Delta EFB0405HA Manual

42
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
40 x 40 x 10 MM SERIES
EFB
DIMENSIONS DRAWING
P & Q CURVE (AT RATED VOLTAGE) MOUNTING PANEL CUTOUT
mm
(INCH)
UNIT:
OUTLET SIDE INLET SIDE
*
*
*
*
*
Bearing Type
Ball Bearings
Material
Impeller & Frame : Plastic(UL 94V-0)
Lead Wires :
UL 1007 AWG #28 OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
Weight : 14.5g (0.51 OZ)
Rib Type Only
Air Pressure
(mm H O)
(IN H O)
Air Flow
0 4.0 12.08.0 16.0
2.0
1.0
00
2
2
0.08
0.04
0 0.1
5.0
3.0
4.0
0.16
0.12
0.20
0.2 0.3 0.4 0.5
(CFM)
(M /MIN)
3
EFB0405/12XA
6.0
0.24
L
M
H
HH
VH
(12.165 0.394)
(0.394)
309.0 10.0
10.0
(0.394 0.020)
10.0 0.5
(1.575 0.020)
(1.260 0.012)
40.0 0.5
32.0 0.3
(4- 0.126 0.012)
4- 3.2 0.3
LABEL
(1.575 0.020)
32.0 0.3
(1.260 0.012)
40.0 0.5
38.2
(1.260) (1.504)
38.2 32.0
( 1.583)
(4- 0.126)
4- 3.2
40.2
(1.504)
(1.260)
32.0
38.2
32.0
(1.504) (1.260)
(4- 0.126)
4- 3.2
( 1.583)
40.2
32.0
(1.260)
(1.504)
38.2
Operating
Voltage
Range
MODEL Rated
Voltage
Maximum
Air Flow
Speed
Maximum
Air Pressure
Noise
PART NO. FUNCTION VDC VDC Amp Watt R.P.M. CFM mmH O IN H O dB-A
22
EFB0405LA -R00 / -F00 5 4.5 to 5.5 0.07 0.35 4000 0.106 3.74 1.45 0.057 20.5
EFB0412LA -R00 / -F00 12 9.0 to 13.8 0.05 0.60
EFB0405MA -R00 / -F00 5 4.5 to 5.5 0.10 0.50 5000 0.167 5.90 2.24 0.088 24.5
EFB0412MA -R00 / -F00 12 7.0 to 13.8 0.06 0.72
EFB0405HA -R00 / -F00 5 4.5 to 5.5 0.13 0.65 6000 0.196 6.92 3.28 0.129 28.5
EFB0412HA -R00 / -F00 12 7.0 to 13.8 0.08 0.96
EFB0405HHA -R00 / -F00 5 4.5 to 5.5 0.19 0.95 7000 0.229 8.09 4.42 0.174 33.0
EFB0412HHA -R00 / -F00 12 7.0 to 13.8 0.10 1.20
EFB0412VHA -R00 / -F00 12 7.0 to 13.8 0.15 1.80 8000 0.268 9.46 5.76 0.227 37.5
http://www.deltaww.com
UNIT: (INCH)
mm
Input
Power
Input
Current
