Dell PowerEdge T100 User manual

Dell™ PowerEdge™
Getting Started
With Your System
系统使用入门
開始使用系統
はじめに
시스템시작하기

Dell™ PowerEdge™
Getting Started
With Your System
Model EMT

Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use
of your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data
and tells you how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury,
or death.
____________________
Information in this document is subject to change without notice.
© 2008 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly
forbidden.
Trademarks used in this text: Dell, the Dell logo, and PowerEdge are trademarks of Dell Inc.; Intel,
Celeron, Pentium, and Xeon are registered trademarks and Core is a trademark of Intel corporation
in the U.S. and other countries. Microsoft, Windows, and Windows Server are either trademarks or
registered trademarks of Microsoft Corporation in the United States and/or other countries; Red Hat
and Red Hat Enterprise Linux are registered trademarks of Red Hat, Inc. in the United States and other
countries; SUSE is a registered trademark of Novell Inc. in the United States and other countries.
Other trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and
trade names other than its own.
Model EMT
May 2008 P/N F268G Rev. A01

Getting Started With Your System 3
System Features
This section describes the major hardware and software features of your
system. It also provides information about other documents you may need
when setting up your system and how to obtain technical assistance.
• One of the following processors:
–Intel
®
Celeron
®
processor
– Intel Celeron Dual-Core processor
– Intel Pentium
®
Dual-Core processor
– Intel Core™2 Duo processor
– Dual-Core Intel Xeon
®
processor
– Quad-Core Intel Xeon processor
NOTE: Processor availability may differ by region.
NOTE: Use the System Setup program to view processor information.
See the Hardware Owner’s Manual.
• A minimum of 512 MB of 667- or 800-MHz DDR II SDRAM memory,
upgradable to a maximum of 8 GB DDR II SDRAM memory by installing
512-MB, 1-GB, or 2-GB unbuffered ECC memory modules in the four
memory module sockets on the system board; single or dual rank.
• Support for the following internal hard-drive (non-hot-pluggable)
configurations:
– Up to two internal 3.5-inch SATA hard drives with an integrated SATA
controller
or
– Up to two internal 3.5-inch Serial-Attached SCSI (SAS) hard drives
with a SAS controller card
• One 3.5-inch peripheral drive bay for the optional diskette drive, and
two 5.25-inch bays for the following supported drives: DVD-ROM,
combination CD-RW/DVD, DVD+/-RW, or backup device.
NOTE: DVD devices are data only.

4Getting Started With Your System
• Support for the following RAID volumes with an optional SAS RAID
controller card: simple, spanned, striped (RAID 0), and mirrored (RAID 1).
• A chassis intrusion alert.
The system board includes the following integrated features:
• SATA controller that supports up to two optical devices including
DVD-ROM, CDRW/DVD combination drive, and DVD+/- RW.
NOTE: DVD devices are data only.
• SATA controller that supports up to two cabled SATA hard drives.
• One 32-bit, 33-MHz expansion card slot, one PCI Express x1 expansion
slot, and two PCI Express x8 expansion slots; one with x4 bandwidth.
• An integrated ATI ES1000 graphics controller with 32 MB of graphics
memory. Maximum resolution is 1600x1200 with 65,536 colors; true-color
graphics are supported in the following resolutions: 640 x 480, 800 x 600,
1024 x 768, and 1280 x 1024.
• An integrated Gigabit NIC, capable of supporting 1000-Mbps, 100-Mbps,
or 10-Mbps data rates, with support for PXE and Wake-on-LAN.
• Front-panel connectors include two USB connectors.
• Back-panel connectors include serial, video, five USB connectors, and one
NIC connector.
• Eight USB 2.0-compliant connectors (two on the front, one internal for a
bootable memory key and Unmanaged Internal Persistent Storage (UIPS),
and five on the back) capable of supporting a diskette drive, a CD-ROM
drive, a keyboard, a mouse, or a USB flash drive.
• Four front-panel system diagnostic LEDs for failure messaging and
notification during startup.
For more information about specific features, see "Technical Specifications"
on page 8.
Supported Operating Systems
Your system supports the following operating systems:
• Microsoft
®
Windows Server
®
2008, Standard Edition (32-bit x86)
• Microsoft Windows Server 2008, Standard Edition (x64)
• Microsoft Windows Server 2003, R2 and SP2 Standard Edition(32-bit x86)

