DeLonghi DCH5090ER User manual

CERAMIC FAN HEATER
INSTRUCTIONS FOR USE
SAVE THESE INSTRUCTIONS
RADIATEUR SOUFFLANT EN CÉRAMIQUE
CONSIGNES D'UTILISATION
CONSERVER CES CONSIGNES
TERMOVENTILADOR CERÁMICO
INSTRUCCIONES DE USO
GUARDE ESTAS INSTRUCCIONES
LEA CUIDADOSAMENTE ESTE INSTRUCTIVO ANTES
DE USAR SU APARATO
MODEL/MODELE/MODELO
DCH5090ER
Register this product on-line and receive a free trial issue of Cook's Illustrated.
Visit www.delonghiregistration.com.
Visit www.delonghi.com for a list of service centers near you. (U.S. Only)
Enregistrez ce produit en ligne et recevez un numéro gratuit de Cook's Illustrated. Visi-
tez www.delonghiregistration.com.
Visitez www.delonghi.com pour y voir une liste des centres de réparation proches
de chez vous. (É.-U. uniquement)
Registre este producto en línea y reciba un ejemplar gratis de Cook's Illustrated.
Visite www.delonghiregistration.com.
Visite www.delonghi.com para ver la lista de centros de servicios cercanos a
usted. (Solamente en los Estados Unidos)
ELECTRONIC CHARACTERISTICS/CARACTÉRISTIQUES ÉLECTRONIQUES
CARACTERISTICAS ELECTRICAS
120V~60Hz 1500W

2
DESCRIPTION
AON/OFF button
B+/- Adjustment buttons
COscillation button
D“ECO” function button
ETimer button
FMODE button
(for selecting the operating mode)
GReceiver for remote control
HPower indicator light
IBack cover
JFilter
DESCRIPCIÓN
A Botón de Encendido/Apagado (ON/OFF)
B Botones de ajuste +/-
C Botón de oscilación
DBotón de función “ECO”
E Botón de temporizador
F Botón MODE (MODO – para seleccionar
el modo de funcionamiento)
G Receptor del control remoto
H Luz indicadora de encendido
I Cubierta posterior
J Filtro
DESCRIPTION
ABouton de MARCHE/ARRÊT
BBoutons de réglage +/-
C Bouton d'oscillation
DBouton de fonction ECO
E Bouton de minuterie
F Bouton MODE (pour la sélection du mode de
fonctionnement)
GRécepteur pour commande à distance
H DEL d'alimentation
I Couvercle arrière
J Filtre
H
A
B
C
FG
D
E
I
J
B
C
A
F
D
Fig. 1
EN FR
MX

