Dell PowerEdge XR5610 Manual

Dell PowerEdge XR5610
Installation and Service Manual
Regulatory Model: E72S
Regulatory Type: E72S002
May 2023
Rev. A00

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid
the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2023 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc. or its
subsidiaries. Other trademarks may be trademarks of their respective owners.

Chapter 1: About this document.................................................................................................... 7
Chapter 2: PowerEdge XR5610 system configurations and features.............................................. 8
System configurations - front view for PowerEdge XR5610....................................................................................9
System configurations - rear view for PowerEdge XR5610....................................................................................12
Bezel view............................................................................................................................................................................15
Bezel overview..............................................................................................................................................................16
Status LED control panel................................................................................................................................................. 18
Power button control panel.............................................................................................................................................19
System configurations - inside view for PowerEdge XR5610................................................................................20
Locating the Express Service Code and Service Tag............................................................................................... 21
System information labels............................................................................................................................................... 23
Rail sizing and rack compatibility matrix...................................................................................................................... 27
Chapter 3: Technical specifications.............................................................................................28
Chassis dimensions........................................................................................................................................................... 29
System weight................................................................................................................................................................... 30
Processor specifications..................................................................................................................................................30
PSU specifications............................................................................................................................................................ 30
Supported operating systems........................................................................................................................................ 32
Cooling fans specifications............................................................................................................................................. 32
System battery specifications........................................................................................................................................32
Expansion card riser specifications............................................................................................................................... 32
Memory specifications..................................................................................................................................................... 33
Storage controller specifications...................................................................................................................................33
Drives specifications.........................................................................................................................................................34
Ports and connectors specifications............................................................................................................................ 34
USB ports specifications........................................................................................................................................... 34
Display port specifications.........................................................................................................................................34
GPU specifications......................................................................................................................................................34
iDRAC9 port specifications....................................................................................................................................... 35
Serial connector specifications................................................................................................................................ 35
RJ45 dry contact.........................................................................................................................................................35
NIC port specifications...............................................................................................................................................36
Video specifications.......................................................................................................................................................... 37
Environmental specifications.......................................................................................................................................... 37
Particulate and gaseous contamination specifications.......................................................................................39
Rugged certifications and specifications...............................................................................................................40
Thermal restriction matrix......................................................................................................................................... 40
Chapter 4: Initial system setup and configuration........................................................................44
Setting up the system......................................................................................................................................................44
iDRAC configuration......................................................................................................................................................... 44
Options to set up iDRAC IP address.......................................................................................................................44
Contents
Contents 3

Options to log in to iDRAC........................................................................................................................................ 45
Resources to install operating system......................................................................................................................... 46
Options to download drivers and firmware ..........................................................................................................46
Options to download and install OS drivers .........................................................................................................47
Downloading drivers and firmware.......................................................................................................................... 47
Chapter 5: Pre-operating system management applications........................................................ 48
System Setup.....................................................................................................................................................................48
System BIOS.................................................................................................................................................................49
iDRAC Settings............................................................................................................................................................ 68
Device Settings............................................................................................................................................................68
Service Tag Settings.................................................................................................................................................. 68
Dell Lifecycle Controller...................................................................................................................................................68
Embedded system management..............................................................................................................................68
Boot Manager.................................................................................................................................................................... 68
PXE boot............................................................................................................................................................................. 69
Chapter 6: Minimum to POST and system management configuration validation......................... 70
Minimum configuration to POST ..................................................................................................................................70
Configuration validation................................................................................................................................................... 70
Error messages............................................................................................................................................................. 71
Chapter 7: Installing and removing system components ..............................................................72
Safety instructions............................................................................................................................................................ 72
Before working inside your system ..............................................................................................................................73
After working inside your system.................................................................................................................................. 73
Recommended tools......................................................................................................................................................... 73
Front bezel.......................................................................................................................................................................... 74
Removing the front bezel.......................................................................................................................................... 74
Installing the front bezel............................................................................................................................................ 75
Bezel filter........................................................................................................................................................................... 76
Removing the bezel filter for Rear Accessed configuration..............................................................................77
Installing the bezel filter for Rear Accessed configuration................................................................................78
System cover......................................................................................................................................................................78
Removing the system cover..................................................................................................................................... 78
Installing the system cover....................................................................................................................................... 80
Air shroud............................................................................................................................................................................ 82
Removing the air shrouds..........................................................................................................................................82
Installing the air shrouds............................................................................................................................................83
Cooling fans........................................................................................................................................................................85
Removing the cooling fan..........................................................................................................................................85
Installing the cooling fan............................................................................................................................................85
Intrusion switch................................................................................................................................................................. 86
Removing the intrusion switch module.................................................................................................................. 86
Installing the intrusion switch module.................................................................................................................... 87
Drives................................................................................................................................................................................... 88
Removing a drive blank.............................................................................................................................................. 88
Installing the drive blank............................................................................................................................................ 89
Removing the drive carrier........................................................................................................................................90
4Contents

