Delta Breez 50F-LED User manual

1
VENTILATION FAN / LED LIGHT
MODELS 50F-LED / 80F-LED
Installation and Operating Instructions
READ AND SAVE THESE INSTRUCTIONS
GENERAL SAFETY INFORMATION
1. Make sure that the electric service supply voltage
is AC 120V, 60Hz.
2. Follow all local electrical and safety codes, as well
as the National Electrical Code (NEC) and the
Occupational Safety and Health Act (OSH Act).
3. Always disconnect the power source before
working on or near the ventilating fan, motor or
junction box.
4. Protect the power cord from sharp edges, oil,
grease, hot surfaces, chemicals or other objects.
5. Do not kink the power cord.
6. Do not install the unit where ducts are confugured
as shown in Fig.A.
7. Provide suction parts with proper ventilation.
8. This unit is UL Listed for use over a bathtub or
shower when installed in a GFCI protected branch
circuit.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY TO PERSONS, OBSERVE THE
FOLLOWING:
1. Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
2. Before servicing or cleaning the unit, switch the
power o󰀨 at the service panel and lock the service
disconnecting means to prevent the power from
being switched on accidentally. When the service
disconnecting means cannot be locked, securely
fasten a prominent warning device, such as a tag,
to the service panel.
3. Installation work and electrical wiring must be
done by a qualied person(s) in accordance with
all applicable codes and standards, including re-
rated construction.
4. Su󰀩cient air is needed for proper combustion and
exhausting of gases through the ue (chimney) of
fuel burning equipment to prevent backdrafting.
Follow the heating equipment manufacturer’s
guideline and safety standards such as those
published by the National Fire Protection
Association (NFPA), and the American Society
for Heating Refrigeration and Air Conditioning
Engineers (ASHRAE) and local code authorities.
5. When cutting or drilling into the wall or ceiling,
do not damage electrical wiring and other hidden
utilities.
6. Ducted ventilating fans must always be vented to
the outdoors.
7. If this unit is to be installed over a tub or shower, it
must be marked as appropriate for the application
and be connected to a GFCI (Ground Fault Circuit
lnterrupter) – protected branch circuit.
8. Do not use this unit with any other solid-state
control device. Solid-state controls may cause
harmonic distortion, which can cause a motor
humming noise.
9. NEVER place a switch where it can be reached
from a tub or shower.
10. Not to be installed in a ceiling thermally insulated
to a value greater than R40. (This is required for
installation in Canada only).
Fig. A
Turning angle too large
Too many elbows
Duct shrink
Elbow near the body
.
Body
Minimum 18 in.
CAUTION
1. For general ventilating use only. Do not use to
exhaust hazardous or explosive materials and
vapors.
2. Not for use in cooking areas. (Fig.B)
3. This product must properly connect to the
grounding conductor of the supply circuit.
4. To reduce the risk of injury to persons, install the
fan at least 8.2 feet (2.5m) above the oor.
Cooking area
Do not install above or
inside this area
Cooking
Equipment
Fig. B
oor
45°
45°
PREPARATION
Tools Required for Assembly (not included): Hammer,
Flathead Screwdriver, Wire Nuts, Nails, Duct Tape,
Phillips Head Screwdriver, Utility Knife
Helpful Tools (not included): Electric Drill, Drill Bits
WARNING: Turn o󰀨 electricity at breaker box
before beginning installation.
Carefully remove unit from carton.
Check area above installation location to be sure
that wiring can run to the planned location and
that duct work can be run. Make sure the area is
su󰀩cient for proper ventilation.
Inspect duct work and wiring before proceeding with
installation.
Before installation, provide inspection and future
maintenance access at a location that will not
interfere with installation work.
You may need the help of a second person to install
this fan: one person on the attic side and one on the
room side.
Note: Installations may vary depending on how the
previous bath fan was installed. Supplies necessary for
the installation of your bath fan are not all included.
However, most are available at your local home
improvement or hardware store.
Proper insulation around the fan to minimize building
heat loss and gain. 4” circular duct is recommended
for installation. The ducting from this fan to the
outside of building has a strong e󰀨ect on air ow,
noise and energy use of the fan. Use the shortest,
straightest duct routing possible for best performance,
and avoid installing the fan with smaller ducts than
recommended. Insulation around the ducts can reduce
energy loss and inhibit mold growth. Fans installed
with existing ducts may not achieve their rated air ow.
The fan will operate most e󰀩ciently when located
where the shortest possible duct run and minimum
number of elbows will be needed.
Use a roof cap or wall cap that has a built-in damper
to reduce backdrafts.
External timer/dimmer switch can be used. Please
contact Delta Breez customer service and consult
with a licensed electrician for compatibility.
DIMENSION REQUIREMENTS
Housing
Dimension (L)
Housing
Dimension (W)
Housing
Dimension (H)
7 1/2 in. 7 1/4 in. 5 3/4 in.