3
When using any electrical appliance, some
basic safety precautions should always be
observed to reduce the risk of fire, electric
shock, and/or injury to persons. Specifical-
ly:
1. Read all instructions carefully before
using the appliance.
2. This appliance gets very hot when in
use. To prevent burns, do not touch
hot surfaces with bare skin. Use the
handle when moving the appliance.
Keep all flammable materials, such as
furniture, pillows, bedding, paper,
clothing, and curtains at least 3 feet
(90 cm) from the front and top of the
appliance also avoid contact with the
sides and back.
3. The appliance is not intended for use by
persons (including children) with redu-
ced physical, sensory or mental capabi-
lities, or lack of experience and know-
ledge, unless they have been given
supervision or instruction concerning
use of the appliance by a person
responsible for their safety. Children
should be supervised to ensure that
they do not play with the appliance.
4. Always disconnect the plug from the
power outlet when the appliance is not in
use.
5. Do not operate the appliance with a
damaged cord or plug,after faulty opera-
tion, or when it has been dropped or
damaged in any way. Contact the neare-
st authorized service facility for exami-
nation, electrical or mechanical adjust-
ment,or repair.
6. Do not use the appliance outdoors.
7. This heater is not intended for use in
bathrooms, laundry areas, or similar
indoor locations. Never position the
appliance where it may fall into a bath-
tub or come in contact with water.
8. Do not run the power cord under carpe-
ting. Do not cover cord with throw rugs,
runners, or the like. Keep the cord away
from any passageways where it could be
tripped over.
9. To completely turn off the appliance,
push the ON/OFF button (A), and then
unplug the heater.
10.Do not wrap the cord around the
appliance immediately after use.
11.Do not insert or allow foreign objects
to get into the air intake or air outlet
grille, as this may cause electric shock
or fire, or damage the appliance.
12.To prevent a possible fire, do not
block air intake or air outlet grille in
any way. Do not use the appliance on
soft surfaces, such as beds, where the
openings may become blocked.
13.Do not cover the appliance while it is
functioning in order to avoid overhea-
ting and the risk of fire.
14 The internal parts of the appliance can
become very hot or produce sparks
during operation. Do not use the
appliance in areas where gasoline,
paints, or other flammable liquids are
used or stored.
15.Use this appliance only as described in
this manual. Any other use not indica-
ted by the manufacturer may cause
fire, electric shock, or injury to per-
sons.
16.To prevent current overload and blown
fuses, make sure that no other appliance
is plugged into the same outlet or into
another outlet wired into the same cir-
cuit.
17.It is normal for heater’s plug and cord
to feel warm to the touch. However, an
excessively hot or deformed plug or
cord is not normal and may be the
result of a defective electrical outlet.
Defective outlets must be replaced
before using the heater. Plugging the
heater into a worn outlet may result in
overheating of the power cord or may
cause the risk of fire.
18.If the supply cord is damaged, to reduce
the risk of malfunction it must be repla-
ced by the manufacturer, its service
IMPORTANT INSTRUCTIONS EN

4
ELECTRICAL CONNECTION
Before connecting the plug to the power
outlet, make sure that the voltage of your elec-
trical system corresponds to the voltage
shown on the appliance rating label and the
outlet you are going to use is in good condi-
tion.
INSTALLATION
The appliance may be used on any rigid hori-
zontal surface. Do not overload the electrical
circuit; avoid using the same outlet for multi-
ple appliances.
OPERATION AND USE
1. Connect the appliance to the power outlet.
2. The appliance emits a beep and the power
indicator light (H) comes on and remains
on as long as the appliance is powered.
3. The appliance goes into OFF and the
display shows a dot “  ”.
If the dot is blinking it means that the tip
over switch has been activated.
See paragraph: “Additional safety featu-
res” page 6.
4. Press the ON/OFF button (A) to turn on the
appliance. It will begin to heat with the
predefined settings.
5. Press the MODE button (F) to select one
of the following functions available:
Ventilation ( ) Anti-freeze ( )
Heating at minimum power (1) Heating
at maximum power (2)
5.1 Ventilation ( )
In this operating mode only the fan
operates, so the appliance does not
heat the room.
5.2 Anti-freeze ( )
In this operating mode the appliance
keeps the room at a temperature of
45°F (7°C) to prevent freezing tempe-
ratures.
5.3 Heating 1 and Heating 2
In this operating mode you can set the
desired temperature by pressing the +
and - adjustment buttons (B).
Heating 1 (minimum power level):
The appliance operates at the mini-
mum power reducing energy con-
sumption to the minimum.
Heating 2 (maximum power level):
The appliance operates at the maximum
power for rapid heating of the room.
SAVE THESE INSTRUCTIONS
For Household use only
agent, or a licensed and qualified pro-
fessional.
19.Do not use this appliance with an
extension cord or outlet strip. Connect
the appliance directly to a suitable
outlet.
20. Make sure that the plug is fully inser-
ted into the outlet. Wall outlets may
deteriorate with time, so check the
plug periodically for signs of overhea-
ting or deformation. If the outlet has
deteriorated, stop using it and have it
repaired.
21.Check that neither the appliance nor
the power cord have been damaged
during shipping.
22.Make sure that no styrofoam or other
packing materials remain in the applian-
ce.
23.The first time the appliance is used, run
it at the maximum power for at least
two hours. During this time, ventilate
the room thoroughly to eliminate the
“new” smell released by the appliance.
It is completely normal for the applian-
ce to emit “creaking” sounds the first
time it is run.
24. CAUTION: To prevent electric shock,
make sure the wide prong of the plug is
inserted in the wide slot of the outlet.
25.Do not place the heater near a bed
because objects such as pillows or
blankets can fall off the bed and be
ignited by the heater.
26.Extreme caution is necessary whenever
the heater is left operating unattended.
27.Do not open the appliance. No user-
serviceable parts inside.

