Delta KFB1724EHS User manual

125
175 x 54 MM SERIES
KFB
DIMENSIONS DRAWING
P & Q CURVE (AT RATED VOLTAGE) MOUNTING PANEL CUTOUT
Bearing Type
Ball Bearings
Material
Impeller : Plastic(UL 94V-0)
Pillow :Die-CastAluminum
Lead Wires :
UL 1430 AWG #22 OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
Weight : 620g (21.87 oz)
*
*
*
*
http://www.deltaww.com
*
UNIT: (INCH)
mm
UNIT: (INCH)
mm
*
*
*
*
*
Function type is optional.
The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
Noise is measured in anechoic chamber in free air, one meter from intake side.
All readings are typical values at rated voltage.
Specifications are subject to change without notice.
Operating
Voltage
Range
MODEL Rated
Voltage
Maximum
Air Flow
Speed
Maximum
Air Pressure Noise
PART NO. FUNCTION VDC VDC Amp Watt R.P.M. CFM mmH O IN H O dB-A
22
KFB1724SHS -R00 / -F00 24 14.0 to 30.0 1.65 39.60 3800 7.584 267.84 47.21 1.859 71.0
KFB1748SHS -R00 / -F00 48 28.0 to 60.0 0.80 38.40
KFB1724EHS -R00 / -F00 24 14.0 to 30.0 2.30 55.20 4200 8.421 297.39 56.96 2.361 73.5
KFB1748EHS -R00 / -F00 48 28.0 to 60.0 1.15 55.20
Input
Power
Input
Current