Roof cap
(with built-in
damper)
Seal gap
around
housing Caulk termination
to duct
Fan housing
Short piece of flexible
duct helps alignment
and absorbs sound
or
Wall cap
(with built-in
damper)
Wall cap
(with built-in
damper)
2~3 ft straight run
before elbow
MFG MODELS VFB050B4LED1 / VFB080B4LED1

2
PACKAGE CONTENTS
PART DESCRIPTION APPEARANCE QTY
1Fan Body 1
2Grille 1
3Duct Connector 1
WIRING DIAGRAM
Turn o󰀨 power source. Review all safety precautions.
FAN SWITCH
LIGHT SWITCH
OFF
ON
OFF
ON
GRD
L
N
L
N
WHITE
BLACK
RED
GREEN
WHITE
ON/OFF SWITCH
(purchase separately) SWITCH BOX
120 VAC
LINE IN
FAN
SWITCH
WIRING
PLATE
LIGHT
SWITCH
BLACK
WHITEGROUND
RED
SWITCH BOX
JUNCTION BOX
WIRE NUT
(NOT INCLUDED)
WIRE NUT
(NOT
INCLUDED)
FAN SWITCH
LIGHT SWITCH
OFF
ON
OFF
ON
GRD
L
N
L
N
WHITE
BLACK
RED
GREEN
WHITE
ON/OFF SWITCH
(purchase separately)
SWITCH BOX
120 VAC
LINE IN
FAN
SWITCH
WIRING
PLATE
LIGHT
SWITCH
BLACK
WHITEGROUND
RED
SWITCH BOX
JUNCTION BOX
WIRE NUT
(NOT INCLUDED)
WIRE NUT
(NOT
INCLUDED)
ASSEMBLY INSTRUCTIONS
NEW CONSTRUCTION
Turn o󰀨 power source. Review all safety precautions.
1. Attach the Duct Connector 3to the Fan Body 1
3
1
1
2. Remove the wiring box cover from the Fan Body 1.
Remove the wiring knockout from the wiring box
cover with a athead screwdriver (not included).
1
2
3. Place the Fan Body 1next to a ceiling joist
or wall stud. The fan body should be level and
perpendicular to the joist or stud.
1
3
4. Mount the Fan Body 1to the joist or stud using
nails (not included) where indicated.
Joist or
wall stud
1
4
5. Pull the wire through the hole and into the junction
box(not included), secure 120VAC house wiring from
the wall diagram on page4. 14AWG is the smallest
conductor that shall be used for branchcircuit wiring.
Push the wires back through the hole. Reattach the
wiring box cover.
5
6. Install a circular 4 in. duct (not included) and secure
it with duct tape or clamps (neither included).
Finish ceiling work. The ceiling hole should be
aligned with the edge of the Fan Body 1.
Ceiling
4 in. Duct
Duct tape
or clamp
1
6
EXISTING CONSTRUCTION
Turn o󰀨 power source. Review all safety precautions.
1. Remove existing fan.
1
2. Measure the opening to ensure it is large enough to
accommodate the new Fan Body(7 1/2in. x 7 1/4in).
Note: 7 1/4 inch side of opening should be ush with
the joist.
2
3. If this fan is not replacing an old fan, be sure to cut
a 7 1/2in. x 7 1/4in. opening for the Fan Body 1.
Make sure the 7 1/4 inch side of opening is ush
with the joist for installation from below.
7 1/2 in.
7 1/4 in.
3
4. Attach the Duct Connector 3to the Fan Body 1.
3
1
4

2 3
5. Remove the wiring box cover from the Fan Body 1.
Remove the wiring knockout from the wiring box
cover with a athead screwdriver (not included)
1
5
6. Remove the three screws that hold the fan motor
assembly in place. Remove the fan motor assembly
from the Fan Body 1. Unplug fan connector.
1
6
7. Pull the wire through the hole and into the junction
box(not included), secure 120VAC house wiring
from the wall diagram on page4. 14AWG is the
smallest conductor that shall be used for branch
circuit wiring.
Push the wires back through the hole. Reattach the
wiring box cover.
7
8. Install a circular 4 in. duct (not included) and secure
it with duct tape or clamps (neither included). Mount
the Fan Body 1to the joist or stud using nails (not
included) were indicated.
1
Joist or wall stud 4 in. Duct
Nail
Tape
8
9. Plug the fan assembly back into the Fan Body 1.
Reattach the fan assembly using the three screws.
Plug fan connector.
1
9
GRILLE INSTALLATION
Insert the LED light connector into the fan body.
Pinch the mounting springs on the Grille 2, and insert
them into the narrow rectangular slots inside the fan.
Push the Grille 2up toward the ceiling.
Turn on electricity at the breaker box after nishing
installation.
