DeLonghi TCH8093ER User manual

5711411341/01.13_00
De’Longhi Appliances
via Seitz, 47
31100Treviso Italia
Instructions

CERAMIC FAN HEATERInstructions
TCH8093ER

2
A) If your appliance comes tted with a plug, it will incorporate a 13 Amp fuse. If it does not t your socket, the plug should
be cut o from the mains lead, and an appropriate plug tted, as below.
WARNING: Very carefully dispose of the cut o plug after removing the fuse: do not insert in a 13 Amp socket elsewhere
in the house as this could cause a shock hazard.
With alternative plugs not incorporating a fuse, the circuit must be protected by a 15 Amp fuse. If the plug is a moulded-
on type, the fuse cover must be re-tted when changing the fuse using a 13 Amp Asta approved fuse to BS 1362. In
the event of losing the fuse cover, the plug must NOT be used until a replacement fuse cover can be obtained from your
nearest electrical
dealer.The colour of the correct replacement fuse cover is that as marked on the base of the plug.
B) If your appliance is not tted with a plug, please follow the instructions provided below.
IMPORTANT
The wires in the mains lead are coloured in accordance with the following code:
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead may not correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
The blue wire must be connected to the terminal marked with the letter N or coloured black.The brown wire must be connec-
ted to the terminal marked with the letter L or coloured red. If you have a 3-pins plug, do not connect any wire to the
“earth” terminal.
- Voltage and wattage can be found on the rating label on the underside of the machine.
electrical connection (UK only)

3
Description
Fig. 1
Fig. A Fig. B Fig. C
H
G
I
J
A
B
C
D
E
F

4
INTRODUCTION
Thank you for choosing a De’Longhi Ceramic fan heater.
Please take a few minutes to read these instructions.
This will avoid all risks and damage to the appliance.
IMPORTANT SAFEGUARDS
- Do not use this heater near showers, bathtubs, sinks,
swimming pools, etc.
- Always use the heater in an upright position.
- Do not use the heater to dry laundry. Never obstruct the
intake and outlet grilles (danger of overheating).
The appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mentalcapabilities,orlackofexperienceandknowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure
that they do not play with the appliance.
- The heater must be positioned at least 50 cm from
furniture or other objects.
- Do not use the appliance near walls, furniture, curtains,
etc.
- To avoid risk of cable overheating, extension leads must
not be used in powering this appliance.
- If the power cable is damaged, it must be replaced by
the manufacturer, an authorised service centre or a
qualied electrician in order to eliminate all risk. Please
contact customer Experience, see enclosed guarantee
- The appliance must not be placed immediately under a
xed power socket.
- Do not use the appliance in rooms with a oor area of
less than 4 m².
- Before storing the appliance, check it is completely o
and the cable is unplugged. At this point wrap the cord
around the base. Do not store in a dusty room.The room
temperature should be between 0-30°C. Do not load
anything above it.
IMPORTANT: To avoid overheating, never under
any circumstances cover the appliance during
operation as this would lead to a dangerous rise in
temperature.
WARNING: to avoid the safety system resetting accidentally,
this appliance must not be powered through an external on/
o device such as a timer, or connected to a circuit which is
turned o and on regularly by the energy supplier.
Safety functions
-Safety device: the appliance is tted with a safety
device which switches it o in the event of accidental
overheating (e.g. obstruction of air intake and outlet
grilles, motor turning slowly or not at all).
To reset, unplug the appliance from the mains socket for
a few minutes, remove the cause of overheating then
plug in again.
-Tip over safety device: a tip over safety device turns
the appliance o if it falls over or is positioned inappro-
priately in such a way as to jeopardise safety.
The appliance emits a beep and a dot ashes on the di-
splay. The appliance resumes operation a few seconds
after being placed in an upright position again.
Disposing of the appliance
In compliance with European directive 2002/96/EC,
the appliance must not be disposed of with house-
hold waste, but taken to an authorised waste separa-
tion and recycling centre.
Important safeguards

