HSX3320 Series
CONVECTOR
Instructions for use

23
A) If your appliance comes tted with a plug, it will incorporate a 13 Amp fuse. If it does not t your socket, the plug should be
cut o from the mains lead, and an appropriate plug tted, as below. WARNING: Very carefully dispose of the cut o plug
after removing the fuse: do not insert in a 13 Amp socket elsewhere in the house as this could cause a shock hazard.
With alternative plugs not incorporating a fuse, the circuit must be re-tted when changing the fuse using a 13 Amp Asta
approved fuse to BS 1362. In the event of losing the fuse cover, the plug must NOT be used until a replacement fuse cover
can be obtained from your nearest electrical dealer. The colour of the correct replacement fuse cover is that as marked on
the base of the plug.
B) If your appliance is not tted with a plug, please follow the instructions provided below:
Important
The wires in the mains lead are coloured in accordance with the following code:
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.
ELECTRICAL CONNECTION
J
JGK
GK
900mm (min.)
300mm(min.)
300mm
(min.)
600mm(min.)
400mm(min.)
400mm
“ ”
200mm
200mm
75mm
800mm 200mm
500mm
“ ”
I
H
4
56
Important - This appliance is Class II. If you have a 3-pin plug, do not connect any wire to the“earth”terminal.

3
23
F
1
A
B
C
E
D
2 X
2 X
2X
2 X
4X
4X
(F) 3,5x13 PH
G
H
I 3,5 X 9,5 PH
J 4,5 X 25 PH
K 6 X 30

45
IMPORTANT INFORMATION
Safety warnings
Danger!
Failure to observe the warning may result in life-threatening
injury by electric shock.
- The appliance must not be placed
immediately below a power socket.
- Do not use the heater close to bath,
wash-basin, shower and swimming
pool.
- If you intend to x your appliance to the
wall, make sure that the switch or other
control devices are not within reach of
persons in the bath or shower.
- If the power cable has been damaged, it
must be replaced by the manufacturer
or the service centre or by an expert
sta member so as to avoid all risks.
Important!
Failure to observe the warnings could result in injury or damage
to the appliance.
- The appliance can be used by children
at least 8 years old and by persons
with reduced physical, mental and
sensory capacities or with inadequate
experience and knowledge, as long
as they are carefully supervised or
instructed on how to safely use the
appliance and the hazards involved.
Make sure that children do not play
with the appliance. Cleaning and
maintenance performed by the user
must not be performed by children
without supervision.
- Children less than 3 years old should be
kept away from the appliance unless
continuously supervised.
- Children between 3 and 8 years old
may only switch the appliance on and
o, provided that it has been placed
or installed in its normal operating
position, they are carefully supervised
and instructed concerning use of
the appliance in a safe way and they
understand the hazards involved.
Children between 3 and 8 years old
should not insert the plug, adjust
and clean the appliance or perform
maintenance on it. ATTENTION: Some
parts of the appliance can become very
hot and cause burns. Pay particular
attention when children and vulnerable
persons are present.
- ATTENTION: to avoid any danger caused
by an accidental reset of the safety
system, this appliance must not be
powered through an external timer.
- Do not use the appliance in small rooms
when they are occupied by persons that
are not capable of leaving the room on
their own, unless constant supervision
is provided.
Danger of burns!
Failure to observe these warnings may cause burns.
- ATTENTION: to avoid overheating, do
not cover the appliance for any
reason during operation, this
would cause dangerous
overheating.
- Use of extension lead is not recommended as it could
overheat during operation of the appliance.
Note:
This symbol indicates recommendations and important
information for the user.
- Never use the appliance to dry laundry.
- Do not place the power cable on the appliance when it is
hot.
- For greater eciency position the device away from
draughts.
- Only use the heater in an upright position.
- The appliance must be positioned at a minimum distance
of 80cm from curtains or other movable objects sensitive
to heat.
- The rst time you use the appliance it may emit smells. It