5
6. Eco function
In this operating mode the appliance will
automatically set the power level to gua-
rantee the best comfort reducing the
energy consumption. In this operating
mode the unit may switch the heating
power level from maximum to minimum
and viceversa, several time in an hour. The
maximum temperature setting is 79°F
(26°C). To activate this function, press the
ECO button (D). The unit, will always start
at the maximum power.
7. If you want the appliance to distribute the
airflow over a larger area, press the oscil-
lation button (C) ( ). The appliance will
then oscillate right and left. To stop the
oscillation in the desired position, just
press oscillation button (C) again.
8. To turn off the appliance press button
ON/OFF (A). The display could show the
count down for about 6 seconds.
NOTE: The display can show the temperature
in both °F and °C. To change the temperature
scale, press and hold the + key for few
seconds, then release.
Please be informed that as this is not a preci-
sion device, the showed temperature not
necessary corresponds to the real one.
24-HOUR DIGITAL TIMER
This function can be activated from any opera-
ting mode.
Delayed switch-on: with the appliance in the
OFF position, press the timer button (E) ( ).
The display shows the symbol and the
time remaining before switch-on. To set the
timer, use the + and - adjustment buttons
(B), then wait a few seconds for the pro-
gramming to be set.
The display returns to show “  ” for stand-
by and the symbol to indicate you have
set the timer. When the programmed time
has been reached, the appliance turns on
with the same settings it had during the pre-
vious operation.
Delayed shut-off: With the appliance on, press
the timer button (E) ( ). The display
shows the symbol and the time remai-
ning before shut-off. To set the timer, use
the + and - adjustment buttons (B), then
wait a few seconds for the programming to
be set. The display returns to show the cur-
rent settings and the symbol to indicate
you have set the timer. When the program-
med time as been reached the appliance
shuts off automatically.
If you want to go back to operation without the
timer, press the timer button (F) twice.
The timer symbol disappears from the
display.
USING THE REMOTE CONTROL
• The remote control functions correspond
to those on the control panel. See the sec-
tion “Operation and Use" on the previous
page for a description of the functions.
Inserting or replacing the batteries
- Remove the cover on the rear of the remo-
te control;
- Insert two AAA (R03/1.5V) batteries
(included but packaged separately)
making sure they are in the correct posi-
tion (see the instructions inside the battery
compartment);
- Do not mix old and new batteries;
- Do not mix alkaline, standard (carbon-
zinc), or rechargeable (ni-cad, ni-mh, etc)
batteries;
- Replace the cover;
- Old batteries must be removed and dispo-
sed of in accordance with current legisla-
tion as they are harmful to the environ-
ment.
MAINTENANCE
- Before carrying out any maintenance,
always remove the plug from the power
outlet.
-During the season when the appliance is
being used, regularly clean the air intake
and outlet grilles using a vacuum clea-
ner.
- Never use abrasive powders or solvents to
clean the appliance.
- Remove the back grille by pulling it
outward (Fig. 1).
- Remove the dust filter that filters impuri-
ties from the air taken in from the room,
blow it lightly, then reposition it in the
appliance.
WARNINGS
- Never use this heating appliance in the
immediate vicinity of a bathtub, shower, or
swimming pool.
- Use the appliance always and only in the
vertical position.