2
1
FAN / LED LIGHT OPERATION
Operation
1. Fan mode: Turn the Fan switch to operate ON/OFF
of Fan function.
1
2. Light mode: Turn the Light switch to operate ON/
OFF of LED lighting function.
2
CARE AND MAINTENANCE
See safety information before proceeding. Routine
maintenance should be done at least once a year.
• Never use solvents, thinner or harsh chemicals
when cleaning the fan.
• Do not allow water to enter the motor.
• Do not immerse metal parts in water.
• Do not immerse resin parts in water over 140º
Fahrenheit.
Turn o󰀨 power source. Review all safety precautions
1. To remove grille 2, squeeze springs and pull down.
2
1
2. Wash and clean the grille 2in a sink and dry with a
cloth.
2
2
3. Remove dust and dirt from the fan body 1with a
vacuum cleaner.
1Vacuum
cleaner
3
4. Dampen cloth with dust detergent and wipe the fan
body 1. Then wipe dry with a clean cloth.
1
4
5. Replace grille 2back onto fan body 1.
2
5
6. Turn on power source to operate fan again.

4
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
The fan is not turning ON 1. Power o󰀨
2. Faulty switch
3. Faulty wire connection
1. Make sure power supply is on.
2. Test or replace switch.
3. Check wire in switch box.
The fan seems louder than it should 1. CFM too great
2. Damper not working properly or damaged
3. Bend in duct too close to fan discharge
4. Fan discharge reduced to t smaller duct
5. Fan body not securely attached
1. Be sure the CFM rating on the fan matches the size of your room.
2. Check damper to ensure it is opening and closing properly. If the damper has
become damaged, please call Customer Service.
3. Be sure you do not have any sharp bends in duct closer than 18 in. to the fan
discharge.
4. Use recommended size ducting to reduce fan noise.
5. Be sure the fan is securely attached to your ceiling joists.
The fan is not clearing the room 1. Insu󰀩cient intake airfow within room
2. Insu󰀩cient CFM
1. Be sure a door or window is slightly ajar or opened to allow airow. The fan is
not able to draw air out of the room without enough airow to draw in from.
2. Be sure the CFM rating on the fan matches the requirements for your room
size.
The light is not turning ON 1. Power o󰀨
2. Faulty switvh
3. Faulty wire connection
1. Male sure power supply is on.
2. Test or replace switch.
3. Check wire in switch box.
DIMENSIONS Unit: Inch
WARRANTY
DELTA ELECTRONICS THREE YEAR LIMITED WARRANTY
Delta Electronics Inc. (“Delta Electronics”) warrants to the original consumer purchaser in the USA that the Breez ventilation fan products will be free
from defects in material or workmanship. This warranty is limited to three (3) years from the original date of purchase.
Limitations and Exclusions
1. During the warranty period, a replacement for any defective product will be supplied free of charge for installation by the consumer. The warranty
provided herein does not cover charges for labor or other costs incurred in the troubleshooting, repair, removal, and installation service.
2. All returns of defective parts or products must include the product model number, and must be made through an authorized Delta Electronics
distributor. Authorized returns must be shipped prepaid. Repaired or replacement products will be shipped by Delta Electronics F.O.B. shipping point.
3. Delta Electronics shall not be liable for any indirect, incidental, consequential, punitive, or special damages arising out of or in connection with
products use or performance, regardless of the form of action whether in contract, tort (including negligence), strict product liability or otherwise.
4. This warranty does not extend to uorescent lamp starters and tubes.
5. The warranty does not cover if user does not comply with manufacturer’s installation manual.
6. To qualify for warranty service, you must notify Delta Electronics at the address or telephone number below.
7. Delta Electronics shall have no liability to the original owner-user with respect to any defect caused by abuse, misuse, neglect, improper
transportation or storage, improper testing, improper installation, improper operation, improper use, improper maintenance, improper repair, improper
alteration, improper modication, tampering or accident of products or parts thereof, or unusual deterioration or degradation of products or parts
thereof due to a physical environment beyond the requirement of products' specications.
Address: 46101 Fremont Boulevard, Fremont, CA 94538
US Toll Free Number:
1-888-979-9889 – Technical Support
1-877-685-4384 – Customer Sales Support
www.deltabreez.com
10 4/5
10 4/5 5 4/54/5
4.0
PRODUCT SPECIFICATIONS
Model No. Voltage
(V)
Frequency
(Hz)
Air Flow
@ 0.1SP (CFM)
Power
@ 0.1SP (W)
Max Current
(amps)
Weight
(lb.) Note LED light spec.
50F-LED /
VFB050B4LED1 120 60 50 5.0 0.22 4.8 Single Speed 13.0 Watts, 850Lumens, 3000K
80F-LED /
VFB080B4LED1 120 60 80 11.3 0.28 4.8 Single Speed 13.0 Watts, 850Lumens, 3000K
Note: Design and specications subject to change without notice.
