Getting Started With Your System 3
Installation and Configuration
WARNING: Before performing the following procedure, review the safety
instructions that came with the system.
This section describes the steps required to set up your system for the first time.
Unpack the System
Unpack your system and identify each item.
Installing the Rails and System in a Rack
Assemble the rails and install the system in the rack following the
safety instructions and the rack installation instructions provided
with your enclosure.

4Getting Started With Your System
Installing the Blades
Beginning at the top, slide the modules into the enclosure from left to right.
When the blade is securely installed, the handle returns to the closed position.
Connecting the CMC and KVM Modules
Connect the serial cable and network cable(s) from the management
system to the CMC module. If a second, optional CMC module is installed,
connect it as well.
Connect the keyboard, mouse, and monitor to the optional iKVM module.

Getting Started With Your System 5
Connecting the System to Power
Connect the system’s power cables to the system power supplies.
CAUTION: To prevent the power cables from being disconnected accidentally,
use the plastic clip on each power supply to secure the power cable to the
power supply, and use the Velcro strap to secure the cable to the strain-relief bar.
Plug the other end of the power cables into a power distribution unit (PDU).
CAUTION: Do not plug the power cables directly into a power outlet; you must
use a PDU. For optimal system functionality, a minimum of three power supplies
are required.

6Getting Started With Your System
Turning On the System
Press the power button on the enclosure. The power indicator should light.
NOTE: Once you have connected the system to the power supplies, there may
be a minimal delay before you can turn on your system.
Turning On the Blades
Press the power button on each blade, or power on the blades using the
systems management software.

Getting Started With Your System 7
Complete the Operating System Setup
If you purchased a preinstalled operating system, see the operating system
documentation that ships with your system. To install an operating system
for the first time, see the installation and configuration documentation
for your operating system. Be sure the operating system is installed before
installing hardware or software not purchased with the system.
Supported Operating Systems
Operating System M915 M910 M905 M805 M710 M710HD M610 M610x M605
Citrix XenServer 5.5   
Citrix XenServer 5.6   
Microsoft Windows
Server 2008 Hyper-V
Server
 
Microsoft Windows
Essential
Business Server 2008
Standard and
Premium Editions

Microsoft Windows
HPC Server 2008
(x64)
 
Microsoft Windows
Server 2008
Standard and
Enterprise (x86)
Editions

Microsoft Windows
Web Server 2008
(x86) Edition

Microsoft Windows
Web Server 2008
(x86) Edition
with SP2


8Getting Started With Your System
Microsoft Windows
Server 2008
Standard and
Enterprise (x86)
Editions with SP2

Microsoft Windows
Server 2008
Standard, Enterprise,
and Datacenter
(x64) Editions
 
Microsoft Windows
Web Server 2008
(x64) Edition

Microsoft Windows
Web Server 2008
(x64) Edition
with SP2
  
Microsoft Windows
Server 2008 R2
Standard, Enterprise,
and Datacenter
(x64) Editions
  
Microsoft Windows
Server 2003 Standard
and Enterprise
Editions

Microsoft Windows
Server 2003
Web Edition

Microsoft Windows
Server 2003
Standard, Enterprise,
and Web Editions
with SP1 and later

Microsoft Windows
Server 2003 R2
Standard and
Enterprise (x86)
Editions
  
Operating System M915 M910 M905 M805 M710 M710HD M610 M610x M605

Getting Started With Your System 9
Microsoft Windows
Server 2003
Standard and
Enterprise (x64)
Editions

Microsoft Windows
Server 2003 R2
Standard and
Enterprise (x64)
Editions
  
Microsoft Windows
Server 2003 R2
Datacenter (x64)
Edition

Microsoft Windows
Server 2003 R2
Standard, Enterprise,
and Datacenter
(x64) Editions
with SP2

Red Hat Enterprise
Linux AS, ES,
and WS (version 4.0)
Update 5 (x86)
 
Red Hat Enterprise
Linux AS, ES,
and WS (version 4.0)
Update 5 (x86_64)
 
Red Hat Enterprise
Linux AS and
ES (version 4.7)
(x86)

Red Hat Enterprise
Linux AS and
ES (version 4.7)
(x86_64)

