Dell PowerEdge Programming manual

VMware®ESXi Software on
Dell™ PowerEdge™ Servers
Systems Management Guide

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of
your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data if
instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal
injury, or death.
____________________
Information in this document is subject to change without notice.
© 2008 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.
is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, OpenManage, PowerVault, and PowerEdge are
trademarks of Dell Inc.; VMware, ESX Server and VMotion are registered trademarks or trademarks
of VMware, Inc. in the United States and/or other jurisdictions; Intel is a registered trademarks of
Intel Corporation; Microsoft and Windows are either trademarks or registered trademarks of Microsoft
Corporation in the United States and/or other countries.
Other trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and
trade names other than its own.
September 2008 Rev. A02

Contents 3
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Common Information Model. . . . . . . . . . . . . . . . . . . . 5
Simple Network Management Protocol . . . . . . . . . . . . . . 6
Remote Management . . . . . . . . . . . . . . . . . . . . . . . 6
Install and Configure Systems Management Components . . . . . . 8
First Boot Setup and Configuration . . . . . . . . . . . . . . . . 8
Management Station Setup . . . . . . . . . . . . . . . . . . . . 9
ESXi Software Configuration . . . . . . . . . . . . . . . . . . . 10
Systems Management Use Cases . . . . . . . . . . . . . . . . . . 11
Discovery and Health Monitoring Using VI Client . . . . . . . . 11
Alert Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . 12
Change Management . . . . . . . . . . . . . . . . . . . . . . 13
Troubleshooting, Logging, and Diagnostics . . . . . . . . . . . 14
Remote Management . . . . . . . . . . . . . . . . . . . . . . 14
Advanced System Configuration . . . . . . . . . . . . . . . . . 14
Troubleshooting and Known Issues . . . . . . . . . . . . . . . . . 16
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Systems Management features comparison between
ESX software with OpenManage and ESXi software . . . . . . 19

4Contents

Systems Management Guide 5
Introduction
VMware ESXi software is the next generation virtualization software that
comes integrated with Dell PowerEdge™ servers. By integrating VMware
virtualization, Dell has taken a major step toward simplifying deployment and
management of virtualized environments. Unlike traditional ESX Server,
ESXi Server does not have a service console, helping reduce the installation
footprint of the software and allowing the hypervisor to be directly installed
on the server’s internal flash storage. ESXi ships pre-installed on certain Dell
servers. No additional software installation is needed on the server for systems
management. With minimal configuration, users will be able to monitor and
manage their virtualization environment.
This document provides an overview of the systems management architecture
in VMware ESXi software on Dell PowerEdge systems. Detailed steps to
install and configure the server and tools to manage the server are provided,
including troubleshooting tips and known issues.
For more information on setting up ESXi with your Dell PowerEdge server,
refer to the VMware ESXi Dell Solutions Guide at support.dell.com. For
information on managing the virtualization environment, refer to the
VMware documentation at
www.vmware.com/support/pubs/vi_pages/vi_pubs_35_3i_e.html.
Overview
Common Information Model
To help reduce the system footprint and simplify deployment, ESXi does not
have a traditional service console management interface where Dell
OpenManage™ agents are installed. Instead, to provide the required hardware
manageability, VMware has incorporated standard Common Information
Model (CIM) management profiles into the virtualization software. The CIM
framework is an open standard that defines a framework on how managed
hardware elements in a server are represented. The CIM framework consists
of CIM providers developed by hardware vendors to enable monitoring and
managing of the hardware device. By representing the hardware elements
using standard CIM, ESX provides any management tool implementing the

