Delta Electronics AFB0305HA Manual

Air Pressure
Air Flow
(mm H2O)
(IN H2O)
(M3/MIN)
(CFM)
UNIT : (INCH)
mm
UNIT : (INCH)
mm
INLET SIDE OUTLET SIDE
4-Ø3.2
(4-Ø0.126)
Ø29.0
(Ø1.142)
24.0
(0.945)
(0.945)
24.0
(4-Ø0.126)
4-Ø3.2
(Ø1.142)
Ø29.0
24.0
(0.945)
(0.945)
24.0
H
M
L
0.02
0.04
0.06
0.08
0.10
0.12
0
3.0
2.5
2.0
1.0
0.5
0
1.5
4.03.02.01.00
.125.075 .100.050.025
AFB0305/12XA-A
LABEL
24.0±0.3
30.0±0.5
(1.181±0.020) (0.945±0.012)
(1.181±0.020)
30.0±0.5
24.0±0.3
(0.945±0.012)
10.0±0.5
(0.394±0.020)
10.0
150.0±10.0
(0.394)
(5.901±0.394)
4-Ø3.2±0.3
(4-Ø0.126±0.012)
http://www.deltaww.com
AFB
■DIMENSIONS DRAWING
■P & Q CURVE (AT RATED VOLTAGE) ■MOUNTING PANEL CUTOUT
30 x 30 x 10 MM SERIES
* Bearing Type
Ball Bearings
* Material
Impeller & Frame : Plastic(UL 94V-0)
* Lead Wires :
UL 1061 AWG #26 OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
* Weight : 10.5g (0.37 OZ)
* Rib Type Only
MODEL Rated
Voltage
Operating
Voltage
Range
Input
Current
Input
Power Speed Maximum Air Flow
Maximum
Air Pressure Noise
PART NO. REV. FUNCTION VDC VDC Amp Watt R.P.M. m3/min CFM mmH2O IN H2O dB-A
AFB0305LA -A -R00 / -F00 5 4.0 to 5.5 0.07 0.35 6000 0.067 2.37 1.00 0.040 17.5
AFB0312LA -A -R00 / -F00 12 9.5 to 13.8 0.05 0.60
AFB0305MA -A -R00 / -F00 5 4.0 to 5.5 0.09 0.45 7500 0.085 3.00 1.50 0.060 20.0
AFB0312MA -A -R00 / -F00 12 9.5 to 13.8 0.07 0.84
AFB0305HA -A -R00 / -F00 5 4.0 to 5.5 0.16 0.80 9000 0.100 3.53 2.50 0.100 25.0
AFB0312HA -A -R00 / -F00 12 9.5 to 13.8 0.09 1.08
* Function type is optional.
* The max. air ow and the speed are measured in free air ; max. air pressure is measured at zero air ow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specications are subject to change without notice.