Installing the drive carrier..........................................................................................................................................90
Removing the drive from the drive carrier.............................................................................................................91
Installing the drive into the drive carrier................................................................................................................92
Drive backplane..................................................................................................................................................................94
Drive backplane............................................................................................................................................................94
Removing the drive backplane................................................................................................................................. 94
Installing the drive backplane ..................................................................................................................................95
Cable routing...................................................................................................................................................................... 96
System memory............................................................................................................................................................... 105
System memory guidelines......................................................................................................................................105
General memory module installation guidelines..................................................................................................106
Removing a memory module................................................................................................................................... 107
Installing a memory module..................................................................................................................................... 107
Processor and heat sink module.................................................................................................................................. 109
Removing the processor and heat sink module..................................................................................................109
Removing the processor and extended heat sink module.................................................................................111
Removing the processor from the processor heat sink module .................................................................... 113
Installing the processor into a processor heat sink module ............................................................................ 114
Installing the processor and heat sink module.....................................................................................................118
Installing the processor and extended heat sink module................................................................................. 120
Expansion cards and expansion card risers...............................................................................................................122
Expansion card installation guidelines...................................................................................................................123
Removing the expansion card risers......................................................................................................................127
Installing the expansion card risers........................................................................................................................128
Removing an expansion card from the expansion card riser...........................................................................128
Installing an expansion card into the expansion card riser............................................................................... 131
M.2 SSD module...............................................................................................................................................................133
Removing the BOSS N1 card.................................................................................................................................. 133
Installing the BOSS N1 card.....................................................................................................................................133
Removing M.2 SSD module..................................................................................................................................... 134
Installing M.2 SSD module....................................................................................................................................... 135
System battery ................................................................................................................................................................136
Replacing the system battery.................................................................................................................................136
Power supply unit............................................................................................................................................................ 138
Hot spare feature.......................................................................................................................................................138
Removing a power supply unit blank.....................................................................................................................138
Installing a power supply unit blank.......................................................................................................................139
Removing a power supply unit................................................................................................................................139
Installing a power supply unit...................................................................................................................................141
Power distribution board................................................................................................................................................142
Removing power interposer board (PIB)............................................................................................................. 142
Installing the power interposer board (PIB)........................................................................................................ 143
Optional OCP card...........................................................................................................................................................144
Removing the OCP riser...........................................................................................................................................144
Installing the OCP riser.............................................................................................................................................145
Removing an OCP card............................................................................................................................................ 146
Installing an OCP card...............................................................................................................................................147
Removing the OCP filler...........................................................................................................................................148
Installing the OCP card filler................................................................................................................................... 149
System board....................................................................................................................................................................150
Contents 5