6Systems Management Guide
same open standards the ability to manage the server. The hardware
management data is provided to management applications via CIM XML as
well as WSMAN.
VMware Infrastructure (VI) Client has been enhanced to provide hardware
health status of various hardware devices. VMware Infrastructure Client uses
CIM XML, a protocol to read hardware information provided by the CIM
providers. Each of the monitored hardware devices are listed along with the
health status. Future Dell Systems Management applications will make use of
WSMAN for hardware management on ESXi.
Simple Network Management Protocol
In addition to CIM, hardware health alerts are available through standard
Simple Network Management Protocol (SNMP) traps. Administrators may
now monitor and manage the hardware through any management application
that supports any of these standard protocols. Dell OpenManage IT Assistant
may be used to monitor the PowerEdge servers running ESXi through SNMP.
VMware has developed remote command line (RCLI) tool to configure the
SNMP agent in ESXi. This tool is available for download for Windows, Linux
and also as a Virtual Appliance. The RCLI tool can be downloaded from the
VMware website at www.vmware.com/download/vi/drivers_tools.html.
Remote Management
PowerEdge servers may also be remotely managed through the Dell Baseboard
Management Controller (BMC) and Dell Remote Access Controller
(DRAC). Both BMC and DRAC use the Intelligent Platform Management
Interface (IPMI) for out-of-band remote access. The BMC can be accessed by
using the BMC Management Utilities (BMU), a collection of software
applications that enable remote management of Dell systems equipped with
a BMC. BMU include the following components: IPMItool with Dell
extensions, IPMI Shell, and Serial-Over-LAN Proxy (SOL Proxy). IPMItool is
a CLI utility that helps in configuring and managing devices using the IPMI
version 1.5 and later. IPMItool supports out-of-band (OOB) remote access
(over a LAN or through the serial port) to a single system at a time. DRAC
can be accessed via its web served GUI as well as SSH and the racadm
command line interface. IT Assistant can be utilized in conjunction with the

Systems Management Guide 7
BMC’s IPMI over LAN interface for limited network discovery and health
monitoring. Its event console can also receive and act upon SNMP Platform
Event Traps (PETs) that are generated by the BMC.
Figure 1-1. Systems Management Overview With VMware ESXi
The following table lists the common use cases in systems management and
the tools used to perform the task:
Use Case Tools Needed
Deployment and
Configuration
VMware ESXi comes pre-installed on Dell PowerEdge servers.
There is no need to utilize the System Build and Update Utility
(SBUU) to install ESXi. Note that the SBUU does not create or
install Virtual Machine (VM) images.
The Dell Deployment Toolkit (DTK) and SBUU may be used to
configure the BIOS, storage, and DRAC prior to booting into
ESXi. The server can also be configured at boot time by pressing
<F2> to enter BIOS setup, <Ctrl><M> to configure the RAID
controller, and <Ctrl><E> to configure the BMC/DRAC
features.

8Systems Management Guide
NOTE: Each of these use cases and various operations for these use cases are
explained in detail in "Systems Management Use Cases" on page 11.
Install and Configure Systems Management
Components
First Boot Setup and Configuration
VMware ESXi comes pre-installed on supported Dell PowerEdge servers. For
steps to setup and configure ESXi on PowerEdge server, refer to VMware ESXi
Dell Solutions Guide at support.dell.com. Make sure that the DRAC is
configured as per the steps in the document.
Health
Monitoring
VI Client may be used to monitor the health information of
various hardware components. IT Assistant, DRAC, and the BMU
can also be used for limited health monitoring.
Alert Monitoring The event console feature of IT Assistant may be used to monitor
hardware and virtual machine traps generated from ESXi as well
as SNMP Platform Event Traps generated by the BMC.
Change
Management
SBUU may be used to update the BIOS and firmware of the PE
server. SBUU does not support updating of device drivers for ESXi
or virtual machines.
VMware update manager is used to update the ESXi image
which could contain updated device drivers for the system.
Troubleshooting,
Logging, and
Diagnostics
The system log and management agent log may be retrieved using
VI Client or may be viewed from the terminal.
The BMC System Event Log (SEL) is available using DRAC, IT
Assistant, or the BMU.
Diagnostics can be performed using Dell offline diagnostics tools.
Remote
Management
Dell Remote Access Controller (DRAC) provides lights out
remote management functionality.
Use Case Tools Needed