Getting Started With Your System 5
• Microsoft Windows Server 2003, R2 and SP2 Standard Edition (x64)
• Microsoft Windows Small Business Server 2003, R2 and SP2 Standard
Edition (32-bit x86)
• Microsoft Windows Small Business Server 2003, R2 and SP2 Premium
Edition (32-bit x86)
•RedHat
®
Enterprise Linux
®
ES (version 5) (x86_32)
• Red Hat Enterprise Linux ES (version 5) (x86_64)
•SUSE
®
Linux Enterprise Server 10 (x86_64)
Other Information You May Need
CAUTION: The Product Information Guide provides important safety and
regulatory information. Warranty information may be included within this
document or as a separate document.
• The Hardware Owner’s Manual provides information about system
features and describes how to troubleshoot the system and install or
replace system components. This document can be found on
support.dell.com .
• CDs or DVDs included with your system provide documentation and tools
for configuring and managing your system.
• Updates are sometimes included with the system to describe changes
to the system, software, and/or documentation.
NOTE: Always check for updates on support.dell.com and read the updates
first because they often supersede information in other documents.
• Release notes or readme files may be included to provide last-minute
updates to the system or documentation or advanced technical reference
material intended for experienced users or technicians.
• Operating system documentation describes how to install (if necessary),
configure, and use the operating system software.
• Documentation for any components you purchased separately provides
information to configure and install these options.

6Getting Started With Your System
Obtaining Technical Assistance
If you do not understand a procedure in this guide or if the system does
not perform as expected, see your Hardware Owner’s Manual.
Dell Enterprise Training and Certification is available; see dell.com/training
for more information. This service may not be offered in all locations.
Installation and Configuration
CAUTION: Before you begin this procedure, read and follow the safety
instructions that came with the system.
This section describes the steps to set up your system for the first time.
Unpack the System
Upack your system and identify each item. Keep all shipping materials in case
you need them later.
Connect the Keyboard, Mouse, and Monitor
Connect the keyboard, mouse, and monitor (optional).
The connectors on the back of your system have icons indicating which
cable to plug into each connector. Be sure to tighten the screws (if any)
on the monitor's cable connector.

Getting Started With Your System 7
Connect the System to Power
Connect the system’s power cable to the system. Next, plug the other end of
the power cable into a grounded electrical outlet or a separate power source such
as an uninterrupted power supply (UPS) or a power distribution unit (PDU).
Turn on the System and Monitor
Press the power button on the system and the monitor. The power indicators
should light. Adjust the monitor's controls until the displayed image is
satisfactory.

8Getting Started With Your System
Complete the 0perating System Setup
If you purchased a preinstalled operating system, see the operating system
documentation that ships with your system. To install an operating system
for the first time, see the Quick Installation Guide. Be sure the operating
system is installed before installing hardware or software not purchased
with the system.
Technical Specifications
Processor
Processor type
•Intel
®
Celeron
®
processor
• Intel Celeron Dual-Core processor
• Intel Pentium
®
Dual-Core processor
• Intel Core™2 Duo processor
• Dual-Core Intel Xeon
®
processor
• Quad-Core Intel Xeon processor
NOTE: Processor availability may differ
by region.
Expansion Bus
Bus type PCI and PCIe
Expansion slots
PCIe 0.5 GB/sec PCIe x1, 3.3-V, 12-V (slot 4)
2 GB/sec PCIe x8 with x4 bandwidth,
3.3-V, 12-V (slot 1)
4 GB/sec PCIe x8, 3.3-V, 12-V (slot 2)
PCI One 3.3-V, half-length, 32-bit, 33-MHz
(slot 3)
Memory
Architecture 72-bit, ECC, PC-5300/6400, unbuffered,
DDR II SDRAM, DIMMs, rated for 667-
or 800-MHz operation
Memory module sockets four 240-pin

Getting Started With Your System 9
Memory module capacities 512 MB, 1 GB, or 2 GB
Minimum RAM 512 MB (one 512-MB module)
Maximum RAM 8 GB (four 2-GB modules)
Drives
Hard Drives Up to two non-hot-plug, 3.5-inch, internal
SATA hard drives with the integrated
SATA controller
or
Up to two non
- hot-plug, 3.5-inch, internal
SAS drives with a SAS controller card
Diskette drive one optional 3.5-inch, 1.44-MB
Optical drives up to two optional internal drives: SATA
Interface DVD-ROM, or combination
CD-RW/DVD or DVD+/-RW
NOTE: DVD devices are data only.
external optional USB optical disk drive
Backup device one optional internal half-height,
5.25-inch backup device
Flash drive optional USB flash drive
(internal or external)
Connectors
Back
NIC one RJ-45 (for Broadcom Gigabit LOM)
Serial 9-pin, DTE, 16550-compatible
USB five 4-pin, USB 2.0-compliant
Video 15-pin VGA
Memory (continued)

