AboutYourProjector:Dell™2100MPProjector
Features
Equipment
Main Unit
Control Panel
Connection Ports
Remote Control

Features
Singlechip0.55"TexasInstrumentsDLP™technology
High contrast, double data rate(DDR) digital micromirror device
True SVGA, 800 x 600 addressable pixels
4.0 lb (1.81 kg) lightweight compact design
1000 ANSI lumens brightness(Max), 900 ANSI lumens brightness (Average)
Auto image re-sizing to 800 x 600 full screen with scaling compression compatibility for SXGA, XGA, SVGA, VGA, MAC
Preset video modes for image optimization
Self-diagnostic for video troubleshooting
State-of-the-art motion adaptive hardware deinterlacing with 3:2 and 2:2 pull down
150-watt, user-replaceable P-VIP lamp
Compatibility with Macintosh®computers
Compatibility with NTSC, NTSC4.43, PAL, PAL-M, PAL-N, SECAM, and HDTV (1080i, 720P, 576P, 480i/P)
Multi-function remote control
D-Sub 15-pin cable for analog video connectivity
High-definition TV compatibility
User-friendly, multi-language on-screen display (OSD)
Advanced electronic keystone correction
User-friendly control panel with backlight
Carrying case included
Equipment
Your projector comes with all the items shown below. Ensure that you have all the items, and contact Dell if anything is missing.

Main unit
Power cord
VGA cable (D-sub to D-sub)

S-video cable
USB cable

Composite video cable
D-sub to YPbPr cable
Carrying case
Batteries (2)
Remote control

Dell 2100MP Projector
User's Guide
Dell 2100MP Projector Quick Start
Card
Downloaded From projector-manual.com DELL Manuals


Dell 2100MP Projector Safety and
Warranty Guide
Owner's Manual


Main Unit

Control Panel

1
Control panel
2
Focus ring
3
Lens
4
Elevator button
5
Remote control receiver
1
Power button
2
Four directional keys
Downloaded From projector-manual.com DELL Manuals


Connection Ports



3
Keystone adjustment
4
Temperature warning light
5
Lamp warning light
6
Re-sync
7
Menu
8
Keystone adjustment
9
Source
1
VGA in (D-sub) connector
2
VGA out (monitor loop-through)
3
IR receiver
4
USB connector
5
S-video connector
6
Composite video connector
Remote Control

1
Light
2
Power button
3
Previous Page button (page up)
4
Four Direction buttons
5
Source button
6
Resync button
7
Keystone Correction button
8
Zoom in/out
9
Hide button
Downloaded From projector-manual.com DELL Manuals

10
Freeze button
11
Menu button
12
Next Page button (page down)
13
Video Mode button

Battery Disposal: Your projector remote control uses zinc-manganese batteries. If you need to replace the batteries, see your Dell
2100MP Projector Quick Start Card.
Do not dispose of used batteries along with household waste. Contact your local waste disposal agency for the address of the nearest
battery deposit site.