Systems Management Guide 9
Management Station Setup
The Management Station is the system from which one or more systems
running ESXi will be managed. The management station can also be used to
manage systems not running ESXi. The management station is required to
support some but not all of the identified use cases, and typically contains the
following set of management tools:
• IT Assistant
• Baseboard Management Utilities
• VMware Infrastructure Remote Command Line Interface (RCLI)
•
VMware Infrastructure Client
• VMware VirtualCenter Server (optional)
Based on number of systems and devices to be managed and the hardware
configuration of the management station, it may be desirable to install IT
Assistant and VirtualCenter Server on separate systems. Figure 1-2 shows the
various components required to manage ESXi on PowerEdge Servers.
Figure 1-2. Systems Management Components in VMware ESXi
Refer to the following documents to install and configure the management
tools:
• IT Assistant User's Guide: support.dell.com/support/edocs/software/
smitasst

10 Systems Management Guide
• Baseboard Management Utilities User's Guide:
support.dell.com/support/edocs/software/smbmcmu
• VMware Infrastructure Remote Command Line Interface (RCLI):
www.vmware.com/download/vi/drivers_tools.html
• VMware Infrastructure Client: www.vmware.com/support/pubs
• VMware VirtualCenter Server: www.vmware.com/support/pubs
ESXi Software Configuration
ESXi must be configured to enable monitoring of the server using SNMP. To
configure SNMP in ESXi:
1
Configure the SNMP settings in ESX Server by using VMware RCLI. The
following commands must be executed from the server where VMware
RCLI is installed:
a Configure the SNMP setting using the following command:
vicfg-snmp --server <ESX_IP_Address> --username
root --password <password> -c <community_name>
-t <ITAIP>@162/<community_name>
b Enable SNMP using the following command:
vicfg-snmp --server <ESX_IP_Address> --username
root --password <password> -E
c To view the SNMP configuration, execute the following command:
vicfg-snmp --server <ESX_IP_Address> --username
root --password <password> -s
2
Perform discovery and inventory of the server using IT Assistant.
a Perform discovery and inventory of the ESX server system interface
using SNMP
b Perform discovery and inventory of the DRAC interface using IPMI.
For more information, refer to the
IT Assistant User Guide at
www.support.dell.com/support/edocs/software/smitasst/ .
Once discovered, the ESX server is ready to be monitored using IT
Assistant. SNMP traps from the ESX server can be received in IT Assistant.

Systems Management Guide 11
3 Execute the following VMware RCLI command to verify that IT Assistant
is configured to receive SNMP traps from ESXi:
vicfg-snmp --server <ESX_IP_Address> --username
root --password <password> -T
Systems Management Use Cases
The following section describes how various system management tasks and
operations can be done in a VMware ESXi environment on PowerEdge
servers.
Discovery and Health Monitoring Using VI Client
VMware Infrastructure Client has been enhanced to provide hardware health
monitoring functionality with ESXi release. Health status of various hardware
components are listed under Configuration→Health Status. VMware
Infrastructure Client provides the health statuses for various hardware
components in the server. The health status is either green (normal), yellow
(warning), or red (critical). For some components the relevant hardware
reading is reported. The following is a list of components reported by the VI
Client:
• Individual Processor health status
• Memory health status
– Overall memory health status is reported. Health status at the
individual memory DIMM is not available in this release.
• Storage components health status
– Storage controller health information
– Health status of storage controller battery
– Health status of physical disks attached to the controller
– Health status of RAID volumes (virtual disks) attached to the
controller
– Health status of SAS PHY connections (or ports)
– Health status of various sensors for each physical disk

