DeLonghi TRRS Series User manual

De’Longhi Appliances via Seitz, 47 31100 Treviso Italia www.delonghi.com
5718510751/05.15_00

TRRS Series
OIL FILLED RADIATORS
Instructions for use

2
1
4
2
5
3
6

3
A
B
C
D

4
IMPORTANT WARNINGS
Safety warnings
Danger!
Failure to observe the warning may result in life threatening
injury by electric shock.
-This appliance can be used by children
aged from 8 years and above and per-
sons with reduced physical, sensory or
mental capabilities or lack of experi-
ence and knowledge if they have been
given supervision or instruction con-
cerning use of the appliance in a safe
way and understand the hazards in-
volved. Children shall not play with the
appliance. Cleaning and user mainte-
nance shall not be made by children
without supervision.
- Children of less than 3 years should be
kept away unless continuously super-
vised.
- Children aged from 3 years and less
than 8 years shall only switch on/o
the appliance provided that it has been
placed or installed in its intended nor-
mal operating position and they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children aged from 3 years
and less than 8 years shall not plug
in, regulate and clean the appliance or
perform user maintenance. CAUTION
— Some parts of this product can
become very hot and cause burns.
Particular attention has to be giv-
en where children and vulnerable
people are present.
- Do not use the appliance near show-
ers, bathtubs, sinks, swimming pools,
etc.
- If the power cable has been damaged,
it must be replaced by the manufac-
turer or the technical service centre or
by a qualied person so as to avoid all
risks.
- ATTENTION: in order to avoid any dan-
ger caused by an accidental resetting
of the safety system, this appliance
must not be powered through an ex-
ternal timer.
Important!
Failure to observe the warning could result in injury or dam-
age to the appliance.
-The appliance must not be located im-
mediately below a xed socket-outlet.
- The use of an extension lead is not recommended, as
overheating of the extension lead may occur during the
operation of the heater.
Danger of burns!!
Failure to observe the warning could result in burns or scalds.
- WARNING: In order to avoid
overheating, never under any
circumstances cover the appli-
ances during operation, as this would
lead to dangerous overheating.
Please note:
This symbol indicates recommendations and important infor-
mation for the user.
- Never use the heater to dry laundry.
- Never place the power cable on top of the heater while
it is hot.
- We recommend that you not place the heater in a
draught, because strong draughts of air may adversely
aect the equipment’s operational eciency.
- Only use the heater in an upright position.
- The heater must be positioned at least 30cm from furni-
ture or other objects.
- The rst time you use the appliance, operate it of at least
15 minutes with the thermostat at maximum to elimi-
nate the “new” smell. A little smoke due to the protec-
tive substances applied to the heating element before
transport may be given o.
- Position the appliance so that the plug and the outlet
can be easily reached even after installation.

