Delta Loytec LIP-3333ECTC User manual

Installation instructions
LIP-3333ECTC CEA-709/IP router
Instructions de montage
Montageanweisung
Montagevoorschrift
Instruzioni di montaggio
Instrucciones de montaje
Monteringsanvisning
159
89
100
164
60
13
15
[.512] [2.362]
[.591]
[3.937]
[3.504]
[6.260]
[6.457]
LOYTEC
www.loytec.com
Made in Austria
Ethernet 2
Ethernet 1
USB 1
USB 2
PWR
1234
+
-
FT FTFT FT
FTFTFTFT
B A
L-IP
EIA709/IP router
LIP-3333ECTC
B A BNCNCNC NCA B A
max 50º C
min 0º C
0,370 kg [inch]
mm
10 - 90 %
kg
RH
Version 1.11

Connectors
POWER 1 Power supply input GND
2 Power supply input PLUS
CEA-709 6 not connected (NC)
TP/FT-10 7 Input B
PORT 1 8 Input A
CEA-709 9 not connected (NC)
TP/FT-10 10 Input B
PORT 2 11 Input A
CEA-709 12 not connected (NC)
TP/FT-10 13 Input B
PORT 3 14 Input A
CEA-709 15 not connected (NC)
TP/FT-10 16 Input B
PORT 4 17 Input A
Connectors
USB1 USB-A USB Device
USB2 USB-A USB Device
Ethernet1 RJ45 10/100Base-T
Ethernet2 RJ45 10/100Base-T
Buttons
RESET Reset
DIAL Turn-and-Push Dial
0.2 - 2.5 mm2
7
Weidmüller
2 poles: BLZP 5.08/02/180
3 poles: BLZP 5.08/03/180
Weidmüller
BLZB 5.08
LOYTEC
www.loytec.com
Made in Austria
Ethernet 2
Ethernet 1
USB 1
USB 2
PWR
1234
+
-
FTFTFT FT
FTFTFTFT
BNC A BNC A BNC A BNC A
L-IP
EIA709/IP router
LIP-3333ECTC
1 2 6 78 9 10 11 12 13 14 15 16 17
DIAL
DISPLAY
USB 2
USB 1
Ethernet 2
Ethernet 1
RESET
4.5 lb-in/0.5 Nm

FT GREEN flashing fast
GREEN flashing 1 Hz Not comissioned
CEA-709 port damaged
CEA-709 traffic overload
RED permanent
RED flashing fast
Traffic on CEA-709 port
STATUS LEDs
FT EXT
MODBUS or MS/TP (LINX-15x)
LIOB-FT
PLC OPC
Ethernet1 Ethernet2
LINK
ACT
DISPLAY
Please update the firmware of the device first,
see www.loytec.com
LOYTEC
www.loytec.com
Made in Austria
Ethernet 2
Ethernet 1
USB 1
USB 2
PWR
1234
+
-
FT FTFT FT
FTFTFTFT
BNC A BNC A BNC A BNC A
L-IP
EIA709/IP router
LIP-3333ECTC
1 2 6 78 9 10 11 12 13 14 15 16 17
User: admin
Password: loytec4u

Document 88071402
08/29016 Web Edition
Printed in Austria
Data is subject to change
LOYTEC electronics GmbH
MADE IN AUSTRIA
W27/2015
029501-000AB04CF95
SER#
Serial number of the device
Date Code LIP-3333ECTC
http://www.loytec.com
[email protected]
1
7.5
25
35
35 mm x 7.5 mm DIN rail (EN 50022, BS 5584, DIN 46277-3)