12 Systems Management Guide
• Power supply health status
– System level for system board status along with power consumed in
watts
– Power supplies health status along with power consumed in watts,
amps, and voltage
• Voltage sensor health status along with reading (if applicable)
• Health status for all the fans in the system along with RPM readings
• Ambient temperature of the server with status
•Software
– Versions for software components including Dell storage controller
driver firmware, VMware ESXi hypervisor, and Dell BIOS for the
PowerEdge server
• Health status of cable and interconnects
• Chassis intrusion status
• Watchdog timer status
• CMOS battery health status
VMware Infrastructure Client updates the health status by polling every
90 seconds. The heath status can be updated by clicking Refresh at the top
right of the screen. The Power Reading sensors can be reset by clicking Reset
Sensors at the top right of the screen.
To configure the hardware components and to change the threshold of
supported components, refer to "Advanced System Configuration" on
page 14.
Alert Monitoring
IT Assistant can be configured to receive traps from ESXi. SNMP traps are
generated by the server for the following:
1
Hardware Event Alerts:
a For each of the component listed in the previous section, an SNMP
trap is generated when status goes from green to yellow or green to
red. These traps are generated by the ESXi software and delivered
through the ESXi
Management Network .

Systems Management Guide 13
b SNMP Platform Event Traps (PETs) are generated using IPMI for
hardware events. These traps are generated by the DRAC and
delivered through the DRAC network interface.
2 Virtual Machine Operations Alerts:
a For virtual machine operations such as VM power-on and VM power-
off, SNMP traps are generated. These traps are generated by the ESXi
software and delivered through the ESXi
Management Network .
Change Management
Dell System Build and Update Utility (SBUU) provides a utility to perform
BIOS and firmware updates on the server. SBUU is a bootable CD that ships
with every PowerEdge server. The latest ISO image can be downloaded from
support.dell.com. The PE server can be booted with SBUU, which has
options to update the BIOS and firmware. The actual update files are
available in Server Update Utility (SUU) DVD, which can be downloaded
from support.dell.com.
To perform BIOS and firmware updates to VMware ESXi using SBUU:
1
Migrate the VMs running on the server that requires update to another
server using VMware VMotion technology. When VMotion is not
configured, either power off the VMs or suspend the VMs as appropriate
and perform a cold migration.
2 Shutdown the ESXi using VI Client or through the terminal user interface.
3 Boot the server using the bootable SBUU media.
4 Select the option to update the firmware and follow the wizard. Insert the
SUU DVD when required and perform the updates.
5 Once the server is updated, reboot the server to ESXi.
The VMs can now be powered on or migrated back to this server.
BIOS and firmware updates can also be downloaded from support.dell.com
as individual files. To perform the update, download the file and copy the
contents to a DOS-bootable diskette. Boot the server from the diskette and
run the update program.
Using IT Assistant to install the BIOS and firmware updates to PowerEdge
servers running VMware ESXi software is not supported.

14 Systems Management Guide
For the steps to upgrade the ESXi software, refer to the VMware ESXi Dell
Solutions Guide at support.dell.com.
Troubleshooting, Logging, and Diagnostics
The system log, management log, and storage controller log can be viewed
from the terminal.
In addition to viewing, log files can also be retrieved and provided to Dell or
VMware support using the VI Client.
Using DRAC or IT Assistant, the System Event Log (SEL) can be obtained and
viewed. The SEL can be viewed using the IPMItool utility:
ipmitool -I lan -H<DRAC_IP_Address> -U <username> -P
<password> sel list.
Remote Management
Dell Remote Access Controller (DRAC) is designed to allow anywhere,
anytime "Lights Out" monitoring, troubleshooting, and server
repairs/upgrades independent of the operating system status. Remote Access
Controller is supported in VMware ESXi. For more information, refer to the
Dell Remote Access Controller Users Guide at
support.dell.com/support/edocs/software/smdrac3.
Advanced System Configuration
This section describes some of the commonly performed hardware
configuration operations on the server and steps to perform such operations.
BIOS Configuration
BIOS configurations are performed by pressing <F2> during the boot
process. DTK tools can be used to configure BIOS on multiple servers.
Configuring the BIOS while ESXi is running is not supported.
Storage Configuration
Storage configurations, including creating and configuring RAID volumes,
hot spares etc, are performed by pressing <Ctrl><R> during the boot
process and invoking the OptionROM menu.
Configuring the storage while ESXi is running is not supported.