Red Hat Enterprise
Linux AS and
ES (version 4.8)
(x86)

Operating System M915 M910 M905 M805 M710 M710HD M610 M610x M605

10 Getting Started With Your System
Red Hat Enterprise
Linux AS and
ES (version 4.8)
(x86_64)

Red Hat Enterprise
Linux
(version 5.0) (x86)
  
Red Hat Enterprise
Linux (version 5.0)
(x86_64)
 
Red Hat Enterprise
Linux (version 5.2)
(x86)

Red Hat Enterprise
Linux (version 5.5)
(x86)

Red Hat Enterprise
Linux (version 5.5)
(x86_64)

Red Hat Enterprise
Linux (version 6.0)
(x86_64)

SUSE Linux
Enterprise Server 10
(x86_64)
 
SUSE Linux
Enterprise Server 10
(x86_64) SP3
  
SUSE Linux
Enterprise Server 11
(x86_64)
  
Solaris 10 (x86_64) 
VMware ESX
version 3.0  
VMware ESX version
3.0.2 Update 1 
VMware ESX
version 3.5  
Operating System M915 M910 M905 M805 M710 M710HD M610 M610x M605

Getting Started With Your System 11
NOTE: For the latest information on supported operating systems for all
PowerEdge systems, see dell.com/ossupport.
Other Information You May Need
WARNING: Before performing the following procedure, review the safety
instructions that came with the system.
• The Configuration Guide provides information on configuring the system
enclosure and the blades.
•
Rack Installation Instructions included with your rack solution describes
how to install your system into a rack.
• The
Hardware Owner’s Manual provides information about system
features and describes how to troubleshoot the system and install or
replace system components.
• Dell systems management application documentation provides
information about installing and using the systems management software.
NOTE: Always check for updates on support.dell.com/manuals and read the
updates first because they often supersede information in other documents.
VMware ESX
version 4.0 Update 1 
VMware ESXi
version 4.0 Update 1 
VMware ESX
version 4.0 Update 2 
VMware ESXi
version 4.0 Update 2 
VMware ESX
version 4.1 Update 1 
VMware ESXi
version 4.1 Update 1 
—Supported
Operating System M915 M910 M905 M805 M710 M710HD M610 M610x M605

12 Getting Started With Your System
Obtaining Technical Assistance
If you do not understand a procedure in this guide or if the system does not
perform as expected, see your Hardware Owner’s Manual. Dell offers
comprehensive hardware training and certification. See dell.com/training for
more information. This service may not be offered in all locations.
Technical Specifications
Blade Specifications
Processor
Processor type
PowerEdge M915 Two or four AMD Opteron 6000 series processors
(eight- or twelve-core processors)
PowerEdge M910 Two or four Intel Xeon 7000 series processors
(up to eight-core processors)
PowerEdge M905 Four dual- or quad-core AMD Opteron 8000 series
processors
PowerEdge M805 Two dual- or quad-core AMD Opteron 2000 series
processors
PowerEdge M710HD,
M710, M610x, M610
One or two dual-, quad-, or six-core Intel Xeon 5000
series processors
PowerEdge M605 One or two dual- or quad-core AMD Opteron 2000
series processors
PowerEdge M600 One or two dual- or quad-core Intel Xeon processors
Memory
Architecture
PowerEdge M915 1333 MHz DDR3 single-, dual-, or quad-ranked
registered LV DIMMs (RDIMMs)
PowerEdge M910 DDR3 memory modules,
rated for 1066 MHz operation
PowerEdge M905,
M805, M605
DDR2 memory modules,
rated for 677 MHz operation