5
is advisable to let it run for at least 15 minutes with the
thermostat at the maximum setting and then ventilate
the room. A little smoke may be emitted due to the
protective substances applied to the heating element
before transport.
- Do not position the appliance on deep-pile carpets or
rugs, to avoid obstruction to the air intake grille located
under it.
- Do not obstruct the hot air outlet grille or the air intake
grille on the bottom of the appliance.
- Position the appliance so that the plug and the power
socket can be easily reached after installation.
- Do not use this appliance in a room whose surface area is
less than 4 m2.
- An anti-tilt safety device turns the appliance o if it falls
over or is positioned inappropriately so as to jeopardise
safety. The appliance resumes operation after being
placed in an upright position again.
- The appliance is tted with a safety cuto device
which will switch the appliance o in case of accidental
overheating.
To reset the cuto, disconnect the plug from the power
socket for a few minutes, remove the cause of overheating
then reconnect the appliance. If this abnormal situation
happens several times, contact customer service.
This appliance conforms to the following EC directives:
- Low Voltage Directive 2006/95/EC and subsequent
amendments
- Directive 2004/108/EC on electromagnetic compatibility
(EMC) and subsequent amendments
Use in compliance with intended use
Use this heater only as described in this manual. All other
use is considered improper.
This appliance is not suitable for commercial use.
The manufacturer is not liable for damage deriving from
improper use of the appliance. This is a household appliance
only. It is not intended to be used in:
• staff kitchen areas in shops, offices and other working
environments;
• farm houses;
• by clients in hotels, motels and other residential type
environments;
• bed and breakfast type environments.
Use in this manner will invalidate the manufacturers
warranty.
Disposing of the appliance
The appliance must not be disposed of with household
waste but must be taken to an authorised waste
separation and recycling centre.
Fundamental recommendations regarding safety
Dear Customer – The plug on this appliance will get ‘warm’
during use, this is perfectly normal.
This product is A HIGH POWER HEATING APPLIANCE designed
to our usual high standards but please make sure your wall
sockets are in good condition and the plug is inserted
correctly to avoid any accidental overheating.
We suggest that you check the plug AND THE SOCKET
regularly if the heater is in prolonged use, if you are in any
doubt please consult an electrician.
DESCRIPTION
AWarning lamp
BThermostat
C Power selector
D Slider
E Timer
General instructions
Remove the appliance from the packaging.
Check that neither the appliance nor the power cable has
been damaged during transport. Do not operate the heater if
damaged.
Remove all publicity material from the appliance. The
appliance is suitable for free-standing or wall-mounted usage.
Do not assemble the feet if wall-mounted.
Electrical connection
- Before connecting the appliance to the power socket,
check that the voltage indicated on the appliance rating
plate is the same as your electrical system and that it can
support the power consumption (Watt) indicated.
- If more than one appliance is used at the same time, it is
important to ensure that the electrical system is able to
support the power required.
Use on the oor, feet assembly
Tools required:
Screwdriver PH2x100 (crosshead)
2 supplied screws 3.5x13 PH (F)
Place the appliance on a stable surface.
For mounting the feet, proceed as follows:
- Insert the two hooks in the slots and rotate the foot until
it is engaged as shown in gure 2.
- Insert the two pins in their respective holes.