Systems Management Guide 15
Front Panel LCD Settings
Using the IPMItool utility on the OpenManage CD, invoke the ipmitool
command to get and set front panel LCD information. For the various
options available, use:
ipmitool -I lan -H <DRAC_IP_Address> -U <username> -P
<password> delloem lcd help
To identify a particular server in a rack of servers, use the following command:
ipmitool -I lan -H <DRAC_IP_Address> -U <username> -P
<password> chassis identify
This command will blink the LCD for 15 seconds.
Ambient Temperature Configuration
VMware Infrastructure client reports ambient temperature. Alerts will be
generated when the ambient temperature breaches the threshold values. Use
the following ipmitool command to change the default thresholds values.
To learn about the various options supported, use the following command:
ipmitool -I lan -H <DRAC_IP_Address> -U root -P
<password> sensor thresh "Ambient Temp" help
Other Sensor Values
The ipmitool command can also be used to report other sensor
information in the server. To learn about the various options supported, use
the following command:
ipmitool -I lan -H <DRAC_IP_Address> -U root -P
<password> sensor help
Accessing Sensor Values Remotely
Use the following ipmitool command to access the sensor values of ESXi:
ipmitool –I lan –H <DRAC_IP_Address> -U root –P
<password> sdr
where sdr stands for Sensor Data Records.
Similarly, there are multiple options to get different BMC values using
ipmitool. See the manpage of ipmitool for more details.

16 Systems Management Guide
TROUBLESHOOTING AND KNOWN ISSUES
This section describes known issues and workarounds.
IT Assistant
Problem Description Resolution
IT Assistant
categorizes the
server as
“Unknown”
IT Assistant lists the ESXi
under ‘Unknown’ category in
the Devices hierarchy.
This occurs when the
DRAC/BMC is not discovered
and inventoried by IT Assistant.
Make sure that the
DRAC/BMC interface is
appropriately configured and
the IP address is added to the
range that IT Assistant queries
for IPMI based discovery.
IT Assistant does
not list the server
under “VMware
ESX Server”
category
IT Assistant lists the ESXi
under ‘Servers’ category in the
Devices hierarchy and not
under “VMware ESX Server”.
This is a known issue for this
release. VMware ESXi does not
have all the MIBs implemented.
IT Assistant
SNMP shows up
as unknown
SNMP traps from IT Assistant
are not categories and are listed
as “Unknown”.
This issue is seen in IT
Assistant version 8.1. Update to
IT Assistant version 8.2 or later.
IT Assistant does
not report server
hardware
information under
“Device details”
IT Assistant does not
enumerate all the hardware
information under “Device
details”. It does not perform an
inventory of ESXi.
Hardware inventory of ESXi is
not supported. On a typical
server hardware configuration,
inventory is made available by
OpenManage agents running
on the PE server. OpenManage
Server Administrator agents are
not supported in ESXi and
hence hardware inventory using
IT Assistant is not supported.

Systems Management Guide 17
Storage
Problem Description Resolution
Health status of
components in
MD1000/MD1120
is not available in
VI Client
Health status of hardware
components like fans,
controller, and power supply of
MD1000/MD1120 is not
available in VI Client.
MD1000/MD1120 is not
supported with ESXi. Health
status of hardware components
of MD1000/MD1120 is not
implemented in ESXi.
RAID10 virtual
disks show up as
"RAID Level
Unknown" in VI
Client
The RAID level 10 is shown as
"RAID Level Unknown" Logical
Volume in VI Client.
This is a known issue with this
release of ESXi.
PERC Battery
health status is
not properly
reported in VI
Client
When battery health status
becomes critical, the battery
status sensor is removed from
the VI Client.
This is a known issue with this
release of ESXi.
VI Client does not
report Critical
Array Assert for
the removed drive
on PE1950
When a drive is removed from a
configured Logical Disk in SAS
6i/R, VI Client does not show
the Critical Array Assert for the
failed drive.
This is a known issue with this
release of ESXi.
VI Client reports
Critical Array
Assert for all
physical drives in a
logical volume if
one physical drive
fails
VI Client reports Critical Array
Assert for all physical drives in a
logical volume if one physical
drive fails.
This is a known issue with this
release of ESXi.