Getting Started With Your System 13
PowerEdge M710HD DDR3 and DDR3L single-, dual-, and quad-rank
memory modules, rated for1066 and 1333 MHz
PowerEdge M710,
M610x, M610,
800, 1066, or 1333 MHz DDR3 single- or dual-ranked
registered DIMMs (RDIMMs) or unbuffered DIMMs
(UDIMMs)
or
800 or 1066 MHz DDR3 quad-ranked registered
DIMMs (RDIMMs) or unbuffered DIMMs
(UDIMMs)
PowerEdge M600 FBD memory modules, rated for 677 MHz operation
Memory module sockets
PowerEdge M915, M910 32 240-pin sockets
PowerEdge M905 24 240-pin sockets
PowerEdge M805 16 240-pin sockets
PowerEdge M710HD,
M710
18 240-pin sockets
PowerEdge M610x, M610 12 240-pin sockets
PowerEdge M605, M600 Eight 240-pin sockets
Memory module capacities
PowerEdge M915 1 GB, 2 GB, 4 GB, 8 GB, and 16 GB LV DIMMs
PowerEdge M910 1 GB, 2 GB, 4 GB, 8 GB, and 16 GB RDIMMs
PowerEdge M905, M805, 1 GB, 2 GB, 4 GB, and 8 GB
PowerEdge M710HD 1 GB, 2 GB, 4 GB, 8 GB, and 16 GB
RDIMMs and LV DIMMs
PowerEdge M710,
M610x, M610
2 GB, 4 GB, 8 GB, and 16 GB RDIMMs and LV DIMMs;
1 GB and 2 GB UDIMMs
PowerEdge M605, M600 512 MB, 1 GB, 2 GB, 4 GB, and 8 GB
Minimum RAM
PowerEdge M915 8 GB
PowerEdge M910 4 GB
PowerEdge M905 8 GB (Eight 1 GB memory modules)
Memory (continued)

14 Getting Started With Your System
PowerEdge M805 4 GB (Four 1 GB memory modules)
PowerEdge M710D 4 GB
PowerEdge M710,
M610x, M610
One 1 GB memory module (one-processor system) or
two 1 GB memory modules (two-processor systems)
PowerEdge M605, M600 1 GB (two 512 MB memory modules)
Maximum RAM
PowerEdge M915 512 GB
PowerEdge M910 512 GB
PowerEdge M905 192 GB
PowerEdge M805 128 GB
PowerEdge M710HD 288 GB
PowerEdge M710 288 GB (Eighteen 16 GB RDIMMs);
36 GB (Eighteen 2 GB UDIMMs)
PowerEdge M610x,
M610
192 GB (Twelve 16 GB RDIMMs);
24 GB (Twelve 2 GB UDIMMs)
PowerEdge M605, M600 64 GB
Drives
Hard Drives
PowerEdge M915, M910 Up to two 2.5-inch SAS hard drives support through
value RAID or performance RAID storage card.
or
Up to two 2.5-inch SSD hard drives support through
value RAID or performance RAID storage card.
PowerEdge M905, M805 Up to two 2.5-inch SAS hard drives support through
value RAID or performance RAID storage card.
PowerEdge M710HD Up to two 2.5-inch SAS hard drives support through
PERC H200 embedded storage controller.
or
Up to two 2.5-inch SSD hard drives support through
PERC H200 embedded storage controller.
Memory (continued)

Getting Started With Your System 15
PowerEdge M710 Up to four 2.5-inch SAS hard drives support through
value RAID or performance RAID storage card.
PowerEdge M600,
M610x, M610
One 2.5-inch SATA hard drive support through non-
RAID, value RAID, or performance RAID
storage card.
or
Two 2.5-inch SATA hard drives support through value
RAID or performance RAID storage card.
or
One solid-state disk (SSD) hard drive support
through non-RAID storage card.
or
Up to two SAS hard drives support through value
RAID or performance RAID storage card.
PowerEdge M605 Up to two SATA hard drives support through value
RAID or performance RAID storage card.
or
Up to two solid-state disk (SSD) hard drives support
through non-RAID storage card.
or
Up to two SAS hard drives support through value
RAID or performance RAID storage card.
NOTE: For all modular systems, SAS and SATA hard
drives cannot be mixed within a blade.
NOTE: Hot-plug operation is supported if an optional
RAID controller card is installed.
Connectors
External
USB
PowerEdge M915, M910,
M905, M805, M710
Three 4-pin, USB 2.0 compliant
PowerEdge M710HD,
M610x, M610, M605,
M600
Two 4-pin, USB 2.0 compliant
Drives (continued)