6
- Do not use the appliance to dry laundry,
and do not obstruct the air intake and
outlet grilles (danger of overheating).
- Do not operate the appliance in contact
with walls, furniture, curtains, etc.
- If the power cord is damaged, it must be
replaced by the manufacturer, the authori-
zed service facility, or a qualified electri-
cian, in order to prevent the risk of mal-
function.
- Do not cover the appliance while it is ope-
rating, as this could potentially cause a
fire.
- Do not use this appliance in a room smal-
ler than 43 square feet (4 m²).
- Heaters should never be used with an
extension cord or outlet strip. Heaters
should be plugged directly into an outlet.
- Before storing the appliance, check it is
completely off and the cable is unplugged.
At this point wrap the cord around the
base. Do not store in a dusty room. The
room temperature should be between 32-
86°F (0-30°C). Do not load anything
above it.
- Heaters draw more current than small
appliances, overheating of the outlet may
occur even if it has not occured with the
use of other appliances.
Additional safety features
1. Overheating protection: a safety device
switches the fan heater off if it accidental-
ly overheats (e.g.: air intake and outlet
grilles obstructed, filter clogged). In this
case remove the plug from the power
outlet and leave it unplugged for a few
minutes, eliminate the cause of overhea-
ting, then plug the fan heater back and
turn it on again.
2. Tip over safety switch: a safety tip-over
switch turns the fan heater off if it tips
over or is positioned in an improper way
that could jeopardize safety. The appliance
emits a beep and the display will show a
blinking dot. After the appliance has been
restored in the vertical position it will take
just few seconds to start on again.
Note: To avoid overheating the appliance, do
not cover it.
TROUBLE-SHOOTING
In case “PF” is displayed and a warning sound
is emitted, there is a fault on the temperature
sensor. If the problem persists contact the
Service Center.
If the appliance shuts off unexpectedly:
- Check that the appliance is receiving
power.
- Check that the appliance is in the vertical
position and on a flat surface, as the
safety tip-over switch may have been trip-
ped.
- Check the temperature set and the timer:
the appliance may be off because the set
temperature has been reached or the time
set on the timer has elapsed.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digi-
tal device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guar-
antee that interference will not occur in a particular installation. lf this equipment does cause harm-
ful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
- Consult the dealer or an experienced radio/TV technician for help.
Modifications not approved by the party responsible for compliance could void user’s authority to
operate the equipment.

7
LIMITED WARRANTY
This warranty applies to all products with De’Longhi or Kenwood brand names.
What does the warranty cover?
We warrant each appliance to be free from defects in material and workmanship. Our obligation
under this warranty is limited to repair at our factory or authorized service center of any defective
parts or part thereof, other than parts damaged in transit. In the event of a products replacement
or return, the unit must be returned transportation prepaid. The repaired or new model will be
returned at the company expense.
This warranty shall apply only if the appliance is used in accordance with the factory directions,
which accompany it, and on an Alternating current ( AC ) circuit.
How long does the coverage last?
This warranty runs for one year (1) from the purchase date found on your receipt and applies only
to the original purchaser for use.
What is not covered by the warranty?
The warranty does not cover defects or damage of the appliance, which result from repairs or alte-
rations to the appliance outside our factory or authorized service centers, nor shall it apply to any
appliance, which has been subject to abuse, misuse, negligence or accidents. Also, consequential
and incidental damage resulting from the use of this product or arising out of any breach of con-
tract or breach of this warranty are not recoverable under this warranty. Some states do not allow
the exclusion or limitation of incidental or consequential damage, so the above limitation may not
apply to you.
How do you get service?
If repairs become necessary, see contact information below:
U.S. Residents:
Please contact our toll free hotline at 800-322-3848 or log onto our website at www.delonghi.com.
For all accessories, spare parts or replacement parts, please contact our parts division at 1-800-865-6330.
Residents of Canada: Please contact our toll free hotline at 1-888-335-6644 or log onto our web-
site at www.delonghi.com.
Residents of Mexico: Please refer to the Limited Warranty statement for Mexico.
Please refer to the back page of the manual for De’Longhi addresses.
The above warranty is in lieu of all other express warranties and representations. All implied war-
ranties are limited to the applicable warranty period set forth above. This limitation does not apply
if you enter into an extended warranty with De’Longhi. Some states do not allow limitations on
how long an implied warranty lasts, so the above exclusions may not apply to you. De’Longhi
does not authorize any other person or company to assume for it any liability in connection with
the sale or use of its appliance.
How does state law apply?
This warranty gives you specific legal rights, and you may also have other rights, which vary from
state to state.