18 Systems Management Guide
VI Client does not
report memory
error conditions in
PE805
Memory health status is shown
as green even if System Event
Log (SEL) files show the error
"Mem ECC Warning: Memory
sensor, transition to critical
from less severe (DIMM_B4)
was asserted".
This is a known issue with this
release of ESXi. Memory failure
errors can be seen from the
"System Event Log (SEL)"
section of the DRAC webpage.
The SEL files can also be
viewed by going to https://<IP
address of ESX Server
host>/host/ipmi_sel. This
might not be the latest SEL
record.
VI Client reports
"Rebuild in
Progress" assert for
all the physical
drives on SAS6i/R
controller
When a rebuild is occurring for
a single drive on a SAS6i/R
controller, all of the drives are
shown as Rebuild In Progress
Assert.
This is a known issue with this
release of ESXi.
Storage
Problem Description Resolution

Systems Management Guide 19
APPENDIX
Systems Management Features Comparison between ESX Software with
OpenManage and ESXi Software
This section compares the system management capabilities of ESX Server 3
with OpenManage and ESXi.
Systems Management
Feature
ESX Server 3 with
OpenManage
ESXi
Deployment
Configuring the BIOS,
storage, and DRAC
Supported by boot time
utilities and DTK.
Supported by boot time
utilities and DTK.
Installing ESX Server
software
Supported by SBUU. Not required. ESXi is pre-
installed in the server.
Installing OpenManage
software after the
installation of ESX
Supported through the
OpenManage media or
through IT Assistant.
OpenManage Server
Administrator is not
supported in ESXi.
Systems Management
Feature
ESX ESXi
Health Monitoring
Processor health status Available through
OpenManage Server
Administrator.
Available through VI
Client.
System battery status Available through
OpenManage Server
Administrator and DRAC.
Available through VI Client
and DRAC.
Fan status with RPM
reading
Available through
OpenManage Server
Administrator and DRAC.
Available through VI Client
and DRAC.
Intrusion Available through
OpenManage Server
Administrator and DRAC.
Available through VI Client
and DRAC.

20 Systems Management Guide
Memory Individual memory status is
available through
OpenManage Server
Administrator.
Overall memory status is
available in VI Client.
Individual memory status is
not available through VI
Client.
Network Connectivity Available through
OpenManage Server
Administrator.
Available through VI
Client.
Power Supply Status
including power consumed
in amps, voltage and watts,
with power statistics
Available through
OpenManage Server
Administrator and DRAC.
Available through VI Client
and DRAC. Power statistics
can be reset using
ipmitool.
Ambient Temperature with
threshold settings
Available through
OpenManage Server
Administrator.
Available through VI
Client. Threshold values
and configuration are
available only through
ipmitool.
Voltage status CPU, riser, and several
system board voltages are
available through
OpenManage Server
Administrator.
Available through VI Client
and DRAC.
Storage:
Battery status Battery status including
battery state, predicted
capacity size, learn state,
next learn time, maximum
learn delay, and configuring
learn tasks are available in
OpenManage Server
Administrator.
Battery status is available in
VI Client.
Battery state, predicted
capacity size, learn state,
next learn time, maximum
learn delay, and configuring
learn tasks are not available
in VI Client.
Controller status Available through
OpenManage Server
Administrator.
Available through VI
Client.
Systems Management
Feature
ESX ESXi
Health Monitoring (continued)
