Click Finish.
For more information about reinstalling Windows using the USB recovery drive, see the Troubleshooting section of your product's
Service Manual at www.dell.com/support/manuals.
2
Create a USB recovery drive for Windows 7

Chassis overview
Topics:
•Chassis view variables
Chassis view variables
1. Array microphone
2. Camera shutter
3. Camera
4. Camera status light
5. Array microphone
6. LCD panel
7. LED activity light
3
8 Chassis overview

1. Power connector port
2. USB 3.2 Gen 2(USB Type-C) port with Thunderbolt
3. USB 3.2 Type-A port
4. Smart card reader (optional)
1. microSD card reader
2. microSIM card slot (optional)
3. Universal audio jack
4. USB 3.2 Gen 1 port
5. USB 3.2 Gen 1 port with PowerShare
6. HDMI port
7. Network port
8. Wedge-shaped lock slot
Chassis overview 9

1. Power button with optional fingerprint
2. Keyboard
3. Contactless smart card reader (optional)
4. Touchpad
10 Chassis overview