10 Getting Started With Your System
Front
USB one 4-pin USB 2.0-compliant
(CD/DVD/USB key)
one 4-pin USB 2.0-compliant
(floppy drive)
Internally accessible
SATA channels four 7-pin
USB key (for memory key) one 4-pin, USB 2.0-compliant/
1.1-compliant
Video
Video type Integrated
Video memory 32 MB
Power
AC power supply (per power supply)
Wattage 305 W
Voltage 100-120V/200-240V, 9/4.5A, 50/60 Hz
Heat dissipation 1040 BTU/Hour
CMOS Backup Battery CR 2032 3.0-V lithium ion coin cell
Physical
Height 414.1 mm (16.3 inches)
Width 186.9 mm (7.40 inches)
Depth 460.14 mm (18.11 inches)
Weight (maximum configuration) 13 kg (28.70 lb)
Connectors (continued)

Getting Started With Your System 11
Environmental
NOTE: For additional information about environmental measurements for specific
system configurations, see dell.com/environmental_datasheets.
Temperature
Operating 10° to 35°C (50° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity
Operating 20% to 80% (noncondensing) with a
maximum humidity gradient of 10%
per hour
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating 0.26 G, 5 to 350 Hz at 0.0002 G2/Hz
Storage 1.54 G, 10 to 250 Hz at 0.003
to 0.01 G2/Hz
Maximum shock
Operating 31 G +/- 10% with pulse duration
of 2.6 msec +/- 10%,
Storage 71 G +/- 10% with pulse duration
of 2 msec +/- 10%, 32G +/-5% with
velocity change of 270 ips +/- 5%
Altitude
Operating –15.2 to 3,048 m (–50 to 10,000 ft)
Storage –15.2 to 10,600 m (–50 to 35,000 ft)

12 Getting Started With Your System

Dell™ PowerEdge™
系统使用入门
型号 EMT

注、注意和警告
注：“注”表示可以帮助您更好地使用计算机的重要信息。
注意：“注意”表示可能会损坏硬件 导致数据丢失，并告诉您如何避免
此类问题。
警告：“警告”表示可能会导致财产损失、人身伤害甚至死亡。
____________________
本说明文件中的信息如有更改，恕不另行通知。
© 2008 Dell Inc. 版权所有，翻印必究。
未经 Dell Inc. 书 许可，严禁以任何形式进行复制。
本文中使用的商标：Dell、Dell 徽标和 PowerEdge 是Dell Inc. 的商标； Intel、Celeron、
Pentium 和Xeon 是Intel corporation 在美国和其它国家 /地区的注册商标而 Core 是Intel
corporation 在美国 和其它国家 /地区的商标。Microsoft、Windows 和Windows Server 是
Microsoft Corporation 在美国和 /或其它国家 /地区的商标或注册商标； Red Hat 和Red Hat
Enterprise Linux 是Red Hat, Inc. 在美国和其它国家 /地区的注册商标； SUSE 是Novell Inc.
在美国和其它国家 /地区的注册商标。
本文中述及的其它商标和产品名称是指拥有相应商标和产品名称的公司或其制造的产品。
Dell Inc. 对本公司的商标和产品名称之外的其它商标和产品名称不拥有任何专有权。
型号 EMT
2008 年5 月P/N F268G Rev. A01

系统使用入门 15
系统功能
本节介绍系统的主要硬件和软件功能。此外，还将介绍有关在安装系统时
可能需要的其它 明文件的信息，以及如何获得技术帮助的信息。
• 以下处理器之一：
–Intel®Celeron®处理器
–Intel Celeron Dual-Core 处理器
–Intel Pentium®Dual-Core 处理器
–Intel Core™2 Duo 处理器
–Dual-Core Intel Xeon®处理器
–Quad-Core Intel Xeon 处理器
注：处理器的可用性视具体的地区而定。
注
：使用系统设置程序可以查看处理器信息。请参阅《硬件用户手册》。
• 至少
512 MB
的
667
或
800 MHz DDR II SDRAM
内存，通过在系统板
上的四个内存模块插槽（单排或 排）中安装
512 MB
、
1 GB
或
2 GB
非缓冲
ECC
内存模块，最多可升级至
8 GB DDR II SDRAM
内存。
• 支持以下内部硬盘驱动器（非热插拔）配置：
–通过集成的 SATA 控制器，最多支持两个内部 3.5 英寸 SATA
硬盘驱动器
或
–通过 SAS 控制器卡，最多支持两个内部 3.5 英寸串行连接 SCSI
(SAS) 硬盘驱动器
• 一个
3.5
英寸外围设备驱动器托架，用于可选的软盘驱动器；
两个
5.25
英寸托架，用于以下支持的驱动器：
DVD-ROM
、
组合
CD-RW/DVD
、
DVD+RW
或备份设备。
注：DVD 设备仅用于数据。
• 支持具有可选
SAS RAID
控制器卡的以下
RAID
卷：简单卷、跨区卷、
条带卷
(RAID 0)
和镜像卷
(RAID 1)
。
• 机箱防盗警报。
系统板包括以下集成功能：
•SATA 控制器，最多支持两个光学设备，包括
DVD-ROM
、
CDRW/DVD
组合驱动器和
DVD+/- RW
。
注：DVD 设备仅用于数据。