5
- Do not use the appliance in rooms less than 4m2in
area.
- The appliance is tted with a safety device which will
switch o it in case of accidental overheating. To reset,
please contact Customer Experience, see enclosed guar-
antee.
The appliance complies with the following EC direc-
tives:
- LowVoltage Directive and subsequent amendments;
- EEC Directive on electromagnetic compatibility (EMC)
and subsequent amendments;
Use in compliance with intended use
Use this heater only as described in this manual. All other
use is considered improper.
This appliance is not suitable for commercial use.
The manufacturer is not liable for damage deriving from
improper use of the appliance. This is a household appliance
only. It is not intended to be used in:
• staff kitchen areas in shops, offices and other working
environments;
• farm houses;
• by clients in hotels, motels and other residential type
environments;
• bed and breakfast type environments.
Use in this manner will invalidate the manufacturers
warranty.
Disposing of the appliance
The appliance must not be disposed of with hou-
sehold waste, but taken to an authorised waste se-
paration and recycling centre.
INTRODUCTION
Thank you for choosing a De’Longhi product.
Please take a few minutes to read these instructions.
This will avoid all risks and damage to the appliance.
Fundamental recommendations regarding safety
Dear Customer – The plug on this appliance will get ‘warm’
during use, this is perfectly normal. This product is A HIGH
POWER HEATING APPLIANCE designed to our usual high
standards but please make sure your wall sockets are in
good condition and the plug is inserted correctly to avoid
any accidental overheating. We suggest that you check the
plug AND THE SOCKET regularly if the heater is in prolonged
use, if you are in any doubt please consult an electrician.
DESCRIPTION
(see figure on pag. 3).
A Thermostat
B Switches
C Cord holder
D Wheel
USE
Electrical connection
- Before plugging the radiator into the mains, check that
the voltage of your mains electricity supply corresponds
to the value V indicated on the appliance and that the
socket and power line are appropriately dimensioned.
- CONNECTTHE RADIATOR TO EFFICIENTLY EARTHED SOCK-
ETS ONLY.
- This appliance complies with directive on electromag-
netic compatibility.
Fitting the feet
Remove the feet and the castors from the polystyrene pack-
ing. Insert the threaded u-bolt as shown in gures 1, 2 and
3 and use wing nuts to x the feet to the bottom of the ra-
diator between the last two elements, then t the castors to
the spindles on the feet and push rmly until they click into
position (g. 4-5).
Pull each castor to check that it is tted correctly.
In certain models, the castors are already mounted on the
feet.
Models with “Easy wheel”sytem
Turn the radiator upside-down on a rug or a soft surface in
order to prevent damaging the paint nish.
Fully unfold the castors by turning them outwards (Fig.6).
Turn the radiator back to its upright position.
Important!
When in use, the radiator should always be kept vertical
(wheels at the bottom, controls at the top). Any other posi-
tion could be dangerous!
INSTRUCTIONS FOR USE
Switching on
Turn the thermostat dial clockwise to maximum (6).
Turn on both switches. The lights on the switches remain on
until the room temperature reaches the set temperature,
then, they will switch o.
When the room reaches the required temperature, turn the
dial anticlockwise slowly until you hear a click and the lights
will switch o.
The appliance will come on and go o automatically to main-
tain the required temperature.
- button in position «MIN» = minimum power (indicator
light on);
- button in position «MED» = intermediate power (indi-
cator light on);
- both buttons in position «MIN» «MED» = maximum
power (indicator lights on)

6
Using the thermostat
The thermostat operates on the basis of room temperature
and not radiator temperature. Turn the thermostat dial anti-
clockwise towards the lower numbers to reduce the tempera-
ture; turn it clockwise towards the higher numbers to raise
the temperature. To turn the appliance o completely, turn
the thermostat to minimum and unplug from the mains.
Frost protection function
With the thermostat in position and the switches pressed,
the appliance maintains the room at a temperature of about
5˚C, preventing freezing with minimum energy consump-
tion.
MAINTENANCE
Before carrying out any operation on the radiator, unplug
from the electric mains and wait for it to cool.
The oil-lled electric radiator requires no particular mainte-
nance. It is sucient to remove the dust with a soft, dry cloth.
Never use abrasive powders or solvents. If necessary remove
concentrations of dirt using a vacuum cleaner.
TECHNICAL CHARACTERISTICS
Power supply See rating label
Absorbed power “
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
The appliance doesn't work Be sure it is plugged in and that the elec-
trical outlet is working.
Check for any obstruction.
The temperature may be set too low.
Plug into the power outlet.
Remove the obstruction and let the appli-
ance cool down. If the appliance doesn't work
please contact Customer Experience.
Set the temperature to a higher position.
ELECTRICAL CONNECTION
A) If your appliance comes tted with a plug, it will incorporate a 13 Amp fuse. If it does not t your socket, the plug should
be cut o from the mains lead, and an appropriate plug tted, as below. WARNING: Very carefully dispose of the cut o
plug after removing the fuse: do not insert in a 13 Amp socket elsewhere in the house as this could cause a shock hazard.
With alternative plugs not incorporating a fuse, the circuit must be protected by a 15 Amp fuse. If the plug is a moulded-
on type, the fuse cover must be re-tted when changing the fuse using a 13 Amp Asta approved fuse to BS 1362. In the
event of losing the fuse cover, the plug must NOT be used until a replacement fuse cover can be obtained from your nearest
electrical dealer. The colour of the correct replacement fuse cover is that as marked on the base of the plug.
B) If your appliance is not tted with a plug, please follow the instructions provided below:
WARNING -THIS APPLIANCE MUST BE EARTHED
IMPORTANT
The wires in the mains lead are coloured in accordance with the following code:
Green and yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead may not correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
The green and yellow wire must be connected to the terminal in the plug marked with the letter E or the earth symbol
or coloured green or green and yellow. The blue wire must be connected to the terminal marked with the letter N or coloured
black. The brown wire must be connected to the terminal marked with the letter L or coloured red.