16 Getting Started With Your System
Internal
Internal Secure Digital
(SD) module (PowerEdge
M915, M910, M905, M805,
M710HD, M710,
M610x, M610)
Internal Secure Digital
(SD) vFlash module
(PowerEdge M915, M910,
M710HD, M710,
M610x, M610)
One optional flash memory card slot
with the internal SD module.
One optional vFlash memory card slot for
use with the iDRAC Enterprise support.
USB key (PowerEdge M915,
M910, M710HD,
M710, M610x, M610)
One internal USB key connector.
PCIe Expansion Solution
PowerEdge M610x Supports two single-wide or one double-wide
full length standard PCIe card.
Mezzanine Cards
PowerEdge M915, M910 Up to four PCIe Gen 2 x8 mezzanine card slots,
supporting dual-port Gb Ethernet, 10 Gb Ethernet,
FC8 Fibre Channel, or Infiniband mezzanine cards.
PowerEdge M905, M805 Up to four PCIe Gen 1 x8 mezzanine card slots,
supporting dual-port Gb Ethernet, 10 Gb Ethernet,
FC8 or FC4 Fibre Channel, or 4x DDR Infiniband
mezzanine cards.
PowerEdge M710HD Up to two PCIe Gen 2 x8 mezzanine card slots,
supporting dual-port and quad-port Gb Ethernet,
10 Gb Ethernet, FC8 or FC4 Fibre Channel,
or 4x DDR Infiniband mezzanine cards.
PowerEdge M710 Up to four PCIe Gen 2 mezzanine card slots (three x8
and one x4 lane width), supporting dual-port Gb
Ethernet, 10 Gb Ethernet, FC8 or FC4 Fibre
Channel, or 4x DDR Infiniband mezzanine cards.
Connectors (continued)

Getting Started With Your System 17
PowerEdge M610x, M610 Up to two PCIe Gen 2 x8 mezzanine card slots,
supporting dual-port Gb Ethernet, 10 Gb Ethernet,
FC8 or FC4 (M610 only) Fibre Channel, or 4x DDR
Infiniband mezzanine cards.
PowerEdge M605, M600 Up to two PCIe x8 mezzanine card slots, supporting
dual-port Gb Ethernet, 10 Gb Ethernet, FC8 or
FC4 Fibre Channel, or 4x DDR Infiniband
mezzanine cards.
Embedded Ethernet Controllers
PowerEdge M915, M910,
M905, M805, M710HD,
M710
Four Ethernet ports with TOE and iSCSI boot
support, provided by two integrated dual-port
Broadcom 5709S Ethernet controllers.
PowerEdge M610x, M610 Two Ethernet ports with TOE and iSCSI boot
support, provided by one integrated dual-port
Broadcom 5709S Ethernet controller.
PowerEdge M605, M600 Two Ethernet ports with TOE and iSCSI boot
support, provided by two integrated Broadcom 5708S
controllers.
Video Controller
PowerEdge M905, M805,
M605, M600
ATI RN50 video controller. 32 MB video memory
PowerEdge M915, M910,
M710HD, M710, M610x,
M610
Matrox G200 video controller. 8 MB video memory
Physical
PowerEdge M915
Height 38.5 cm (15.2 in)
Width 5 cm (2 in)
Depth 48.6 cm (19.2 in)
Weight (maximum
configuration)
12.7 kg (28 lb)
Mezzanine Cards (continued)

18 Getting Started With Your System
PowerEdge M910
Height 38.5 cm (15.2 in)
Width 5 cm (2 in)
Depth 48.6 cm (19.2 in)
Weight (maximum
configuration)
13.1 kg (29 lb)
PowerEdge M905, M805,
M710, M610x
Height 38.5 cm (15.2 in)
Width 5 cm (2 in)
Depth 48.6 cm (19.2 in)
Weight (maximum
configuration)
11.1 kg (24.5 lb)
PowerEdge M710HD
Height 18.9 cm (7.4 in)
Width 5 cm (2 in)
Depth 48.6 cm (19.2 in)
Weight (maximum
configuration)
7.4 kg (16.3 lb)
PowerEdge M605, M600
Height 18.9 cm (7.4 in)
Width 5 cm (2 in)
Depth 48.6 cm (19.2 in)
Weight (maximum
configuration)
5.2–6.4 kg (11.5–14.0 lb)
Battery
NVRAM backup battery CR 2032 3.0-V lithium coin cell
Physical (continued)