Removing the system board................................................................................................................................... 150
Installing system board..............................................................................................................................................151
Trusted Platform Module...............................................................................................................................................154
Upgrading the Trusted Platform Module............................................................................................................. 154
Initializing TPM for users......................................................................................................................................... 155
Initializing the TPM 1.2 for users............................................................................................................................155
Initializing the TPM 2.0 for users...........................................................................................................................155
Control panel.................................................................................................................................................................... 156
Removing the status LED control panel for Rear Accessed configuration................................................. 156
Installing the status LED control panel for Rear Accessed configuration ...................................................157
Removing the status LED control panel for Front Accessed configuration................................................158
Installing the status LED control panel for Front Accessed configuration .................................................159
Removing the power button control panel for Rear Accessed configuration.............................................160
Installing the power button control panel for Rear Accessed configuration................................................161
Removing the power button control panel for Front Accessed configuration........................................... 162
Installing the power button control panel for Front Accessed configuration............................................. 163
Chapter 8: MIL 901E and MIL 461G rugged kit............................................................................ 165
Installing the MIL 901E and MIL 461G rugged kit.................................................................................................... 165
Chapter 9: Jumpers and connectors........................................................................................... 167
System board jumpers and connectors .....................................................................................................................167
System board jumper settings......................................................................................................................................168
Disabling a forgotten password....................................................................................................................................169
Chapter 10: System diagnostics and indicator codes.................................................................. 170
Power button LED........................................................................................................................................................... 170
Bezel LED........................................................................................................................................................................... 171
Status LED indicators...................................................................................................................................................... 171
System health and system ID indicator codes..........................................................................................................173
iDRAC Direct LED indicator codes...............................................................................................................................174
NIC indicator codes......................................................................................................................................................... 174
Power supply unit indicator codes...............................................................................................................................175
Drive indicator codes.......................................................................................................................................................177
Using system diagnostics...............................................................................................................................................177
Dell Embedded System Diagnostics...................................................................................................................... 178
Chapter 11: Getting help.............................................................................................................179
Recycling or End-of-Life service information........................................................................................................... 179
Contacting Dell Technologies....................................................................................................................................... 179
Accessing system information by using QRL............................................................................................................ 179
Quick Resource Locator for PowerEdge XR5610 system............................................................................... 180
Receiving automated support with Secure Connect Gateway (SCG)................................................................ 181
Chapter 12: Documentation resources........................................................................................ 182
6Contents

About this document
This document provides an overview about the system, information about installing and replacing components, diagnostic tools,
and guidelines to be followed while installing certain components.
1
About this document 7

PowerEdge XR5610 system configurations
and features
The PowerEdge XR5610 system is a 1U server that supports:
●Rear Accessed configuration or Front Accessed configuration
●One Intel Xeon Scalable and Edge-Enhanced processor with up to 32 cores
●8 DDR5 DIMM slots
●Two redundant AC or DC power supply units
●Up to 4 x 2.5-inch SAS, SATA, or NVMe SSD drives
NOTE: The Rear Accessed and Front Accessed configurations cannot be modified into the other configuration.
NOTE: For more information about how to hot swap NVMe PCIe SSD U.2 device, see the Dell Express Flash NVMe
PCIe SSD User's Guide at https://www.dell.com/support > Browse all products > Infrastructure > Data Center
Infrastructure > Storage Adapters & Controllers > Dell PowerEdge Express Flash NVMe PCIe SSD > Select This
Product > Documentation > Manuals and Documents.
NOTE: All instances of SAS, SATA drives are referred to as drives in this document, unless specified otherwise.
NOTE: Only use certified Optical Fiber Transceiver Class | Laser Products.
CAUTION: Do not install GPUs, network cards, or other PCIe devices on your system that are not validated
and tested by Dell. Damage caused by unauthorized and invalidated hardware installation will null and void the
system warranty.
Topics:
•System configurations - front view for PowerEdge XR5610
•System configurations - rear view for PowerEdge XR5610
•Bezel view
•Status LED control panel
•Power button control panel
•System configurations - inside view for PowerEdge XR5610
•Locating the Express Service Code and Service Tag
•System information labels
•Rail sizing and rack compatibility matrix
2
8 PowerEdge XR5610 system configurations and features