67
- Fix the foot with the screw (F) supplied (gure 3).
- See Figure 4 for the minimum distances of the device
from the walls. The measurements are indicated both for
models equipped with fan " " and for models without.
Important! never use the appliance without the feet
attached if it is not mounted on the wall.
Installation on the wall
The kit for wall installation contains:
2 metal brackets for mounting above (G)
2 metal brackets for mounting below (H )
2 screws 3.5 x 9.5 PH (I )
4 screws 4.5 x 25 PH (J )
4 plastic wall plugs 6 x 30 ( K )
Tools required for installation and estimated time for
installation
Screwdriver PH 2x100 (crosshead)
Estimated time for installation: 30 minutes
Before installing the unit, ensure the following:
a. The device must not be placed directly under a
power socket.
b. The plug and power socket must be easy to reach
after installation.
c. No electric cables or other pipework could be
damaged during installation.
d. Keep away from curtains or ammable materials.
For wall mounting, proceed as follows:
Place the appliance on a stable surface. Use a screwdriver to x
the two brackets H with screws I as shown in Fig. 6.
1. Before drilling the wall, mark the exact spot, respecting
the minimum distances as shown in Fig. 5. The
measurements are indicated both for models equipped
with fan " " and for models without.
2. Drill following the marks that you have made and
insert the wall plugs K. For brick walls use a masonry
bit of 6 mm. For plasterboard or false walls (empty), we
recommend the use of appropriate screws and anchors
(not supplied).
3. Fix the 2 metal brackets G to the wall using the screws J
provided.
4. Hang the appliance on the brackets.
5. Mark the lower xing points corresponding to the holes
of the brackets H . Remove the appliance, drill the lower
holes and insert the wall plugs K .
6. Now you can hang the unit on the brackets and secure the
bottom of the appliance with the 2 screws J remaining.
USE
Operation and use
Insert the plug into the socket and switch on at the socket if
necessary, turn the thermostat knob (B ) to position 6 and turn
the appliance on via the power selector ( C ) as follows:
• The warning lamp ( A ) lights up.
• Turn the power selector knob to Min to select minimum
power.
• Turn the power selector knob to Med to select medium
power.
• Turn the power selector knob to Max to select maximum
power.
• To switch o the appliance completely: turn the power
selector to "0" and the thermostat to , then disconnect
at the power socket.
Adjusting the thermostat
When the room has reached the required temperature, turn the
thermostat knob (B) slowly anticlockwise until you hear a click
and no further. The warning lamp ( A ) goes out.
The thermostat will automatically maintain the temperature.
In spring or autumn or on mild days, you can save energy by
using minimum power.
Freezing protection
With the knob of the thermostat (B) in position and one
of the power levels selected, the appliance will maintain the
room at a temperature of about 5°C preventing freezing with
minimum energy consumption.
Models with fan
The appliance is equipped with a fan that provides even more
rapid and uniform heating.
To start this function, turn the power selector (C ) to Max .
Models with 24-hour timer
When the appliance is connected to the power supply the timer
is always active so as to stay synchronized with the local time.
To operate the appliance without timer, position the timer
slider (D ) to .
To operate the appliance at the times set, position the timer
slider to ( Fig. 1) and proceed as follows:
• Check the time on your clock or watch. If it is 10.00 for
example, turn the numbered programmer disk until the
number 10 coincides with the pointer marked on the
programmer device.
• Set the periods of time during which you want the
appliance to operate by pushing the teeth outwards (see
gure). Each tooth corresponds to a period of 30 min. At
the end of the procedure, the sectors corresponding to the

7
periods of operation will be visible.
• In this way, the appliance will function automatically
each day at the times set. (Important: the appliance must
always be connected to the power supply).
• To modify the settings, return the teeth to the initial
position and set the new operating periods.
• To turn the appliance o, turn the power selector to "0".
MAINTENANCE
Before carrying out any maintenance, disconnect the appliance
from the power supply and wait for it to cool down completely.
This appliance requires no particular maintenance.
It is sucient to remove dust with a soft, dry cloth. Never use
abrasive powders or solvents.
If necessary remove areas of concentrated dirt with a vacuum
cleaner.
TECHNICAL CHARACTERISTICS
Power supply See appliance rating plate
Power consumption "
PROBLEM CAUSE SOLUTION
The appliance doesn’t
work
The plug is not inserted properly into the po-
wer socket or the socket switch is o.
Check for any obstruction.
The power selector is in the ”0”position.
The thermostat is set too low.
Timer setting.
Insert the plug into the power socket and
switch on if necessary.
Remove the obstruction, disconnect the po-
wer plug of the heater and let the appliance
cool down. If the problem persists, contact
customer experience.
Move the power selector to position MIN, MED,
MAX or MAX .
Turn the thermostat knob clockwise to higher
settings until the heater restarts.
Make sure the timer is correctly set to local
time and check the position of the teeth.
TROUBLESHOOTING