16 系统使用入门
•SATA 控制器，最多支持两个以电缆连接的
SATA
硬盘驱动器。
• 一个
32
位、
33 MHz
的扩充卡插槽，一个
PCI Express x1
扩充槽和两个
PCI Express x8
扩充槽；一个具有
x4
带宽。
• 一个集成的
ATI ES1000
图形控制器，具有
32 MB
的图形内存。
最大分辨率是
1600x1200
（
65,536
色）；以下分辨率支持真彩色图形：
640 x 480
、
800 x 600
、
1024 x 768
和
1280 x 1024
。
• 一个集成的千兆位
NIC
，可支持
1000 Mbps
、
100 Mbps
或
10 Mbps
数据速率，支持
PXE
和通过
LAN
唤醒的功能。
• 前面板连接器，包括两个
USB
连接器。
• 背面板连接器，包括串行连接器、视频连接器、五个
USB
连接器和一
个
NIC
连接器。
• 八个
USB 2.0
兼容连接器（两个在正面、一个在内部，用于可引导存
储钥匙和非管理型内部永久存储
[UIPS]
以及五个在背面），可支持软
盘驱动器、
CD-ROM
驱动器、键盘、鼠标或
USB
快擦写驱动器。
• 四个前面板系统诊断
LED
，用于启动时的故障信息传送和通知。
有关特定配置的详细信息，请参阅第 20 页的“技术规格”。
支持的操作系统
您的系统支持以下操作系统：
•Microsoft
®
Windows Server
®
2008
标准版（
32
位
x86
）
•Microsoft Windows Server 2008 标准版
(x64)
•Microsoft Windows Server 2003
，
R2
和
SP2
标准版（
32
位
x86
）
•Microsoft Windows Server 2003 ，
R2
和
SP2
标准版
(x64)
•Microsoft Windows Small Business Server 2003
，
R2
和
SP2
标准版
（
32
位
x86
）
•Microsoft Windows Small Business Server 2003 ，
R2
和
SP2
高级版
（
32
位
x86
）
•Red Hat
®
Enterprise Linux
®
ES
（第
5
版）
(x86_32)
•Red Hat Enterprise Linux ES
（第
5
版）
(x86_64)
•SUSE
®
Linux Enterprise Server 10 (x86_64)

系统使用入门 17
可能需要的其它信息
警告：《产品信息指南 提供了重要的安全与管制信息。保修信息可能包
括在该说明文件中，也可能作为单独的说明文件提供。
• 《硬件用户手册》提供了有关系统功能的信息，并说明了如何排除系统故
障以 安装或更换系统组件。可在
support.dell.com
上找到本说明文件。
• 系统附带的
CD
或
DVD
提供了用于配置和管理系统的说明文件和工具。
• 系统有时附带更新，用于说明对系统、软件和
/
或说明文件所做的更改。
注：请经常访问 support.dell.com 以查看是否有更新，并先阅读更
新信息，因为这些更新通常会取代其它说明文件中的信息。
• 系统可能附带的版本注释或自述文件，提供系统或说明文件的最新
更新，或者为有经验的用户或技术人员提供高级技术参考资料。
• 操作系统说明文件介绍了如何安装（如果有必要）、配置和使用操作
系统软件。
• 单独购买的任何组件所附带的说明文件提供了有关配置和安装这些选
件的信息。
获得技术帮助
如果您对本指南中的步骤有疑问，或系统运行无法达到预期效果，
请参阅《硬件用户手册》。
Dell 可以提供企业培训与认证；有关详情，请访问 dell.com/training。
并非在所有国家和地区均可提供此服务。
安装和配
警告：开始执行该步骤之前，请阅读并遵循系统附带的安全说明。
本节介绍初次安装系统时的步骤。
打开系统包装
打开系统包装并识别每件物品。妥善保管所有运输包装材料，
以备将来使用。

18 系统使用入门
连接键盘、鼠标和显示器。
连接键盘、鼠标和显示器（可选）。
系统背面的连接器附有图标，这些图标指示了要插入每个连接器的电缆。
确保拧紧显示器的电缆连接器上的螺钉（如果有）。
将系统连接到电源
将系统的电源电缆连接到系统上。接下来，将电源电缆的另一端插入接地
的电源插座或单独的电源，如不间断电源设备 (UPS) 或配电装置 (PDU)。