System configurations - front view for PowerEdge
XR5610
Figure 1. Front view of the Front Accessed configuration with front bezel
Figure 2. Front view of the Front Accessed configuration without front bezel
Table 1. Features available on the front view of Front Accessed configuration
Item Ports, panels, or slots Icon Description
1 Power button Indicates if the system is
powered on or off. Press
the power button to manually
power on or off the system.
2 iDRAC Direct (Micro USB) The iDRAC Direct (Micro-AB
USB) port enables you to
access the iDRAC direct
Micro-AB USB features.
For more information, see
the Integrated Dell Remote
Access Controller User's
Guide at www.dell.com/
poweredgemanuals.
3 iDRAC dedicated port It is a RJ-45 port.
PowerEdge XR5610 system configurations and features 9

Table 1. Features available on the front view of Front Accessed configuration(continued)
Item Ports, panels, or slots Icon Description
Enables you to remotely
access iDRAC. For
more information, see
the iDRAC User’s
Guide at www.dell.com/
poweredgemanuals.
4 Optional OCP 3.0 N/A The OCP NIC card supports
OCP 3.0. The NIC ports are
integrated on the OCP card
which is connected to the
OCP riser.
5 PCIe expansion card riser 3
(slot 1 and 2)
N/A Enables you to connect PCIe
expansion card installed on
riser 3
6 Power supply unit (PSU1 and
PSU2)
Indicates the PSU1 or primary
PSU.
7Mini Express Service Tag
(MEST)
N/A The Mini Express Service Tag
(MEST) is a sticker on the
metal plate that contains the
system service tag.
84 x 25 GbE LOM ports N/A Provides network connectivity
and can also be shared with
iDRAC when iDRAC network
settings is set to shared
mode.
9 Serial port Enables you to connect a
serial device to the system.
NOTE: The serial port is
a micro USB type port.
It only supports serial
connection functions.
The serial port does
not support any USB
functions.
10 Mini-DisplayPort Enables you to connect a
display device to the system.
11 USB 3.0 port This port is USB 3.0-
compliant.
12 RJ45 Dry Input N/A It is a RJ-45 Dry Input port.
Enhance penetration in IoT
space. These are interruptible
inputs to iDRAC. Dry means
no energy is supplied to the
contacts.
13 System identification button Press the system ID button:
●To locate a particular
system within a rack.
●To turn the system ID on
or off.
To reset iDRAC, press and
hold the button for more than
16 seconds.
NOTE:
10 PowerEdge XR5610 system configurations and features

Table 1. Features available on the front view of Front Accessed configuration(continued)
Item Ports, panels, or slots Icon Description
●To reset iDRAC using
system ID, ensure that
the system ID button is
enabled in the iDRAC
setup.
●If the system stops
responding during
POST, press and hold
the system ID button
(for more than 5
seconds) to enter the
BIOS progress mode.
Figure 3. Front view of the Rear Accessed configuration with front bezel
Figure 4. Front view of the Rear Accessed configuration without front bezel
Table 2. Features available on the front view of Rear Accessed configuration 
Item Ports, panels, and slots Icon Description
1 Status LED control panel N/A Contains the system health,
system ID, status LED.
●Status LED: Enables you
to identify any failed
hardware components.
There are up to five
status LEDs and an
PowerEdge XR5610 system configurations and features 11

