Delphi DS350E User manual

Dangerfield June 2009 V3.0
DelphiPSS 1
UserGuidefor DS350E, withMotion
LE1700 tablet

Dangerfield June 2009 V3.0
DelphiPSS 2
CONTENTS
Main components………………………….3 WritetoECU………………………….………..87
Bluetooth configuration ………………7 Scan………………..........................................90
Main Menu…………………………………19 History………………………………………….95
DiagnosticProgram…………………….. 40 EOBDCommunication……………….............98
File…………………………………………42 Read faultCodes (EOBD)…………………..101
Settings…………………….......................44 Erase FaultCodes(EOBD)…………………104
Documents…………………………………52 Real TimeData(EOBD)………………………107
Help…………………………………………54 FreezeFrame Data(EOBD)………………..111
OBD Communication………………….....57 OxygenSensor(EOBD)……………………..114
Print&Save………………………………..67 Non-continuoustests(EOBD)……………...117
Real TimeData……………......................74 ControlofSystem (EOBD)………………….120
AdjustParameters…………………… ..81 VehicleInformation (EOBD)………………..123
ComponentActivation…………………..84

Dangerfield June 2009 V3.0
DelphiPSS 3
MAINCOMPONENTS

Dangerfield June 2009 V3.0
DelphiPSS 4
MainComponents
The Tablet
VehicleCommunication Interface (V.C.I.)

Dangerfield June 2009 V3.0
DelphiPSS 5
Motion LE 1700Tablet
Power switch and USBports Power/chargingport
Escape
Functionbutton
Directionalpad
Dashboard
Rotatedisplay

Dangerfield June 2009 V3.0
DelphiPSS 6
VehicleCommunication Interface(V.C.I.)
Protocols
J1850PWM(SCP)
J1850VPW
ISO9141
J1939(CAN)
ISO11898,11519(CAN)
ISO14230(KWP2000)
ISO15765(DiagOnCAN)
RS422,J1708(FordDCL)
RS485
5VoltComms(RangeRover),
Flashcode,etc
Connectiontothetablet via:
Bluetooth
USB
OperatingVoltage:
1–10V

Dangerfield June 2009 V3.0
DelphiPSS 7
BLUETOOTHCONFIGURATION

Dangerfield June 2009 V3.0
DelphiPSS 8
BluetoothConfiguration 1
SelectUtilities thenITTools

Dangerfield June 2009 V3.0
DelphiPSS 9
BluetoothConfiguration 2
Click

Dangerfield June 2009 V3.0
DelphiPSS 10
BluetoothConfiguration 3
Click add

Dangerfield June 2009 V3.0
DelphiPSS 11
BluetoothConfiguration 4
Click thebox

Dangerfield June 2009 V3.0
DelphiPSS 12
BluetoothConfiguration 5
Click Next

Dangerfield June 2009 V3.0
DelphiPSS 13
BluetoothConfiguration 6
SelecttheVCI

Dangerfield June 2009 V3.0
DelphiPSS 14
BluetoothConfiguration 7
Select“Use theproductkey…”enter0, click “Next”

Dangerfield June 2009 V3.0
DelphiPSS 15
BluetoothConfiguration 8
Make anoteof theOUTGOINGcomport, click finish

Dangerfield June 2009 V3.0
DelphiPSS 16
BluetoothConfiguration 9
YourVCI isnowreadyforuse
aftercom portcheck

Dangerfield June 2009 V3.0
DelphiPSS 17
BluetoothConfiguration 10
1Clickon toolboxicon
2Clickon gearwheel icon
Ifautosearchfails, selectmanual

Dangerfield June 2009 V3.0
DelphiPSS 18
BluetoothConfiguration 11
Ensurethat comportisidenticalto
theportquotedinpage15,
ifnotselectthecorrectportfrom
thedrop downmenu.
Bluetoothconfiguration isthencomplete.
Click“OK”,or update toupdate firmware.

Dangerfield June 2009 V3.0
DelphiPSS 19
MAINMENU

Dangerfield June 2009 V3.0
DelphiPSS 20
TheMainMenu
TheMainmenu isautomaticallyactivatedatstart-up
EachIconrepresentsanaccess toaprecise functionof thetool.
Click with thetouchsensitivepento activatethefunction.
NOTE:Thefunctionsavailabledependupon theoptionsordered
atthetimeof purchase.