5
Description/Use
DESCRIPTION
(see g. 1)
A ON/STAND-BY button
B +/- adjustment buttons
C MODE button (selects the operating mode)
D “ECO plus”button
E Timer button
F Swing button
G Remote control receiver
H Indicator light
I Air intake grille
J Filter
USE
Installation
- The appliance can be used on any horizontal surface.
Do not overload the electrical circuit. Avoid using the
same socket for other appliances.
Electrical connection
- Before connecting the plug to the power outlet,
make sure that the voltage of your electrical system
corresponds to the voltage shown on the appliance
rating label and the outlet you are going to use is in
good condition.
- THIS APPLIANCE COMPLIES WITH DIRECTIVE 2004/108/
EEC ON RADIO INTERFERENCE SUPPRESSION.
Mounting the base
- Fit the two parts of the base together, matching the
guide pins on the front with the recesses on the back
and snapping the two clips into place (g. A and g. B).
- Turn the appliance upside down and x the base to the
body with the 6 screws supplied (g. C).
Operation and use
1. Plug into the mains socket.
2. Theapplianceemitsabeep.Theindicatorlight(H)comes
on and remains lit while the appliance is powered.
3. The appliance switches to stand-by. A dot ashing on
thedisplaymeansthetipoverdevicehasbeenactivated.
See paragraph:“Safety functions”.
4. Press the ON/STAND-BY (A) to turn the appliance on.
It begins heating the room according to the current
settings.
5. Press the MODE button (C) to select one of the following
operating modes:
Fan
Freeze prevention
Heating 1
Heating 2
Heating 3
5.1 Fan
In this mode, only the fan operates and the appliance does
not heat the room.
5.2 Freeze prevention
In this mode, the appliance keeps the room at a temperature
of 7°C to avoid freezing.
5.3 Heating 1, 2 and Heating 3
In this mode, the desired temperature can be selected by
pressing the adjustment buttons + and – ( B ):
-Heating 1
The appliance operates at low power, reducing noise
levels and energy consumption to a minimum.
-Heating 2
The appliance operates at medium power.
-Heating 3
The appliance operates at high power to heat the room
rapidly.
6. “ECO plus” function
The “ECO plus” function is available in Heating 1, 2 and 3
modes only.
Toactivatethefunction,pressthe“ECOplus”button(D).When
this function is active the appliance automatically sets the
most appropriate power level to guarantee optimum comfort
while reducing energy consumption. While the “ECO plus”
function is active, the appliance may switch automatically to
a lower heating power than the one displayed.
7. To distribute the air ow over a wider surface, press the
swing button (F).The appliance starts swinging to
the right and left. To stop the appliance in the desired
position, simply press the swing button (F) again.
8. Toturntheapplianceo,presstheON/STAND-BY button
(A). The display may visualise a countdown for about 6
seconds.
Please note: Room temperature can be displayed in
either °C or °F. To change the unit of measurement for the
temperature, press and hold the + button for a few seconds,
then release.

6
Digital 24 h timer
This function can be activated from any operating mode.
Auto-start: with the appliance in STAND-BY, press the timer
button (E) . The symbol is displayed together with
the time remaining before the appliance comes on.To adjust
the timer, use the adjustment buttons + and - (B), then wait
a few seconds for the setting to be memorised. The stand-by
light(H)isdisplayedtogetherwith the symbol,indicating
that the timer has been set. When the programmed time
is reached, the appliance comes on with the settings used
during the previous period of operation.
Auto-o: with the appliance on, press the timer button
(E). The symbol is displayed together with the time
remaining before the appliance goes o.
To set the timer, use the adjustment buttons + and - (B),
then wait a few seconds for the setting to be memorised.
The current settings are displayed again, together with the
symbol indicating that the timer has been set.
When the programmed time is reached, the appliance goes
o automatically. To go back to operation without the timer,
press the timer button (E) twice.
The timer symbol disappears from the display.
Using the remote control
The functions on the remote control are the same as those on
the appliance control panel.
For a description of the functions, see the“Operation and use”
section on the previous page.
Inserting or replacing the batteries
The remote control is powered
by a CR2032 lithium battery.
To operate the remote control,
pull and remove the plastic
strip under the battery cover.
To replace the batteries,
remove the battery cover
by sliding it as shown in the
gure.
When replacing the batteries,
make sure you respect the
polarity (see gure 2).
Replace the cover as shown in the gure.
Old batteries are harmful to the environment and must
be removed and disposed of in compliance with current
legislation.
MAINTENANCE
- Always unplug from the mains socket before cleaning.
- During the season when the appliance is in use, clean
the air intake and outlet grilles regularly using a vacuum
cleaner.
- To clean the lter, remove the rear grille by pulling it
outwards (g. 1). Remove the dust lter which retains
impurities in the air drawn in from the room, blow on it
lightly then replace in the appliance.
- Never use abrasive powders or solvents to clean the
appliance.
TROUBLESHOOTING
If the appliance displays “PF” and emits a beep, the
temperature sensor is malfunctioning.
If the problem continues, contact customerexperience, see
enclosed guarantee.
If the appliance goes o unexpectedly:
- Make sure it is plugged in correctly to the mains socket.
- Make sure the appliance is standing upright on a at
surface, otherwise the tip over device may be activated.
- Check the temperature and timer settings.
The appliance may have gone o because the set
temperature has been reached or the time set on the
timer has elapsed.
TECHNICAL CHARACTERISTICS
Power supply See rating plate
Absorbed power “
Max Power 2400W
Use
Fig. 2