Table 2. Features available on the front view of Rear Accessed configuration (continued)
Item Ports, panels, and slots Icon Description
overall system health
LED (Chassis health and
system ID) bar. For
more information, see
the Status LED indicators
section.
2 Drives N/A Enables you to install up to 4
x 2.5-inch SAS/SATA/NVMe
SSD drives.
3 Express service tag N/A The Express service tag is
a slide-out label panel that
contains Service Tag, iDRAC
MAC address and LOM 1 MAC
address.
4 Power button Indicates if the system is
powered on or off. Press
the power button to manually
power on or off the system.
5 USB 2.0 port This port is USB 2.0-
compliant.
6 iDRAC Direct (Micro USB) The iDRAC Direct (Micro-AB
USB) port enables you to
access the iDRAC direct
Micro-AB USB features.
For more information, see
the Integrated Dell Remote
Access Controller User's
Guide at www.dell.com/
poweredgemanuals.
System configurations - rear view for PowerEdge
XR5610
Figure 5. Rear view of the Front Accessed configuration with no bezel
Table 3. Features available on the rear view of Front Accessed configuration
Item Ports, panels, and slots Icon Description
1 Status LED control panel N/A Contains the system health,
system ID, status LED.
12 PowerEdge XR5610 system configurations and features

Table 3. Features available on the rear view of Front Accessed configuration(continued)
Item Ports, panels, and slots Icon Description
●Status LED: Enables you
to identify any failed
hardware components.
There are up to five
status LEDs and an
overall system health
LED (Chassis health and
system ID) bar. For
more information, see
the Status LED indicators
section.
2 Drives N/A Enables you to install up to
4x 2.5-inch SAS/SATA/NVMe
SSD drives.
3 Express service tag N/A The Express service tag is
a slide-out label panel that
contains Service Tag, iDRAC
MAC address and LOM 1 MAC
address.
Figure 6. Rear view of the Rear Accessed configuration
Table 4. Features available on the front view of Front Accessed configuration
Item Ports, panels, or slots Icon Description
1 iDRAC dedicated port It is a RJ-45 port.
Enables you to remotely
access iDRAC. For
more information, see
the iDRAC User’s
Guide at www.dell.com/
poweredgemanuals.
2 Optional OCP 3.0 N/A Provides network connectivity
and can also be shared with
iDRAC when iDRAC network
settings is set to shared
mode.
3 PCIe expansion card riser 3
(slot 1 and 2)
N/A Enables you to connect PCIe
expansion card installed on
riser 3
4 Power supply unit (PSU1 and
PSU2)
Indicates the PSU1 or primary
PSU.
PowerEdge XR5610 system configurations and features 13

Table 4. Features available on the front view of Front Accessed configuration(continued)
Item Ports, panels, or slots Icon Description
5Mini Express Service Tag
(MEST)
N/A The Information tag a sticker
that contains Service Tag and
Express Service Code
6 4 x 25 GbE LOM ports N/A Provides network connectivity
and can also be shared with
iDRAC when iDRAC network
settings is set to shared
mode.
7 Serial port Enables you to connect a
serial device to the system.
NOTE: The serial port is
a micro USB type port.
It only supports serial
connection functions.
The serial port does
not support any USB
functions.
8 Mini-DisplayPort Enables you to connect a
display device to the system.
9 USB 3.0 port This port is USB 3.0-
compliant.
10 RJ45 Dry Input N/A It is a RJ-45 Dry Input port.
Enhance penetration in IoT
space. These are interruptible
inputs to iDRAC. Dry means
no energy is supplied to the
contacts.
11 System identification button Press the system ID button:
●To locate a particular
system within a rack.
●To turn the system ID on
or off.
To reset iDRAC, press and
hold the button for more than
16 seconds.
NOTE:
●To reset iDRAC using
system ID, ensure that
the system ID button is
enabled in the iDRAC
setup.
●If the system stops
responding during
POST, press and hold
the system ID button
(for more than 5
seconds) to enter the
BIOS progress mode.
14 PowerEdge XR5610 system configurations and features

Bezel view
Figure 7. Bezel for the Rear Accessed configuration
Table 5. Bezel for the Rear Accessed configuration
Item Indicator, button, or
connector
Description
1 Bezel filter Provides protection from sand and dust.
NOTE: To maintain optimal system health, Dell recommends checking and
changing the filter every three months. Filters can be ordered from Dell.
2 Bezel key lock Locking mechanism for the bezel. The bezel comes with a key.
3 Bezel LED indicator System health indicator.
4 Bezel release button When pressed, the bezel will unlock from the system.
5 Bezel filter release button Bezel filter button is pressed to release the bezel filter.
Figure 8. Bezel for the Front Accessed configuration
NOTE: Without the front bezel, Front Accessed configuration support racks with 80 mm spacing from rack ear of chassis
to inside surface of rack door. With the front bezel installed, the Front Accessed configuration system support racks with
100 mm spacing from rack ear of chassis to inside surface of the rack door
Table 6. Bezel for the Front Accessed configuration
Item Indicator, button, or
connector
Description
1 Bezel filter Provides protection from sand and dust.
NOTE: To maintain optimal system health, Dell recommends checking and
changing the filter every three months. Filters can be ordered from Dell.
2 Bezel key lock Locking mechanism for the bezel. The bezel comes with a key.
3 Bezel LED indicator System health indicator.
4 Pressure sensor Indicates when to replace the filter.
NOTE: The pressure sensor device is located behind the bezel.
5 Bezel release button When pressed, the bezel will unlock from the system.
6 Bezel filter release button Bezel filter button is pressed to release the bezel filter.
PowerEdge XR5610 system configurations and features 15

Bezel overview
Bezel filter
Figure 9. Bezel filter
The PowerEdge XR5610 has a front bezel that comes with a lock feature and a diagnostics LED. The bezel is designed with a
filter that provides protection against sand and dust.
Pressure sensor
The pressure sensor device on the front bezel is only available on the Front Accessed configuration systems. The pressure
sensor indicates when to replace the bezel filter in iDRAC. The connection between the pressure sensor with the XR5610
system is established through the POGO pin that connects the pressure sensor to the system chassis.
Filter modes
There are two filter modes available in the iDRAC when a bezel installed.
●Count Down mode
●Active Sensing mode
NOTE: Only available for the Front Accessed configuration with pressure sensor.
Count Down mode and Active Sensing mode is mutually exclusive, thus the user can activate either the Count Down mode or
the Active Sensing mode. Not both simultaneously in a single server. The sensor events can be enabled or disabled by using the
"Air filter alert" option. In the Active Sensing mode, the sensor events are triggered when a physical bezel is installed. The "Air
filter alert" option is disabled by default. When the option is disabled, iDRAC monitors the presence or absence of the filter. It
monitors the status of the filter.
Count Down mode
The Count Down mode works as follows:
●The alerts are sent out based on the filter life expiry date. iDRAC provides the following data for users to manage the filter:
NOTE: This mode can be used for passive or active bezel filters. It counts down when the system is switched on.
16 PowerEdge XR5610 system configurations and features

○Filter Change Interval — This attribute is configurable in months and set to 3 months by default. This option allows
users to configure filter change interval from 1 to 24 months.
○Filter Life Remaining — This attribute indicates the filter life span in days. The count down timer is activated when the
server is switched on. Once the it counts down to zero, the filter status goes to a degraded state.
○Reset Filter Life — Enable users to reset the filter life. This loads the Filter Life Remaining time with the current Filter
Change Interval time. The count down starts when the system is switched on. Enabling this option activates a system
log—BEZL0007.
●Readings and alerts:
○BEZL0003 filter dirty—indicates that a filter replacement is required. Occurs when the count down mode has reached
the time limit.
Figure 10. iDRAC interface of the Count Down mode
Active Sensing mode
The Active Sensing mode works as follows:
NOTE: This mode requires active bezel filter. An unsupported configuration indicates that the filter baseline is not
supported and generates an error log—BEZL0006.
●When enabled, the iDRAC monitors the filter pressure sensor to determine the filter status.
●Reset Filter Life — resets the filter reading and sets it as a baseline reading.
NOTE: Resets the clean filter baseline against which degradation is measured. This activates system log—BEZL0007.
●Scheduling Active Filter Check — Default Monday 3:00 AM. Fans run at full speed to get viable airflow reading. This
happens by default every Monday at 3.00am. User may change to the preferred time.
Table 7. Readings and alerts
System logs Description Action Severity
BEZL0001 The filtered bezel is removed from the
server.
No response required Severity -3 (Info)
BEZL0003 Air filter functionality in bezel is
degraded.
Replace the Air filter with a
cleaner air inlet.
Severity -2 (Warning)
BEZL0005 The filtered bezel is installed in the
chassis.
No response action required Severity -3 (Info)
PowerEdge XR5610 system configurations and features 17

Table 7. Readings and alerts(continued)
System logs Description Action Severity
BEZL0006 Air filter system detected unsupported
system configuration. Insufficient data
to take air flow
Check that all nodes are
installed and powered up.
Reset filter life with new filter
installed.
Severity -2 (Warning)
Figure 11. iDRAC interface of the Auto Sensing mode
Status LED control panel
Figure 12. Status LED control panel
Table 8. Status LED control panel
Item Indicator, button, or
connector
Icon Description
1 Status LED indicators NA Indicates the status of the system. For more information, see the
Status LED indicators section.
2 System health and system
ID indicator Indicates system health. For more information, see the System health
and system ID indicator codes section.
NOTE: For more information about the indicator codes, see the System diagnostics and indicator codes section.
18 PowerEdge XR5610 system configurations and features

Power button control panel
Figure 13. Power button control panel for Rear Accessed configuration
Table 9. Power button control panel
Item Indicator or button Icon Description
1 Power button Indicates if the system is powered on or off. Press the power button to
manually power on or off the system.
NOTE: Press the power button to gracefully shut down an ACPI-
compliant operating system.
2USB 2.0-compliant port The USB port is a 2.0-compliant. This port enables you to connect USB
devices to the system.
NOTE: The USB 2.0 port is not available on Front Accessed
configuration.
3iDRAC Direct port (Micro-
AB USB)
The iDRAC Direct port (Micro-AB USB) enables you to access the iDRAC
direct features. For more information, see the https://www.dell.com/
idracmanuals.
NOTE: You can configure iDRAC Direct by using a USB to micro USB
(type AB) cable, which you can connect to your laptop or tablet. Cable
length should not exceed 3 feet (0.91 meters). Performance could be
affected by cable quality.
4iDRAC Direct LED
indicator
N/A The iDRAC Direct LED indicator lights up to indicate that the iDRAC Direct
port is actively connected to a device.
NOTE: For more information see the Dell PowerEdge XR5610 Technical Specifications on the product documentation page.
Figure 14. Power button control panel for Front Accessed configuration
Table 10. Power button control panel
Item Indicator or button Icon Description
1 Power button Indicates if the system is powered on or off. Press the power button to
manually power on or off the system.
NOTE: Press the power button to gracefully shut down an ACPI-
compliant operating system.
2iDRAC Direct LED
indicator
N/A The iDRAC Direct LED indicator lights up to indicate that the iDRAC Direct
port is actively connected to a device.
PowerEdge XR5610 system configurations and features 19

Table 10. Power button control panel(continued)
Item Indicator or button Icon Description
3 iDRAC Direct port (Micro-
AB USB)
The iDRAC Direct port (Micro-AB USB) enables you to access the iDRAC
direct features. For more information, see the https://www.dell.com/
idracmanuals.
NOTE: You can configure iDRAC Direct by using a USB to micro USB
(type AB) cable, which you can connect to your laptop or tablet. Cable
length should not exceed 3 feet (0.91 meters). Performance could be
affected by cable quality.
NOTE: For more information see the Dell PowerEdge XR5610 Technical Specifications on the product documentation page.
System configurations - inside view for PowerEdge
XR5610
Figure 15. Inside the system - Rear Accessed configuration
1. OCP 3.0 card
2. System board
3. Processor and heat sink module
4. Memory DIMM sockets
5. Processor shroud
6. Cooling fans
7. Express service tag
8. Drive cage
9. Backplane
10. PCI air shroud
11. Power Interposer Board (PIB)
12. Power supply units
20 PowerEdge XR5610 system configurations and features
